JB-Lighting P18 User manual

Operating instructions
Version 1.12
Software >= 1.1.0
P18 Wash

- 02 -
P 18 W a s h
Content
1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .03
1.1 P18 Wash models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
1.2 Important differences between the models HP/HC/WW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
2. Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .04
3. Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05
4. Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06
5. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .08
5.1 Unpacking the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
5.2 Connection of the fixture to the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
5.3 Mains connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
5.4 Wiring the power feed-through . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
5.5 Signal connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5.1 DMX cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5.2 Ethernet cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5.3 Wireless reception .... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.6 Mounting the devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6. Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6.1 Menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.2 FACTORY DEFAULTS - Factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.3 USER DEFAULTS - User settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.4 DMX / NET ADDRESS - DMX addressing / Artnet addressing / sACN addressing . . . . . . . . . . . . . . . 16
6.5 PERSONALITY - Personal settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.6 STANDALONE operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.7 INFO-menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.8 Shortcuts - quick access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7. Control options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
7.1 DMX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.1.1 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.1.2 DMX channel assignment Mode 1 and Mode 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7.1.3 Control channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.1.4 Sparkle effect, sparkle speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.2 Artnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.3 Streaming ACN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.4 Wireless-DMX .......... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.5 RDM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.5.1 RDM-UID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.5.2 RDM-PIDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.5.3 Standard RDM parameter IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.5.4 Manufacturer specific RDM parameter IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.5.5 RDM sensor IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8. Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
8.1 Service menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8.2 Cleaning the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8.3 Service and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.5.1 Inspection of lubricated moving parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.5.1 Checking the plastic parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.4 Software update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.5 Testing of electrical equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
9. Overview of error codes for all fixtures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
10. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
11. Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

- 03 -
P 18 W a s h
1.1 P18 Wash models
The P18 Wash is available in 3 models. The models differ in the light module and partly in the
color lters and in the CTC lters. The differences can be found in the DMX channel functions.
- P18 Wash HP (High Power)
- P18 Wash HC (High CRI)
- P18 Wash WW (Warm White)
Specication HP - High Power HC - High CRI WW - Warm White
Color temperature 7200 K 6000 K 3200 K
Luminosity 56.000 lm
(34.000 lm Output)
47.500 lm
(28.000 lm Output)
42.000 lm
(23.000 lm Output)
CRI >= 70
(with CRI lter >= 90) >= 90 >= 92
Correction lter linear CTO
7200 K to 2900 K
linear CTO
6000 K to 2700 K
linear CTB
3200 K to 6500 K
1.2 Important differences between the models HP/HC/WW
The differences between the models High Power / High CRI / Warm White are as follows:
DMX channel 24 (38)
color wheel - color no. 8 is: at the HP model a HCRI filter
at the HC and WW model a pink filter
DMX channel 29 (46/47)
color temperature correction: at the HP and HC model a CTO filter
at the WW model a CTB filter
Detailed information see DMX channel assignment on page 23.
1. Introduction

- 04 -
P 18 W a s h
2. Dimensions
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
komplett_Hülle
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
630
435
480,5
140
140
258,4
307
267
541
Name
Erstellt
Art.-Nr.:
Datum
Prisma
F
ax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
komplett_Hülle
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lich
tanlagentechnik GmbH
Sall
ersteig 15, 89134 Blaustein
630
435
480,5
140
140
258,4
307
267
541
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
komplett_Hülle
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
435
480,5
140
140
258,4
307
6
754
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
komplett_Hülle
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
630
435
480,5
140
140
258,4
307
267
541

- 05 -
P 18 W a s h
3. Product overview
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
komplett_Hülle
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
630
435
480,5
140
140
258,4
307
267
541
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
P18
17.01.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
435
140
140
258,4
307
480,5
755
Head
Fresnel front lens
Tilt lock
Arm
PowerCON TRUE1 Output
Pan lock
DMX/Ethernet/USB ports
Base
PowerCON TRUE1 Input
Bottom cover
Top cover
Arm cover
Handles
LCD display
Function keys

- 06 -
P 18 W a s h
ATTENTION: For your own safety, please read these operating instructions carefully
before rst use.
!
4. Safety instructions
This spotlight has left our company in excellent condition. To maintain this condition and to
ensure safe operation, it is absolutely essential to observe the following safety instructions and
warnings which are described in this operating manual.
The manufacturer accepts no liability for damage caused to the device by disregard of these
operating instructions or unauthorised modications.
Please note that damage caused by manual modications to this unit is not covered bythewarranty.
Ensure that the mains voltage to be connected is not higher than that indicated on the type plate.
Thisdevice should only be operated with the power source indicated on the type plate. If you are
not sure what type of power supply you have, contact your dealer or power supplier.
Always disconnect the device from the power supply before carrying out cleaning work or before
replacing fuses or parts.
The mains plug must always be accessible after the spotlight has been installed. Do not overload
the sockets or extension cables as this could result in re or electric shock. Do not place any
objects on the power cable. Do not install the spotlight in such a way that people can trip over
or step on the power cable. Make sure that the power cable can never be crushed or damaged
by sharp edges. Check the unit and the power cable from time to time.
Leave maintenance work to a qualied technician!
ATTENTION: This device is only suitable for professional use! Protection class IP 20
- only for use in dry environments (indoors)!
ATTENTION: JB-Lighting Lichtanlagentechnik GmbH does not authorise the use
of its devices in life support systems. Life-supporting systems are systems whose
purpose is to maintain or stabilise life and whose defect or malfunction may result
indeath or injury to persons.
The product in this manual complies with the following EU directives:
- Low Voltage Directive 2014/35/EU
- EMC Directive 2014/30/EU
ATTENTION: Allow the device to cool down and disconnect the device from the
mains before opening the device. Touching live parts (high voltage) can give you an
electric shock.
!
!

- 07 -
P 18 W a s h
Never connect this device to a dimmer pack.
During rst use, some smoke and odour may occur. This is normal and does not necessarily
mean that the device is defective.
The device becomes hot during operation. Never touch the device with bare hands during
operation!
When replacing fuses, only use the same types with identical values! Only have fuse replacement
carried out by a qualied technician
If the device has been exposed to strong temperature uctuations (e.g. after transport), thedevice
must not be switched on immediately. The resulting condensation can damage your device.
Leave the device switched off until it has reached room temperature.
If the P18 Wash is operated below 20°C, prism swapping and prism rotation are reduced
in speed. This is a protective mechanism of the P18 Wash, as at low temperatures the
lubricant is relatively viscous in the rotational mechanism and can therefore cause the
effect to be slurred. From indoor temperatures of 21°C and upwards, the spotlight runs
normally! Thistemperature is quickly reached under normal operation (LED engine on).
Do not shake or knock the device. Avoid brute force during installation or operation.
This light was designed for indoor use only. Do not expose this device to rain or moisture.
When choosing a mounting location, make sure that the device is not exposed to extreme heat,
moisture or dust.
Ventilation openings and slots in the head and foot of the spotlight are used for ventilation
toensure reliable operation of the device and to protect it from overheating, these openings must
not be covered.
Never cover the front lens when the spotlight is in use.
The openings should never be covered with substances or other objects so that the airways are
blocked.
This device must not be operated in an environment without adequate ventilation.
The device may only be operated when the housing is closed and all screws/Camlocs are rmly
tightened.
The device must always be secured with an additional safety device.
Ensure that the area below the spotlight is clear during installation, alteration and removal.
ATTENTION: This xture corresponds to protection class I. For this reason, this
spotlight must be connected to a mains socket with earthing contact.
!
ATTENTION: DAMAGE TO EYES! Do not look into the light source for long periods
during operation. This can be harmful to the eyes. Attention: potentially hazardous
radiation - Risk group 2 based on DIN EN 62471

- 08 -
P 18 W a s h
5. Installation
The maximum ambient temperature of 45°C must not be exceeded.
Do not operate the device until you have become familiar with its functions. Prevent operation by
persons who are not qualied to use the device. Most damage is the result of improper operation!
Please use the original packaging or specially adapted ight cases if the device is to betransported.
When using the original packaging, the locks must not be closed!
ATTENTION: Allow a xture distance of at least 1 metres from easily ammable ma-
terial and the distance between the light emission and the surface to be illuminated
must be at least 4 meters.
ATTENTION: The front lens must be replaced if it is visibly damaged to the extent
that itsfunction is impaired, e.g. by cracks or deep scratches!
ATTENTION: To avoid damaging the internal parts of the light head, never let sunlight
shine directly into the front lens.
!
!
!
Wire colour Function Symbol
Brown Phase “L”
Blue Neutral wire “N”
Green/Yellow Protective earth “PE”
5.1 Unpacking the device
Contents of the packaging: This spotlight, two Omega brackets with original Camloc fasteners,
powerCON-TRUE1 Schuko cable and a safety note. Open the packaging at the top and remove
the powerCON TRUE1 cable, the inlay and the safety instructions. The Omega brackets are
located under the spotlight. Check the P18 Wash for possible transport damage. This should be
communicated immediately to the transport company.
The P18 Wash is supplied with an assembled Schuko power cable with the powerCON-TRUE1
plug (only the powerCON-TRUE1 plug is included in the US version). The connection of the P18
Wash to the power supply (100-240 volts, 50 - 60 hertz) must comply with the connection rules
of the respective country.
Connection in Germany/Europe:
5.2 Connection of the fixture to the power supply

- 09 -
P 18 W a s h
Connected loads: Voltage 100-240 V, frequency 50 - 60 Hz, power max. 1200 VA
The electrical safety and function of the device can only be guaranteed if it is connected to a properly
installed protective conductor system. It is very important that this basic safety requirement
is met. If in doubt, have the electrical installation checked by a specialist. The manufacturer
cannot be held responsible for damage caused by a missing or interrupted protective conductor
(e.g. electric shock)! Only use the device when it is completely assembled so that no electrical
components can be touched. (Danger 100-240 V)
If you have observed the listed points, you can plug in the devices or have them connected
tothe mains by a specialist.
5.3 Mains connection
ATTENTION: The P18 Wash can light up immediately if standalone operation is acti-
vated oraDMX signal is present!
!
Connection outside Europe:
The P18 Wash may only be operated on the following power supply systems:
Mains P18
Wash
2 wires, 1 phase L
N
L
N
PE
3 wires, 1 phase L
N
L
L
N
4 wires, 3 phases L1
L2
L3
N
L
N
PE
ATTENTION:
In Canada, the P18 Wash may only
be operated in a 2-wire, 1 phase
network with a maximum voltage of
120V!
!
The P18 Wash has a powerCON-TRUE1 out power output. Depending on the local conditions
several devices can be linked by powerCON-TRUE1 in and powerCON-TRUE1 out. Connect a
maximum of two (when using 230V/16A) P18 Washs in a row.
Use an approved three-core cable with a cross-section of at least 1.5 mm². Cabling must be
done with the original Neutrik coded plugs. The installation instructions of the manufacturer
(www.neutrik.com) and the colour coding of the cable must be observed.
5.4 Wiring the power feed-through
ATTENTION: Only have it carried out by a specialist!
!
Wire colour Function Symbol
Brown Phase “L”
Blue Neutral wire “N”
Green/Yellow Protective earth “PE”

- 10 -
P 18 W a s h
The P18 Wash has a DMX-in and DMX-out connector. Now connect the DMX output of your
controller to the 1st P18 Wash (Controller DMX-Out -> P18 Wash DMX-In). Then the 1st P18
Wash with the 2nd P18 Wash (P18 WashDMX-Out -> P18 Wash DMX-In) and so on. In some
cases it is advisable to insert a so-called end connector (XLR connector with a 120 Ohm
resistor between pin 2 and pin 3). Whether an end connector is required depends on various
factors, including the cable lengths used and the number of devices. However, as long as no
problems occur in the DMX line, this is not necessary.
5.5 Signal connections
The DMX cabling (signal lines) should be done with a 4-pin cable with shielding. We recommend
a DMX cable (110 Ohm, 4x0.22mm2), alternatively a 2-pole micro cable can be used. The plugs
and sockets are 5-pin XLR connectors, which can be purchased in specialist shops.
Pin assignment:
Pin1 = Ground/Shielding
Pin2 = DMX -
Pin3 = DMX +
Pin4 = not connected
Pin5 = not connected
1
2
3
45
12
3
4
5
Cable with shielding
5.5.1 DMX cabling
5.5.2 Ethernet cabling
Ethernet cabling can be done with standard network lines. The sockets on the device are Neutrik
etherCON sockets. Special cables with etherCON connectors are recommended by Neutrik. The
two sockets on the P18 Wash are connected to each other via a switch. Up to 10 devices can
be connected in series without any delay. Of course, the spotlights can also be supplied in a
star conguration via an external switch. The received signal can be output via DMX. To do this,
set the DMX OUTPUT CONFIG setting to ON in the PERSONALITY menu. After conrming with
ENTER, the spotlight emits the entire universe received via DMX.
5.5.3 Wireless reception
The P18 Wash is equipped as standard with a LumenRadio CRMX receiver for wireless DMX.
The receiver can process both DMX and RDM. If a cable and wireless connection are connected
to the P18 Wash, the cable connection has priority! The received signal can be output via DMX.
To do this, set the DMX OUTPUT CONFIG setting to ON in the PERSONALITY menu. After
conrming with ENTER, the spotlight emits the entire universe received via DMX.
ATTENTION: Make sure that there is no signal at the DMX input at the same time !!
!
ATTENTION: Make sure that there is no signal at the DMX input at the same time !!
!

- 11 -
P 18 W a s h
5.6 Mounting the devices
ATTENTION: Allow a xture distance of at least 1 metres from easily ammable ma-
terial and the distance between the light emission and the surface to be illuminated
must be at least 4 meters.
!
The P18 Wash can be placed on the oor or hang
on a hanging system, for example a trussing system.
Mounting horizontally to the truss (see picture) is
only possible with our special mounting plate.
When placing the unit on the oor make sure that it
stands on rigid ground, because the air inlets in the
base must not be covered with anything!
140
258,4
140
1 2 43
To mount the unit on a trussing system use two of the original JB-Lighting omega brackets with
original Camloc-connectors. You have following four possibilities to mount the omega brackets.
✔
✔
!
Name
Erstellt
Art.-Nr.:
Datum
Prisma
Fax.: 07304 / 9617-99
Tel.: 07304 / 9617-0
Montage
06.11.2018 Kuehngruen
Allgemeintoleranzen
ISO 2768-m
Blechdicke:
Material:
Farbe:
Oberfläche:
Abmessung:
Lichtanlagentechnik GmbH
Sallersteig 15, 89134 Blaustein
The Camlocs must snap in to be locked properly. Ensure that the structure (for example a truss
system ) to which you are attaching the xture is secure. If you install the xture to a hanging
system (for example to a truss system) always attach a safety cable, that can hold at least 10
times the weight of the xture. There is a corresponding eyelet on the xture for the secondary
safety device (see picture).
eyelet for the secondary
safety device
This type of assembly
only with special
mounting plate

- 12 -
P 18 W a s h
6. Control panel
The P18 Wash has a graphic colour display that can be rotated 180° when installed in a suspended
position. The display can be rotated in the PERSONALITY MENU or via short cut ENTER + UP
in the main screen.
All parameters of the P18 Wash can be set on the control panel (see menu overview page 14).
Function and operation of the display
The main menu provides information regarding the set DMX mode and, when the wireless mode
is switched on, the eld strength of the associated transmitter module. "ENTER" calls up a sub-
menu or conrms an input. "ESC" is used to exit a function or a menu item. "UP" and "DOWN"
are used to navigate within the menu and to enter values.
Special areas can only be called up using a specic key combination. To do this, press and hold
the "ENTER" key and then use the opposite "ESC" key to access the menu. To exit the function,
proceed in reverse order.
This applies in the STANDALONE area for the MODIFY, RUN and REMOTE functions.
The main menu can also be locked to prevent unintentional access. It is also locked by pressing
the "ENTER" key (keep it pressed) and then additionally locking it with the opposite "ESC" key.

- 13 -
P 18 W a s h
Display illumination as function display
The display illumination remains switched off during the reset. Slowly ashing display illumination
when "JB-Lighting" is displayed means no DMX signal is present.
A very rapidly ashing display illumination when "JB-Lighting" is displayed means that a new
error has been stored in the "ERROR LIST", also an error message in the display (e.g. *PAN
TIMEOUT) indicates this current error. This error occurs during this reset or in the operation. This
error is now automatically set to "read", but remains in the "ERROR LIST".
A rapidly ashing display illumination shows an error in the "ERROR LIST" is still in it but has
already been conrmed or was automatically conrmed. Only when the error has been deleted
from the ERROR LIST does the P18 Wash start again without error signalling.
If errors occur again and again contact the dealer / distributor or our service department.
If the P18 Wash receives a DMX signal, the display illumination goes out after a short time.
DMX addressing
In the main menu, the DMX address can be set directly by pressing the up/down keys.
Display operation via battery backup
By pressing the left button below the display, the conguration battery operation of the headlamp
is activated, so the headlamp can be congured without power. It is possible to congure all the
settings displayed by the menu, for example the DMX address can be set.

- 14 -
P 18 W a s h
6.1 Menu overview
grey - corresponds to the default setting
FACTORY DEF. LOAD DEFAULTS SURE?
ENTER ENTER ENTER
PERSONALITY
UP
USER DEFAULTS LOAD DEFAULTS SURE?
SAVE DEFAULTS SURE? PASSWORD
STANDARDMAIN SCREEN MO
USER ID
FAST
SQUARE
CURVES DIMMER CURVE
COOLING MODE
STANDARD
BOOST
CAMERA MODE
60 HZ
FLEX
50 HZ
LINEAR
LONGLIFE
THEATRE WHISPER
THEATRE SILENT
FLEX FAST
DMX MODE MODE 1
MODE 2
SQUARE INV.
PAN TILT SPEED
MEDIUM
WHISPER
SILENT
FAST
EFFECT SPEED
MEDIUM
WHISPER
SILENT
AUTO
BACKLIGHT MODE OFF
ON
STANDARDDISPLAY ORIENTA.
FLIP
ON
SAFE MODE SWIT OFF
ID +/-USER FIXTURE ID
STANDARDLED FADE OUT
SOFT
LINEARRGB/CMY CURVE
SQUARE INV.
LINEARFROST CURVE
SQUARE INV.
DMX OUTPUT CONF OFF
ON
LINEAR MK2
SQUARE INV.MK2
DMX / NET ADDR ADDRESS +/-DMX ADDRESS
ADDRESS +/-ARTNET ADDRESS
ADDRESS +/-SACN ADDRESS
DMX INPUT CONFIG ON/OFF
UNLINK
NETWORK
ON
OFF
DEFAULT IP NETWORK 10
NETWORK 2
USER IP BYTE 1
BYTE 2
BYTE 3
BYTE 4
ADDRESS +/-
ADDRESS +/-
ADDRESS +/-
ADDRESS +/-
SURE?
WIRELESS
IP ADDRESS
MODE ARTNET
SACN

- 15 -
P 18 W a s h
SERVICE RESET FIXTURE SURE?
ERROR LIST LIST
CLEAR
FUNCTION TEST START TEST
INIT PAN/TILT
TEST RUNNING
SURE?
PAN TIMEOUT COUNT: 1 CLEAR?
SURE?
DMX TEST DMX CHANNEL CH 001: --- +/-
DISPLAY CONTR. D. CONTR: +000 +/-
STANDALONE EDIT STEP NR. +/-
RUN
TIMEBASE 1 SEC
1/10 SEC
MODIFY
REMOTE
CAPT DMX
INSERT
DELETE
RESET STEP
CLEAR ALL
FADE TIME FADE TIME +/-
NEXT TIME NEXT TIME +/-
PAN PAN +/-
TILT TILT +/-
CONTROL CONTROL +/-
SHUTTER SHUTTER +/-
DIMMER DIMMER +/-
FOCUS FOCUS +/-
ZOOM ZOOM +/-
IRIS IRIS +/-
BL 1A
BL 1B
BL 2A
BL 2B
BL 3A
BL 3B
BL 4A
BL 4B
BL 1A +/-
BL 1B +/-
BL 2A +/-
BL 2B +/-
BL 3A +/-
BL 3B +/-
BL 4A +/-
BL 4B +/-
COLOR
CYAN
MAGENTA
BL ROT BL ROT +/-
COLOR +/-
CYAN EFF +/-
MAGENTA +/-
FINE ADJUST
OFS FOCUS
YELLOW
CTO
SPARKLE
SPARKLE SP
FROST
FROST 2
SPEED P/T
SPEED EFF
MOVE B-OUT
YELLOW +/-
CTO +/-
SPARKLE +/-
SPARKLE SP +/-
FROST +/-
FROST 2 +/-
SPEED P/T +/-
SPEED EFF +/-
MOVE B-OUT +/-
RESERVED RESERVED +/-
RESERVED RESERVED +/-
OFS FOCUS +/-
OFS TILT OFS TILT +/-
OFS PAN OFS PAN +/-
IDENTIFY DEVICE SURE?
COLOR COLOR +/-
ADJ BL
SET BL1 LOWER
SET BL2 UPPER
SET BL3 LEFT
SET BL4 RIGHT
STORE BL ADJ
SET BLROT

- 16 -
P 18 W a s h
INFO SOFTWARE VER.
FIXTURE ID
TOT OP. TIME
TEMP BASE LCD ACTUAL
MAX RESET?
TEMP HEAD MAIN ACTUAL
MAX RESET?
TEMP HEAD DRV ACTUAL
MAX RESET?
TEMP BASE PS ACTUAL
MAX RESET?
TEMP HEAD LED ACTUAL
MAX RESET?
TEMP HEAD AMB. ACTUAL
MAX RESET?
TOT BAT CHARGE T.
TOT LAMP TIME
6.2 FACTORY DEFAULTS - Factory settings
To reset P18 Wash to factory settings, go to the menu item FACTORY DEFAULTS, LOAD
DEFAULTS. After conrming the security query SURE? by pressing the "ENTER" button for 2
seconds, all parameters are reset to the factory settings.
6.3 USER DEFAULTS - User settings
If the user has set the P18 Wash in the PERSONALITY menu to their personal settings, these can
besaved and loaded in the USER DEFAULTS menu. In order to prevent unintentional alteration
of the data, you must enter the following password during the saving process: Buttons "ESC
DOWN UP ENTER"
6.4 DMX / NET ADDRESS - DMX addressing / Artnet addressing / sACN addressing
The DMX addressing can be done either directly in the display. Press the "UP" or "DOWN"
button to set the desired DMX address. The value is conrmed with the "ENTER" key. However,
the DMX addressing can also be done within the menu item DMX / NET ADDR, and there under
DMX ADDRESS.
To set the Artnet address, the menu item ARTNET ADDRESS must be selected in the DMX /
NET ADDR menu. The Artnet address can now be set using the UP / DOWN buttons. The Artnet
address is displayed in the form 000.00.00. This display corresponds to: Net.Subnet.Universum.
The sACN address can then be selected in the DMX / NET ADDR -> sACN ADDRESS menu. The
address can now be set using the UP / DOWN buttons. The sACN address is displayed in the
form 00000.
6.5 PERSONALITY - Personal settings
DMX INPUT MODE
In this menu item the options WIRELESS and NETWORK are available.
Under WIRELESS -> ON / OFF the factory-installed radio DMX receiver module of Lumen-Radio
can be activated or deactivated and via WIRELESS -> UNLINK the connection to the connected
transmitter can be deleted. In order to connect the xture to a transmitter, wireless must be
set to ON on the xture and the connection button must be pressed briey on the transmitter.
The transmitter is now looking for all xtures where wireless is enabled and xtures that are not
connected to a transmitter. If the P18 Wash has successfully connected to the transmitter, the
display shows a level indication of the current reception quality. If the P18 Wash is additionally
connected via the DMX / etherCON connection sockets, these signals have priority over the
radio link. Using the key shortcut ESC and DOWN, pressed in the main menu, the headlamp can
be booked out of the booked transmitter (see page 20).
Under NETWORK -> MODE you can toggle between Artnet operation and sACN operation.
For network operation, the IP address of the spotlight must be selected or set under NETWORK
-> IP ADDRESS. Each headlight has a unique standard IP address.

- 17 -
P 18 W a s h
DMX MODE - setting the operation mode
The P18 Wash has 2 operating modes (see channel assignment page 21). All parameters of
P18 Wash can be operated via mode 1. However, all channels (except pan/tilt) are controlled with
8 bits. Byselecting Mode 2 - 16 Bit the gobo, prism rotation, CMY/CTO, dimmer, focus, zoom,
thecomplete shutter slide unit as well as pan/tilt are controlled via 16 Bit.
CAMERA MODE - setting the repetition frequency of the LEDs
To avoid ickering during TV recordings, the P18 Wash can be adjusted from 50 Hertz (PAL,
Secam) to 60 Hertz (NTSC) for different camera systems. Flex mode is set when using different
camera systems or when shooting with mobile phone cameras or similar non-professional
cameras. A HighFlex mode is also available. In this mode, the repetition frequencies are set
to 3 kHz, which is necessary to ensure smooth movements in dimmed lighting scenes. The
factory setting oftheP18 Wash is 60 Hertz. The changeover is also possible with the light mixing
console via thecontrol channel.
CURVES - setting dimmer, RGB/CMY, frost curve
Dimmer curve:
The dimmer curve can be changed from exponential (square) to linear. The “exponential” dimmer
curve (factory setting) causes the dimmer to fade in and out more smoothly.
RGB/CMY curve:
4 different curves can be set for the RGB / CMY curve. LINEAR and SQUARE INV., The square-
inv. Curve causes a visually more uniform retraction. LINEAR MK2 and SQUARE INV. MK2, are
the two adapted curves on the P18 MK2.
Frost curve:
The frost curves can be changed from invers exponential (square inv.) to linear. The “invers
exponential” frost curve causes the frost to fade in and out more smoothly.
COOLING MODE - adjustment of brightness and fan volume
In the COOLING MODE menu item you can set the fan control and thebrightness of the P18
Wash. The following settings are available.
THEATRE WHISPER: Brightness 27000lm (model HP), volume 29dB(a). In this mode, the spot-
light runs at the same brightness up to an ambient temperature of 40°C. It is not necessary to
speed up the fans in this mode.
THEATRE SILENT: Brightness 29000lm (model HP), from 40°C ambient temperature the spotlight
regulates thefans a little up thus remains that the brightness is always the same level.
STANDARD: Brightness 32000lm (model HP), from an ambient temperature of approx. 36°C the
fans run to cool the LED accordingly. The brightness remains constant.
BOOST: Brightness 34000lm (model HP), the fans run a little stronger in this mode, from approx.
40° ambient temperature the fans run again accordingly.
LONGLIFE: Brightness 29000lm (model HP), the fans run a little stronger in this mode, from ap-
prox. 40° ambient temperature the fans run again accordingly. We would recommend this mode
for permanent installations, as the LED module runs cooler and thus more “stress-free”.
DMX OUTPUT CONFIG - configuration of the DMX output
Under this menu item, the DMX output of the headlamp can be activated, that is a received Art-
net, or wireless DMX signal can be output by activating this menu item -> ON via the DMX socket
again. Make sure that there is no signal at the DMX input at the same time !!
Under IP ADDRESS -> DEFAULT IP this can be changed from the network 10.xxx.xxx.xxx to a
network 2.xxx.xxx.xxx. For your own self-denable IP address, you can set your own desired IP
address under IP ADDRESS -> USER-IP. This address is divided into BYTE1 to BYTE 4 and can
be set one after the other.

- 18 -
P 18 W a s h
PAN TILT SPEED - setting pan/tilt speed
In the PAN TILT SPEED menu you can set the maximum speed, the acceleration and thus also
the movement volume of the P18 Wash. The following setting options are available.
WHISPER: The speed of Pan / Tilt is reduced so much that a volume of 29dB (A) is not exceeded.
SILENT: The speed of Pan / Tilt is slightly faster and thus louder as compared to the Whisper
setting.
MEDIUM: The acceleration and deceleration ramps are set very soft so that the headlamp brakes
softly and starts.
FAST: The acceleration and deceleration ramps are set very hard so that the headlamp moves
very fast and directly at maximum speed.
EFFECT SPEED - setting effect speed
In the menu item EFFECT SPEED you can set the maximum speed, the effects and thus also the
volume of the effects of the P18 Wash. The following setting options are available.
WHISPER: The speed of the effects is reduced so much that a volume of 29dB (A) is not exceed-
ed.
SILENT: The speed of the effects is slightly faster and thus a bit louder than with the Whisper
setting.
MEDIUM: The acceleration and deceleration ramps of the effects are set very soft, so that the
effects are very soft and thus cause little noise.
FAST: The acceleration and deceleration ramp effects are set to maximum speed. Very fast gobo
and color changes are possible!
BACKLIGHT MODE - setting the display backlight
This menu item controls the backlight of the display.
OFF: The backlight of the display is always off. The lighting only switches on when a button is
pressed. Errors that are indicated by ashing are not displayed in this mode.
ON: The backlight of the display is always on.
AUTO: The backlight is switched on / off due to the action.
DISPLAY ORIENTATION - setting the display orientation
This menu item turns the display orientation. The display can also be rotated when the shortcut
ENTER and UP is pressed in the main screen.
MAIN SCREEN MODE - view of the main screen
With this menu item the display of the main screen can be changed. Either the standard (STAND-
ARD) screen is displayed with DMX address and DMX mode or the USER FIXTURE ID. This ID is
used to number the headlights and to display this number in the display.
SAFE MODE SWITCH - setting of the safe mode switch
This setting can be used to decide whether switching the menu item COOLING MODE can be
done directly "OFF" or whether for safety the dimmer and the shutter of the xture must be
closed before switching. -> "ON"
USER FIXTURE ID - adjustment of the user fixture ID
Used to set the USER FIXTURE ID (0-65535). This can be displayed via MAIN SCREEN MODE
and serves as an info display of the headlight number.
There is no danger to the life of the device in any mode, as the P18 Wash has a temperature safe-
ty shutdown. In addition, the LED module is switched off from an ambient temperature of 60°C!

- 19 -
P 18 W a s h
LED FADE OUT - type of dimming
Used to set how to dim the lower range from 0-5%.
STANDARD: When dimming the headlamp, all LED's dim out at the same time.
SOFT: When the headlamp is dimmed, the LED's are dimmed out in groups (in a row) one row
after the other.
6.6 STANDALONE operation
In standalone operation, up to 10 program steps can be stored in the P18 Wash, which can then
run in an endless loop. The images can be saved in two ways. Either you program the desired
DMX values directly on P18 Wash and save them, or you set the DMX values via a connected
DMX console and then store them in the P18 Wash.
The menu items MODIFY, RUN and REMOTE can only be called up using a specic key
combination. To do this, press and hold “ENTER”, and also press “ESC”. Before activating these
menu items, remove all other devices in the DMX line that send DMX, e.g. consoles or other
spotlights that are not congured as slave devices, as otherwise damage to the DMX drivers
may occur.
Programming the standalone programme on the spotlight display:
Call up the STANDALONE, EDIT menu item. In the STEP NR+/- menu item, select the desired step
and you can change it and its channel parameters in the following menu items: In theMODIFY
menu item, set the desired lighting scene and position and determine the individual sequence
times of the steps with FADE TIME and NEXT TIME (time for the complete step).
Use INSERT to insert an additional programming step. The DMX values of the previous step are
copied to the new step.
Use DELETE to delete a step. The display shows STEP NR: 1/X. Use the selection keys to move
to the desired step.
With RESET STEP you reset one step to its default values (DMX 000). The display shows STEP
NR: 1/X. Use the selection keys to select your step. CLEAR ALL resets the complete standalone
programming steps. Under MODIFY you will nd STEP1/1 again. In the STANDALONE, TIMEBASE
menu item you have the possibility to change the Fade Time and Next Time from 1 second to
1/10 second.
Launch the standalone program:
Call up the STANDALONE menu and navigate to the RUN sub menu. Conrm the selection by
pressing the key combination “ENTER” (press and hold) and simultaneously “ESC”. The display
then shows: S-ALONE: 01/XX and the program runs in an endless loop.
Deactivation: Press and hold the “ESC” key and then also press "ENTER". The menu jumps back
one level and RUN appears in the display.
Accept the DMX values from an external console:
To accept the DMX values of a connected console, you must rst enable the Capture DMX input.
To do this, go to the CAPT DMX menu item. The display now shows CAPTURE DMX 01/01, press
the Enter key to switch to START CAPTURE. Now the P18 Wash reacts to the signals from the
external console.

- 20 -
P 18 W a s h
Operation via master-slave function:
Connect the P18 Wash via DMX lines and activate the REMOTE menu item for all slave devices.
Todothis, navigate in the STANDALONE menu to the REMOTE sub-menu. Activate the REMOTE
function by pressing and holding “ENTER”, and also pressing “ESC”. The spotlight is in slave
mode when the display shows the status REMOTE INACTIVE or REMOTE ACTIVE.
REMOTE INACTIVE: The P18 Wash is in slave mode but does not receive a DMX signal.
REMOTE ACTIVE: The P18 Wash is in slave mode and receives a DMX signal.
The master device is programmed via the MODIFY menu item and started via RUN (press
andhold “ENTER” and also press “ESC”).
6.7 INFO-menu
The Info menu informs you about the respective software and rmware status, about the total
operating time and the different temperatures of the spotlight. The rst two menu items in theInfo
area are the software version and the rmware version, whereby the software version is an
important source of information for our service requests, the rmware version is less important
source of internal information. Under the menu item TOT OPERATE TIME the complete operating
time of the headlight is displayed. The menu item TOT LAMP TIME provides information about the
pure operating time of the LED module. TOT BAT CHARGE TIME shows the complete charging
time of the battery (battery backup). The TOT OPERATE TIME and the TOT BAT CHARGE TIME
can not be deleted!The following temperatures are also displayed:
TEMP BASE LCD, the temperature on the display board
TEMP BASE PS, the temperature of the power supply unit
TEMP HEAD MAIN, the temperature of the head board
TEMP HEAD DRV, the temperature of the LED driver board
TEMP HEAD LED, the temperature of the LED module
TEMP HEAD AMBIENT, the temperature in the head next to the air inlet (ambient temperature)
Both the current temperature and the maximum temperature are displayed. The maximum
temperatures can be individually deleted.
6.8 Shortcuts - quick access
ESC + DOWN
Pressing the ESC and DOWN buttons in the main menu will log the xture off the programmed
Lumen Radio Wireless transmitter. The xture is now ready to be logged in another transmitter.
ENTER + UP
If ENTER + UP is pressed in the main screen, the screen orientation is rotated by 180 °.
ENTER + ESC
Durch Drücken der Taste ENTER und ESC wird der Scheinwerfer für Benutzereingaben gesperrt
-> LOCKED. ESC und ENTER löst die Sperre wieder auf!
