Jilong PSS-14-GB User manual

1
2013
PSS-14-GB
POOL SURFACE SKIMMER
USER'S MANUAL

2013
2 3
PSS-14-GBwww.jilong.com
PSS-14-GBwww.jilong.com
Warnings / Safety Rules
Please read the following instructions carefully before use.
1. This product tends to be used by adults only.
2. Power off your lter pump before assembling, adjusting, removing or cleaning this
appliance.
3. Strong suction may be hazardous and result in body entrapment.
4. Keep your ngers & hair off this appliance, also keep away from the basket opening
while the lter pump is operating.
5. Do not operate the lter pump and be sure to remove all the maintenance kits when
pool is in use.
CAUTION: Failure to follow these warnings may result in property damage, electric
shock, drowning or serious injury. Always use common sense and good judgement
when enjoying any water activity.
Features
1. Simple installation and maintenance.
2. Designed for above ground pool use. Helps to catch leaves and other debris before
they sink to the bottom of the pool.
3. Adjustable ttings to be mounted on portable pools and can be attached to the lter
pump system for automatic skimming.
4. Reusable strainer basket can be removed for easy cleaning.
5. Durable, oxidization resistance plastic materials not affected by pool chemicals.
6. Low cost on maintenance and labor.
7. Compatible with 1,200 liter/h (300gal) ow rate and above lter pumps.
8. Compact size for easy storage.
9. Optional 38mm diameter PE hose available.
Parts List
ITEM NO DESCRIPTION QUANTITY
P01 Trap Body 1
P02 Align Handle (For Inatable Pool only) 1
P03 Clutch Handle (For Inatable Pool only) 1
P04 Hose Adaptor 1
P05 Rubber Retainer 4
P06 Skimmer Strainer 1
P07 Skimmer Top 1
P08 Frame Hanger (For Frame Pool only) 1
P09 Screw Set (Plastic Ladder, For Frame Pool only) 1
P10 Screw Set (Screw, For Frame Pool only) 1
P11 Skimmer Hose (Dia. 32mm, 70cm) 1

2013
4 5
PSS-14-GBwww.jilong.com
PSS-14-GBwww.jilong.com
Step 1:
(1) Unlock the Handle Lock from the Trap Body (P01)
as indicated.
(2) Insert and lock the Align Handle (P02) to the Trap
Body (P01) at the desired position.
Step 5:
Place the Skimmer Strainer (P06), which has already
assembled with Skimmer Top (P07), into the Trap
Body (P01). Gently push downwards and immerse the
Skimmer Strainer (P06) until it is well in place.
Step 2:
(1) Connect one end of the Skimmer Hose (P11) to the
bottom of the Trap Body (P01).
(2) Connect the other end of the Skimmer Hose (P11)
to the Hose Adaptor (P04) as shown.
Note:
Ensure the Strainer Top (P07) is floating parallel
against the water surface at all time and should be
oating perpendicularly off the Trap Body (P01). Adjust
the surface skimmer position if necessary.
Step 4:
Secure the Skimmer Hose (P11+P04) properly to the
water outlet and adjust the height of the Trap Body
(P01) to a 2 cm lower than the water level.
Step 7:
Connect the lter pump to an electrical outlet, and it is
set to work. Enjoy !
Step 3:
(1) Place the assembled unit over the top of an
inflatable pool top ring near the water outlet (that is,
the lower hose connection to the lter pump’s inlet).
(2) Assemble the hook unit as shown -- press and
slide the Clutch Handle (P03) into the Align Handle
(P02), then adjust the handle unit to be snug around
the inflatable ring. Make sure the handle is securely
tightened over the pool.
Step 6:
Lastly, refer to the filter pump system picture as
shown. You can now start setting up the Filter Pump
by following the owner’s manual.
Assembly for inatable pools with inatable top rings
Note: if you are using METAL FRAME POOL, GO TO PAGE 6

2013
6 7
PSS-14-GBwww.jilong.com
PSS-14-GBwww.jilong.com
Step 1:
(1) Unlock the Hanger Lock from the Trap Body (P01)
as indicated.
(2) Insert and lock the Frame Hanger (P08) to the Trap
Body (P01) at desired position.
Step 5:
Place the Skimmer Strainer (P06), which has already
assembled with Skimmer Top (P07), into the Trap
Body (P01). Gently push downwards and immerse the
Skimmer Strainer (P06) until it is well in place.
Step 2:
(1) Connect one end of the Skimmer Hose (P11) to the
bottom of the Trap Body (P01).
(2) Connect the other end of the Skimmer Hose (P11)
to the Hose Adaptor (P04) as shown.
Note:
Ensure the Skimmer Top (P07)) is oating parallel
against the water surface at all time and should be
oating perpendicularly off the Trap Body (P01). Adjust
the surface skimmer position if necessary.
Step 4:
Secure the Skimmer Hose (P11+P04) properly to the
water outlet and adjust the height of the Trap Body
(P01) to a 2 cm lower than the water level.
Step 7:
Connect the lter pump to an electrical outlet and it is
set to work. Enjoy !
Step 3:
(1) Place the assembled unit over the top of a FRAME
Pool Top Beam near the water outlet (that is, the lower
hose connection to the lter pump’s inlet).
(2) Adjust the Frame Hanger (P08) by fastening the
Screw Set (P09 Plastic Ladder + P10 Screw) to be
tight on the top beam. Make sure the Frame Hanger
(P08) is securely tightened over the pool.
Step 6:
Lastly, refer to the filter pump system picture as
shown. You can now start setting up the Filter Pump
by following the owner’s manual.
AAssembly for Metal Frame Pools
Note: if you are using INFLATABLE POOL WITH TOP RING, GO TO PAGE 4

8PSS-14-GBwww.jilong.com
Maintenance & Storage
1. To avoid motor overheating of a lter pump, make sure pool water is always owing
into the lter pump. Also, ensure the surface skimmer is perpendicular to the water
surface and below the water surface. Then open the air release valve located on the
lter enclosure top cover, and close the air release valve when water starts to ow.
2. Periodically check and remove any obstacle from the opening of oating skimmer.
3. Clean regularly of the debris, sediments or leaves that traps in the skimmer basket.
4. Remove the skimmer and hanger from the pool before placing a pool cover.
5. To avoid hazard of electrical shock, always disconnect the power cord from the
electric outlet when disassembling.
6. Clean and air dry all the accessories thoroughly after disassembly. No lubrication or
regular mechanical maintenance is needed.
7. You could take advantage of the original packing carton by storing all the parts for
next season. Store in a dry, cool storage location.
