JBL MR-6.2 User manual

EST.JBL(MR6.2)-061129-I/B
145x210mm
Revised 27 / May / 05
Model No.: MR-6.2
MARINEMARINE
PWR
MODE MR - 6.2 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
SH
SR
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
Operation Manual
for Users
MARINE
COMPACT
DIGITAL AUDIO
This product is sold and serviced exclusively by Prospec Electronic Inc. and must be returned
to Prospec for in and out of warranty repairs. It can not be serviced under warranty by other JBL
service centers. All Products sold and serviced exclusively by Prospec Electronics Inc.
For service contact us: 3325 South Morgans Point Road Mount Pleasant SC 29466
Tel 843-849-9037 Fax 843-849-9054
.

Trouble shooting guide
INTERFERENCE ON RADIO
Poor atmospheric conditions - Try again later in the day.
Antenna / lead broken or damaged.
Power Output : 4 x 45 watts
Power Supply : DC + 12V
Negative Ground
Speaker Impedance: 4 ohm
Tuning Range : 530~1710KHz (USA)
522~1620KHz (EUR)
Sensitivity : 35dB / uV
Tuning Range : 87.5~107.9MHz(USA)
87.5~108MHz (EUR)
Sensitivity : 10dB / uV
Separation : 30dB
FM TUNER
COMPACT DISC AUDIO AMP & GENERAL
Freq. Response : 20 Hz-20 KHz
Total Harmonic Distortion : 0.8%
Signal - Noise Ratio : 65 dB
Dynamic Range : 90 dB
DISTORTED AUDIO
Specification
AM TUNER
Check loudspeaker wiring.
This product contains a biamp. It is important not to connect the front
loudspeaker ground to the rear speaker ground.
Faulty loudspeaker.
Distortion at highest volume levels may be normal, as amplifier has
reached maximum power output. Otherwise the power and ground wire s
gauge might be too small (use 10amp cable or more).
Reduce the bass effect or switch off the loudness mode.
Boat battery and or charging circuit may be faulty.
13
EST.JBL(MR6.2)-061129-I/B

1
12
Contents
Wiring
Removing or Detaching the Front Panel
Important Notes
Installation
Supporting the Unit
Identification of Control Functions
Controls
Operating the Radio
Operating the CD Player
Precautions and Maintenance
Trouble Shooting Guide & Specifications
Identification
Contents
1
2
3
4
5
6
7
8-9
10
11
12
13
145x210mm
1. Reset function
A microprocessor reset button has been provided to facilitate manual resetting of the
internal microprocessor. In the unlikely event that the player fails to operate correctly,
refer to step 3 below.
Note: It will be necessary to re-enter the radio preset memories as these will have
been erased when the microprocessor was reset. After resetting the player,
ensure that all functions are operating correctly.
2. General Precautions
If the unit has become extremely hot we strongly recommend that you allow it to cool
down before using. Take care of your CD to preserve the quality of the recording.
Do not allow CDs to be exposed to direct sunlight. Store them in a place protected
from dirt and dust and avoid handling them with oily, greasy or wet hands.
Be sure the CD is put into the CD slot label side up.
3. Caution
Precautions and Maintenance
RESET: If you are faced with a malfunction during the operation, simply press
the reset button.
LED: It flashes when the faceplate is removed.
CONNECTOR PIN: Always keep connector pin clean.
If the PIN connector looks dirty, use cotton tips and clean it to avoid any
unexpected malfunction caused by dirt.
1
1
2
2
3
2
11 233
EST.JBL(MR6.2)-061129-I/B
PLEASE NOTE: In order to receive Sirius Satellite radio broadcast, you must install
JBL Sir2.5 as well as a satellite antenna (both sold separately).
What is SIRIUS Satellite Radio?
SIRIUS, headquartered in New York, offers over 120 cannels of digital quality radio
transmitted across the continental US from three high-tech satellites. Along with offering
a full spectrum of music genres, users can also listen to popular news, entertainment
and sports channels. SIRIUS currently offers 65 music channels, 24 news channels
(including traffic and weather), 7 sports channels (including two dedicated play-by-play
channels) and 24 talk / entertainment channels.
For more information on SIRIUS, visit siriusradio.com.

2
Wiring Identification
145x210mm
Installation Notes
Applicable to both 2 and 4-speaker connection:
A. Connections
B. Amp cable connection for remote control
C. Din cable connection for SIRIUS control
D. AUX-IN
E. Antenna socket
This radio contains four separate power amplifiers. To prevent possible damage to
these amplifiers, please ensure the following:
i) The boat chassis is not used as a loudspeaker ground(-).
ii) Front and Rear loudspeaker connecting wires are not joined together.
iii) Any wires not used when completing a two speaker installation are fully insulated.
iv) The memory wire (yellow) is connected to a permanent + 12V supply.
v) The power wire (red) is connected via the ignition switch of the boat.
CONNECTOR
(AUTO ANT)
( BACK-UP B+ )
FUSE
1A
( GROUND )
FUSE
( IGNITION B+ )
Blue
Yellow
Black
Red
Gray
Gray/Black
Violet
Violet/Black
( Front Right )
( Rear Right )
Green
Green/Black
White
White/Black
( Front Left )
( Rear Left )
10A
Red
White
Black
White
(ANT. socket)
A
Red
Gray
Rear Line out
Front Line out
BC
D
E
( Remote control )
( SIRIUS control )
( AUX-IN )
11
Operating the CD Player
1. Loading a CD
Insert a CD label side up into the slot opening.
The CD will begin playing automatically after it is loaded.
2. Select the Radio -> CD by pressing the "MODE" button (4) .
3. Track Tuning (9)
Search the tracks on the DISC with the and buttons. If you press and hold
the or button continuously, the track goes fast - forward or rewinds.
4. Play / Pause (10)
Push to pause and push again to resume play.
5. Intro Scan (11)
Press this button to hear the first 10 seconds of each track on the disc.
Press this button again to restore the player to its normal play mode.
6. Repeat play button (12)
While playing a desired track, press the RPT button to play the track repeatedly.
Press the RPT button again to return to normal play mode.
7. Random play button (13)
Press the RDM button to play all tracks on a CD disc in a random sequence.
Press the RDM button again to return the player to normal mode.
Notes:
NEVER insert foreign objects into the CD slot opening.
If a CD is difficult to insert, there may already be a CD loaded in the unit.
Some recorded CD-Rs or CD-RWs may not be usable with this CD player.
3
2
7
4
8
18
16
10 11 12 13 14 15
617
1
5
9
SEL
MARINEMARINE
PWR
MODE MR - 6.2 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
SH
SR
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
EST.JBL(MR6.2)-061129-I/B

3
Carrying Case
Front Panel
1. Press Release Button to detach the front panel.
2. Keep the detachable front panel in the protective case provided.
3. Attaching the front panel
- Put the front panel into the body of the unit in the correct position.
Be sure the front panel is facing the correct direction to avoid malfunction or damage
to the unit.
Front Panel
Removing or Detaching the Front Panel
4. Attaching the trim ring
- Attach the trim ring to the radio after installing.
- Be sure to insert the trim ring in the correct direction.
145x210mm
Release button
SEL
MARINEMARINE
PWR
MODE MR - 6 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
VOL
SH
SR
SEL
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
10
Operating the Radio
1. Manual / Seek tuning buttons (9) : Press this button quickly to activate the
Seek mode. The Seek mode will automatically seek up or down the wave band and
stop at the next station of sufficient signal strength. Press and hold tuning buttons for
2 seconds to enter manual tuning mode. The unit will revert back to Seek mode after
10 seconds without use.
2. Manual station store: Select the desired band and tune to a radio station to be
memorized. Choose the preset button memory location 1-6 into which the station is
to be stored and press and hold that preset button for 2 seconds. The station will
now be entered into the preset memory. 6 stations can be memorized on each of the
FM1, FM2, FM3, AM1 & AM2.
3. A.PS - Auto store function. (18)
Press and hold button (18) for approximately 2 seconds until you hear a beep which
confirms the memory function if engaged. The unit will “SEARCH”for six strong
stations and automatically store them on buttons 1 - 6.
4. SCAN (16) function
Press this key (SCAN 16) to scan strong stations for previewing. At the desired station
press the SCAN (16) button again to stop scanning.
5. Program Memory Scan
Momentarily press A.PS and unit will scan for stored stations.
Momentarily press it again to stop scanning.
3
2
7
4
8
18
16
10 11 12 13 14 15
617
1
5
9
SEL
MARINEMARINE
PWR
MODE MR - 6.2 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
SH
SR
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
EST.JBL(MR6.2)-061129-I/B

Important notes
4
Prior to the final installation, carry out a sound check. If high distortion or intermittent
sound is experienced, it is possible that the wiring from the CD receiver to the boat's
electrical system is poor or that the battery needs recharging.
If the battery and its charging circuit are OK, then rewire the red fused wire of the CD
player directly to the positive terminal (+) of the boat battery.
Marine accessory shops stock the connector blocks and the 10 Amp cable which may
be necessary for extending the fuse wire connection.
Grounding
Make sure that the black wire on the wiring harness is connected to a good ground
point on the boat. If the chassis of the boat is used as a grounding point, make sure
that the surface is scraped clean from the metal before attaching the wire to it.
It is preferable to connect the black ground wire directly to negative terminal (-) of the
boat battery.
Warning: polarity...
This model is only suitable for use in boats which have a negative ground system, e.g:
the negative terminal of the boat battery is connected to the chassis.
Connecting the speakers and power cables
Before you wire your system, disconnect your boats battery's positive (+) cable.
This helps prevent damage in case of a short. When you complete the wiring,
reconnect the battery cable and test your marine stereo. When connecting your
marine stereo's black ground wire, be sure to connect the wire to a metal part of your
boat or preferably to the negative (-) terminal of the boat battery.
POSITIVE
CHASSIS
NEGATIVE
CHASSIS
145x210mm
c. Area Selection
By pressing SEL button again, the unit will be in Area Selection mode. Use the spindle
knob to choose USA or EUR (Europe). Press and hold the BAND button for 1-2
seconds to set the format.
d. DSP
Choose from flat, classic, pop or rock by pressing the SEL button again. Adjust with
spindle knob.
3.Volume control
Turn the spindle knob (2) left or right to decrease or increase the volume level.
The radio will automatically default to volume mode when powered up.
- Bass control
Turn left to lower the bass.
Turn right to increase the bass.
- Treble control
Turn left to lower the treble.
Turn right to increase the treble.
-Balance control
Turn left to decrease the right speaker volume.
Turn right to increase the left speaker volume.
- Fader control
Turn left to decrease the volume level of any loud speakers connected to the front channel.
Turn right to decrease the volume level of any loud speakers connected to the rear channel.
4."MODE" button (4)
Press this MODE button (4) to select Radio CD SIRIUS AUX-IN.
5. BD/FN button (8)
In Radio mode, press the BD/FN button (8) will shift FM/AM bands:
FM1 FM2 FM3 AM1 AM2.
In SIRIUS mode, press BD/FN button (8) to select the SSR1, SSR2 or CATEGORY.
6. SHIFT / SCROLL button (5)
SIRIUS function button only.
7. How to adjust the clock / time (17)
a. Press and hold the DIS (17) button until the time flashes on the display.
b. Turn spindle knob clockwise to set hour.
c. Turn spindle knob counter clockwise to set minutes.
d. Press the DIS button again quickly to accept the adjusted time.
If no button is pressed within 5 seconds, then it automatically accepts the adjusted
time without further intervention from the user.
8. Loudness function (7)
In order to emphasize the bass and the treble at low volume, press the LD (8) button.
To turn off loudness, press the LD button again.
9
Controls
EST.JBL(MR6.2)-061129-I/B

Installation
5
1. Precautions
Choose the mounting location carefully so that the unit will not interfere with the normal
driving functions of the boat.
Avoid installing the unit where it would be subject to high temperature (such as from
direct sunlight or hot air) or where it would be subject to dust, dirt or excessive
vibration. Use only the supplied mounting hardware for a safe and secure installation.
Be sure to remove the front panel before installing the unit.
2. Mounting angle adjustment
The mounting angle of the receiver should not exceed 20 degrees from the horizontal
position.
3. Mounting example
1 2
4
Release Key Half Cabinet
Tap
Bend these claws, if necessary.
3
<< Installation in the cabinet >>
Note Keep the release key in a safe place as you may need it in future to remove
the unit from the boat.
145x210mm
1. POWER ON/OFF
Push the button (6) to turn on the unit. Push the button again to turn off the unit.
2. SELECT button (2)
1) Audio control ( VOLUME / BASS / TREBLE / BALANCE / FADER )
Press key quickly to select the following features;
"VOL" display - volume control > press key (2)>
"BAS" display - bass tone control >press key (2)>
"TRB" display - treble tone control > press key (2)>
"BAL" display - balance control > press key (2)>
"FAD" display - fader control > press key (2)>
Then use the spindle knob to adjust. If the key or one of the keys is not pressed within
5 seconds, the radio automatically switches into volume control mode.
These settings are indicated on the display window.
2) Beep 2nd , I-Vol , Area and DSP Selection
When the SEL button is pressed over 2 seconds, the unit will be operated as below:
a. Beep 2nd
On the Beep 2nd, you can control the Beep on or Beep 2nd by turning the spindle knob.
-Beep on : You can hear "Beep" sound when you press all buttons.
-Beep 2nd :You can hear "Beep" sound when you press the button over 1.5 seconds.
b. I-Vol
By pressing the button again, the unit will be into the I- VOL mode. (Initial Volume Level
Adjustment). You can adjust the I-Vol of what you want to set by turning the spindle
knob and the I-Vol will be set automatically. After the setting of initial levels, when the
unit is power on/off, detach on/off, and ACC on/off, if the present level is lower than
Initial level or if the present level is higher than initial level, it will keep the present level.
VOLUME Select BASS Select TREBLE
Select FADER Select BALANCE Select
8
Controls
Beep 2nd I-Vol Area
Press Press Press DSP
3
2
7
4
8
18
16
10 11 12 13 14 15
617
1
5
9
SEL
MARINEMARINE
PWR
MODE MR - 6.2 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
SH
SR
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
EST.JBL(MR6.2)-061129-I/B

1. UNIT
2. RELEASE CASE
3. HEX NUT
4. LOCK WASHER
5. PLAIN WASHER
6. BODY
7. REAR SUPPORT STRAP
8. TAPPING SCREW
9. M5 X 20 HEX BOLT
3
5
2
1
4
6
8
HEX
Lock Washer
Plain Washer
7
Accessories subject to change without notice.
1. Fuse replacement
If the fuse blows, check the power connection and replace the fuse. If the fuse blows
again after the replacement, there may be an internal malfunction. In this case,
consult your nearest dealer.
2. Warning
Use the specified amperage fuse for each lead.
Use of a higher amperage fuse may cause serious damage.
Supporting the unit
3
9
7
6
145x210mm
1. CD eject button
2. Electronic function SELECT button, Volume control knob
3. Front panel release button
4. MODE button ( radio CD SIRIUS AUX-IN ----> repeatedly)
5. SH.SR (SHIFT / SCROLL) button (SIRIUS only)
6. POWER ON/OFF button
7. LOUD (loudness) button (# 0 SIRIUS only)
8. BD / FN button
9. Radio tune UP/DOWN, CD track UP/DOWN ( # 0 SIRIUS only)
10. CD play / pause, preset 1 button
11. CD intro Scan button, preset 2 button
12. CD repeat track button, preset 3 button
13. CD random play button, preset 4 button
14. Preset 5 button (# 5 SIRIUS only)
15. Preset 6 button (# 6 SIRIUS only)
16. SCAN button (# 7 SIRIUS only)
17. DISP (display) button (# 8 SIRIUS only)
18. A.PS - Auto Preset Scan button (# 9 SIRIUS only)
7
Identification of Control Functions
3
2
7
4
8
18
16
10 11 12 13 14 15
617
1
5
9
SEL
MARINEMARINE
PWR
MODE MR - 6.2 / 4CH x 45Watts
2 INT 3 RPT
56
0.LD
BD/FN
8.DIS
7. SCN
9.A.PS
REL
1
SH
SR
COMPACT DISC PLAYER DETACHABLE SYSTEM
4 RDM
EST.JBL(MR6.2)-061129-I/B
Table of contents
Other JBL CD Player manuals
Popular CD Player manuals by other brands

Sony
Sony CDP-CX210 - 200 Disc Cd Changer operating instructions

Sony
Sony Walkman D-NS707F Specifications

Lenoxx Sound
Lenoxx Sound CD-163 operating instructions

SOUNDMASTER
SOUNDMASTER CD9220 instruction manual

Pioneer
Pioneer SUPER TUNER III DEH-323 Operation manual

Pioneer
Pioneer DRM-7000 operating instructions
