DOOR AND PANEL PARTS
1
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
3−09 Litho In U.S.A. (cre) (eeb) Part No. W10267596 Rev. A
UNDERCOUNTER
DISHWASHER
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10158012 Instructions,
Installation
W10260101 Energy Guide
W10157785 Guide, Use & Care
2 99002693 Insulation, Door
3 99003048 Barrier, Foam
4 Block, Foam
99003046 Left
99003047 Right
5 99003049 Wrap, Foam
6 Bracket, Hinge
W10118638 Left
W10118637 Right
7 99001075 Screw
8 99003094 Support, Inner
Door
9 99003095 Anchor, Panel
Fastener
10 99003093 Pad, Foam
11 Panel, Front
99003090 Black
99003092 White
W10166535 Stainless
12 Screw
912366 Black
99001194 White
13
W10167659 Plate, Handle
Black
14
W10191101 Handle, Door
15 6−920587 Insulation, Toe
Panel
16 Damper, Toe Panel
99002694 Black
99002698 White
17 Panel, Toe
(Includes Item 16)
99002765 Black
99002766 White
18 Support, Front
99002859 Black
99002860 White
19 6918667 Stud, Handle
20 99003154 Screw

CONTROL PANEL PARTS
2
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99002575 Housing, Board
(Top)
2
W10218836 Board, Control
3 99002576 Housing, Board
4
W10161783 Panel, Control
5 99002751 Switch, Door
6 99003347 Latch, Assembly
7 99003096 Fastener, Panel

DOOR AND LATCH PARTS
3
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10237912 Harness, Wiring
2 99003045 Seal, Door
(Bottom)
3 99003060 Cap, Rinse Aid
4 99003320 Dispenser, Rinse
Aid
5 Y912620 Screw, Door
6
W10120976 Inner Door
W/ Damper
7 99002465 Bracket, Dispenser
8 912615 Screw
9 99003044 Insulation, Door

LOWER WASHARM PARTS
4
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99003083 Cap, Wash Arm
2 99003144 Wash Arm, Lower
(Includes Item 3)
3
W10218606 Shield, Radiant

HEATER PARTS
5
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99002971 Heater Element
Assembly
W/ Gasket
2 99003033 Nut, Heater
3 99003032 Bracket, Heater
Support
NOTE:
If heater element is
removed, it must be replaced.

FILL AND OVERFILL PARTS
6
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99002852 Hose, Inlet
2 911856 Clamp, Spring
3 99002975 Valve, Water
4
W10205539 Switch, Float
5 99002652 Hose, Drain
6
W10130099 Float
7 99003028 Inlet, Air/Water
8 99003037 Standpipe, Float
9 99003040 Seal, Standpipe
10
W10130109 Adapter, Float

TUB AND FRAME PARTS
7
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596

TUB AND FRAME PARTS
8
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10119337 Strike, Door
2 99002648 Bracket, Cabinet
Mounting
3 6−912799 Screwr
4 99002610 Bracket, Spring
Adjustment
5 99002636 Bracket, Support
6 Trim, Corner Edge
99003039 Right
99003038 Left
7 99003688 Nut
8
W10173920 Bracket, Cable
9 99002608 Roller, Cable
Bracket
10 99003687 Bolt, Shoulder
11 99003118 Spring, Door
12 99003446 Door Cable Assy.
13 Gap Seal,
Toe Kick
99002701 Black
99002703 White
14 99002849 Insulation, Tub
15 99003337 Seal, Door
16
W10142298 Tub Assembly
(Not Serviced)
17 99003041 Trim, Tub Edge
(Bottom)
18
W10167660 Bracket, Support
(Rear)
19 99002633 Thermostat,
Limiting
20
W10167658 Clip, Thermostat
21 99002692 Screw, Trim
Mounting
22 99002637 Bracket, Junction
Box
23
W10143258 Leg, Leveling
24
W10164700 Strip,Trim Left
25 99002638 Cover, Junction
Box
26
W10164702 Strip,Trim Top
27
W10164701 Strip,Trim Right
28 Support, Hinge
W10117484 Right
W10117485 Left
29 Backer, Hinge
W10174581 Right
W10174569 Left
30 99003155 Screw
31 99002150 Seal, Air/Water
Inlet
32 6−918397 Grill, Air/Water
Inlet
33
W10167916 Clamp, Rear
Support

PUMP AND MOTOR PARTS
9
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596

PUMP AND MOTOR PARTS
10
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99002666 Screw
2
W10166790 Guard, Filter
3 99002668 Screw
4
W10212444 Discharge, Housing
Assembly
5 99002659 Wash Impeller
Assembly
6
W10192800 Filter/Flowplate,
Assembly
7 99003055 Gasket, Motor
Mount
8 99003056 Lever, Motor Mount
9 99003057 Plunger, Motor
Mount
10 99002651 O−Ring, Turbidity
Sensor
11
W10120019 Sensor, Turbidity
12 99003697 Pivot, Wash Arm
13 99002664 Screw
14 99003427 Chopper
15
W10118627 Wash Motor Assy.
16 99003309 Flapper, Drain
Pump Inlet
17 99002857 O−Ring, Drain Pump
18 99002740 Screw
19
W10200518 Drain Pump Assy.
20
W10167912 Sheild, Capacitor
21 99002665 Capacitor
22 99002601 Screw

UPPER AND LOWER RACK PARTS
11
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596

UPPER AND LOWER RACK PARTS
12
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 W10214026 Dishrack, Upper
2
W10144736 Rail, Inner Slide
3 99003148 Wheel Assembly
4 99003252 Shelf, Cup
5
W10141603 Cover, Silverware
Basket
6
W10169391 Stop, Rail
7 99003070 Wash Arm
8 99003142 Wash Manifold
Assembly
9 99003071 Clip, Upper Wash
Manifold (Back)
10 99003072 Clip, Upper Wash
Manifold (Front)
11
W10203870 Dishrack, Lower
12 6−918869 Wheel Assembly
(Lower)
13
W10171736 Basket, Silverware
14 99003069 Cage, Ball Bearing
15 99003068 Bearing, Ball

UPPER WASH AND RINSE PARTS
13
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
1 99003081 Feed Tube
Assembly
2 99002643 Bracket
3 99002753 Retainer, Top
Wash Arm
4 99003143 Station, Docking
(with Flapper)
5 99002911 Wash Arm, Top
(with Retainer)

OPTIONAL PARTS (NOT INCLUDED)
14
For Models: JDB1095AWB1, JDB1095AWW1,JDB1095AWS1
(Black) (White) (Stainless)
W10267596
Illus. Part
No. No. DESCRIPTION
INSTALLATION KIT
8212488RC Kit, Installation
(Includes Power
Cord, 6 Ft. Fill
Hose and Necessary
Hardware for
Installation)
4396897RP Kit, Installation
(Includes 6 Ft.
Fill Hose and
Necessary Hardware
for Installation)
Moisture Barrier Kit
4396277 Kit
Drain Hose
8212486 12 Ft.
4396897RW 6 Ft.
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392899 Biscuit
