JBL® GTO Series high-delity automotive speakers feature innovative technologies engineered for the environment
and conditions in today‘s cars to deliver exceptional sound. Using the patented Plus One® woofer cone technology
and rugged construction materials like FRP (breglass reinforced plastic) frames, butyl rubber surrounds and fabric
tweeter diaphragms, GTO Series automotive speakers are the ideal upgrade to any car‘s audio system. The most
popular factory-replacement and aftermarket sizes are covered including component separates with woofer, tweeter
and passive crossover. Easily installed and built to last, JBL GTO Series speakers bring music to life in the car,
providing high-end performance at moderate prices.
A complete, innovative line of high-fidelity automotive speakers in popular
factory-replacement and aftermarket-size configurations
JBL®GTO series sPeAKers
HIGHLIGHTS (All Models)
• Advanced FRP frames are nonmagnetic to transfer more energy to the voice coil, and the nonresonant property
improves overall sound quality.
• Carbon-injected Plus One cones deliver more diaphragm area than other speakers in the class.The carbon material
is light while still maintaining stiffness to perform well with rapid cone movement.
• Frequency response up to 21kHz means a bright, airy sound that opens up the listening space.
• Vented magnet assemblies keep the voice coil cool and reduce power compression over time.
• Three-ohm voice coils help compensate for added resistance in thin-gauge factory speaker wire. Compatible with
all 4 ohm-rated ampliers and head units.
• High sensitivity (91-94dB @ 2.83V/1m) means these speakers play loud even with moderate power.
• Modern cosmetics with high-tech grilles on many models where surface mounting is common.
• Rigorous testing and evaluation equal to carmaker reliability standards. No other competitors even come close to
this level of product development detail.
• Modern cosmetics with high-tech grilles on many models where surface mounting is common.
HIGHLIGHTS (Coaxial Models)
• Edge-driven soft dome tweeter diaphragm delivers a rich detail of vocals and instruments in music
while improving overall power handling.
• Unipivot™ tweeter on 5-1/4" (130mm) and larger models aims the sound to the listener’s ears.
• 0 or +3dB adjustable tweeter level on 5-1/4" (130mm) and larger models to suit on or off-axis placement.
• Mounting adapter rings included in 4"x6" and 6-1/2" (165mm) models for increased install coverage.
HIGHLIGHTS (Component Separates)
• 3/4" (19mm) edge-driven soft dome tweeter for greater exibility of placement within the vehicle’s interior.
• Patented I-Mount™ tweeter mounting system allows ush or surface mounting to blend with the interior.
• Dedicated 12dB/octave passive crossover networks increase power handling and musical clarity.
SUMMARY
GTO Series speakers provide high-end performance at moderate prices.
Online-store car audio and autogoods Winauto
winauto.ua

A complete, innovative line of high-fidelity automotive
speakers in popular factory-replacement and aftermarket-
size configurations
JBL®GTO series sPeAKers
TECHNICAL SPECIFICATIONS (Component Separates)
GTO 509C (Component System) 5-1/4" (130mm)
Peak power handling: 225W
Power handling: 75W RMS
Recommended power: 5W – 200W RMS
Frequency response: 67Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 92dB
Fits behind factory grilles. Accessory grilles included.
GTO 609C (Component System) 6-1/2" (165mm)
Peak power handling: 270W
Power handling: 75W RMS
Recommended power: 5W – 200W RMS
Frequency response: 67Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 92dB
Fits behind factory grilles. Accessory grilles included.
GTO 329 (Coaxial) 3-1/2" (87mm)
Peak power handling: 75W
Power handling: 25W RMS
Recommended power: 5W – 50W RMS
Frequency response: 85Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 91dB
Fits behind factory grilles.
GTO 429 (Coaxial) 4" (100mm)
Peak power handling: 105W
Power handling: 35W RMS
Recommended power: 5W – 50W RMS
Frequency response: 75Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 92dB
Fits behind factory grilles. Accessory grilles included.
GTO 529 (Coaxial) 5-1/4" (130 mm)
Peak power handling: 135W
Power handling: 45W RMS
Recommended power: 5W – 75W RMS
Frequency response: 67Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 92dB
Fits behind factory grilles. Accessory grilles included.
GTO 629 (Coaxial) 6-1/2" (165 mm)
Peak power handling: 180W
Power handling: 60W RMS
Recommended power: 5W – 125W RMS
Frequency response: 53Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 93dB
Fits behind factory grilles. Accessory grilles included.
GTO 6429 (Coaxial) 4" x 6"
Peak power handling: 135W
Power handling: 45W RMS
Recommended power: 5W – 50W RMS
Frequency response: 75Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 92dB
Fits behind factory grilles.
GTO 939 (Three-way) 6" x 9"
Peak power handling: 300W
Power handling: 100W RMS
Recommended power: 5W – 200W RMS
Frequency response: 46Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 94dB
Fits behind factory grilles. Accessory grilles included.
GTO 8629 (Coaxial) 6" x 8" / 5" x 7"
Peak power handling: 180W
Power handling: 60W RMS
Recommended power: 5W – 125W RMS
Frequency response: 49Hz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 93dB
Fits behind factory grilles.
Also Available -
Stand-alone 3/4" Component Tweeter
GTO 19T 3/4" (19mm)
Peak power handling: 135W
Power handling: 45W RMS
Recommended power: 5W – 75W RMS
Frequency response: 2.5kHz – 21kHz
Nominal impedance: 3 ohms
Sensitivity (2.83V/1m): 93dB
Fits behind factory grilles. Accessory grilles included.
TECHNICAL SPECIFICATIONS (Coaxials and 6" x 9" Three-way)
Online-store car audio and autogoods Winauto
winauto.ua

HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
© 2012 HARMAN International Industries, Incorporated. All rights reserved. JBL and Plus One are trademarks of HARMAN
International Industries, Incorporated, registered in the United States and/or other countries. I-Mount and UniPivot are
trademarks of HARMAN International Industries, Incorporated.
Features, specifications and appearance are subject to change without notice.
www.jbl.com
FEATURES ADVANTAGES BENEFITS
Carbon injected Plus One cone A larger diaphragm than other speakers in
the same size class means more air moves
with the stiff carbon cone
Better low-frequency response and musical
character than other speakers the same size
Carbon composite, nonmagnetic frames Transfers more energy to the moving parts
of the speaker and resists warping on
uneven surfaces during installation
Consistent performance and longer life
Frequency response up to 21kHz Helps to compensate for placement
variations in the car and human hearing
deciencies in the high frequencies
Delivers more of the full-range response that
you associate with great sound
Vented magnet assemblies Increases cooling to the speaker’s voice coil Reduces power compression and unwanted
distortion
Three-ohm voice coils Compensates for added resistance in
thin-gauge factory speaker wiring for full
power delivery. Compatible with all 4 ohm-
rated ampliers and head units
Full power delivery means more rich sound
delivered to the listener’s ears
High sensitivity (91-94dB @ 2.83V/1m) Allows a wider range of power to have
positive results
Excellent volume and musicality with as little
as 5W RMS means better performance
Edge-driven soft dome tweeter (on 5-1/4"
and larger coaxials and component sets)
Increased power handling and smoother
high-frequency response
More lifelike vocals, cymbals, brass
instruments and piano sounds
UniPivot™(U.S. patent no. 6,002,780) tweeter
on 5-1/4" and larger coaxials)
Allows tweeter to be aimed toward listener’s
ears in lower factory speaker positions to
project the sound much higher up across
the dash
Raises the sound stage and makes the
music more realistic
0 or +3dB tweeter level adjustment (on
5-1/4" and larger coaxials)
More control of the high-frequency blend
to accommodate a greater variety of
installation locations
Increased ability to personalize the sound
for the listener’s taste
I-Mount™(U.S. patent no. 5,859,917) tweeter
mounting system on component speaker
sets
Allows for surface or ush mounting of the
3/4" (19mm) component tweeter
Offers greater exibility of installation to
blend placement tastefully with interior
surfaces
Dedicated 12dB/octave passive crossover
network on component speaker sets
Filters low and high-frequencies to the
appropriate speakers while increasing
power handling
Enhances sound quality and blend of the
components as if a single speaker
Mounting hardware Grilles, mounting adapter rings and/or
tweeter cups all included in the specic
models where necessary
More exibility for installation options
A complete, innovative line of high-fidelity automotive
speakers in popular factory-replacement and aftermarket-
size configurations
JBL®GTO series sPeAKers
