jbc GN-A User manual

Nitrogen Generator
Ref. GN-A
www.jbctools.com

Packing List
Connection
The following items should be included:
Nitrogen Generator ...................................1 unit
Ref. GN-A
Manual ..........................................................1 unit
Ref. 0006929
Nitrogen Flow Regulator
Ref. MN-A
Control Unit
Ref. DI, DD, DDR, DM
Nitrogen Flow Regulator
Ref. MN-A Nitrogen Generator
Ref. GN-A
Compressed
Air Inlet
or from N2 net
Module cable
connector
Ref. 0010207
N2pressure range
supply 3 to 6 bar
6 bar MAX
Power
Cord
Socket
Nitrogen Handpiece
Ref. T245-NA
Handpiece
N2tube
Stand cable connector R e f. 0 01128 3
Stand
Ref. DN-SD
Nitrogen Gas Circuit Electric Circuit
2
www.jbctools.com

N2outlet
GN-A is a Nitrogen Gas Generator. Nitrogen gas (N2) simply obtained from compressed air through
action of high-performance separator membrane.
Features of the compressed air:
- Dry air and without oil
- Water filter of at least 0,01µm
- Particles filter of at least 0,3µm
Compressed air intlet
Valve open/close
The gas concentration and gas flow N2generated, depends on the inlet pressure
Description
www.jbctools.com
3
Concentration N2(%)
99,9% * 99,5% 99% 98% 97% 96% 95%
Pressure (bar) Gas flow N2(NL/min)
6 0,35 0,73 1,00 1,37 1,83 2,33 2,67
5 0,27 0,57 0,80 1,13 1,45 1,67 2,00
4 0,18 0,43 0,58 0,82 1,03 1,28 1,52

This product should not be thrown in the garbage.
In accordance with the European directive 2002/96/EC, electronic equipment at the end of their life
must be collected and returned to an authorized recycling facility.
Manual in other languages available on our website
Warranty
JBC’s 2 year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment
must be returned, postage paid, to the dealer
where it was purchased.
0006929-0717
-Weight: 2 kg (4.41 lb)
- Dimensions: 85 x 90 x 355 mm (3.35 x 3.54 x 13.98 in)
- Compressed air pressure: 4 - 6 bar
- Gas concentration: Up to 99%
- Concentrated N2 gas flow: 1 - 2 SLPM
- Ambient operating temperature: 10 - 40 ºC (50 - 104 ºF)
Complies with CE standards.
ESD protected.
Specifications
