JEM AF-2 User manual

2
JEM Smoke Machine Training Program
INDEX
An Introduction To Smoke Technology:
Smoke Machine Markets3
Smoke Machine Principles 3
CE Marking 4
Searching for information on the NET 5
Which fluid can I use with my machine? 6
What can my machine do? 6
Specifications 7
Service of machines:
Tools and optional extras 8
Machine Overview 9
Opening The Machine 10
Inside The Machine 10
How To…
How To ChangeA Fan 11
How To Change APCB 13
Main PCB 13
DMX PCB 14
How To Change The Software 15
Spare Parts Lists:
Spare Parts 240V 16
Spare Parts 110V 16
Appendix:
Fuse Ratings 17
PCB Schematics 18

3
AN INTRODUCTION TO SMOKE TECHNOLOGY
Smoke Machine Markets
Jem /Martin smoke machines are categorised into 2 ranges: The Professional and the Club /DJ range.
If a product is branded as a “Martin” product this is aimed at the Club/DJ market.
All products branded as a “JEM” product are classed as Professional and are aimed at the higher end touring /
installation market.
All JEM /Martin Smoke products can be used across both of the different markets without any compromise of
performance or features.
Smoke machine principles:
All JEM /Martin conventional smoke machines utilise the same technology:
In Brief:
When the run button on the remote is pressed, smoke fluid is pumped from a removable container
situated within the machine via the flexible fluid pipe into an oscillating piston pump.
The fluid passes through the pump and enters the heat exchanger were the fluid is vaporised and
exits as thick, white smoke.
The heat exchanger is comprised of a heating element and a coil of copper or steel tubing between 3 and 6
metres in length. This is cast into a mass of aluminium.
The heat exchanger is heated via the heating element.
This is controlled by a J Type thermocouple fitted to the heat exchanger.
The temperature is determined by the calibration ofthe main control PCB.
Once the working temperature is reached, the main control PCB will allow the pump to be operated and the
machine will now be ready to run.
Haze machine principles:
The JEM ZR24/7 and Magnum Hazer work on the same smoke generation principles as the JEM /Martin
smoke machines.
The only difference is the smoke output on a hazer exits into a metal chamber where there is a fan creating a
fast moving air stream. This air stream disperses the smoke output and creates the haze.
Again the principles are identical to that of a conventional smoke machine.
There is a pump, heat exchange, PCBs and onboard controls. The major difference is the air chamber.
A radial fan is used with this system. It is used to allow the exiting smoke to have the maximum dispersal.
As with several of the smoke machines, the haze machine has a low fluid shut off system. This is an
electronic temperature control device that measures the temperature of the heat exchange over a short
period. If the temperature has not changed but the unit has been pumping; the unit will assume that the
system has run out of fluid and shut down. This prevents the system from running dry and burning out
the pump.

4
CE mark
All products that are produced by JEM / Martin carry the CE Certification.
These products meet the requirements of the following EC Standards and as such, comply with the EMC
(Electromagnetic Compatibility) and LVD (Low Voltage Directives),directives of the European Community:
EN 50 081-1 1992 Generic Emission Standard for domestic and light Industrial environments.
EN 50 082-1 1992 Generic Immunity Standard for domestic and light Industrial environments.
EN 60 335-1 1995 Safety of household and similar electrical appliances
These standards reference the following European standards:
Emissions:
EN 55 022 /B RF voltage and field strength
EN 60 555 Harmonic current content
EN 55 014 RF voltage (discontinuous)
Immunity:
IEC 801-2Electrostatic discharge to case
IEC 801-4Common mode fast transients
These standards also meet the requirements of CISPR 22.
JEM did not carry the CE mark on products that were produced prior to 1995.
These products can be identified by either the DIN/XLR socket on the rear or top of the unit or the Mains PCB:
If the unit has a 5 pin DIN or a 4 pin XLR without the CE text on the rear, the unit is classed as NON-CE.
If the PCB has a 12 pin Molex connector fitted to it, this is classed as a NON-CE unit.

5
Searching for information on the INTERNET
If you require information with regards to JEM /Martin Smoke, Haze and Heavy Fog products an ideal place to
start is the Internet.
Martin has a dedicated team of staff who are constantly monitoring and updating the information that is placed
onto the INTERNET. This is to ensure that the best possible service is being given to not just dealers and end
users but also to internal staff.
Locating information is simple:
First go to: www.jemsmoke.com
Here you will find information on all of our current range of products including news, bulletins,
specifications and even videos of machines in action.
To access support information:
On the left hand side of the screen there are several different categories.
Click on SUPPORT.
This will bring you to the SMOKE USER SUPPORT page.
If you have a LOGIN NAME AND PASSWORD then press the LOGIN icon at the top of the page and
enter your username and password into the relevant boxes.
(If you do not have a LOGIN NAME you can still use the site, just with limited access to information)
Select SMOKE from the menu on the left hand side.
Go to the PRODUCTS MENU and choose the PRODUCT you require information on.
Now go to the CATEGORY menu and select which piece of information you require (parts,manuals,etc)
Once you have done this press the SEARCH icon.
All of the information relevant to the product you have chosen will now be displayed.
A LOGIN is required for access to TECHNICIAN and DISTRIBUTOR SUPPORT areas.
Please direct all inquires regarding access to your national distributor.

6
Which fluid can I use with my machine?
X=NO
O=YES
Pro-Smoke
Studio
DX Mix
Pro-Smoke
Super
ZR Mix
Pro-Smoke
High-
density SP
Mix
I-Fog Reg. DJ
Fluid
Party Pack Pro Haze Heavy Fog
Fluid
B2 Mix
Heavy Fog
Fluid
C3 Mix
AF-1XXXXXXXXX
What can my machine do?
The AF-2is a compact but powerful fan designed with clubs, studios, theatres and touring applications in mind.
The AF-2features DMX input as standard and can be installed on a ceiling, in a truss or can be floor standing.
It can be used alone or as part of a complete fog system by linking with other Jem machines using DMX.
The fan unit incorporates a very high quality scaled fan motor to withstand high condensation levels associated
with close proximity to fog.
The AF-2 is constructed from mainly aluminium sheet for minimal weight, without compromising ruggedness.
If you want extra protection for the AF-2 the accessory Touring Frame is available. This at the same time acts
as a floor stand, and adds the ability to mount the remote control.
An analogue remote control is provided enabling variable output and timer control of fan speed allowing you to
adjust to every situation.

7
Specifications:
Physical
Width: 682 mm
Height: 707 mm
Depth: 318 mm
Dry weight: 17 kg
Performance
Maximum airflow: 6500 m3per hour
Fan speed: 0-1380 rpm
Control and Programming
Control options: Remote control (supplied) or on-board DMX
Remote control features: Instant or timer-controlled output, 0-100% adjustable output level
Timer Range: Delay 2-18 secs (X1), 16-144 secs (X8) / Run Time 2-18 secs (X1), 16-144 secs (X8)
DMX channels: 1
Protocol: USITT DMX512/1990
Construction
Housing: Steel & aluminium
Installation
Orientation: Any
Connections
Remote control: 3-pin locking XLR
DMX data: 3-pin and 5-pin XLR sockets
Power connection: 3-pin IEC
Electrical
AC power (EU models): 220-240 V nominal, 50 Hz
AC power (US models): 110-120 V nominal, 60 Hz
Main fuse (220-240 V power): 5 AT (slow blow)
Main fuse (110-120 V power): 6.3 AT (slow blow)
Typical Power and Current
US model
110 V, 60 Hz: 320 W, 2.9 A
115 V, 60 Hz: 350 W, 3.04 A
120 V, 60 Hz: 381 W, 3.18 A
EU model
220 V, 50 Hz: 206 W, 0.93 A
230 V, 50 Hz: 225 W, 0.98 A
240 V, 50 Hz: 245 W, 1.02 A
Measurements made at nominal voltage. Allow for a deviation of +/-10%.
Approvals
EU safety: EN 50 081-1, EN 50 082-1
EU safety: EN 60 335-1 (1995)
US safety: UL Std. 507
Accessories
AF-2 Touring Frame: P/N 92620006
Ordering Information
Jem AF-2 Fan, 110 V: P/N 92615400
Jem AF-2 Fan, 240 V: P/N 92615300

8
SERVICE OF MACHINES
TOOLS AND THINGS:
For successful servicing of a machine you will need some basic tools which are in good working order
and the right size for the job. Other tools /equipment are available for specific jobs but in most cases these are
not needed for general service.
Equipment needed:
Screwdrivers
Pozidrive, size 1 and 2
Flat tip, size small and medium
Wrenches
7mm
12mm x2
Pliers
Needle Nose, small
Wire Cutters, small
Digital Multi Meter (With ability to measure mV)
Additional Items / recommended:
Cable Ties (p/n 13104000)
Silicone Sealant
JEM Calibration Box (p/n 92620005)
Paper towels (or other absorbent material)
Ammeter (For measuring current draw of machine –could be handheld or bench mounted)
Epsilon 5 Portable ISP Programmer (p/n 50502004)
Common Sense!!
WARNING –MAINS VOLTAGE
DISCONNECT FROM MAINS SUPPLY
BEFORE REMOVING COVERS
AND SERVICING THIS MACHINE
PROCEED WITH EXTREME CAUTION

9
AF-2MACHINE OVERVIEW
The Outside:
3
PIN DMX
REMOTE INPUT
SOCKET
MAINS INPUT
5
PIN DMX

10
Opening The Machine:
1. Move the FAN to a flat position.
2. Remove the 10 screws from the BOTTOM PANEL of the machine and store safely.
3. Lift off the ACCESS PANEL and disconnect the EARTH LOOM.
The Inside:
DMX PCB
(BEHIND PANEL)
EARTH POINT
FAN OUTPUT
MAINS INPUT
CAPACITOR

11
HOW TO….
REFER TO SCHEMATICS / DIAGRAMS IN THE APPENDIX FOR MORE DETAILS
How To Change A Fan:
1. DISCONNECT FROM MAINS SUPPLY.
2. Move to a flat position and remove BOTTOM COVER.
3. Disconnect the EARTH LOOM and remove the COVER.
4. Remove the FAN EARTH LOOM from the EARTH POINT (THIN GREEN/YELLOW).
5. Remove the BLACK WIRE from the terminal block.
6. Remove the BROWN WIRE from the terminal block.
7. Remove the PURPLE WIRE from the terminal block.
8. Remove the BLACK WIRE from its CRIMP.
9. Remove the BROWN WIRE from its CRIMP.
10. Remove the loom from the clip holding the loom to the chassis.
PURPLE
BLACK
BROWN

12
11. Undo and remove the 4 bolts and washers that hold the fan to the chassis. (OBSERVE ORDER
OF WASHERS)
12. Withdraw the fan from the chassis pulling the LOOM and GROMMET through the hole at the
same time.
13. Remove the FAN from the chassis and place on your workbench.
Refitting Your New Fan:
1. Feed the wires through the hole in the chassis.
2. Secure the FAN using the 4 bolts and washers ensuring not to cross thread the inserts.
3. Reconnect the EARTH LOOM to the EARTH POINT.
4. Reconnect the BLACK,BROWN AND PURPLE WIRES to their relevant place in the terminal
block. (RECRIMP IF NECESSARY)
5. Replace the BOTTOM COVER ENSURING TO RECONNECT THE EARTH LOOM
6. APPLY POWER TO THE MACHINE AND TEST THE FAN OPERATION.
BOLT
GROMMET
PURPLE
BLACK
BROWN

13
How To Change A PCB:
REFER TO SCHEMATICS / DIAGRAMS IN THE APPENDIX FOR MORE DETAILS
Main PCB
1. DISCONNECT FROM MAINS SUPPLY.
2. Move to a flat position and remove BOTTOM COVER.
3. Remove the 2 screws that hold the PCB to the chassis.
4. Disconnect the MAIN PCB WIRING LOOMSfrom the MAIN PCB (Note orientation before
removal).
5. The MAIN PCB is mounted on 2mounting postswhich need to be squeezed to remove the
PCB.
6. Remove the PCB.
Refitting:
7. Mount the PCB on the mounting posts
8. Replace the 2 screws that hold the PCB to the CHASSIS.
9. Reconnect the MAIN PCB WIRING LOOMS(Observe polarity).
10. Check the operation of the unit.
11. Refit the TOP COVER.

14
DMX PCB
1. DISCONNECT FROM MAINS SUPPLY.
2. Move to a flat position and remove BOTTOM COVER.
3. Remove the 4 screws that hold the MOUNTING PLATE to the chassis.
4. Move the MOUNTING PLATE to oneside and gain access to the rear of the plate.
5. Remove the screws holding the DMX PCB to the MOUNTING PLATE.(THROUGH XLR
SOCKETS)
6. Disconnect the wiring looms. (OBSERVE POLARITY).
7. Remove the PCB.

15
Refitting:
8. Fit new DMX PCB to the MOUNTING PLATE using the screws through the XLR sockets.
9. Ensure that the RED LED lines up with the hole in the chassis.
10. Reconnect the DMX PCB WIRING LOOMS(Observe polarity).
11. Check the operation of the unit and adjust if necessary.
12. Refit the
13. Refit the TOP COVER.
How To Upgrade The Software:
1. Using the SOFTWARE provided with the EPSILON 5 PROGRAMMER upload the latest
SOFTWARE VERSION (which is available for free from our WEBSITE) onto the EPSILON 5
PROGRAMMER.
2. Disconnect the PROGRAMMER from your PC.
3. Remove the BOTTOM COVER of the machine.
4. Plug the 6WAY HEADER into the AVR PORT on the MAIN PCB of the machine.
5. Apply power to the machine.
6. Check that the ‘POWER’ LED on the PROGRAMMER comes on.
7. On the PROGRAMMER, press the ‘NO’ button once to clear the fail indicator.
8. Press the 'YES' button.
9. Wait for the 'BUSY' LED to go out.
10. When the PROGRAMMER shows 'PASS', press 'NO', and then disconnect the machine
from power.
11. Unplug the PROGRAMMER.
12. Apply power to the machine and check the operation of the machine.

16
SPARE PARTS LISTS
240V
Part Description Spare Part Number Comments
PCB MAIN 62020079 MAIN CONTROL PCB -TESTED
PCB DMX INTERFACE 62021035 PROGRAMMED AND TESTED
PCB XLR INTERFACE 62021021 5 PIN XLR MALE / FEMALE BOARD
PCB REMOTE 62020508 TESTED w/o BUTTON TOPS OR
KNOBS
CASEWORK TOP PANEL 26566670 TOP PANEL -BARE
CASEWORK BOTTOM PANEL 26566680 BOTTOM PANEL -BARE
CASEWORK FRONT SPINNING 26566590 FRONT CHASSIS RING
CASEWORK REAR SPINNING 26566600 REAR CHASSIS RING
CASEWORK FRONT GRILL DISC 26566740 FRONT GRILL DISC
CASEWORK MAIN CHASSIS 26566650 MAIN CHASSIS -BARE
CASEWORK HANGING PLATE 26566690 HANGING PLATE
CASEWORK HANGING BRACKET 26562551 HANGING BRACKET
OTHER REMOTE CONTROL 92765013 COMPLETE REMOTE CONTROL
OTHER MAINS SOCKET 05247205 MAINS SOCKET (IEC) c/w FUSE HOLDER
OTHER FAN 05731211 240V FAN AC AXIAL
OTHER FAN GUARD 05749022 FAN GUARD (FAN MOUNT)
OTHER CAPACITOR 04030070 8uF CAPACITOR -CHASSIS
MOUNT
OTHER HAND WHEEL 08132309 HANDWHEEL M8
OTHER WIRING LOOMS COMPLETE ALL WIRING LOOMS FOR MACHINE
OTHER STICKERS COMPLETE ALL STICKERS / LABELS FOR MACHINE
110V
Part Description Spare Part Number Comments
PCB MAIN 62020078 MAIN CONTROL PCB -TESTED
PCB DMX INTERFACE 62021035 PROGRAMMED AND TESTED
PCB XLR INTERFACE 62021021 5 PIN XLR MALE / FEMALE BOARD
PCB REMOTE 62020508 TESTED w/o BUTTON TOPS OR
KNOBS
CASEWORK TOP PANEL 26566670 TOP PANEL -BARE
CASEWORK BOTTOM PANEL 26566680 BOTTOM PANEL -BARE
CASEWORK FRONT SPINNING 26566590 FRONT CHASSIS RING
CASEWORK REAR SPINNING 26566600 REAR CHASSIS RING
CASEWORK FRONT GRILL DISC 26566740 FRONT GRILL DISC
CASEWORK MAIN CHASSIS 26566650 MAIN CHASSIS -BARE
CASEWORK HANGING PLATE 26566690 HANGING PLATE
CASEWORK HANGING BRACKET 26562551 HANGING BRACKET
OTHER REMOTE CONTROL 92765013 COMPLETE REMOTE CONTROL
OTHER MAINS SOCKET 05247205 MAINS SOCKET (IEC) c/w FUSE
HOLDER

17
OTHER FAN 05731212 110V FAN AC AXIAL
OTHER FAN GUARD 05749022 FAN GUARD (FAN MOUNT)
OTHER CAPACITOR 04030069 25uF CAPACITOR -CHASSIS
MOUNT
OTHER HAND WHEEL 08132309 HANDWHEEL M8
OTHER WIRING LOOMS COMPLETE ALL WIRING LOOMS FOR
MACHINE
OTHER STICKERS COMPLETE ALL STICKERS / LABELS FOR MACHINE
APPENDIX
Fuse Ratings
Fuse 240V 110V
Internal 5A6.3A
External 5A6.3A

1
2
3
LN
FAN OUTPUT MAINS I/P
NL
FS 1
TX 1
PL 1
PL 2
PL 4
PL 3
JP 1
JP 4
JP 3
JP 2
PL 3
PL 1
SW 1
DMX RECIEVER PCB (3 PIN XLR) PCB 5 PIN XLR REMOTE CONTROL I/P
FAN : 240V @
110V @
MAIN CONTROL PCB
GREEN
BLUE
BROWN
BLACK
BLUE
BROWN
CAPACITOR: 8.0uF@240V
GREEN
BROWN
1
3
31
1
3
1
31
31
3
COMPANY
PROJECT AF 2 WIRING DIAGRAM
MARTIN MANUFACTURING UK PLC
DRAWN J RAMONES REV/DATE A. 7-JUNE-2005
IEC CKETSO IEC FUSE:
LIVE
NEUTRAL
EARTH
5.0A @ 230V
6.3A @ 110v
BLACK
BLUE
BROWN
25uF@110V
FS 1:5A@230V
6.3A@110V

339mm
[13.35"]
Martin
Product
Description
Item No.
Sign.
Material
Date
Rev. Date Sign.
Scale
AF-2 Touring Frame
15/06/05
General Dimensions
-
-xx/xx-05
-B
M.D.
-
-C - xx/xx-05 -
Material Item No.
-
A4
1:8
Measurement without tolerance -DS2768 M
FIRST ANGLE PROJECTION 92620006
Remote Control
Docking Point
772mm
[30.38"]
745mm
[29.33"]
