Jiawen Electronic Technology JW-X3000 User manual

— I —
MANUAL MS-X3000 dual cam GPS
Besides general functions of the recorder, this machine has three new
main features:
(1) Built-in double lens can be used to take two images at front and
back at the same time;
(2) Newly added PS module can record the whole driving track.
Using random specialized software, you can see the video at computer,
at the same time connect oogle map through the Internet. Driving
track shows on the map and you can trace the running route of the
vehicle.
(3) Built-in gravity sensor -Sensor can record the gravity sensing
information. Using random specialized software, you can see the
video at computer, at the same time read the gravity sensing data to
trace accident and abnormal circumstance occurred in the running
process.
In order to maximize the performance of the recorder, please read this
instruction manual carefully before use (This machine and accessories
for the design and specifications are subject to change without prior
notice).

— II —
Content
Product Structure …………………………..
Begin to use travelling recorder …………………………..
Battery Charging ………………………..
Insert a memory card ………………………...
Adjust the positions of the lens ………………………..
Turn on and turn off ………………………..
Basic operations of the travelling recorder …………….…...
Change operating mode ……………………………
Setup menu ………………………………..
System setting ………………………………..
How to shoot ………………………………..
Start / Stop shooting …………………………………
Open / Close audio …………………………………
Video playback and file management…………………………..
Video playback …………………………….
Computer access to the machine file………………………..
Reset of this machine ………………………………..
Product characteristics ……………………………….
Technical Specifications ………………………………..
Accessories list ………………………………..

— 1 —
Product Structure

— 2 —

— 3 —
Begin to use travelling recorder
Battery Charging
There are two methods for battery charging:
1 Using USB line to connect the machine with the computer for
charging;
2 Using accessory vehicle-mounted power source for charging.
In the whole process of charging, charging indicator lights up in red.
When the charging is finished, indicator automatically extinguishes.
The whole charging process takes about 240 minutes.
Insert a memory card
Insert TF (Micro SD) memory card straightly into the slot in
accordance with the indicating direction on the machine body until
hear a “Ka" sound.
Remove card: Push the TF card inside and the card will pop up. Then
you can remove.
Notice
When using the memory card for the machine for the first time, since
the format of the memory card is not compatible with the machine,
you must use the machine or attached tool software ( ) to
format the memory card (The formatting of the memory card by
computer is not supported). Formatting will permanently delete all the
data on the memory card, including the protected image, which can
not be restored. Therefore, before formatting the memory card, please
back up important data.
If you can't use the machine to format the memory card format, please
use attached software ( ) on a computer.

— 4 —
Adjust the positions of the lens
The front lens of this machine can be turned 20 degrees up and down
in order to better meet the recorder fixed position and get better
shooting.
Turn on and turn off
Turn on: press power supply once for a relative long time until red ON
indicator lights up.
Turn off: press power supply once more time for a relative long time
until red ON indicator extinguish.
Notice
When in low battery, the travelling recorder will prompt automatic off
because of low battery.
Basic operations of the travelling recorder
Change operating mode
This machine has two operating modes：pickup and playback。
Press MODE button to change between them。
Setup menu
Press MENU button to enter MENU page，now the column of “Menu
setting” is in blue background.
In the menu setting page, click left and right keys to select the
required setting fields; click "OK" button to accept the settings, again
presses the MENU key to exit the menu.
System setting: You can make system setting in framing preview
mode.
Video mode: double lens /front lens /back lens;
Time setting: press left and right keys for time adjustment; press OK
key to confirm and exit;

— 5 —
Formatting: press the OK key to enter and select Yes/No;
Video format: NTSC/PAL setting;
Voice: On/Off;
Recording: On/Off;
Language: English / erman / French / Spanish / Italian / Portuguese /
Traditional Chinese / Simplified Chinese/ Japanese
Screen preset: On/Off;
Automatic video protection sensitivity: low / general / high /
automatically turn off video protection function (This function set
gravity sensor to start up automatic video recording sensitivity).
Frequency: 50HZ / 60HZ.
How to shoot
Start / Stop shooting:
In the shooting mode, press OK key to start shooting, then press OK
key again to stop shooting.
When the traveling recorder is on or insert a memory card, it will
automatically start shooting.
Open / Close audio:
During video recording process, pressing left key can fast open / close
audio in the video.
Video playback and file management
Press MODE key to enter playback mode and now the screen shows
playback picture of the last video file.
Video playback:
Press left and right buttons to select audio and video files need
playback.
Press OK key for play and pause of the video file.
Computer access to the machine file
This machine does not support USB protocol. Computer access to the

— 6 —
recorded file of this machine can be done by a device supporting IF
card (such as a card reader).
When the machine insert memory card and complete formatting for
the first time, it will automatically generate specialized software tool
( ) in the memory card. Computer access to the file of the
machine must be done via this tool.
Notice
(1) For easy use and to avoid abnormal circumstance of the storage
card causing software tool damage, it is recommended to backup the
tool on computer.
(2) The computer operating system must be Windows 2000 / XP /
Vista / Windows 7, MAC OS x above 10.3.6.
Usage of the software ( )：
1. Use card reader to read video information on the TF card.
In TF card disk under “my computer”, the user can see three files:
ap.bin、Default_Folder.ini and .
2. Run .
3. Open the player to play video documents.
Click to open the player.
Select TF Card disk path, then click the “apply" to load and
automatically play the document in the card.
Clicking the ActiveX can control playing state:
from left to right can realize: slow turning / stop / play (pause) / fast
turning.

— 7 —
4. Select double lens channel：
Clicking the ActiveX can select double lens channel of
video playing: double lens / front lens / back lens.
5. Video on file:
Select video file for save and click to pop up saving file
path picture. After selection, click “sure" to save the selected file.
6. Photo on file：
Select image photo for save and click to pop up saving file path
picture. After select the path, click the "save".
7. Delete document：
Select the video file not needed and click . Appear
“sure/ cancel" options, select “Sure" to delete the selected video file.
8. Kit：
Kit can proceed as follows: SD card formatting / upload software to
the SD card / SD card speed test / map selection and user password
setting.
Click to enter the kit.
9. oogle map：

— 8 —
Click ，and the computer will connect to oogle map via
Internet and show travelling path on the map. You can trace the
travelling path of the vehicle.
10. ravity sensor：
Click ，watch the video on the computer, at the same time read
and display the gravity sensing data, trace accident and abnormal
circumstance occurred during the driving process.
11. Other operations:
Click respectively from left to right, and following
operations can be realized: repair film / unlock protection / choose to
display size.
Reset of this machine
When abnormal circumstance occur due to improper operation, you
can press reset button and then restart the machine, now the machine
can return to normal.
Product characteristics
—Ultra small volume; the front lens with ultra wide angle of 140
degrees can be rotated up and down 20 degrees; the back lens with

— 9 —
ultra wide-angle of 120 degrees high resolution; this perfect modular
design is more convenient for various angle and high resolution video
shooting.
—Built-in 1/4 inch low-noise and high-quality photographic element
can capture ultra clear picture in a dark place.
—Built-in lithium battery with charging and meanwhile recording
function.
—Built-in microphone/speaker.
—Support high-capacity Micro TF Card
—Automotive turning on and recording function when the vehicle
start.
—With a delayed start function to prevent transient pulse current
damage machine at the moment the vehicle start.
—PS scanning and positioning。
—ravity induced SENSOR
Technical Specifications
LCD screen size 2.7 “（16：9）
Lens
Front lens with ultra wide angle of 140 degrees;
back lens with ultra wide-angle of 120 degrees
Optional
language
English / erman / French / Spanish / Italian /
Portuguese / Traditional Chinese / Simplified
Chinese/ Japanese
Video format AVI
TF memory card
slot
Micro TF
Microphone /
speaker
Built-in
Television output NTSC/PAL
TV output and
DC access 5V 500MA
Battery Built-in lithium polymer battery

— 10 —
System
requirement
Windows 2000/XP/Vista/Windows 7,MAC OS x
above 10.3.6
Note we reserve the modification right of the machine design and
specifications without notice.
Accessories list
1. Vehicle-mounted power supply; 2.TV line; 3.Vehicle mount; 4. PS
module; 5. Specification.
