CABINET PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
10−08 Litho In U.S.A. (mjb)(bay) Part No. W10231838 Rev. A
42" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10151251 Use & Care Guide
W10164077 Energy Guide
W10159832 Service & Wiring
Sheet
2306424 Icemaker and
Ingredient Care
Center Service
Sheet
2318069 Main Control
Service Sheet
W10151249 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2260503B Button, Filter
4
W10138054 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
W10163493 Right Side
W10163491 Left Side
6 2004514 Clip, Conduit
8 Cap, Water Filter
2260518B Black
9 2307640 Mounting Stud,
Grille
10 2307584 Grommet, Crossover
Tube
11 2005783 Cam, Door Closer
12
W10121140 Housing, Water
Filter
13 2318189 Tray, Drip Filter
14 3400525 Screw
15 4396841 Filter, Water
16 489399 Screw
17 3400230 Screw, Door Stop
18 2257644 Hinge (Top)
19 2318190 Bracket, Mtg
(Water Filter)
20 489464 Screw
21 2004994 Lock, Adjustable
Bushing
22 2300082 Bushing
24 2221242 Spring, Door
Closure (2)
25 486194 Screw
26 2005008 Retaining Ring,
Adjustable Bushing
27
W10129069 Wire Clip (5)
28 2006342 Gap, Cover
Assembly (Bottom)
29 Hinge (Bottom)
2006780 Freezer Side
2006779 Refrigerator Side
30 2302876 Bushing,
Adjustable
31 8533913 Screw 1/4−20 x 5/8
32 Skirt−Grille,
Bottom
2209025B Black
33 Extension Arm,
Door Closer
2266882 Right
2266881 Left
34 Grille Bottom,
Front
2325185B Black
35 2005921 Screw
36 Bracket, Support
Base (Front)
2006616 Left
2006556 Right
37 1157158 Screw
38 2006617 Bracket, Support
Base (Rear) (2)
39 2006346 Washer
40 2266880 Bushing,
Extension Arm
41 1163283 Screw
42 Connector, Water
Tube
2209709 5/16−1/4"
2300868 1/4"
43 8281163 Screw
44 Switch, Rocker Arm
1118894 Refrigerator Door
Side
1115373 Freezer Door Side
45 2215938 Cover, Switch (2)
46 487415 Screw (2)
47 Bracket, Switch
2221097 Right
2221096 Left
48 2215612 Cover, Rear

3
CABINET TRIM PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 Cabinet, Trim
(Right Side)
W10132472 Stainless Steel
3 Screw
1163283 Stainless Steel
4 2316687 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2314017 Cabinet, Trim Top
7
W10132541 Cabinet Trim
(Left Side)
8
W10121451 Nutsert (4)
9 2005925 Seal−Trim, Side
10 489464 Screw

4
FREEZER SHELF PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 W10175905 Wire, Shelf
3 2302883 Shelf, Fixed (2)
4 2259082 Basket
5 2256270 Front, Basket
6 Slide, Basket
2259317 Right Side
2259318 Left Side
7 8533928 Screw

5
REFRIGERATOR LINER PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

6
REFRIGERATOR LINER PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2306010 Thermistor
3 2208970 Air Duct
4
W10159487 Diverter, Crisper
Cover
5 2259077 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 2006475 Screw
8 487539 Screw
9 2302937 Thermistor
10 2302986 Lid, Meat Pan
Baffle
11
W10169528 Baffle Control
Assembly
12 2171846 Release Valve
13 2310205 Jumper, Air Baffle
14 488357 Screw
15 486194 Screw
16 2003577 Guard, Air Return
17 2221296 Air Baffle
Assembly
18 2327509 Reservoir
19 488280 Screw
21 2309222 Diffuser Assembly
22 2317844 Thermistor Assy
23 2188820 Thermistor
24 2302992 Spacer, Air−
Baffle
25 2309087 Cover, Diffuser
27 2259412 Seal, Air Duct
(Round Hole)
28 2259398 Seal, Air Duct
(Square Hole)

7
CONTROL PANEL PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 W10151196 Control Box Assy
2 2317000 Clip, Box
4 2310390 Wire, Jumper
5 2307592 Bracket,
Control Box
6 2307595 Shield,
Control Box
7 487539 Screw (2)
8
W10151210 Display,
Ingredient Care
Center
9 2223857 Socket, Light
10 2326255 Light Bulb (2)
11 8281185 Screw

TOP GRILLE AND UNIT COVER PARTS
8
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 Panel, Decorative
Assembly
W10150056 Stainless Steel
2
W10161693 Cover, Unit
3 486194 Screw
4 2256466 Back Panel
5
W10185625 Cover, Unit Front
6 487415 Screw
7
W10167456 Wire Assembly
RC/FC Light Switch
8
W10159578 Badge, Jenn−Air
9 489348 Clamp
10 2215910 Grommet

REFRIGERATOR SHELF PARTS
9
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

REFRIGERATOR SHELF PARTS
10
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 W10141494 Shelf Assembly
3
W10151215 Assembly, Meat Pan
Cover
4
W10151213 Assembly, Crisper
Cover
5 2257582 Trim, Glass Rear
6 2252412 Crisper Pan (2)
7 Slide, Meat Pan
2302954 Left Side
2302955 Right Side
8 2302831 Trim, Glass Front
9 2256254 Trim, Glass Rear
10 2256248 Front, Crisper
Pan
11 2252255 Trim, Glass Side
Crisper Pan
12 2256250 Trim, Glass Side
Meat Pan
13 Spacer, Crisper
2256222 Right Side (2)
2256223 Left Side (2)
14 Slide, Crisper
2302956 Right Side
2302957 Left Side
15 Spacer, Meat Pan
2256243 Left Side
2256244 Right Side
16 Screw
8533929 Right Side−
(8−18 x 1.375)
8533928 Left Side−
(8−18 x .750)
17 2256369 Pan Assembly
Meat
18 2256366 Front, Meat Pan

11
FREEZER LINER AND AIR FLOW PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

12
FREEZER LINER AND AIR FLOW PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2259385 Fan Motor
2 2198665 Tube, P.C. Board
3 2169142 Fan Blade
4 2223733 Retainer,
Fan Motor
5 2302817 Gasket, Cover
6 2223986 Grommet
7 486194 Screw
8 2259464 Wedge, Air Duct
9 488500 Screw, Ground
10 2223857 Socket, Light (2)
11 488937 Clamp, Nylon
12 2326255 Light Bulb
13 489214 Screw
14 2182120 Scroll, Fan
15 2259465 Wedge, Air Duct
17 2307774 Air Duct
18 2198643 Lens
19 Block, Fan Scroll
2209480 Right
2209066 Left
20
W10151205 Cover, Emitter
21 Liner (Not A
Serviceable Part)
23 2259025 Cover, Air Outlet
24 2307751 Light Shield
25
W10158003 Cover, Evaporator
26 2302850 Support, Air Duct
27 487539 Screw
28 2198635 Spring
29 2309283 Deflector, Air
Duct
30 1112260 Support,
Evaporator
31 2196483 Shelf, Stud (20)
32
W10191952 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
36
W10151208 Cover, Receiver
37
W10139189 Harness, Evap Fan
(Includes Item 55)
39 2306010 Thermistor
41 2317844 Thermistor Assy
42 2006475 Screw
46 2259032 Ladder, Shelf
47 2259445 Support, Screw
50 2198634 Pin
51
W10193840 P.C. Board
Emitter
52 2198633 Flipper
53 2315398 Slide, Icemaker
Shut Off
54
W10193666 P.C. Board,
Receiver
55
W10160570 Defrost, Bi−Metal
56 8281185 Screw

MOTOR AND ICE CONTAINER PARTS
13
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

MOTOR AND ICE CONTAINER PARTS
14
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 2222965 Ice Bin
2
W10151247 Crusher Bin
3
W10140642 Auger
4 2258220 Washer, Auger
5 1119007 Spacer, Flat (6)
6 2317248 Cover, Crusher
7 2257024 Blade, Rotary
8 1119005 Spacer, Step (2)
9 2257020 Blade, Fixed
10 2257023 Blade, Rotary
11 2317239 Block, Blade
12 489229 Roll Pin
13 2257022 Blade, Rotary
14 489235 Washer, Plain
15 2198661 Washer, Coupling
16 2188918 Coupling, Top
17 8281164 Screw
18 3400065 Screw
19 2266800 Button, Bin
20
W10134783 Latch, Bin
21 2198608 Spring, Latch
22 2198671 Screw (2)
23 8281163 Screw
24 2188919 Holder
25 2198628 Seal
26 2318030 Drive Shaft
27 2318011 Enclosure, Motor
28 2315546 Dispenser, Motor
29 2318028 Cover
30 2315559 Sleeve. Coupling
31 2317250 Divider Chamber
32 2317243 Wiper

REFRIGERATOR DOOR PARTS
15
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

REFRIGERATOR DOOR PARTS
16
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 W10193490 Door Assy, RC
(Includes
Item #9)
2 2258951 Brace, Door Corner
3 2266854 Hinge Assembly,
Top
4 2316804 Spacer−Door,
Top & Bottom
5 489282 Screw
6 2302878 Hinge Assembly,
Bottom
7 2222796 Rail, Lid
8 2222982 Gaasket, Utility
Bin
9 2222811 Door Gasket,
Magnetic
10 Skin, Door
W10144969 Stainless Steel
11 Handle, Door
12859108 Stainless Steel
12 Spacer, Door−Skin
(Handle Side)
2309060 For Stainless
Steel Model
13
W10153450 Stud, Mounting
14 488568 Screw
15 Screw, 8−15 x .500
8281250 Stainless Steel
16 2005433 Spacer, Door−Skin
(Top)
17 308544 Screw, Handle
18
W10142296 Spacer, Door−Skin
(Hinge Side)
19 2004934 Spacer, Door−Skin
(Bottom)
20 2005326 Filler, Door
21 End Cap
2222919 Right Side
2222920 Left Side
22
W10127710 Plate, Door−Handle
23 2222922 Bin, Utility
Center
24 2257616 Door, Utility Bin
25 2222773 Bin, Door (3)
26 2222770 Bin, Door

FREEZER DOOR PARTS
17
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

FREEZER DOOR PARTS
18
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 Door Assy, FC
(Includes #14)
W10193494 Black
2
W10127710 Plate, Door Handle
3 2302879 Hinge, Bottom
4 489282 Screw
5 2266854 Hinge, Top
6 2316804 Spacer−Door,
Top & Bottom
7 2222814 Door Gasket,
Magnetic
8 Handle, Door
12859107 Stainless Steel
9 Spacer, Door−Skin
(Handle Side)
2309060 For Stainless
Steel Model
10 Skin, Door
W10144963 Stainless Steel
11 Screw
8281250 Stainless Steel
12 2005433 Spacer, Door−Skin
(Top)
13 488568 Screw
14 2257385 Spacer, Door−Skin
(Bottom)
15
W10142296 Spacer Door Assy
(Hinge Side)
16 308544 Screw, Handle
17 Filler, Door
W10159585 Top
W10159582 Bottom
18 2258951 Brace, Door Corner
19 2222776 Bin, Door (3)
20
W10153450 Stud, Mounting

19
DISPENSER FRONT PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838

DISPENSER FRONT PARTS
20
For Model: JS42PPDUDB01
(Stainless Steel)
W10231838
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 486194 Screw (3)
3
W10132946 Bracket, Motor
4 2305242 Connector,
Door Bracket
5 2318021 Motor, Ice Door
6 2180353 Door, Ice
7 2318020 Support, Ice Door
8 4449745 Screw (2)
9 2305235 Spigot
10 2318017 Separator Assembly
11 Housing, Middle
(Not Available
Order Item 12)
12
2307675US Housing Assembly
13
2305307GN Water, Paddle Asy
14
2305306GN Ice, Paddle Asy
15 2305219 Cover, Control
16 2321746 Electronic Control
(Includes #15)
17
W10151236 User Interface Asy
18
2318062US Tray, Housing
19 2305342 LED Assembly
