Jfopt JF954MM-2 User manual

User Manual
Fast Ethernet Optical Switch
(1 Fiber Port and 4 UTP Ports)
Brief Introduction
Many thanks for purchasing our fiber optic equipment,
this fiber switch supports IEEE802.3U/100Base-Tx/Fx
protocol, as well as 10/100M auto-negotiation full
duplex and half duplex. The following purchasing guide

is for customer's reference.
Model
Specification
JF954MM-2
10/100M,dual fiber,multimode 2km,SC
JF954SM-25
10/100M,dual fiber,single mode 25km,SC
JF954SM-40
10/100M,dual fiber,single mode 40km,SC
JF954SM-60
10/100M,dual fiber,single mode 60km,SC
JF954SM-80
10/100M,dual fiber,single mode 80km,SC
JF954SM-100
10/100M,dual fiber,single mode 100km,SC
JF954SM-120
10/100M,dual fiber,single mode 100km,SC
JF954SM-25A
10/100M,single fiber,single mode 25km,SC
JF954SM-25B
10/100M,single fiber,single mode 25km,SC
JF954SM-40A
10/100M,single fiber,single mode 40km,SC
JF954SM-40B
10/100M,single fiber,single mode 40km,SC
JF954SM-60A
10/100M,single fiber,single mode 60km,SC
JF954SM-60B
10/100M,single fiber,single mode 60km,SC
Packing List
When you unpack this product package, you will find the
items listed below:

Fiber Switch 1 piece
AC/DC5V1A Adapter 1 piece
Copy of user manual 1 piece
Installation
1. Interface
RJ-45 Interface
RJ-45 Connector supports CAT5 twisted-pair with typical
length of 100 meters. It features the function of
MDI-MDIX through parallel lines.
Fiber Interface
SC/ST fiber interface is of 100M full-duplex mode,dual
fiber(TX and RX)should be cross-connected(TX-RX,
RX-TX),direct connection for single optical fiber when
the transmitter and receiver are interfaced or connected
to switch with fiber interface.
Connection

The network device(work station,hub or switch) with
RJ-45 interface is connected to RJ-45 jack of optical
transceiver through twisted-pair,and the
multimode/single mode fiber is connected to SC/ST fiber
interface of the optical transceiver.Then switch on, the
corresponding LED is on for correct connection.(See the
table below for the LED indicator lamp)
Figure 1 Schematic drawing of connection
Explanation for LED indicator lamp
LED indicator lamps serve as device monitoring and
trouble display.The following sheet is the explanation
for each LED indicator lamp.

Transmission Characteristic
LED
indicator
lamp
Statu
s
Explanation
SFP
On
Fiber link is in correct connection
Blink
Packet goes through FX end
TX
Link/Act
On
Electric link is correct
Blink
Packet goes through TX end
PWR
On
Power is on and normal
Model
Optical
wavelengt
h
(nm)
Tx
Power
(dBm)
Receiving
Sensitivit
y (dBm)
Distance
(KM)
JF954MM-2
1310
-22~-12
≤-30.0
≥2
JF954SM-25
1310
-15~-8
≤-38.0
≥25
JF954SM-40
1310
-8~-3
≤-38.0
≥40
JF954SM-60
1310
-3~0
≤-38.0
≥60

Main Features
1.In conformity to IEEE 802.3 10Base-T standard.In
conformity to IEEE802.3u 100Base-TX/FX standard.
2.Support 1k MAC address.
3.Back pressure flow control for full duplex IEEE802.3X
and half duplex.
JF954SM-80
1550
-5~0
≤-38.0
≥80
JF954SM-100
1550
≥-1
≤-38.0
≥100
JF954SM-120
1550
≥1
≤-40.0
≥120
JF954SM-25A
1310/1550
-15~-8
≤-36.0
≥25
JF954SM-25B
1550/1310
--8~-3
≤-36.0
≥25
JF954SM-40A
1310/1550
-8~-0
≤-36.0
≥40
JF954SM-40B
1550/1310
-8~0
≤-36.0
≥40
JF954SM-60A
1310/1550
-3~0
≤-36.0
≥60
JF954SM-60B
1550/1310
-3~0
≤-36.0
≥60

4.Automatic identification of MDI/MDI-X cross line.
5.Support max forwarding package length 1552/1536
bytes option.
6.In conformity to safety code of FCC and 15 CLASS A
and CE MARK.
Technical Parameters
Support IEEE 802.3z/AB 100Base-T/SX/LX/ZX
1.Connector: 4 UTP RJ45 connector, 1 SC/ST/FC
connector.
2.Operation model: full duplex mode or half duplex
mode.
3.Power supply parameter:
Outside: DC 5V1A
Built-in: 110-265V AC or 48V DC.
4.Operating environmental temperature: 0℃~60℃.
5.Relative humidity: 5%~90%.
6.TP cable: Cat5 UTP cable.
7.Transfer fiber:
multimode: 50/125, 62.5/125 or 100/140μm
single mode:: 8.3/125, 8.7/125, 9/125 or 10/125μm
