Jet JMD-18 User manual

.JET
EQUIPMENT & TOOLS
OPERATOR'S MANUAL
JMD Series Mill IDrills
(JMD-18shownwith optionalCS-18stand)
JET EQUIPMENT & TOOLS, INC.
A WMH - Walter Meier Holding Company P.O. BOX 1349
Auburn, WA 98071-1349 253-351-6000
Fax [phone]
No. M.350019 09/'01

Important Information
1-YEAR
LIMITED WARRANTY JET offers a one-year limited
warranty on this product
REPLACEMENT PARTS
Replacement parts for this tool are available directlyform JET Equipment& Tools.
To place an order, call 1-800-274-6848. Please havethe following informationready:
1. Visa, MasterCard,or DiscoverCard number
2. Expirationdate
3. Part number listedwithin this manual
4. Shipping address other than a Post Office box.
REPLACEMENT PART WARRANTY
JET Equipment & Tools makes every effort to assure that parts meet high quality and durability
standards and warrants to the original retail consumer/purchaser of our parts that each such
part(s) to be free from defects in materials and workmanship for a period of thirty (30) days from
the date of purchase.
PROOF OF PURCHASE
Please retain your dated sales receiptas proofof purchaseto validatethe warranty period.
LIMITED TOOL AND EQUIPMENTWARRANTY
JET makes every effort to assure that its products meet high quality and durability standards and warrants
to the original retail consumer/purchaserof our productsthat each product be free from defects in materials
and workmanship as follows: 1 YEAR LIMITEDWARRANTYON THIS JET PRODUCT. Warranty does not
apply to defects due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations
outside our facilities or to a lack of maintenance. JET LIMITS ALL IMPLIED WARRANTIES TO THE
PERIOD SPECIFIED ABOVE FROM THE DATE THE PRODUCT WAS PURCHASED AT RETAIL.
EXCEPT AS STATED HEREIN, ANY IMPLIEDWARRANTIES OR MECHANTABILITYAND FITNESS ARE
EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG THE IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. JET SHALL IN NO
EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERY OR FOR INCIDENTAL,
CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO
YOU. To take advantage of this warranty, the product or part must be returned for examination, postage
prepaid, to an authorized service station designated by our Auburn office. Proof of purchase date and an
explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, JET
will either repair or replace the product or refund the purchase price, if we cannot readily and quickly
provide a repair or replacement, if you are willing to accept such refund. JET will return repaired product or
replacement at JET's expense, but if it is determined there is no defect, or that the defect resulted from
causes not within the scope of JET's warranty, then the user must bear the cost of storing and returning the
product. This warranty gives you specific legal rights, and you have other rights, which vary, from state to
state.
JET Equipment &Tools. P.O. Box 1349, Auburn, WA 98071-1349 .[phone]

~WARNING
Read and understand the entire contents of
this manual before attempting set-up or
operation of this mill/drill.
.This machine is designed and intended
for use by properly trained and
experienced personnel only. If you are
not familiar with the proper safe use of
mill/drills, do not use this machine until
proper training and knowledge has been
obtained.
Keep guards in place. Safety guards must
be kept in place and in working order.
Remove adjusting keys and wrenches.
Before turning on machine, check to see that
any adjusting wrenches are removed from
the tool.
Reduce the risk of unintentional starting.
Make sure switch is in the OFF position
before plugging in the tool.
Do not force tools. Always use a tool at
the rate for which itwas designed.
Use the right tool. Do not force a tool or
attachment to do a job for which it was not
designed.
Maintain tools with care. Keep tools sharp
and clean for best and safest performance.
Follow instructions for lubrication and
changing accessories.
Always disconnect the tool from the
power source before adjusting or
servicing.
Check for damaged parts. Check for
alignment of moving parts, breakage of
parts, mounting, and any other condition that
may affect the tools operation. A guard or
any part that is damaged should be repaired
or replaced.
.
.
.
.
.
.
.
.
.Turn power off. Never leave a tool
unattended. Do not leave a tool until it
comes to a complete stop.
Keep work area clean. Cluttered areas and
benches invite accidents.
Do not use in a dangerous environment.
Do not use power tools in damp or wet
locations, or expose them to rain. Keep
work area well lighted.
Keep children and visitors away. All
visitors should be kept a safe distance from
the work area.
.
.
.
.Make the workshop child proof. Use
padlocks, master switches, and remove
starter keys.
Wear proper apparel. Loose clothing,
gloves, neckties, rings, bracelets, or other
jewelry may get caught in moving parts.
Non-slip footwear is recommended. Wear
protective hair covering to contain long hair.
Do not wear any type of glove.
Always use safety glasses. Every day
glasses only have impact resistant lenses;
they are not safety glasses.
Do not overreach. Keep proper footing and
balance at all times.
Do not place hands near the cutterhead
while the machine is operating.
Do not perform any set-up work while
machine is operating.
Read and understand all warnings posted
on the machine.
.
.
.
.
.
.
.This manual is intended to familiarize you
with the technical aspects of this
mill/drill. It is not, nor was it intended to be,
a training manual.
Failure to comply with all of these
warnings may result in serious injury.
.
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm Some
examples of these chemicals are:
.Lead from lead based paint
.crystalline silica from bricks and cement and other masonry products, and
.arsenic and chromium from chemically-treated lumber
Your risk from those exposures varies, depending on how often you do this type of work To reduce
your exposure to these chemicals work in a well ventilated area. and work with approved safety
equipment, such as those dust masks that are specifically designed to filter out microscopic
particles

Specifications: JMD-15/18/18PFN
Stock Number:
JMD-15 350017
JMD-18 , 350018
JMD-18PFN 350020
Drilling Capacity:
JMD-15 1"
JMD-18/18PFN 1-1/4"
Face Mill Capacity:
JMD-15 """"""""""""""""""""""""""""""'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 2-1/2"
JMD-18/18PFN """"""""""""""""""""'"'''''''''''''''''''''''''''''''''''''''''''''''''''''''' 3"
End Mill Capacity:
JMD-15 1/2"
JMD-18/18PFN """""""""""'"'''''''''''''''''''''''''''''''''''''''''''''''''''''' """'''''''''''''''''''''''''''''' .3/4"
Swing:
All Models 15-7/8"
Maximum Distance Spindle to Table:
JMD-15 """""""'"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 15"
JMD-18 '"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 18"
JMD-18PFN "'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 26"
Spindle Taper:
All Models , .".. R-8
Spindle Travel:
JMD-15 , 3-1/2"
JMD-18 "'"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 5"
JMD-18PFN 4-1/4"
Quill Diameter:
JMD-15 """"""""""""""""""""""'''''''''''''''''''''''''''''' .., 2-1/2"
JMD-18/18PFN , ""'"'''''' " 3"
Head Swivel:
All Models ...360°
Column Diameter:
JMD-15 '''''''''''''''''''' '''''''''''''''''''''''''''''''''' 3-5/8"
JMD-18/18PFN 4-1/2"
Numberof Power Downfeeds(JMD-18PFNonly) 3
Range Of Power Downfeeds(JMD-18PFNonly) .0.004", .007", .01"
Numberof Spindle Speeds:
All Models 12
Range of Spindle Speeds:
JMD-15 "","""""""""""""""""""""""'" 110-2,580 RPM
JMD-18/18PFN 150- 3,000 RPM
MaximumTable Travel:
JMD-15 , ...14"
JMD-18/18PFN """""""""'"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' ..24"
Cross Travel:
JMD-15 , 6"
JMD-18/18PFN . ... , ...7"
Working Surface of Table:
JMD-15 .. ,... 7-112" X23"
JMD-18/18PFN " 9-1/2" X32"
Number of T-Slots:
All Models 4
2

T-Slot Size:
JMD-15 ..9/16"
JMD-18/18PFN """'''' """"""""""'"'' 5/8"
T-Slot Centers:
JMD-15 ... ""'" ... ... ...... 1-1/2"
JMD-18/18PFN ... ... ...... ...... ... ... ...... 2-1/16"
Overall Dimensions:
JI\,IID-15 ... """'" ... ... ... ... ...~6-1 /2"L x 37-1/2"W x 35-1/2"H
JMD-18 """""""'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 42-1/2"L x 39-3/4"W x 43-1/2"H
JMD-18PFN """'"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 42-1/2"L x 39-3/4"W x 51-1/2"H
Base Dimensions:
JMD-15 """"""""'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 12-1/2" x 19-3/4"
JMD-18/18PFN '"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 15-3/4" x23-3/4"
Motor (UL Listed):
JMD-15 ""'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 1 HP, 1Ph, 115V
JMD-18/18PFN 2 HP, 1Ph, 230Vonly
Net Weight (approx.):
JMD-15 .. ... ......... ...... ... ......... ... "'" 440 Lbs.
JMD-18 . """""'''''''''''''' , 660 Lbs.
JMD-18PFN ""'''''''' """'"'''' """'''''''''''''' "'''''''''''' 700Lbs.
Shipping Weight (approx.):
JMD-15 540 Lbs.
JMD-18 """'"'''''''''''''''''' 760 Lbs.
JMD-18PFN """"'" 800 Lbs.
The specifications in this manualare given as general informationand are not binding. JET
Equipment and Tools reserves the right to effect, at any time and without prior notice, changes or
alterations to parts, fittings, and accessory equipmentdeemednecessaryfor any reason
whatsoever.
Table of Contents
Warning 1
Specifications 2-3
Table of Contents "" 3
Contents of the Shipping Container 4
Unpacking and Clean-up 4
Assembly 5
Installation 5
Lubrication 6
Electrical Connections 6
Controls 7-8
Operation 9
Arbor Replacement 9
GibAdjustment ""'''''''''''''''''' 10
Power Feed Operation "'"'''''''''' 11
Parts Lists and Breakdowns 12-31
Electrical Schematic 32-33
3

Contents of the Shipping Container
1 Mill/Drill
Accessory Package:
1
1
1
1
2
Chuck Arbor (installed)
1/2" Drill Chuck w/ Chuck Key
Adjustable Carbide Facemill
Facemill Arbor
Bolts, Nuts, and Washers to
Attach Vise to Table
2-1/2" Angle Vise (JMD-15)
3-1/2" Angle Vise (JMD-18/18PFN)
Handle Rods
Plastic Knobs
3/8"x1" Hex Socket Cap Screw
3/8" Washer
Crank Body
Crank Handle
3mm HexWrench
5mm Hex Wrench
23mm Hex Socket Wrench (JMD-18/18PFN)
HandWheels w/ Handles
Can Touch-Up Paint
Operator's Manual
Warranty Card
1
1
3
3
1
1
1
1
1
1
1
3
1
1
1
Unpacking and Clean-up
1. Finish removingthe crate from the mill/drill.
Unbolt the machinefrom the crate bottom.
Report shipping damage, if any, to your
distributor.
2. Remove any protective coating with keroseneor
a mild solvent. Do not use gasoline, paint
thinner, or lacquer thinner. Thesewill damage
painted surfaces.
Tools Needed for Assembly
8" Adjustable Wrench or 1/4" to 1-1/4" Combination
Wrench Set
4

Assembly
1. Screw plastic knob (A, Fig. 1)onto handleshaft
(B, Fig. 1). Screw handle shaft intodownfeed
hub (C, Fig. 1) and tighten. Flat spot on shaft
accommodates a combinationor adjustable
wrench. Note: Handle shafts are already
installed into hub on JMD-18PFN.
2. Repeat for other two shaft assemblies.
3. Slide crank (A, Fig. 2) onto shaft and tighten set
screw (B, Fig. 2). Be sure set screw seats on flat
part of shaft.
4. Insert handle (C, Fig. 2) into crank and tighten.
5. Slide handwheel (A, Fig. 3) onto table
handwheel shaft and tighten set screw. Insert
handle (B, Fig. 3) into handwheel and tighten.
6. Repeat for two remainingtable handwheels.
Installation
1. The location for the mill/drillshould be well lit,
dry, and have room enough to allow the headto
rotate 3600.
2. Place nylon slings with a load ratingexceeding
the weight of the mill/drillaround the head so
that the sling will not damageany partswhen
tensioned. See Fig. 4.
3. Carefully lift the mill/drillto a sturdystand or work
bench. For best performance, through bolt the
mill/drill to a bench or stand.
4. Before bolting the mill/drillto a bench or stand,
the unit must be level in both directions. Place a
level on the table in both directions.
5. If the table is not level,shim underthe low corner
(s) untilleve!. Tighten the fastening bolts.
Check for level again. Adjust as necessaryuntil
Fig. 1
Fig. 2
~.
Fig. 3 ...
V\
J)
5

the mill/drill is level after the fastening hardware
has been tightened.
Lubrication
Lubricate all ball oilers on the machine once daily
with 20W machine oil.
The spindle bearings are permanentlysealed and
require no lubrication.
Electrical Connections
CURRENT CARRYING PRONGS
~IA/
GROUND D.RONG
Before making any electrical connections, make sure
the power source available is compatiblewith the
machine. Also, press the Off switchon the front of
the machine before connectingto the powersource.
w
e
CZ)
The JMO-15 is rated at 115/230Vand comes from
the factory prewired at 115V. This mill/drillcomes
with a plug designed for useon a circuitwith an
outlet that looks like (A) in Fig. 5. The JMO-15has a
grounding prong as illustrated in (B). A temporary
adapter (C) may be usedto connect the plugto a
two pole receptacle (0) if a properlygroundedoutlet
is not available. The temporary adapter shouldonly
be used until a qualifiedelectriciancan installa
properly grounded outlet. The green colored plug
must be securely fastened to the cover platescrew.
~ROUNDING
~~~
,~,,~ Fig. 5
To switch the JMO-15 to 230V operation:
1. Disconnectthe machine from the power
source.
2. Removethe junction box cover on the motor.
3. Change the wires according tothe diagramon
the inside of the junction box cover.
4. Replacethe junction box cover.
5. Change the plugto onethat is rated230V or
hardwire the powercord.
6. Change the overload from 18A to
10A Specification. 6

The JMD-18/18PFN is rated at 230V only. Again, be
sure the power source is compatiblewith the mill/drill
before connecting to the powersource.
Controls
Longitudinal HandWheels (X-axis)(A, Fig. 6) -
located on either side of the table. Movestable side
to side.
Cross Feed Hand Wheel (Y-axis) (8, Fig.6) -
located on the front of the base. Movestable toward
or away from the column.
Adjustable Table Stops (C, Fig.6) - locatedon
table front. Adjust to stop table at any setting along
the longitudinal axis.
Table Locks (D & E, Fig.6) - longitudinaltable (0,
Fig. 5) locks are located on front of the table. Cross-
feed table locks (E, Fig.6) are locatedon the right
side under the table. Turn clockwiseto lock.
Depth Stop (A, Fig.7 - JMD-18) or (A, Fig.8- JMD-
15) -located on the left side (JMD-15)or center
(JMD-18) of the quill assembly. Set knurlednuts
(JMD-15) or turn knurled knob (JMD-18) or set the
depth stop on the power down feed assembly (JMD-
18PFN) to desired depth for repetitivedrillingto the
same depth.
Downfeed Handle (8, Fig. 7) - locatedon the right
side of the head casting. Counter-clockwise
movement advances the quill toward the table.
Return spring retracts the handle.
Fine Feed Hand Wheel (C, Fig. 7) - locatedon the
front of the head casting. To activate, turn the power
feed speed range dial to zero and pull the down feed
handles away from the column.
c
Fig. 6
Fig.7
Fig. 8
7

Motor Mount Lock Lever (A, Fig. 9) - located on the
right side of the head casting. Locks and unlocks the
motor mounting plate. Loosen to tension v-belts and
then tighten.
Head Pivot Lock (8, Fig. 9) - located on the right
rear of the head casting. Loosentwo hex nuts to
rotate the head 360°. Tighten two hex nutsto lock
the head.
On-Off Switch (A, Fig. 10)-located on the front of
the head casting. Turns power on and off to the
mill/drill.
Quill Lock Handle (8, Fig. 10)- locatedon the front
left of the head casting. Turn clockwise to lock the
quill inthe desired position. Turn counter-clockwise
to release.
Head Elevating Crank Handle (A, Fig. 11)- located
at left rear of head casting. Loosen head pivot lock
nuts (8, Fig.8) and turn handleclockwiseto raise
head on the column and counter-clockwiseto lower
head.
Fig. 9
Fig. 10
Fig. 11
8

Operation
Changing Spindle Speeds
1. Disconnect the machine from the power
source.
2. Release two catches on the belt cover and open.
3. Loosen the motor mount lock lever(A, Fig,9)
and pull the motor toward the head casting to
release tension on the v-belts.
4. Arrange the v-belts on the pulleysfor the desired
speed according to the speed chart on the inside
of the belt cover.
5. Tension the v-belts by pushingthe motor away
from the head casting and lockingthe motor
mount lock lever.
Arbor Replacement
1. Disconnect machine from the power source.
2. Release latches on belt cover and open.
3. Hold the spindle pulley (A, Fig. 12)with one
hand (to keep the pulley from moving)while
loosening the drawbar (8, Fig. 12)with the other
using a wrench. Fig. 12
9

4. Loosen the drawbar approximatelythree to four
full turns.
5. Tap the drawbar headwith a rubbermalletto
dislodge the arbor.
6. Grasp the arbor with one handwhile loosening
the draw barwith the other. Continueto loosen
the drawbar untilthe arbor can bewithdrawn
from the spindle.
7. Place the new arbor into the spindle nose.
Thread the drawbar into the arbor and tighten
the drawbar with a wrench while holdingon to
the spindle pulley.
drawbar!
etween pull
Gib Adjustment
After a period of time, movementof the table over
the ways will cause normalwear. To adjust the gibs
for this wear:
1. The horizontal gib adjustmentscrew (A, Fig. 13)
is found to the righton the tableface. The
traverse gib adjustment (8, Fig. 13)screw is
found on the rightside of the saddle under the
table.
2. Turn each screw slightly clockwiseto tighten.
Turn the table handwheels and check the
tension.
3. Re-adjust as required. Fig. 13
10

Power Feed Operation (JMD-18PFN only)
1. Set the power feed speed rangedial (A, Fig. 14)
to the desired rate.
2. Set the depth stop to the desired setting by
lowering the quill to the desired depth and
holding in place. Turn the collar (8, Fig. 14)
counter-clockwise until zero is indicatedand
then tighten the lock handle (C, Fig. 14)
3. Start the mill/drill and pull one of two handles(D,
Fig. 14) away from the column to start the power
downfeed.
4. Once the downfeed has reachedthe depth stop,
the trip will release and the spindle will retract.
5. To stop the feed before the cycle has ended or
to disengage the fine feed (E, Fig. 14), press one
of two handles toward the column.
Note: For best results, all milling operations
should be done with the quill/spindle as close to
the head assembly as possible. Lock spindle
and table in place before starting milling
operations.
Fig. 14
11

......
I\.)
73
74
d
57
c..
3:
c
I
~
CJ'I
:::I:
CD
Q)
c.
»
III
III
CD
3
c-
o<:
70
8611
87 19 :17
87A
20-L.I. I 21

Parts List for the JMD-15 Mill/Drill
Head Assembly
Index Part
No. No. Description Size Qty.
1 JMD15-001"""""'"'''''''''' Arbor Bolt (drawbar) 1
2 JMD15-002"""""""'"'''''' Spindle Lotk Nut 1
3 JMD15-003 Spindle Pulley 1
5 JMD15-005 Outer Bearing Plate 1
6 JMD15-006 Spindle Taper Sleeve 1
7 BB-6007ZZ... Ball Bearing ...'" """"" 2
8 JMD15-008. Bearing Spacer . 1
9 JMD15-009.. C-Ring 1
10. JMD18-010 , C-Ring ..." "'"'' """'''''''''''''''''''''''''''''''' 1
11 JMD15-011 Head ""'"'''''''' 1
12 ... JMD15-012 Rubber Flange 1
13 JMD15-013 Feed Base 1
14 JMD15-014 Lock Nut """" 2
15 BB-30205 Taper Roller Bearing 1
16 JMD15-016 Rack Sleeve """'"'''' 1
17 JMD15-017 Spindle Shaft"""'''''''''''''''''''''''''''''''''''''''''''' 1
18 BB-30206 Taper Roller Bearing 1
19 . .JMD15-019 Bearing Cap ...1
20 JMD15-020 CuttingArbor """"""""'''''''''''''''''''''''''''''''''' 1
21 JMD15-021 ChuckArbor 1
22 ...JMD18-022 """ Handle """"""""""""""""""""""""" 1
23 JMD15-023 Retainer Ring """""""""" 1
24 JMD15-024 Lock Handle 1
25 JMD15-025 """"'"'''''''''''' Fixed Collar """""'"'''''''''''''''' 1
26 JMD15-026 Fixed Collar Thread f
27 JMD15-027 Screw Key 3/8 1
35 JMD18-035 Bearing Spacer """""'" """"""" ... 1
38 JMD18-038 """""" Lock Bolt wi Knob """"""""""'" 1
39 JMD18-039 Handle Rod '" """""""""""'" ""'" ... ..3
40 JMD18-040 Knob ... ...""""'" 3
42 JMD18-042 Feed Handle WheeL 1
44 JMD18-044 Micro Adjusting Indicator 1
45 ...JMD18-045 ... Worm Cover """'" "" ... ..1
46 BB-62022 Ball Bearing 2
47 JMD18-047 "'"'''''''''''''''''' Worm Shaft 1
51 JMD18-051 Leaf Screw 1
52 JMD15-052 Head Lock Bolt """""""""""'"'''''''''''''''''''''' 1/2x7 2
54 JMD15-054 Graduated Rod and DiaL 1
55 JMD15-055.. Graduated Dial(re:JMD15-054) '"'''''''''''' 1
56 JMD15-056A Switch """""""'''''''''''''''''''' 1
57 JMD15-057 Name Plate 1
58 JMD15-058 Head Handle 1
59. JMD15-059 """""'" """"" Worm Shaft 1
60 JMD15-060 '"'''''''''''''''''''' Worm 1
61 JMD15-061 Shaft 1
62 JMD18-062 Compression Spring 1
13

63 JMD15-063 Pin """"""""""""""""''''''''''''''''''''''''''''''''', 1
66 JMD15-066 """""""" Motor Mount ""'"'''''''' """"" 1
67 ... JMD15-067. Motor "'''''''''''''''''''''''''''''''''' 1
JMD15-067A ""'"'' Capacitor (Not Shown) 1
69 JMD15-069 Belt Cover (ser.#8040225 and lower) 1
JMD15-069P Belt Cover (ser.#8040226and higher) 1
69-1 JMD15-069A Upper Belt Cover Cap (ser.#8040225and lower) 1
JMD15-069P1 Upper Belt Cover Cap (ser.#8040226 and higher) 1
69-2 JMD15-069B Upper Belt Cover Plate (ser.#8040225 and lower 1
JMD15-069P2 Upper Belt Cover Plate (ser.#8040226 and higher) 1
70 JMD15-070 Motor Pulley """" 1
71 VB-A31.., V-B.elt 1
72 BB-62042 Ball Bearing... .. 2
73 .JMD15-073 Inter Pulley .. 1
74 VB-A38 V-Belt 1
75 JMD15-075 Inter Pulley Shaft (ser.#8040225and lower).. 1
JMD15-075P Inter Pulley Shaft (ser.#8040226 and higher). 1
76 JMD15-076 Speed Change Inter Pulley Base (ser.#8040225 and lower) 1
JMD15-076P Speed Change Inter Pulley base (ser. #8040226 and higher) 1
79 JMD18-079""""'"'''''''''''' Rubber Collar 1
85 """ ..JMD18-085 ScrewwI PlumbKnob 1
86 . JMD15-086 Cutter . 1
JMD15-086A Cutter Insert (not shown).. 4
87 .. ..JMD15-087.. Drill Chuck """"""""""'''''''''''''' 1
87A JMD15-087A Chuck Key "'"'' 1
90 JMD15-090 Tap Screw 2
103 JMD18-103 Spring Cover 1
104......JMD18-104 Spring 1
105......JMD18-105... ,... Spring Base """"""""""""""""""'" 1
106 JMD15-106"'"'''''''''''''''''' Pinion Shaft ,.. : 1
107 .JMD18-107... Worm Gear 1
108 .JMD18-108. Feed Cover 1
110 JMD18-110 Spring Base 1
115 JMD18-115 Spring """"""""'''''''''''''''''' 1
122 JMD18-077 Clip Plate""""'''''''''''''''''''''''''''''''''''''''''''''''' 1
131 TS-081B12 Pan Head Screw 1/4x1/2 5
132 TS-068OO21... , Washer 1/4 5
133 JMD18-133 Round Head Screw 1/4x3/8 3
134 TS-005OO91 Hex Head BoiL 1/4x2 1
135 TS-0561011 Hex NuL "'"'''''''''''' 1/4 1
136 TS-0561051 "... Hex NuL... 1/2 2
137 JMD15-137 '"'''''''''''''''''''' lock Washer 1
138 ..JMD15-138 Rivet 2
139 JMD18-139 Round Head Screw 3/16x3/4 3
140 JMD18-140 Spring Pin " 3x12 2
141 1S-0561031 Hex NuL 3/8 3
142 JMD18-142 Key 7x7x20 1
143 1S-0208041 Hex Socket Cap Screw 5/16x3/4 2
144 TS-0680021 Washer "'"'''''''''''''''''''''''''''''''''''''''''''''''''''''' 1/4 1
145 TS-0270021 Set Screw 5/16x5/16 3
146 TS-0267031 Set Screw 1/4x5/16 1
147 JMD18-147 ". RoundHeadScrew 3/16x1/2 2
148 .JMD18-148 "... C-Retainer Ring ..". 1
150 TS-0561051.. Hex Nut. 1/2 2
14

151 TS-0680061 Washer 1/2 2
152 JMD15-152 RoundHeadScrew 1/4x3/8 6
153 TS-0271061 Set Screw 3/8x5/8 1
154 TS-0561071 Hex NuL 5/8 2
155 TS-0680031 Washer 5/16 8
156 TS-0051051 HexHeadBoiL 5/16x1 4
157 TS-0060011 HexHeadBolt 3/8x1/2 2
158 TS-0561021 HexNuL 5/16 4
159 JMD18-159 Key 7x7x40 1
160 TS-0051071 HexHeadBoiL 5/16x1-1/2 2
161 TS-0680031 Washer 5/16 :2
164 JMD15-164 RoundHeadScrew M3x15 2
187 TS-0680011 Washer 1/4 2
188 JMD18-188 PanHeadScrew 3/16x3/8 1
208 TS-0561031 Hex NuL 3/8 1
15

JMD-15 Table, Base, and Column Assembly
Ie
=ClIO
..
16

JMD-15 Table, Base, and Column Assembly
1 JMD18-201 Table Hand Wheel 3
1-1 . JMD18-201-1 Bolt 3
1-2 JMD18-201-2 Handle 3
1-3 JMD18-201-3 Nut 3
2 JMD18-202 Dial Clutch 2
2-1 .JMD18-202-1 Graduated Dial ... 2
3 BB-51103 Thrust Bearing ... ... 4
4 JMD15-204 Square Flange 1
4-2 ...JMD18-204-2 Rivet 4
5 JMD15-205 Table Screw 1
6 ...JMD15-206.. ... Base ... .. ... 1
7 .JMD15-207 Gib Strip 1
8 JMD15-208 Column Base """"""'"'''''''''''''''''''''''''''''''''''' 1
9 JMD15-209 Column Flange Ring 1
10 .JMD15-21 0 Rack 1
11 JMD15-211 Column Head 1
12 JMD15-212 Adjustment Screw 2
13 JMD15-213 Leaf Screw 2
13-1 JMD15-213-1 Locking Handle 2
14 ..JMD15-214 Block. ...... 1
15 JMD15-215 Table Base Nut... 1
16 JMD15-216 Center Base 1
17 JMD15-217. Antidust Plate.. ...... ...... 1
19 JMD18-219 Bracket Plate 1
20 .JMD18-220 Table Clutch 1
22 JMD15-222 Left Flange 1
23 JMD18-223 Table Nut 1
24 JMD15-224 Table Screw 1
26 JMD15-226 Right Flange 1
27 JMD15-227 ...... Gib Strip. ... ... ...... ... ... .. 1
28 JMD15-228 Table 1
29 JMD18-229 Block 2
30 JMD18-230 Ring 2
121 JMD15-121 IndicatorPlate 2
143 TS-0207021 Hex SocketCap Screw 1/4x1/2 2
145 TS-0270021 Set Screw 5/16x5/16 1
166 .JMD18-366 Spring Pin 3
167 JMD18-367... Zero Indicatorw/ Screw 1/4x3/8 2
168 JMD18-368 Oil Ball 5
169 TS-0208041 HexSocket Cap Screw 3/8x3/4 8
175 TS-0061071 Hex Head Bolt 7/16x2 4
178 TS-0208111 HexCap Bolt 5/16x2-1/4 1
179 TS-0051011 HexCap Bolt 5/16x1/2 6
180 TS-1502041 Hex SocketCap Screw , M5x16 2
189 TS-0267041... Set Screw.. ... ... '... 1/4x3/8 3
JMD15-AP Accessory Package (Not Shown) * 1
17

*Contents of the Accessory Package (JMD15-AP):
..JMD15-020 ... ... Cutter Arbor .., """'" '" 1
.. .JMD15-039 .." Handle """"""""""""""""""""""'''''''''''''''' . 3
JMD 15-040 Knob 3
JMD15-087 Drill Chuck 1
.. ...JMD15-086 Cutter '''' """""""""""'"'' """"""'" 1
.365534 Angle Vise "'"'''''''''''''''''''''' """'"'''''''' """"'" ""'"'''''''' ...1
.. ..JMD15-022 Handle , '''''''''''''''''' 4
.JMD15-201 """"""'"'''''''' Wheel """'''''''''''''''''''' 3
.JMD15-058 Handle Crank """'" ""'"'''''''' 1
MP-007 Paint '"'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''' 1
TS-152704 3mm Hex Wrench """""""' ,.1
TS-152705 4mm Hex Wrench '"'''''''''''''''''''''''''''''''''''''''' 1
TS-152706 5mm Hex Wrench 1
.., ..JMD15-381 Washer ... ...1
..JMD15-380 Hex Bolt. """ """ .... ... 1
JMD15-377 Hex Bolt 2
JMD15-378 Hex Nut "'" 2
JMD 15-379 .., Washer 2
MP-007 Touch Up Paint 1
TS-0071 011 Hex Cap BoiL " """'" ""'''' 5/8x1-1/2 3
... TS-0680081 ...""""'"'''''''' Flat Washer .." 5/8 3
. ..TS-0561 071 Hex Nut ... 5/8 ., 3
18
