OPERATOR'S MANUAL
BACKHOE LOADER
2DX, 2DXL
EN - 9831/3100
ISSUE 2 - 03/2017
THIS MANUAL SHOULD ALWAYS STAY WITH THE MACHINE

OPERATOR'S
MANUAL
BACKHOE LOADER
2DX, 2DXL
EN - 9831/3100
ISSUE 2 - 03/2017
This manual contains original instructions, verified by
the manufacturer (or their authorized representative).
Copyright 6-07-19 © JCB SERVICE
All rights reserved. No part of this publication may
be reproduced, stored in a retrieval system, or
transmitted in any form or by any other means,
electronic, mechanical, photocopying or otherwise,
without prior permission from JCB SERVICE.
www.jcb.com
Foreword
The Operator's Manual
You and others can be killed or seriously injured
if you operate or maintain the machine without
first studying the Operator's Manual. You must
understand and follow the instructions in the
Operator's Manual. If you do not understand
anything, ask your employer or JCB dealer to
explain it.
Do not operate the machine without an Operator's
Manual, or if there is anything on the machine you
do not understand.
Treat the Operator's Manual as part of the machine.
Keep it clean and in good condition. Replace the
Operator's Manual immediately if it is lost, damaged
or becomes unreadable.
Machine Delivery and Installation
Even if you have operated this type of equipment
before, it is very important that your new machines
operations and functions are explained to you by
a JCB Dealer Representative following delivery of
your new machine.
Following the installation you will know how to gain
maximum productivity and performance from your
new product.
Please contact your local JCB dealer if the
Installation Form (included in this manual) has not
yet been completed with you.
Your local JCB Dealer is
Find manuals at https://best-manuals.com

9831/3100-2
Notes:
Find manuals at https://best-manuals.com

Table of Contents
i 9831/3100-2 i
Contents Page No.
Acronyms Glossary ........................................................................................................................................ vii
Introduction
About this Manual
Model and Serial Number ..................................................................................................................... 1
Using the Manual .................................................................................................................................. 1
Left-Hand Side, Right-Hand Side ......................................................................................................... 1
Cross References ................................................................................................................................. 1
Location of Manual ............................................................................................................................... 1
Safety
Safety - Yours and Others .................................................................................................................... 3
Safety Warnings .................................................................................................................................... 3
General Safety ...................................................................................................................................... 4
Clothing and Personal Protective Equipment (PPE) ............................................................................ 5
About the Product
Introduction
General .................................................................................................................................................. 7
Name and Address of the Manufacturer .............................................................................................. 7
Product Compliance .............................................................................................................................. 7
Description
General .................................................................................................................................................. 8
Intended Use ......................................................................................................................................... 8
Log Moving/Object Handling ................................................................................................................. 8
Optional Equipment and Attachments .................................................................................................. 8
Danger Zone ......................................................................................................................................... 8
Main Component Locations .................................................................................................................. 9
Product and Component Identification
Machine ............................................................................................................................................... 10
Engine ................................................................................................................................................. 10
Axle ..................................................................................................................................................... 11
Gearbox ............................................................................................................................................... 11
Hydraulic Pump ................................................................................................................................... 12
Safety Labels
General ................................................................................................................................................ 13
Operator Station
Component Locations ......................................................................................................................... 14
Interior Switches
Ignition Switch ..................................................................................................................................... 17
Multi-Purpose Switch .......................................................................................................................... 17
Cab Interior Light ................................................................................................................................ 18
Console Switches
General ................................................................................................................................................ 19
Road Lights ......................................................................................................................................... 19
Rear Fog Lights .................................................................................................................................. 19
Hazard Warning Lights ....................................................................................................................... 19
Front Work Lights ............................................................................................................................... 20
Rear Work Lights ................................................................................................................................ 20
Kingpost Clamp ................................................................................................................................... 20
Find manuals at https://best-manuals.com

Table of Contents
ii 9831/3100-2 ii
Operation
Introduction
General ................................................................................................................................................ 21
Operating Safety
General ................................................................................................................................................ 22
Worksite Safety ................................................................................................................................... 24
Risk Assessment ................................................................................................................................ 25
Walk-Around Inspection
General ................................................................................................................................................ 27
Entering and Leaving the Operator Station
General ................................................................................................................................................ 28
Doors
Operator Door ..................................................................................................................................... 29
Windows
Side Window ....................................................................................................................................... 30
Rear Window ...................................................................................................................................... 30
Before Starting the Engine
General ................................................................................................................................................ 32
Operator Seat
General ................................................................................................................................................ 34
Basic Seat ........................................................................................................................................... 34
Suspension Seat ................................................................................................................................. 35
Seat Belt
General ................................................................................................................................................ 37
Static Seat Belt ................................................................................................................................... 37
Mirrors
General ................................................................................................................................................ 39
Starting the Engine
General ................................................................................................................................................ 40
Warming Up ........................................................................................................................................ 40
Stopping and Parking
General ................................................................................................................................................ 42
Preparing for Travel
General ................................................................................................................................................ 43
Preparing for Road Travel .................................................................................................................. 44
Preparing for Worksite Travel ............................................................................................................. 45
Beacon ................................................................................................................................................ 46
Safety Equipment
Boom Lock .......................................................................................................................................... 47
Slew Lock ........................................................................................................................................... 47
Drive Controls
Steering Wheel ................................................................................................................................... 49
Accelerator Pedal ................................................................................................................................ 49
Hand Throttle Control ......................................................................................................................... 49
Service Brake Pedal ........................................................................................................................... 49
Park Brake .......................................................................................................................................... 50
Transmission Drive Lever ................................................................................................................... 50
Steer Mode Control ............................................................................................................................ 51
Instruments
Instrument Panel ................................................................................................................................. 52
Find manuals at https://best-manuals.com

Table of Contents
iii 9831/3100-2 iii
Getting the Machine Moving
General ................................................................................................................................................ 54
Slopes
General ................................................................................................................................................ 56
Driving on Slopes ............................................................................................................................... 56
Operating Levers/Pedals
General ................................................................................................................................................ 57
Control Layouts ................................................................................................................................... 57
Loader Controls .................................................................................................................................. 57
Excavator Arm Controls ...................................................................................................................... 60
Stabiliser Controls ............................................................................................................................... 64
Auxiliary Circuit Controls ..................................................................................................................... 65
Lifting and Loading
General ................................................................................................................................................ 67
Working with the Loader
General ................................................................................................................................................ 68
Filling the Shovel ................................................................................................................................ 68
Loading a Truck .................................................................................................................................. 69
Backfilling ............................................................................................................................................ 69
Dozing and Grading ............................................................................................................................ 70
Working with the Excavator Arm
General ................................................................................................................................................ 74
Preparing to Use the Excavator Arm ................................................................................................. 74
Digging ................................................................................................................................................ 75
Changing the Bucket Linkage ............................................................................................................ 76
Power Sockets
Auxiliary Power Socket ....................................................................................................................... 79
Fire Extinguisher
General ................................................................................................................................................ 80
Moving a Disabled Machine
Getting the Machine Unstuck ............................................................................................................. 81
Jump-Starting the Engine ................................................................................................................... 81
Retrieval .............................................................................................................................................. 82
Loader Arm (Emergency Operation) .................................................................................................. 83
Excavator Arm (Emergency Operation) .............................................................................................. 84
Lifting the Machine
General ................................................................................................................................................ 85
Transporting the Machine
General ................................................................................................................................................ 88
Loading the Machine onto the Transporting Vehicle/Trailer ............................................................... 88
Operating Environment
General ................................................................................................................................................ 90
Operating in Low Temperatures ......................................................................................................... 90
Operating in High Temperatures ......................................................................................................... 90
Refuelling
General ................................................................................................................................................ 92
Low Fuel Levels .................................................................................................................................. 92
Filling the Tank .................................................................................................................................... 92
Attachments
Working with Attachments
Introduction .......................................................................................................................................... 95
Find manuals at https://best-manuals.com

Table of Contents
iv 9831/3100-2 iv
Attachments for your Machine ............................................................................................................ 95
Connecting/Disconnecting Hydraulic Hoses ....................................................................................... 95
Direct-Mounted Attachments
General ................................................................................................................................................ 98
Side-Shift Carriage
General .............................................................................................................................................. 100
Preservation and Storage
Cleaning
General .............................................................................................................................................. 101
Preparation ........................................................................................................................................ 101
Checking For Damage
General .............................................................................................................................................. 103
Storage
General .............................................................................................................................................. 104
Put into Storage ................................................................................................................................ 104
During Storage .................................................................................................................................. 104
Take out of Storage .......................................................................................................................... 105
Security
LiveLink ............................................................................................................................................. 106
Maintenance
Introduction
General .............................................................................................................................................. 107
Owner/Operator Support ................................................................................................................... 107
Initial Service and Inspection ............................................................................................................ 108
Obtaining Spare Parts ...................................................................................................................... 108
Maintenance Safety
General .............................................................................................................................................. 109
Fluids and Lubricants ....................................................................................................................... 110
Maintenance Schedules
General .............................................................................................................................................. 114
How to Use the Maintenance Schedules ......................................................................................... 114
Maintenance Intervals ....................................................................................................................... 114
Pre-start Cold Checks, Service Points and Fluid Levels .................................................................. 115
Functional Tests and Final Inspection .............................................................................................. 117
Maintenance Positions
General .............................................................................................................................................. 119
Maintenance Position - Loader Arm Lowered .................................................................................. 119
Maintenance Position - Loader Arm Raised ..................................................................................... 119
Service Points
General .............................................................................................................................................. 122
Access Apertures
General .............................................................................................................................................. 124
Engine Compartment Cover ............................................................................................................. 124
Front Grille ........................................................................................................................................ 124
Tools
General .............................................................................................................................................. 126
Toolbox .............................................................................................................................................. 126
Lubrication
General .............................................................................................................................................. 127
Preparation ........................................................................................................................................ 127
Find manuals at https://best-manuals.com

Table of Contents
v 9831/3100-2 v
Attachments
General ............................................................................................................................................. 128
Body and Framework
General ............................................................................................................................................. 129
Kingpost ............................................................................................................................................ 131
Loader Arm
General ............................................................................................................................................. 132
Excavator Arm
Lubricate ............................................................................................................................................ 133
Operator Station
General ............................................................................................................................................. 134
Seat ................................................................................................................................................... 134
Seat Belt ........................................................................................................................................... 134
Engine
Oil ...................................................................................................................................................... 135
Drive Belt .......................................................................................................................................... 137
Air Filter
General ............................................................................................................................................. 139
Pre-Cleaner ....................................................................................................................................... 140
Dust Valve ........................................................................................................................................ 141
Fuel System
General ............................................................................................................................................. 142
Engine Fuel Filter ............................................................................................................................. 143
Water Separator ............................................................................................................................... 143
Cooling System
Coolant .............................................................................................................................................. 145
Cooling Pack .................................................................................................................................... 145
Brakes
Park Brake ........................................................................................................................................ 147
Axles
General ............................................................................................................................................. 149
Oil ...................................................................................................................................................... 149
Wheels
General ............................................................................................................................................. 150
Tyres
General ............................................................................................................................................. 152
Hydraulic System
General ............................................................................................................................................. 154
Services ............................................................................................................................................ 154
Oil ...................................................................................................................................................... 154
Electrical System
General ............................................................................................................................................. 156
Battery ............................................................................................................................................... 157
Fuses ................................................................................................................................................ 158
Relays ............................................................................................................................................... 159
Technical Data
Static Dimensions
Dimensions ........................................................................................................................................ 160
Performance Dimensions
Lift Arm Dimensions and Performance ............................................................................................. 164
Excavator Arm Dimensions and Performance .................................................................................. 166
Find manuals at https://best-manuals.com

Table of Contents
vi 9831/3100-2 vi
Driving Performance ......................................................................................................................... 167
Fluids, Lubricants and Capacities
General .............................................................................................................................................. 169
Fuel ................................................................................................................................................... 169
Coolant .............................................................................................................................................. 171
Torque Values
General .............................................................................................................................................. 172
Electrical System
General .............................................................................................................................................. 173
Bulbs ................................................................................................................................................. 173
Fuses ................................................................................................................................................. 173
Wheels and Tyres
Tyre Sizes and Pressures ................................................................................................................ 175
Find manuals at https://best-manuals.com

Table of Contents
vii 9831/3100-2 vii
Acronyms Glossary
2WD Two Wheel Drive
2WS Two Wheel Steer
ARV Auxiliary Relief Valve
FEAD Front End Accessory Drive
LCD Liquid Crystal Display
PIN Product Identification Number
PPE Personal Protective Equipment
RPM Revolutions Per Minute
SRS Smooth Ride System
Find manuals at https://best-manuals.com

Notes:
viii 9831/3100-2 viii

Introduction
About this Manual
1 9831/3100-2 1
Introduction
About this Manual
Model and Serial Number
This manual provides information for the following model(s) in the JCB machine range:
Model From: To:
2DX 1915700
2DXL 2475501
Using the Manual
This operator's manual is arranged to give you a good understanding of the machine and its safe operation.
It also contains maintenance and technical data.
Read this manual from the front to the back before you use the machine for the first time, even if you have used
machines of a similar/same type before as the technical specification, systems and controls of the machine
may have changed. Particular attention must be given to all the safety aspects of operating and maintaining
the machine.
If there is anything you are not sure about, ask your JCB dealer or employer. Do not guess, you or others could
be killed or seriously injured.
The general and specific warnings in this section are repeated throughout the manual. Read all the safety
statements regularly, so you do not forget them. Remember that the best operators are the safest operators.
The illustrations in this manual are for guidance only. Where the machines are different, the text and or the
illustration will specify.
The manufacturer's policy is one of continuous improvement. The right to change the specification of the
machine without notice is reserved. No responsibility will be accepted for discrepancies which may occur
between specifications of the machine and the descriptions contained in this manual.
All of the optional equipment included in this manual may not be available in all territories
Left-Hand Side, Right-Hand Side
In this manual, 'left' and 'right' mean your left and right when you are seated correctly in the machine.
This is so whether you are facing the loader (front) or the backhoe (rear).
Figure 1.
B
A
B
A
B
A
A
B
ALeft BRight
Cross References
In this manual, cross references are made by presenting the subject title in blue (electronic copy only). The
number of the page upon which the subject begins is indicated within the brackets. For example: Refer to:
Cross References (Page 1).
Location of Manual
The manual is located in the case attached to the back of the seat. The manual should always be returned
to its case after use.

Introduction
About this Manual
2 9831/3100-2 2
Figure 2.
A
AManual location

Introduction
Safety
3 9831/3100-2 3
Safety
Safety - Yours and Others
All machinery can be hazardous. When a machine is correctly operated and maintained, it is a safe machine
to work with. When it is carelessly operated or poorly maintained it can become a danger to you (the operator)
and others.
In this manual and on the machine you will find warning messages, read and understand them. They inform
you of potential hazards and how to avoid them. If you do not fully understand the warning messages, ask your
employer or JCB dealer to explain them.
Safety is not just a matter of responding to the warnings. All the time you are working on or with the machine
you must be thinking of what hazards there might be and how to avoid them.
Do not work with the machine until you are sure that you can control it.
Do not start any work until you are sure that you and those around you will be safe.
If you are not sure of anything, about the machine or the work, ask someone who knows. Do not assume
anything.
Remember:
• Be careful
• Be alert
• Be safe.
Safety Warnings
In this manual and on the machine, there are safety notices. Each notice starts with a signal word. The signal
word meanings are given below.
The signal word 'DANGER' indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
The signal word 'WARNING' indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
The signal word 'CAUTION' indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
The signal word 'Notice' indicates a hazardous situation which, if not avoided, could result in machine damage.
The safety alert system (shown) also helps to identify important safety messages in this manual and on the
machine. When you see this symbol, be alert, your safety is involved, carefully read the message that follows,
and inform other operators.
Figure 3. The safety alert system

Introduction
Safety
4 9831/3100-2 4
General Safety
Training
To operate the machine safely you must know the machine and have the skill to use it. You must abide by
all relevant laws, health and safety regulations that apply to the country you are operating in. The operator's
manual instructs you on the machine, its controls and its safe operation; it is not a training manual. If you are a
new operator, get yourself trained in the skills of using a machine before trying to work with it. If you don't, you
will not do your job well, and you will be a danger to yourself and others. In some markets and for work on certain
jobsites you may be required to have been trained and assessed in accordance with an operator competence
scheme. Make sure that you and your machine comply with relevant local laws and jobsite requirements - it
is your responsibility.
Care and Alertness
All the time you are working with or on the machine, take care and stay alert. Always be careful. Always be
alert for hazards.
Clothing
You can be injured if you do not wear the correct clothing. Loose clothing can get caught in the machinery.
Keep cuffs fastened. Do not wear a necktie or scarf. Keep long hair restrained. Remove rings, watches and
personal jewellery.
Alcohol and Drugs
It is extremely dangerous to operate machinery when under the influence of alcohol or drugs. Do not consume
alcoholic drinks or take drugs before or while operating the machine or attachments. Be aware of medicines
which can cause drowsiness.
Feeling Unwell
Do not attempt to operate the machine if you are feeling unwell. By doing so you could be a danger to yourself
and those you work with.
Mobile Phones
Switch off your mobile phone before entering an area with a potentially explosive atmosphere. Sparks in such
an area could cause an explosion or fire resulting in death or serious injury.
Switch off and do not use your mobile phone when refuelling the machine.
Lifting Equipment
You can be injured if you use incorrect or faulty lifting equipment. You must identify the weight of the item to
be lifted then choose lifting equipment that is strong enough and suitable for the job. Make sure that lifting
equipment is in good condition and complies with all local regulations.
Raised Equipment
Never walk or work under raised equipment unless it is supported by a mechanical device. Equipment which
is supported only by a hydraulic device can drop and injure you if the hydraulic system fails or if the control
is operated (even with the engine stopped).
Make sure that no-one goes near the machine while you install or remove the mechanical device.
Raised Machine
Never position yourself or any part of your body under a raised machine which is not correctly supported. If the
machine moves unexpectedly you could become trapped and suffer serious injury or be killed.
Lightning
Lightning can kill you. Do not use the machine if there is lightning in your area.
Machine Modifications
This machine is manufactured in compliance with prevailing legislative requirements. It must not be altered in
any way which could affect or invalidate its compliance. For advice consult your JCB dealer.

Introduction
Safety
5 9831/3100-2 5
Clothing and Personal Protective Equipment (PPE)
Do not wear loose clothing or jewellery that can get caught on controls or moving parts. Wear protective clothing
and personal safety equipment issued or called for by the job conditions, local regulations or as specified by
your employer.

Notes:
6 9831/3100-2 6

About the Product
Introduction
7 9831/3100-2 7
About the Product
Introduction
General
Before you start using the machine, you must know how the machine operates. Use this part of the manual
to identify each control lever, switch, gauge, button and pedal. Do not guess, if there is anything you do not
understand, ask your JCB dealer.
Name and Address of the Manufacturer
JCB India Limited, 23/7 Mathura Road, Ballabhgarh, Haryana - 121004, India
Product Compliance
Your JCB product was designed to comply with the laws and regulations applicable at the time of its manufacture
for the market in which it was first sold. In many markets, laws and regulations exist that require the owner to
maintain the product at a level of compliance relevant to the product when first produced. Even in the absence
of defined requirements for the product owner, JCB recommend that the product compliance be maintained
to ensure safety of the operator and exposed persons and to ensure the correct environmental performance.
Your product must not be altered in any way which could affect or invalidate any of these requirements. For
advice consult your JCB dealer.
For its compliance as a new product, your JCB and some of its components may bear approval numbers
and marking's, and may have been supplied with a Declaration/Certificate of Conformity. These marking's and
documents are relevant only for the country/region in which the product was first sold to the extent that the
laws and regulations required them.
Re-sales and import/export of products across territories with different laws and regulations can cause new
requirements to become relevant for which the product was not originally designed or specified. In some cases,
pre owned products irrespective of their age are considered new for the purposes of compliance and may be
required to meet the latest requirements which could present an insurmountable barrier to their sale/use.
Despite the presence of any compliance related marking's on the product and components, you should not
assume that compliance in a new market will be possible. In many cases it is the person responsible for import
of a pre owned product into a market that becomes responsible for compliance and who is also considered
the manufacturer.
JCB may be unable to support any product compliance related enquiry for a product which has been moved out
of the legislative country/region where it was first sold, and in particular where a product specification change
or additional certification would have been required in order for the product to be in compliance.

About the Product
Description
8 9831/3100-2 8
Description
General
The Backhoe Loader is a self-propelled wheeled machine with a main frame designed to carry both front
mounted equipment and rear mounted backhoe equipment with stabilisers.
Intended Use
The machine is intended to be used in normal conditions for the applications and in the environmental conditions
as described in this manual. When used normally in the loader mode (shovel use), the machine loads through
forward motion. A loader work cycle normally comprises filling, elevating, transporting and discharge of material.
When used in the backhoe (excavator) mode, the machine is stationary and normally digs below ground level.
A backhoe work cycle normally comprises excavating digging, elevating, swinging and discharging material.
Applications include earthmoving, road construction, building and construction, landscaping and similar
applications.
The machine is not intended for use in mining and quarrying applications (other than for light yard clearing
operations), in demolition activities, forestry, any use underground, or in any kind of explosive atmosphere.
A backhoe loader can also be used for object or material handling/transportation if it is suitably equipped with
relevant parts, systems and attachments. Refer to: Lifting and Loading (Page 67).
If the machine is to be used in applications where there is a high silica concentration, risk due to materials
containing asbestos or similar hazards, additional protective measures such as the use of PPE (Personal
Protective Equipment) may be required.
The machine should not be operated by any person who does not have an appropriate level of qualification,
training or experience of use of this type of machine.
Prior to use of the machine, its suitability (size, performance, specification etc.) should be considered with
regards to the intended application and any relevant hazards that may exist. Contact your JCB dealer for
support in determining the appropriate JCB machine, attachment and any optional equipment that is suitable
for the application and environment.
Log Moving/Object Handling
Do not use the machine to move or handle logs unless sufficient log protection is installed. You could cause
serious injury to yourself and damage to the machine. For more information, contact your JCB dealer.
Optional Equipment and Attachments
A wide range of optional attachments are available to increase the versatility of your machine. Only the JCB
approved attachments are recommended for use with your machine. Contact your JCB dealer for the full list
of approved attachments available.
Danger Zone
The danger zone is any zone within and/or around the machinery in which a person is subject to a risk to their
health or safety. During operation of the machine, keep all persons out of the danger zone. Persons in the
danger zone could be injured.
Before you do a maintenance task, make the product safe. Refer to: Maintenance Positions (Page 119).

About the Product
Description
9 9831/3100-2 9
Main Component Locations
Figure 4.
E
F
G
H
J
A
B
C
D
ALoader arm BCanopy
CHydraulic oil tank DBattery Compartment
EBoom FFuel tank
GStabilisers HKingpost
JDipper
Your machine might have a cab instead of canopy which is optional.
