MULTI-LINX
Please read and save these instructions. Read carefully before using product. Protect yourself and others by observing all
safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage
to product or property. Please retain instruction sheet for future reference.
IMPORTANT SAFETY INSTRUCTIONS
Read completely before beginning. If you feel you do not have adequate electrical wiring experience, have this installed by
a qualied licensed electrican.
All electrical connections must be in accordance with local codes, ordinances and the National Electric Code. This product
operates on 120V AC; always conrm the maximum wattage of the linear xture does not exceed the maximum wattage of
the circuit it is connected to. If you are unfamiliar with methods of installing electrical wiring, secure the services of a qualied
licensed electrician.
Read and follow all safety instructions.
Read completely before beginning. If you feel you do not have adequate electrical wiring experience, have this
installed by a qualied licensed electrician.
All electrical connections must be in accordance with local codes, ordinances and the National Electric Code.
This product operates on 120V AC; always conrm the maximum wattage of the linear xture does not exceed the
maximum wattage of the circuit it is connected to. If you are unfamiliar with methods of installing electrical wiring,
secure the services of a qualied licensed electrician.
Do not install the linear xture if any damage is seen on the product or power cables.
Prior to starting the installation, disconnect the power by turning off the circuit breaker or removing the appropriate
fuse. (Turning off power using the light switch is not sufcient to prevent electrical shock).
1.
2.
3.
4.
5.
TURN OFF ELECTRICITY
at main fuse box (or circuit breaker box)
before beginning installation by switching
circuit breaker off or removing fuse.
MIN 90º C SUPPLY CONDUCTORS.
MOUNTING OPTIONS
FOR ELECTRICAL CONNECTION, SEE PAGE 8
Surface Mounting with Clips
Single or Multiple xtures connected
linearly. (See page 7)
Single or Linearly Connected
Ceiling Mounting with Cables
Single or multiple xtures connected
linearly. (See page 2)
Multiple Side-by-Side
Ceiling Mounting with Cables
Multiple xtures connected side-by-side.
(See page 4)
RATED 120 VOLT AC
20W per 2 feet xture (15units MAX)
40W per 4 feet xture (7 units MAX)
80W per 8 feet xture (3 units MAX)
CONSULT A QUALIFIED ELECTRICIAN TO
ENSURE CORRECT BRANCH CIRCUIT
300W MAX
connected run

MLX
MULTI-LINX LED Fixture
Modular Linkable Linear Fixture
www.jescolighting.com
[email protected]
Tech Support: 855.592.0029
Instruction sheet subject to change without prior notice.
15 Harbor Park Drive
Port Washington, NY 11050
Main Line: 800.527.7796
Fax Line: 855.265.5768
219 South 6th Ave
City of Industry, CA 91746
Main Line: 855.654.0110
Fax Line: 626.333.2955
Designed, Developed and
Assembled in the U .S.A
Page 2 of 8
JW 06/14/2017
MULTI-LINX
MLX-24 18”(46cm) | MLX-48 44”(112cm) | MLX-96 88”(224cm)Recommended MLX-MC Spacing:
PLASTIC ANCHOR
MLX-MC
#8 SELF-TAPPING SCREW
DRILL 1/4” HOLE
MASONRY DRYWALL/CEILING TILE
MLX-PC(05/10)
MLX-PC-HW(05/10)
MLX MLX
MLX- MEC
Locking Screw
METAL STUD WOOD
DRILL 1/8” HOLE
MLX-MC
MLX-DC
OR
MLX-CC-06/12/18
INPUTOUTPUT
END FEED TOP FEED
#8 SELF-TAPPING SCREW
MLX-PC(05/10)-TF
MLX-PC-HW(05/10)-TF
MLX- MEC
MLX- FEC
BLACK to BLACK
WHITE to WHITE
GREEN or COPPER to GREEN
SUPPLY WIRES
INPUTOUTPUT
MLX MLX
CABLE SUSPENSION (LINEARLY CONNECTED) INSTALLATION INSTRUCTIONS
PLASTIC ANCHOR
COUPLER MOUNT
MOUNTING SCREW
DRILL 1/4” HOLE
DRILL 1/8” HOLE
COUPLER
COUPLER CABLE GRIP
T-NUT MOUNT
CABLE
COUPLER MOUNT
MOUNTING SCREW
BLACK (HOT)
WHITE (NEUTRAL)
GREEN
OR COPPER
(GROUND)
SUPPLY WIRES
A-A B-B
MLX-PC-HW(05/10)
MLX-PC-HW(05/10)-TF
MLX-PC (05/10)
MLX-PC (05/10)-TF
MLX-24 18”(46cm) | MLX-48 44”(112cm) | MLX-96 88”(224cm)Recommended MLX-SCK Spacing:
MLX-SCK
C
C1
C1
C2
C2
CABLE
C3 CABLE C3
COUPLER MOUNT
COUPLER
C1
C2
C3 C4
C5
MASONRY DRYWALL/CEILING TILE METAL STUD WOOD
TOOLS REQUIRED HARDWARE INCLUDED with MLX-SCK
REQUIRED COMPONENTS FOR SINGLE FIXTURE INSTALLATION
ADDITIONAL COMPONENTS REQUIRED FOR CONNECTING MULTIPLE FIXTURES
MINI PHILLIPS
SCREWDRIVER
1A-A Plug in MLX-PC or MLX-PC-HW into MLX xture’s
input port and secure power connector to xture with
provided mounting screws with a mini-phillips screwdriver.
1 B-B Top feed cable is pre-wired onto MLX xture
Single Pendant Installation
End feed xture Insert: MLX-MEC into MLX’s output
port. Top feed xture insert: MLX-MEC into MLX’s
output port and insert MLX-FEC into MLX’s input port.
Multiple Fixtures Installation Insert (1) MLX-DC or (1)
MLX-CC to the output connection of all connecting xtures.
For the last connecting xture. Insert MLX-MEC to the
output connection.
2Based on building material of intended mounting surface,
determine the best mounting method. Each MLX xture
requires (2) MLX-SCK for installation, recommended
distance between each MLX-SCK is determined by
MLX xture’s length.
2 A-A Drill a 1/4” hole in mounting surface and make sure
the depth is at least 1/4” past the length of the plastic
anchor. Insert plastic anchor in drilled hole. Insert mounting
screw through COUPLER MOUNT and screw into plastic
anchor. Repeat the process for second COUPLER MOUNT,
then secure COUPLER with CABLE to COUPLER
MOUNT by hand.
2 B-B Drill a 1/8” pilot hole and fasten mounting screw and
COUPLER MOUNT on to mounting surface. Repeat the
process for second COUPLER MOUNT.
SUSPENSION WITH CABLES
Single or Multiple xtures connected
linearly.
MLX-PC(05/10)
MLX-PC-HW(05/10)
MLX-PC(05/10)-TF
MLX-PC-HW(05/10)-TF
MLX-(24/48/96)
MLX-DC with MLX-CC-(06/12/18)MLX-DCS
OR
MLX-SCK-(1/2) MLX-MEC MLX-FEC
required for top
feed (-TF) input
MOUNTING SCREWSWIRE CUTTER PLASTIC ANCHOR
FOR USE WITH DRYWALL
2
A-A B-B
POWER DRILL WITH:
1/4” DRILL BIT
1/8” DRILL BIT
PHILLIPS BIT
A B C D E
F G H
1BB
A A
E
D D
B
B
A
A
A
A
A
A
C
C
C1
C1
C1
C1
C1
C2 C3
AD
E
F H
D
D
A-A B-B
