Jensen CV2018J User manual

Please read this manual carefully
before using this TV set and keep it
for future reference.
CV2018J
TV / DVD Combination
USER MANUAL

PRECAUTIONS
FCC WARNING-This equipment may
generate or use radio frequency
energy.Changes or modifications to this
equipment may cause harmful
interference unless the modifications are
expressly approved in the instruction
manual.The user could lose the authority
to operate this equipment if an
unauthorized change or modification is
made.
LASER SAFETY
This unit employs a laser.Only a qualified
service person should remove the cover
or attempt to service this device,due to
possible eye injury.
CAUTION:USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN AND
INTERLOCK DEFEATED.DO NOT
STARE INTO BEAM.
LOCATION:INSIDE,NEAR THE DECK
MECHANISM.
CONTENTS
Before Operation
Basic operation
Warning and cautions...........................................................................
Installation..............................................................................................3
..............................................................................
Preparation of the remote control..........................................................3
Function buttons and ........................................
Front panel of the TV set.....................................................................4
Rear panel of the TV set.......................................................................4
Using the remote control......................................................................5
Menu
........................................................................29
Specifications .....................................................................................30
Antenna Connection
External Connections
Functions
Connection to the external audio and video equipment..................28
Troubleshooting guide
......................................................................................
DVD Operation
DVD Features.......................................................................................18
Advanced Playback..............................................................................19
Special Function Playback...................................................................20
DVD System Setup................................................................................22
Playable Discs.......................................................................................26
Disc Protection and DVD Characteristics..........................................27
Others
1
4
4
4
5
5
5
6
9
18
19
20
21
25
26
27
28
29

Important safety Instructions
WARNING:TO REDUCE THE RISK OF FIRE ORELECTRIC SHOCK, DONOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRICSHOCK
DO NOT OPEN
CAUTION: TO REDUCETHE RISK OFELECTRIC
SHOCK, DO NOTREMOVE COVER (OR BACK).
NO USER SERVICEABLEPARTS INSIDE.REFER
SERVICING TOQUALIFIED SERVICE PERSONNEL
THIS SYMBOL INDICATES THATDANGEROUS
VOLTAGECONSTITUTING ARISK OF ELECTRIC
SHOCK IS PRESENTWITHIN THIS UNIT.
THIS SYMBOL INDICATES THATTHERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THELITERATURE
ACCOMPANYING THEAPPLIANCE.
The important noteis located onthe rear ofthe cabinet.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safetyand operating instructions should be readbefore the unitis operated.
2. RETAIN INSTRUCTIONS
The safety andoperating instructions should be retained forfuture reference.
3. HEED WARNINGS
All warnings onthe unit and in the operatinginstructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating anduse instructions should be followed.
5. CLEANING
Unplug this unitfrom the wall outlet before cleaning.Do not use liquid cleaners or aerosol
cleaners.
Use a dampcloth for cleaning the exterior cabinetonly.
6. ATTACHMENTS
The manufacturer ofthis unit does not make anyrecommendations for attachments,as they
may cause hazards.
7. WATER AND MOISTURE
Do not usethis unit near water. Forexample, near a bathtub, washbowl, kitchensink,
laundry tub, ina wet basement, or near aswimming pool.
8. ACCESSORIES
Do not placethis unit on an unstable cart,stand, tripod, bracket,or table. The unit mayfall,
causing serious injury, and seriousdamage to the unit.
(symbol provided byRETAC)
8A. Anappliance and cart combination should bemoved with care. Quick
stops, excessive force,and uneven surfaces may cause theappliance and
cart combination tooverturn.
9. VENTILATION
Slots and openingsin the cabinet back or bottomare provided for ventilation, and to ensure
reliable operation ofthe unit, and to protect itfrom overheating. These openings must not be
blocked or covered.The openings should never beblocked by placing the unit ona bed,
sofa, rug, orother similar surface. This unit should never beplaced near or over a radiatoror
heat source. This unit should not be placedin a built-in installation such asa bookcase or
rack unless properventilation is provided or the manufacturer'sinstructions have been
adhered to.
10. POWER SOURCE
This unit shouldbe operated only from the typeof power source indicated on the rating plate.
If you arenot sure of the type ofpower supply to your home, consult your appliance dealeror
local power company. For unitsintended to operate from battery power, or other sources,
refer to therespective pages in this Owner's Manualfor their operatinginstructions.
S3126A

Important safety Instructions
22
11. GROUNDINGOR POLARIZATION
This unit isequipped with a polarized alternating-current line plug (a plug having one blade
wider than theother). This plugwill fit into the power outletonly one way. This is a safety
feature. If youare unable to insert the plugfully into the outlet, try reversingthe plug. If the
plug should stillfail to fit, contact your electricianto replace your obsolete outlet. Insteadof
the polarized alternating-current line plug, your unit may be equipped with a 3-wire
grounding-type plug (aplug having a third (grounding) pin). This plug will only fit intoa
grounding-type power outlet.This too, isa safety feature. If you areunable to insert the plug
into the outlet,contact your electrician to replace yourobsolete outlet. Do not defeat the
safety purpose ofthe grounding-type plug.
12. POWER-CORD PROTECTION
Power-supply cords shouldbe routed so that they arenot likely to be walked onor pinched
by items placedupon or against them, paying particularattention to cords at plugs,
convenience receptacles, andthe point where they exit fromthe appliance.
13. LIGHTNING
Toprotect your unit from a lightningstorm, or when it is leftunattended and unused for long
periods of time,unplug it from the wall outletand disconnect the antenna or cablesystem.
This will preventdamage to the unit due tolightning and power line surges.
14. POWER LINES
An outside antennasystem should not be located inthe vicinity of overhead power linesor
other electric lightor power circuits, or where itcan fall onto or against suchpower lines or
circuits. When installingan outside antenna system, extreme careshould be taken to keep
from touching suchpower lines or circuits, as contactwith them might be fatal.
15. OVERLOADING
Do not overloadwall outlets and extension cords, asthis can result in a riskof fire or electric
shock.
16. OBJECT AND LIQUID ENTRY
Do not pushobjects through any openings in thisunit, as they may touch dangerousvoltage
points or shortout parts that could result infire or electric shock. Never spillor spray any
type of liquidinto the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outsideantenna or cable system is connectedto the unit, be sure theantenna or cable
system is groundedto provide some protection against voltagesurges and built-up static
charges, Section 810of the National Electrical Code (NEC),ANSI/NFPA70, provides
information with respectto proper grounding of the mastand supporting structure,
grounding of thelead-in wire to an antenna dischargeunit, size of grounding conductors,
location of antennadischarge unit, connection to grounding electrodes, and requirements
for the groundingelectrode.
18. SERVICING
Do not attemptto service this unit yourself asopening or removing covers may exposeyou
to dangerous voltageor other hazards. Refer all servicingto qualified service personnel.

Important safety Instructions
19. DAMAGE REQUIRINGSERVICE
Unplug this unitfrom the wall outlet and referservicing to qualifiedservice personnel under
the following conditions:
a. When thepower-supply cord or plug is damaged.
b. If liquidhas been spilled, or objects havefallen into theunit.
c. If theunit has been exposed to rainor water.
d. If theunit does not operate normally byfollowing the operatinginstructions. Adjust
only those controlsthat are covered by the operatinginstructions, as animproper
adjustment of othercontrols may result in damage andwill often requireextensive
work by aqualified technician to restore the unitto its normaloperation.
e. If theunit has been dropped or thecabinet has beendamaged.
F.When the unit exhibits a distinctchange in performance,this indicates a need for
service.
20. REPLACEMENT PARTS
When replacement partsare required, be sure the servicetechnician uses replacementparts
specified by themanufacturer or those that have thesame characteristics asthe original part.
Unauthorized substitutions mayresult in fire, electric shock orother hazards.
21. SAFETY CHECK
Upon completion ofany service or repairs to thisunit, ask theservice technician to perform
safety checks todetermine that the unit is inproper operating condition.
22. HEAT
The product shouldbe situated away from heat sourcessuch as radiators,heat registers,
stoves, or otherproducts (including amplifiers) that produce heat.
23. DISC SLOT
Keep your fingerswell clear of the disc slotas it isclosing. It may cause serious personal
injury.
24. CONNECTING
When you connectthe product to other equipment, turnoff the power and unplug all of the
equipment from thewall outlet. Failure to do somay cause anelectric shock and serious
personal injury. Read theowner's manual ofthe other equipmentcarefully and follow the
instructions when makingany connections.
25. SOUND VOLUME
Reduce the volumeto the minimum level before youturn on theproduct. Otherwise, sudden
high volume soundmay cause hearing or speaker damage.
26. SOUND DISTORTION
Do not allowthe product output distorted sound fora longtime. Itmay cause speaker
overheating and fire.
27. LASER BEAM
Do not lookinto the opening of the discslot or ventilationopening of the product to seethe
source of thelaser beam. It may cause sightdamage.
28. DISC
Do not usea cracked, deformed, or repaired disc.These discs are easily broken and may
cause serious personalinjury and product malfunction.
29. NOTE TO CABLE TVSYSTEM INSTALLER
This reminder isprovided to call the Cable TV system installer'sattention to Article 820-40 of
the NEC thatprovides guidelines for proper grounding and,in particular,specifies that the
cable ground shallbe connected to the grounding systemof the building,as close to the point
of cable entryas practical.

Installation
Antenna connection
Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV
system or an outdoor antenna .In different places, the suitable antenna type and position
may vary.
Preparation for the remote control
Battery installation
Tips for remote operation
Remove the battery cover.
!When the remote control will not be used for a long period of time or when the
batteries are worn out, remove the batteries to prevent leakage.
! Do not throw the batteries into fire. Dispose of used batteries in the specified
manner.
! Do not drop, dampen or disassemble the remote control.
Insert two size AA batteries matching
the +/-polarities of the battery to the +/-
marks inside the battery compartment.
!
!
Note:
* It is recommended that a 75 ohm coaxial antenna is used to avoid
interference.
*To avoid interference from electrical signals, do not bind the antenna cable
together with any mains lead.
AC power socket
Mixer
(not incl.)
Antenna/ CATV input
75 standard
coaxial type

CHANNEL
Function Buttons and External
Connections
Rear panel of the TV set
Front panel the TV set
OUT
IN
VIDEO L R
AUDIO
Audio left channelinput terminal
Audio right channelinput terminal
Audio left channeloutput terminal
Audio right channeloutput terminal
Antenna input socket
Video input terminal
Video output terminal
COAXIAL
COAXIAL
S-VIDEO
S-Video terminal

Using the Remote Control
TV Time Menu
P
DVD PAUSE/STEP
DVD FAST REVERSE
DVD FAST FORWARD
DVD MENU
DVD A-B REPEAT
DVD Cursor Move button
DVD SLOW
DVD SEARCH
DVD TITLE
DVD PROGRAM
10+
(Not available)
TV Sleep button
Power Switch
Calendar Function
Mute Sound
Return to Previous Channel
Channel / Track Selection
TV / AV Mode Selection
Select 1 or 2 Digit Channel / Track Number Inputting
TV / DVD Mode Selection
Adjusting
Go to TV Menu
Exit On Screen Display
Adjust Picture Mode
Playback
CCD ( closed caption) On / Off
Enter
Chapter / Track
Chapter / Track
Mode
Playback / Confirm Menu Selection
Change
Mode
DVD INFORMATION
Selection
Zoom Function
Open/close DVD Tray
Channel Scan
On Screen Display
(Non Functional)
Volume/Channel
DVD STOP
DVD SETU
DVD NEXT
DVD REPEAT
DVD
DVD ANGLE
DVD AUDIO
DVD CAPTION (SUBTITLE)
DVD PREVIOUS
Buttons on the remote control
UP
DOWN
LEFT RIGHT
POWER TIME OPEN/CLOSE
SCAN RECALL DISPLAY MUTE
1234
5678
9900
TV/AV
TV/DVD
CH+
CH-
VOL
_
MENU
EXIT P.STD
STOP SETUP PAUSE/STEP
REV FWD .PREV NEXT
D.MENU REPEAT A-B
PLAY/ENTER SLOW
ANGLE TITLE/PBC SEARCH
AUDIO
SUBTITLE
D.CALL
CALENDAR
PROGRAM ZOOM
10+
SLEEP
VOL
+
CCD
-/--

Remote Features
Power Button:
To turn power ON or OFF , press power button on remote control.
Control
System and ChannelDisplay Button:
This will show you the current channel number. System type will
also be displayedif set.
TV/AV input Button:
This button hasthree settings:A)Video1, B)Video 2, C)SVHS,D)TV .
Pressing this button will cycle you through each input type.
Mute Button:
Press mute button to turn off the TV volume.
Direct Channel Access Selection:
one of the procedures noted below to access a channel.
Selection:
channel
number digit.
Selection:
When you want to select two-digit channel. Press the digit
button twice, thenenter the twochannel digits .
When you want to select a three digit channel. Press the
digit select buttonthree times, then enter the three digits .
Follow
One Digit Channel
When you want to select one digit channel ,press 0 and
Two Digit Channel
Three Digit ChannelSelection:
CCD Button:
Press CCD buttonto set the C.Caption (Closed ).Captioning
DVD/TV Button:
Press this buttonto change betweenTV and DVD mode.
OPEN/CLOSE Button:
Press this button to open or close the DVD disc tray .
-/--
1234
5678
90
Using the Remote Control (Continued)
POWER
DISPLAY
TV/DVD
TV/AV
MUTE
SLEEP
Sleep Timer Button:
This feature allows you to turn off television in pre-selected
minutes (180.170,160, ........,10 and 0). To cancel, keep
pressing button untilyou exit out.
OPEN/CLOSE
CCD

Channel (+/-) SelectButton:
You can go up and down the channels by pressing CH (+)
button and CH (-) button. This button can also be used in adjusting the functions in
Menu Select Button:
You can select the menu by pressing the MENU button. You
can call onthe menu (PICTURE,TIME, TUNE and FUNCTION)
by pressing the corresponding button on the remote control.
the Menu Mode.
Volume (+/-) Select Button:
You can increase the volume by pressing VOL (+) button and
decrease VOL(-) button. This button can also be used in adjusting the function
selections in the Menu Mode.
Picture Preference SelectButton:
By pressing this exclusive personal preference button, you can
select different preset brightness shades for various viewing
environments.
Program Scan Button:
This feature automaticallyscans the availablechannels.
Pressing it again stops the channel scanning.
System and ChannelDisplay Cancel Button:
This button allows you to turn off the channel display and exit
system menus.
Last Channel RecallButton:
This feature allows you to recall the previously viewed channel.
Time Menu Button:
When pressed it displays Time Menu Screen.
10+ Button:
This button canalso be usedto select 2digit channel numbers.
RECALL
P.STD
SCAN
EXIT
TIME
Using the Remote Control (Continued)
CH+
CH-
VOL
_
MENU VOL
+
10+
