Jenn-Air JUBFL242HL User manual



UNDER COUNTER BEVERAGE CENTER
’’
’
RÉFRIGÉRATEUR POUR BOISSONS SOUS COMPTOIR
For questions about features, operation/performance, parts, accessories, or service, call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-JENNAIR (1-800-536-6247), or visit our website at www.jennair.ca.
Pour des questions à propos des caractéristiques, du fonctionnement/rendement, des pièces, accessoires ou service,
composer le 1800JENNAIR (1800536-6247) ou visiter notre site Web au www.jennair.com.
Au Canada, composer le 1800JENNAIR (1800536-6247) ou visiter notre site Web au www.jennair.ca.
W11325206C

2
TABLE OF CONTENTS
INTRODUCTION
Safety....................................................................................................................3
Proper Disposal of Your Old Beverage center..........................4
Features..............................................................................................................4
INSTALLATION REQUIREMENTS
Tools and Parts...............................................................................................5
Location Requirements...........................................................................5
Product Dimensions..................................................................................6
Custom Overlay Panel ..............................................................................6
Handle (Optional).........................................................................................7
Electrical Requirements..........................................................................8
INSTALLATION INSTRUCTIONS
Unpack the Beverage center...............................................................8
Custom Overlay Panel Installation...................................................9
Installation and Door Closing..............................................................10
USING BEVERAGE CENTER
Controls...............................................................................................................11
Normal Sounds..............................................................................................12
Stocking the Beverage center ............................................................13
Wine Racks.......................................................................................................13
Beverage Center Shelves........................................................................13
CARE AND CLEANING
Cleaning .............................................................................................................14
Removing Base Grille................................................................................14
Vacation Care..................................................................................................14
Moving Care.....................................................................................................14
TROUBLESHOOTING
Operation...........................................................................................................15
Temperature and Moisture ...................................................................15
Door.......................................................................................................................15
ASSISTANCE
IN the U.S.A. .....................................................................................................16
IN Canada..........................................................................................................16
Warranty.............................................................................................................17
TABLE DES MATIÈRES
INTRODUCTION
Sécurité...............................................................................................................19
Mise au rebut de votre vieux réfrigérateur pour boissons....20
Caractéristiques ............................................................................................20
EXIGENCES D’INSTALLATION
Outils et Pièces ..............................................................................................21
Exigences d’emplacement....................................................................21
Dimensions du produit............................................................................22
Panneau Décoratif Personnalisé.......................................................22
Poignées (Facultatif)..................................................................................23
Spécifications électriques......................................................................23
INSTRUCTIONS D’INSTALLATION
Déballage du réfrigérateur pour boissons.................................24
Installation du Panneau Personnalisé...........................................24
Installation et fermeture de laporte...............................................25
UTILISATION DU RÉFRIGÉRATEUR
POUR BOISSONS
Commandes....................................................................................................26
Sons normaux ................................................................................................26
Stockage dans le réfrigérateur pour boissons.........................28
Porte-bouteilles.............................................................................................28
Tablettes du réfrigérateur pour boissons....................................29
ENTRETIEN ET NETTOYAGE
Nettoyage..........................................................................................................29
Enlever la grille de la base......................................................................30
Entretien avant les vacances ...............................................................30
Précautions à prendre avant undéménagement................30
DÉPANNAGE
Utilisation...........................................................................................................31
Température et humidité.......................................................................31
Porte......................................................................................................................31
ASSISTANCE
Aux É.-U...............................................................................................................32
Au Canada.........................................................................................................32
Garantie ..............................................................................................................33

3
INTRODUCTION
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your beverage center, follow these basic
precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3 prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all parts and panels before operating.
■Remove doors from your old beverage center.
■Use non flammable cleaner.
■Do not store or use petrol, flammable liquids or gas in the
vicinity of this or other electrical appliances. The fumes can
cause fires or explosions.
■Do not store explosive substances such as aerosol cans with
a flammable propellant in this beverage center.
■Do not use or place electrical devices inside the beverage
center compartments if they are not of the type expressly
authorized by the manufacture.
■Use two or more people to move and install beverage center.
■This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
■Children should be supervised to ensure that they do not
play with the appliance.
■To avoid the risk of children becoming trapped and
suffocating, do not allow them to play or hide inside the
beverage center.
■If the power supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly qualified
person.
■Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
■Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
the manufacturer.
■Do not damage the refrigerant circuit.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING

4
PROPER DISPOSAL OF YOUR
OLD BEVERAGE CENTER
IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned beverage
centers are still dangerous – even if they will sit for “just
a few days.” If you are getting rid of your old beverage
center, please follow these instructions to help prevent
accidents.
Before You Throw Away Your Old Beverage center:
Take off the door.
Leave the racks in place so that children may not
easily climb inside.
FEATURES
1. Stealth Flush Design with
Smooth Close Door
Create an unbroken silhouette. Discreet 1/8" reveals
envelop every side, without exposed hinges or trim
pieces. Quiet, soft, secure. An articulating hinge
discreetly ushers the door open and gently pulls it
closed.
2. Daring Obsidian Interior
Inspired by volcanic glass, this dark finish erupts
with reflective, high-contrast style. Let the object of
your desire emerge like vibrant art, begging to be
consumed.
3. Glass Shelves
Gaze through platforms of glass wrapped in
unyielding shelf frames.
4. UV-Resistant Thermal Glass
Let your tongue meet tannins. Double-paned
glass helps filter out ultraviolet light and rejects
temperature swings to sustain the body and finish
you covet.
5. LED Lighting
LED lights instinctively come alive, chasing away
shadows to reveal vivid details.
6. Independent Temperature Zones
Compose ideal climates for choice beverages and
tempting bites. Two temperature zones and six
curated presets await your command.
7. Smooth Close Racks
Smooth moves. Each beechwood rack opens and
closes fluidly and quietly, even when fully loaded.
8. 13 Bottle Capacity
Take your fill. Relish the spine-tingling flavors of wines
at your leisure.
9. NOIR™ Design Expression
Lose yourself in a world that’s yours alone. Crisp
silhouettes crackle with mystique; beguiling
reflections flow in and out of sight. Taut with
ceaseless allure and minimalist appeal, the NOIR™
design expression rejects dated ideals of beauty.
10. RISE™ Design Expression
Embrace an era of striking proportions. A stainless
steel suit of armor gleams with spectacular light. This
is strength—inextricable from beauty. Forged in the
fires of progress, the RISE™ design expression towers
over stagnant, uninspired designs that have inherited
undeserved standing.
11. Custom Overlay Design
Break free with custom panels that allow
unapologetic expression. Custom panels and handles
must be purchased separately.
12. Auto Light Option
Features a proximity sensor in the base grille that
automatically ramps on the LED interior display
lighting when motion is detected.
WARNING
Suffocation Hazard
Remove doors from your old beverage center.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.
1.
2.
4.
5.
6.
7.
8.
9,10,11.
14.
13.
12.
3.

5
13. Hushed Acoustics
Our internal compressor keeps your beverages
impeccably chilled, while running unobtrusively in
the background. Brilliance doesn’t have to announce
itself; it just is.
14. Emotive Controls
Hold sway over every zone. Let your light-guided
touch coax out the flavors of beverages, spirits and
beyond.
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before starting
installation
TOOLS AND PARTS NEEDED:
Phillips screwdriver
Custom Overlay Door Panel — Refer “Custom Overlay
Panel Preparation.”
Custom handle and mounting hardware (optional)
PARTS SUPPLIED:
M4 x 30 flathead screws (8)
LOCATION REQUIREMENTS
IMPORTANT: This appliance is intended to be used in
household and similar applications such as:
Staff kitchen areas in shops, office and other working
environments;
Farm houses and by clients in hotels, motels and
other residential type environments;
Bed and breakfast type environments;
Catering and similar non-retail applications.
NOTES:
For the beverage center to be flush with the front
of the base cabinets, remove any baseboards or
moldings from the rear of the opening. See “Product
Dimensions” and later in this section, “Opening
Dimensions.”
It is recommended that you do not install the
beverage center near an oven, radiator, or other heat
source.
Do not install in a location where the temperature will
fall below 55°F (13°C). For best performance, do not
install the beverage center behind a cabinet door or
block the base grille.
OPENING DIMENSIONS
Height dimensions are shown with the leveling legs
extended to the minimum height.
NOTE: When leveling legs are fully extended, add
5/8" (15 mm) to the height dimensions. See “Product
Dimensions.”
If the floor of the opening is not level with the kitchen
floor, shim the opening to make it level with the
kitchen floor.
Opening width - A 24" (60.96 cm) min.
Opening depth - B 24" (60.96 cm) min.
Opening height - C 34⁄" (87.6 cm) min.
35" (88.9 cm) max.
Dimension - D 12⁄" (30.64 cm)
Dimension - E 21⁄" (55.16 cm)
Dimension - F 1⁄" (4.44 cm)
Dimension - G 3" (7.55 cm)
Dimension - H 4⁄" (11.37 cm)
Dimension - I 9⁄" (23.47 cm)
For flush installation, the power outlet can be installed in
adjacent cabinetry with a cutout on the power cord side
for routing of the power cord.
The power outlet can also be recessed on the back
wall behind the unit as per recommended receptacle
locations in the above illustration.
WARNING
Explosion Hazard
Keep flammable materials and vapors,
such as gasoline, away from beverage center.
Failure to do so can result in death, explosion, or fire.
Opening and utility location dimensions
A
B
C
D
E
F
F
G
H
G
I
Recessed
receptacle
locations
Utility
opening

6
PRODUCT DIMENSIONS
OVERALL PRODUCT
Width (up to hinge cover) 23⁄" (60.72 cm)
Height (up to hinge cover) 34⁄" (87.32 cm)
Glass door model (NOIR™) depth
(no handle) 23⁄" (60.36 cm)
Glass door model (RISE™) depth
(no handle) 23⁄" (60 cm)
Solid door models
(NOIR™/ RISE™) 23⁄" (60 cm)
Panel ready models depth
(with 3/4" panel and no handle) 23⁄" (60.5 cm)
Raw Door Height 30⁄" (77.75 cm)
NOTE: The power cord is 60" (152.4 cm) long.
CUSTOM OVERLAY PANEL
NOTE: For standard stainless steel or glass door
models, skip these instructions and go to "Electrical
Requirements" section.
If you plan to install a custom overlay panel, you will
need to create the panel yourself or consult a qualified
cabinetmaker or carpenter. Refer dimension drawings for
panel specifications.
IMPORTANT:
The thickness of the overlay panel must be 3/4"
(19 mm).
Custom solid door overlay panel must not weigh
more than 20 lbs (9.07 kg).
Custom glass door overlay panel must not weigh
more than 10 lbs (4.54 kg).
Overlay panels weighing more than recommended
may cause damage to your appliance.
SOLID DOOR OVERLAY PANEL  PREPARATION
Create the custom overlay panel using the dimensions
shown in the illustration “Solid door overlay panel and
hinge routing dimensions”. Route shaded areas to a 1/2"
(12 mm) depth as shown.
IMPORTANT: The following graphic shows a custom
panel for a door with the hinges installed on the right-
hand side. If your beverage center has the hinges
installed on the left-hand side, rotate the custom frame
180° so the hinge markings will be on the left.
Solid door overlay panel and hinge routing dimensions
23⁄"
(60.72 cm)
34⁄"
(87.32 cm)
30⁄"
(77.5 cm)
Depth
(no handle)
4⁄"
(125 mm)
2"
(53 mm)
1/4"
(7 mm)
1/8"
(3 mm)
23⁄"
(60.3 cm)
1/2"
(12 mm)
30⁄"
(77.75 cm)

7
GLASS DOOR OVERLAY PANEL  PREPARATION
Create the custom overlay panel using the dimensions
shown in the illustration “Glass door overlay panel and
hinge routing dimensions”. Route shaded areas to a 1/2"
(12 mm) depth as shown.
IMPORTANT: The following graphic shows a custom
panel for a door with the hinges installed on the right-
hand side. If your beverage center has the hinges
installed on the left-hand side, rotate the custom frame
180° so the hinge markings will be on the left.
HANDLE OPTIONAL
Custom handles are typically attached to the custom
overlay door panel only.
Refer instructions received with JennAir®RISETM and
NOIRTM handle kits to install these handles on custom
wood panels.
Custom handle needs to be installed on the door panel
with countersunk holes and installed before the custom
overlay door panel has been installed on the beverage
center door.
Glass door overlay panel and hinge routing dimensions
4⁄"
(125 mm)
2"
(53 mm)
1/4"
(7 mm)
1/8"
(3 mm)
17⁄"
(43.3 cm)
21⁄"
(55.4 cm)
23⁄"
(60.3 cm)
1/2"
(12 mm)
30⁄"
(77.75 cm)

8
ELECTRICAL REQUIREMENTS Before you move your beverage center into its final
location, it is important to make sure you have the proper
electrical connection.
RECOMMENDED GROUNDING METHOD
A 115 V, 60 Hz, AC only, 15 or 20 A fused, grounded
electrical supply is required. It is recommended that a
separate circuit serving only your beverage center be
provided. Use an outlet that cannot be turned off by a
switch. Do not use an extension cord.
NOTE: Before performing any type of installation,
cleaning, or removing a light bulb, unplug beverage
center or disconnect power.
INSTALLATION INSTRUCTIONS
UNPACK THE BEVERAGE CENTER
Before using your beverage center, all packaging
materials should be removed and the interior should be
cleaned.
Remove tape and glue residue from surfaces before
turning on the beverage center. With your fingers,
rub a small amount of liquid dish soap over any
adhesive and wipe with warm water to remove.
Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These can damage the surfaces of
your beverage center. For more information, refer
“Beverage center Safety” section.
Dispose of and/or recycle all packaging materials.
After all packaging materials have been removed,
clean the inside of your beverage center. Refer the
cleaning instructions in “Cleaning” section.
NOTE: For standard stainless steel or glass door models,
skip to “Door Closing” section.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install beverage
center.
Failure to do so can result in back or other injury.

9
CUSTOM OVERLAY PANEL INSTALLATION
IMPORTANT:
Create custom overlay panel according to the
specifications in the “Custom Overlay Panel” section.
JennAir is not responsible for the removal or addition
of molding or decorative panels that would not allow
access to the beverage center for service.
1. Open the door completely to 90°.
2. Remove the gasket from the corners of the door,
pulling gently until the two screw holes in each
corner of the door can be seen.
NOTE: The gasket does not have to be removed from
the door, only the corners.
3. Using two people, hold the custom overlay panel
against the door. Be sure that the top and bottom
hinges fit accurately into the routing on back of the
custom wood panel.
NOTE: Handle needs to be installed before the custom
overlay door panel has been installed on the beverage
center door.
4. Fasten the custom panel to the door using two wood
screws (provided in installation kit) at each corner.
5. Press the gasket firmly back into it’s original position.
90°
A
A
B
A
A
A. Screw holes
B. Gasket
A. M4 x 30 flathead screws (provided in installation kit)

10
INSTALLATION AND DOOR CLOSING
Your beverage center has four leveling legs. If your
beverage center seems unsteady or you want the door to
close more easily, adjust the beverage center’s tilt using
the instructions below.
1. Plug into a grounded 3 prong outlet.
2. Move the beverage center into its final location.
3. Turn the leveling legs to the right to lower the
beverage center, or turn the leveling legs to the left to
raise it. It may take several turns of the leveling legs to
adjust the tilt of the beverage center.
NOTE: Having someone push against the top of the
beverage center takes some weight off the leveling
legs. This makes it easier to adjust the leveling legs.
4. Open the door and check that it closes as easily as
you like. If not, tilt the beverage center slightly more
to the rear by turning both front leveling screws to
the right. It may take several more turns, and you
should turn both leveling legs the same amount.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install beverage
center.
Failure to do so can result in back or other injury.
When Moving Your Beverage Center:
Your beverage center is heavy. When moving the beverage
center for cleaning or service, be sure to cover the oor with
cardboard or hardboard to avoid oor damage. Always pull
the beverage center straight out when moving it. Do not
wiggle or “walk” the beverage center when trying to move it,
as oor damage could occur.
