Jet Bench JDP-12 User manual

Features
PORTABLE
■
•Combination benchtop jointer & planer provides a 2 in 1 machine to maximize workspace
■
•Compact benchtop design ts conveniently in smallshop environments
■
•Integrated cord wrap makes transporting easy and ensures workshop safety
POWERFUL
■
•Heavy-Duty 13 Amp motor for various cutting applications
■
•Two high speed steel knives for precise, smooth cuts
■
•Oversized, ergonomic knobs provide ease of use andmaximum control
PRECISE
■
•Large aluminum extruded fence makes joining stable and precise
■
•Sheet metal outfeed table with height adjustment supports long workpieces and helps
reduce snipe
■
•Planing and joining tables lock to ensure precision cutting
■
•Precision machined table top ensures a smooth, straight cut
Large aluminum extruded fencea.
Sheet metal outfeed table with b.
height adjustment
Planing and joining tables lockc.
Precision ground table topd.
Oversized, ergonomic knobse.
Integrated cord wrapf.
C FB
SPECIFICATIONS
Stock Number 707400
Model Number JJP-8BT
Motor 120V, 60Hz, 13Amp
Knife Size (in.) 8.25 x .65 x .06
Number of Knives (RPM) 2
Cutting Speed 9,000
Cuts Per Minute CPM 18,000
Feed Speed FPM 19.5
Max. Cutting Width (in.) 8
Jointer Max. Cut Depth (in.) 1/8
Planer Max. Cut Depth (in.) .08
Cutting Thickness (in.) .20 - 4.92
Jointer Table Size (LxW/in.) 29 x 8-1/4
Planer Table Size (LxW/in.) 10-5/8 x 8-1/2
Planer Table with Out feed (LxW/in.) 17-3/4 x 8-1/2
Fence Size (LxW/in.) 4-1/8 x 21
Fence Tilt (deg.) 0-45
Gross Wt. / Net Wt. (lbs.) 68.3 / 58.4
jettools.com/b3nch
HEAVY-DUTY B3NCH™
12" VARIABLE SPEED
DRILL PRESS
When is a Drill Press powerful enough to tackle the big jobs, and portable enough to do it
anywhere? When it's the all-new JET®B3NCH 12" Variable Speed Drill Press. A powerful 1/3 HP
induction motor that pushes through almost anything you throw at it; over 3-1/8" spindle travel for
maximum depth cutting, and our innovative X-shaped XACTA Laser that ensures drilling accuracy;
makes this workhorse the best choice for in your shop or on the go.
THE WOODWORKERS
•
CHOICE FOR
PRECISION
TOOLS
C
D
E
Features
PORTABLE
■
•Compact benchtop design allows for easy transport to different shop locations
■
•11–1/2"x16–1/2" cast iron base ts neatly on workbenches with limited space
■
•Stable base design allows for easy re-positioning on workbench
POWERFUL
■
•Heavy-Duty 1/3 HP induction motor for various drilling applications
■
•Mechanical variable speed drive system for easy speed changes
■
•Industrial 5/8" drill chuck for multiple drilling applications
■
•Oversized, ergonomic knobs provide ease of use and maximum control
PRECISE
•
■
•X-shaped XACTA Laser™ ensures drilling accuracy
■
•Digital readout displays spindle speed for different drilling applications
■
•LED worklight increases visibility for intricate applications
■
•Retractable roller extension provides support and quick workpiece adjustment
■
•Large paddle switch provides easy shutoff and lockout protection
■
•Clear linear scale with depth stop for consistent drilling depths
SPECIFICATIONS
Stock Number 707300
Model Number JDP-12
Motor 120 V, 60 Hz
Horsepower 1/3 HP
Spindle Travel (in.) 3.15
Max. Drilling Capacity (in.) 5/8
Chuck Size (in.) 5/8
Swing (in.) 12
Spindle Taper MT-2
Table Size (LxW/in.) 9-1/2 x 9-1/2
Base Size (LxW/in.) 11-1/2 x 16-1/2
Table Size with extension (LxW/in.) 9-1/2 x 16-1/2
Speed Range (RPM) 530 – 3100
Net Weight / Gross Weight (lbs.) 88.2 / 92.6
Mechanical variable speed drive systema.
X-shaped XACTA Laser™ b.
Digital readoutc.
LED work lightd.
Industrial 5/8" drill chucke.
Clear linear scale with depth stopf.
F
B
A
PRECISION LASER SYSTEM
