Jenn-Air JS42NXFXDW00 User manual

1
CABINET PARTS
For Model: JS42NXFXDW00
(Base Model)
3−09 Litho In U.S.A. (jdc) (eeb) Part No. W10249719 Rev. A
42" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10231366 Use & Care Guide
W10246792 Energy Guide
W10234135 Service & Wiring
Sheet
W10234151 Icemaker and
Ingredient Care
Center
Service Sheet
W10234149 Main Control
Service Sheet
W10231368 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2318189 Tray, Drip Filter
4
W10138054 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
W10138423 Refrigerator Side
W10138425 Freezer Side
6 Cap, Water Filter
2260518B Black
7 2307640 Mounting Stud,
Grille
8 Support, Grille
W10188499 Left
W10188500 Right
9
W10121451 Nutsert, Support
10 2260526 Housing, Water
Filter
12 4396841 Filter, Water
13 489399 Screw
14
W10234202 Pin−Stop, Door
15 Hinge (Top)
W10167397 RC
W10167398 FC
16
W10223655 Bracket, Mount
(Water Filter)
17 489464 Screw
18 486194 Screw
19
W10129069 Wire Clip (5)
20 Hinge (Bottom)
W10182692 RC
W10182693 FC
21 8533913 Screw 1/4−20 x 5/8
22
W10188549 Skirt−Grille,
Bottom
23
W10182717 Grille Bottom,
Front
24 1157158 Screw
25 2006617 Bracket, Support
Base (Rear) (2)
26 1163283 Screw
27 8281163 Screw
28 2260503B Button, Filter
29 C3680314 Switch, Rocker Arm
30 Cover, Switch
W10167387 Left
W10167341 Right
31 487415 Screw (2)
32 2215612 Cover, Rear

3
CABINET TRIM PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10207387 Cabinet, Trim
(Side)
2 1163283 Screw
3
W10188505 Cabinet, Trim
(Bottom)
4 486194 Screw
5
W10138451 Cabinet, Trim Top
6
W10121451 Nutsert (4)
7 2005925 Seal−Trim, Side
8 489464 Screw

4
FREEZER SHELF PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10175905 Wire, Shelf (2)
2
W10213534 Cover, Shelf
3 2302883 Shelf, Fixed (2)
4 2259084 Basket (2)
5 2256269 Front, Basket (2)
6 Slide, Basket
2259317 Right Side
2259318 Left Side
7 8533928 Screw
8 2266934 Door, Ice
9 2266930 Bucket, Ice
10 2266955 Spacer
11
W10188511 Spacer, Ice Bucket
12
W10188539 Spacer, Basket
13 2266924 Bucket, Ice−Front

5
REFRIGERATOR LINER PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719

6
REFRIGERATOR LINER PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2317844 Thermistor Assy
3 2208970 Air Duct
4
W10171433 Diffuser, Assy
Crisper (Upper)
5
W10213536 Ladder, Shelf (2)
6 2259445 Screw Support,
Ladder (8)
7 2006475 Screw
8 487539 Screw
9 2171846 Release Valve
10 486194 Screw
11 2003577 Guard, Return Air
12 2221296 Air Baffle
Assembly
13
W10203322 Diffuser Assembly
14 2317105 Cover, Thermistor
15 2188820 Thermistor
16
W10170104 Cover, Diffuser
17
W10171428 Cover,
Air Diffuser

7
CONTROL PANEL PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10189716 Control Box Assy
2
W10209498 Wire, Jumper
3 2307592 Bracket,
Control Box
4 2307595 Shield, Light
5 487539 Screw
6 2317000 Clip, Control Box
7 2223857 Socket, Light
8 2326255 Light Bulb

TOP GRILLE AND UNIT COVER PARTS
8
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10188580 Cover, Unit
2 486194 Screw
3 2256466 Back Panel
4
W10188585 Cover, Unit Front
5 487415 Screw
6
W10209510 Wire Assembly
RC/FC Light Switch
7 549193 Clamp

REFRIGERATOR SHELF PARTS
9
For Model: JS42NXFXDW00
(Base Model)
W10249719

REFRIGERATOR SHELF PARTS
10
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10187535 Shelf Assy (4)
2 8281160 Screw
3
W10137286 Cover Assy,
Crisper (Upper)
4
W10217204 Cover Assy,
Meat Pan
5
W10189066 Cover Assy,
Crisper (Lower)
6
W10188939 Meat Pan Assy
7 Slide, Meat Pan
2302954 Left Side
2302955 Right Side
8 2256366 Front, Meat Pan
9
W10187549 Sidearm−Shelf (8)
10
W10137277 Spacer, Crisper
11 Slide, Crisper
2302957 Right Side (2)
2302956 Left Side (2)
12
W10217428 Spacer, Pan
13 8533929 Screw
14
W10188942 Pan Assembly
Crisper (2)
15 2256248 Front, Crisper Pan

11
FREEZER LINER AND AIR FLOW PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719

12
FREEZER LINER AND AIR FLOW PARTS
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 2259385 Fan Motor
2 2169142 Fan Blade
3 2223733 Retainer,
Fan Motor
4
W10203260 Gasket, Cover
5 2223986 Grommet
6 486194 Screw
7 488500 Screw, Ground
8 2223857 Socket, Light (2)
9 488937 Clamp, Nylon
10 2326255 Light Bulb
11
W10170114 Scroll, Fan
12 2266801 Deflector, Air
13
W10170084 Air Duct
14
W10170112 Cover, Fan Scroll
15 Liner (Not A
Serviceable Part)
16
W10170101 Cover, Air Outlet
17 2307751 Light Shield
18
W10140154 Cover, Evaporator
19 8281163 Screw
20 2266801 Deflector, Air
Duct
21 1112260 Support,
Evaporator
22 2196483 Shelf, Stud (20)
23 8281158 Screw
24 Evaporator,
Cover Rail
W10135766 Left Side
W10141474 Right Side
25
W10183531 Gasket (2)
Evaporator Cover
26
W10139189 Harness, Evap Fan
(Includes Item 42)
27 2220241 Insulation (4)
28 2188820 Thermistor
29 2317105 Cover, Thermistor
30 2006475 Screw
31
W10175171 Ladder, Shelf
32 2259445 Support, Screw
33
W10160570 Defrost, Bi−Metal
34 486194 Screw
The following service assemblies are
only available for a limited time after
initial production. If the assembly is
not available, the components will be
available for the stocking policy.
101 W10203262 Scroll Assy, Fan

REFRIGERATOR DOOR PARTS
13
For Model: JS42NXFXDW00
(Base Model)
W10249719

REFRIGERATOR DOOR PARTS
14
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10167382 Refrigerator Door
(Includes #9)
2
W10234206 Pin−Door,
Bottom
3
W10199873 Cover−Door, Top
4
W10234194 Pin−Door, Top
5 2252293 Insert, Door Arm
W10197748 Top
W10197766 Bottom
6 2222796 Rail, Lid
7 2222982 Gasket, Utility
Bin
8 2222811 Door Gasket,
Magnetic
9
W10209363 Trim, Side
10
W10167367 Trim−Door
(Handle Side)
11 Screw, 8−15 x .500
8281251 Stainless Steel
12
W10182683 Trim−Door, Top
13
W10182685 Trim−Door
(Hinge Side)
14
W10182690 Trim−Door, Btm
15 End Cap
2222919 Right Side
2222920 Left Side
16 2222922 Bin, Utility
Center
17 2257616 Door, Utility Bin
18 2222773 Bin, Door (3)
19 2222770 Bin, Door

FREEZER DOOR PARTS
15
For Model: JS42NXFXDW00
(Base Model)
W10249719

FREEZER DOOR PARTS
16
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 W10167378 Freezer Door
(Includes #14)
2
W10199886 Cover−Door, Top
3
W10234206 Pin−Door, Bottom
4
W10234194 Pin−Door, Top
5 2222814 Door Gasket,
Magnetic
6
W10182700 Trim−Door,
(Handle Side)
7 Screw
8281251 Stainless Steel
8
W10182705 Trim−Door, Top
9
W10182709 Trim−Door, Btm
10
W10182685 Trim−Door,
(Hinge Side)
11
W10209363 Trim, Side
12 2314003S Insert−Door, Arm
W10197748 Top
W10197766 Bottom
13 2222776 Bin, Door (6)

UPPER UNIT PARTS
17
For Model: JS42NXFXDW00
(Base Model)
W10249719

UPPER UNIT PARTS
18
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10133449 Inverter Box
2 489373 Screw, Compressor
Mounting (4)
3
W10173296 Compressor
(Includes Items
6 & 9)(Also Order
876765 Tube Kit)
4
W10200659 Control−Elek, I/O
5
W10136614 Bracket, Fan Motor
6 1100826 Grommet, Mounting
7 2309002 Support, Condenser
(Right)
8
W10209446 Bracket, Switch
9 2215676 Terminal Cover
10 2309001 Support, Condenser
(Left)
11
W10120824 Control−Elek,
Power Supply
12 2203075 Spacer (5)
13 2256328 Bracket, Inverter
Box
14 2317031 Bracket, Vibration
Condenser
15 1157158 Screw
16 2307998 Condenser
17 2309431 Grommet (4)
18 2317030 Arm, Vibration
Condenser
19 488649 Screw
20 2155774 Wire Tie
21
W10175593 Drier
22 2310207 Wire Assembly
(Condenser Fan)
23 2188875 Motor, Fan
24
W10139483 Blade, Fan
25 2003169 Orifice, Fan
26 2307566 Tube, Drier
Transition
27 8533993 Screw
28
W10234131 Tube, Heat Loop
Transition
29 2309432 Gasket, Condenser
30
W10184634 Control−Elek,
Controls
31 2194319 Process, Tube
32 2309000 Cover, Condenser
33 2310196 Service Cord
34 486194 Screw
35 2266802 Switch, Power
Disconnect
36 487294 Screw, Ground
37 549193 Clamp, Cord
38
W10209460 Wiring Harness, DC
39
W10209462 Wiring Harness, AC
The following service assemblies are
only available for a limited time after
initial production. If the assembly is
not available, the components will be
available for the stocking policy.
101 W10193384 Unit Assy,
Controls
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
7.50 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
19
For Model: JS42NXFXDW00
(Base Model)
W10249719

LOWER UNIT AND TUBE PARTS
20
For Model: JS42NXFXDW00
(Base Model)
W10249719
Illus. Part
No. No. DESCRIPTION
1 486194 Screw
2
W10157752 Bracket, Heater
3 2309076 Suction Tube
4 2309070 Tube, Connect
(Drier/Restrictor)
5
W10196999 Drain Pan Assembly
6
W10153595 Cover, Box
7
W10151288 Cover, Wiring
8
W10121371 Tube, Discharge
9
W10205101 Evaporator
10
W10140161 Heater, Defrost
11 1113048 Clamp, Heater (2)
12
W10139908 Cover Seal,
Evaporator Tubes
13 2220832 Gasket, Evaporator
14 4389107 Wire Tie
15
W10169509 Clip, Heat
Exchanger
16 2320554 Support, Drain Pan
17
W10160981 Bracket Assembly,
Air Return
