JCM Technologies HDOORPOSITION User manual

HDOORPOSITION
User Manual

Table of contents
Introduction 3
Configuration with cloudAssistant 4
Installation 5
Operational mode 6
Operation with two HDOORPOSITION sensors 6
Operation with one HDOORPOSITION sensor 7
Verification 9
LED behaviour 9
Technical data 10
Battery 10
Batteriesreplacement 10
Regulatory Data 10
UKCA Declaration of conformity 10
EU Declaration of conformity 10
jcmtechnologies
2

Introduction
HDOORPOSITION is a door position sensor via radio.
Check door status with cloudAssistant from anywhere, instantly, with no need for more wiresthanks to radio technology.
The HDOORPOSITION sensor activates when the magnet is close to it and sends a radio signal to HONOADOOR. Install the
magnet on the bottom of the door and the sensor at the same height on the wall to know when the door is completely closed.
Install another HDOORPOSITION sensor on the top toknow when the door is totallyopen.
Provided with different product sets, combining radio sensors (HDOORPOSITION) and magnetic
activators (MAGNET). Proper system installation may require more than one magnet or more than
one radio sensor. One single magnet can activate multiple sensors.
HDOORPOSITION MAGNET
Example installation with 2 HDOORPOSITION sensors and 1 MAGNET:
jcmtechnologies
3

Configuration with cloudAssistant
1. Enter cloudAssistant:https://cloudassistantv4.jcm-tech.com/login and login.
2. Enter the installation with the HONOADOOR device to which you wish to link the HDOORPOSITION sensor.
3. Go to the "Equipment" tab. Select the equipment where the HONOADOOR is. Complete the sensor fields. Save.
Three setting fields must be completed for each sensor:
•Radio sensor X name: this is a descriptive field for the sensor.
•Radio sensor X mode: these are the operational settings for the sensors, drop down the list of parameters and select your
desired option.
Settings options may be:
•Unused: default option, entry unused.
•[Door X] Opening limit switch sensor: set as open door position.
•[Door X] Closing limit switch sensor: set as closed door position.
•Radio sensor X key: activation key, input the activation key found on the label of the sensor box.
jcmtechnologies
4

4. Equipments -> Save configuration.
Every time an equipment parameter is modified, you must save con-
figuration.
Installation
The sensor comes with two batteries included inside the device. Remove the cover, remove the contact protector, check that
the LED STATUS lights up once every 15 seconds, close the cover, and mount on the wall.
Example installation with 2 HDOORPOSITION sensors and 1 MAGNET:
The sensors and magnets must be installed according to the distances and layout shown in the
image.
jcmtechnologies
5

Operational mode
The check door status, selection "Get door status" (button with the door).
Operation with two HDOORPOSITION sensors
DOORCLOSED
DOOR OPENED
jcmtechnologies
6

Operation with one HDOORPOSITION sensor
Closing limit switch sensor:
DOORCLOSED
DOORNOT CLOSED
jcmtechnologies
7

Opening limit switch sensor:
DOOR OPENED
DOOR NOT OPENED
The status does not update automatically. Press the "Refresh Status" button to
update the door status..
If the HONOADOOR device has been reset (example: due to a voltage drop), the door's status is
"Undefined." Make the door move and "Refresh status."
jcmtechnologies
8

Verification
Open the HDOORPOSITION sensor cover and press the "TEST"button to check the connection with HONOADOOR. The "ST",
"NW," and "IN"LEDs of HONOADOOR blink for 3 seconds. The next 25 times that the HDOORPOSTION isactivated, the
HONOADOOR LEDs will blink for 3 seconds.
LED behaviour
MAGNET: the LED lights up for 2 seconds every time the sensor detects and stops detecting the magnet.
STATUS: the LED blinks once every 15 seconds to indicate that the device is resting. The LED blinks twice every 15 seconds,
indicating a low battery.
jcmtechnologies
9

Technical data
Parameter Value
Operating frequencies 868,35MHz / E.r.p.<1mW
Power Supply 3Vdc (2x AAA 1,5V / 12mA)
Operating temperature -20ºC / + 55ºC
Battery duration 120,000 activations / 1 year
Battery
Batteries replacement
Proceed to replace the two batteries for newones, taking care of the polarity marked on the connector. Check that the new bat-
teriessupport the same range of temperature that the ones replaced. Do not mix new and old batteries.
Battery type: 2 x AAA1,5 V
Before throwing away the device, the batteries must be removed and deposited in a collection
point.
Regulatory Data
UKCA Declaration of conformity
The manufacturer JCM TECHNOLOGIES, S.A. declares that the product HDOORPOSITION complies with the relevant fun-
damental requirements of the Radio Equipment Regulations 2017 and of the RoHS Regulations 2012.
EU Declaration of conformity
The manufacturer JCM TECHNOLOGIES, S.A. declares that the product HDOORPOSITION complies with the relevant fun-
damental requirements of the RED Directive 2014/53/EU and of the RoHS Directive 2011/65/EU.
See website https://www.jcm-tech.com/declarations/
JCM TECHNOLOGIES, S.A.
C/ COSTA D'EN PARATGE, 6B
08500 VIC(BARCELONA)
SPAIN
jcmtechnologies
10
UM_3201865_HDOORPOSITION_EN_Rev02
