JL Audio Stealthbox SB-F-EDG2G/10TW1 User manual

INSTALLATION GUIDE
for the
SB-F-EDG2G/10TW1
SKU# 94662
2015 & Up Ford Edge
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox®be properly mounted to the vehicle
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
DIFFICULTY:
ESTIMATED TIME:
23 HOURS
Enclosure Type: Sealed
Driver Type: 10TW1-2
Nominal Impedance: 2 ohms
Continuous Power Handling: 300 watts (RMS method)
Continued on Next Page
35
OUT
OF
SB-F-EDG2G/10TW1 INSTR_SKU# 011507

INCLUDED HARDWARE
Continued on Next Page
Page 2 • JL Audio, Inc., 2018
SB-F-EDG2G/10TW1 INSTR_SKU# 011507
BOM ID Qty SKU Description
1 6 151137 1/4 - 20 x 1” Hex Bolt
2 6 151098 1/4” Split Lock Washer
3 6 151021 1/4” Flat Washer
4 1 53676 Side Bracket
5 2 151164 1/4 - 20 U-Nut
6 1 150223 Top Bracket
7 1 153971 Bottom Bracket
8 1 151094 1/4 - 20 Keps Nut
- 1 152499 Grille Assembly (not shown)
54
321
87
2 31
56
321

POWER RECOMMENDATION
JL Audio recommends high quality ampliers such as the JL Audio XD300/1v2. The diagram below shows the recommended crossover settings for the XD300/1v2. For a detailed description of the
amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
Rem. |Oset | Signal
Input Voltage
Low | High
Turn-On Mode
Monoblock Subwoofer Amplifier
CONNECTIONS
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your
Stealthbox® amplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
both channels of the amplier. JL Audio recommends using 12 AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page
Page 3 • JL Audio, Inc., 2018
SB-F-EDG2G/10TW1 INSTR_SKU# 011507

Page 4 • JL Audio, Inc., 2018 Continued on Next Page
STEP 8
Pictured is the vehicle with the cargo side
panel removed.
STEP 7
Carefully unclip the cargo side panel. Unplug
the cargo light from the backside of the panel,
and remove the panel from the vehicle.
STEP 6
Open the rear door on the passenger’s side.
Carefully unclip and remove the door sill panel.
STEP 5
Remove the cargo sill panel.
STEP 4
Carefully remove the clip from under each side
of the cargo sill panel.
STEP 3
Remove the two foam storage inserts.
STEP 2
Remove the cargo floor panel.
STEP 1
Empty the cargo area, and fold down the rear
seat on the passenger side.
SB-F-EDG2G/10TW1 INSTR_SKU# 011507

Page 5 • JL Audio, Inc., 2018 Continued on Next Page
STEP 16
Align the hole in the short side of the Bottom
Bracket with the hole drilled in the previous
step.
Slide a 1/4” Split Lock Washer and a 1/4” Flat
Lock Washer over a 1/4 - 20 x 1” Hex Bolt, and
pass the assembly through the hole in the
Bottom Bracket and through the drilled hole.
From the back, thread a 1/4 - 20 Keps Nut over
the 1/4 - 20 x 1” Hex Bolt. Align the Bottom
Bracket as shown, and fully tighten.
STEP 15
Remove the factory bolt from the lower
subwoofer mounting location.
This will not be reinstalled.
Measure 1/2” down from the factory hole, and
mark the location. Using a 3/8” drill bit,
carefully drill through the panel.
STEP 14
Install a 1/4 - 20 U-Nut in each of the locations
indicated in Step 13, as shown.
STEP 13
Remove the molded jute panel from behind
the factory subwoofer enclosure location.
Remove the two indicated factory U-nuts from
the vehicle.
These will not be reinstalled.
STEP 12
Remove the factory subwoofer enclosure from
the vehicle.
This will not be reinstalled.
ST E P 11
Using a 10mm socket and wrench, remove the
two indicated factory bolts from the top of the
factory subwoofer enclosure.
These will not be reinstalled.
STEP 10
Using a 10mm socket and wrench, remove the
indicated factory nut at the bottom of the
factory subwoofer enclosure.
This will not be reinstalled.
STEP 9
Note: Steps 9-13 are for vehicles equipped
with a factory subwoofer enclosure. For
vehicles without a factory subwoofer
enclosure, skip to Step 14.
Disconnect the factory subwoofer.
SB-F-EDG2G/10TW1 INSTR_SKU# 011507

Page 6 • JL Audio, Inc., 2018 Continued on Next Page
STEP 24
Pictured is the cargo side panel with the
factory subwoofer grille removed.
STEP 23
Place the cargo side panel on a soft, flat surface
with the rear surface facing up.
Using a grinder, carefully remove the plastic
welds to separate the factory subwoofer grille
(or storage pocket for vehicles not equipped
with factory subwoofer) from the cargo side
panel, using caution to not grind through the
panel itself.
STEP 22
Pictured is the Stealthbox installed in the
vehicle.
STEP 21
Connect speaker cable to the terminal cup on
the side of the enclosure, and route the cable
as necessary.
STEP 20
Slide a 1/4” Split Lock Washer and a 1/4” Flat
Washer over a 1/4 - 20 x 1” Hex Bolt, pass the
assembly through the slot in the Side Bracket,
into the 1/4 - 20 U-Nut, and hand tighten.
Repeat the process for the Top Bracket.
Fully tighten the hardware installed in Steps
17-19, then fully tighten the two 1/4 - 20 x 1”
Hex Bolts.
STEP 19
Place the Stealthbox into position in the
vehicle. Align the slot in the Bottom Bracket,
with the threaded insert in the bottom of the
enclosure.
Slide a 1/4” Split Lock Washer and a 1/4” Flat
Washer over a 1/4 - 20 x 1” Hex Bolt, pass
the assembly through the slot in the Bottom
Bracket, into the threaded insert, and hand
tighten.
STEP 18
Align the hole in the short side of the Top
Bracket with the threaded insert in the top of
the enclosure. Slide a 1/4” Split Lock Washer
and a 1/4” Flat Washer over a 1/4 - 20 x 1” Hex
Bolt, pass the assembly through the hole in the
Top Bracket, into the threaded insert, and hand
tighten.
STEP 17
Align the hole in the short side of the Side
Bracket with the threaded insert in the side of
the enclosure. Slide a 1/4” Split Lock Washer
and a 1/4” Flat Washer over a 1/4 - 20 x 1” Hex
Bolt , pass the assembly through the hole in
the Side Bracket, into the threaded insert, and
hand tighten.
SB-F-EDG2G/10TW1 INSTR_SKU# 011507

Page 7 • JL Audio, Inc., 2018
CONGRATULATIONS!
You have completed the installation for this model! Enjoy your new Stealthbox®!
All specifications are subject to change without notice. “JL Audio®” and “How we play®” are registered trademarks of JL Audio, Inc. “Ahead of the Curve” and its respective logo are trademarks
of JL Audio, Inc.
Printed in USA • ©2018 JL Audio, Inc. • For more detailed information please visit us online at www.jlaudio.com.
[phone]
www.jlaudio.com
JLA-SKU# 011507 • ver. 05.15.2018 • 10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
®
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will t in the factory speaker locations of you vehicle.
Location / OEM
Speaker Size
Suggested JL Audio Speaker Models
Coaxial Models Component Models
Front Doors /
6.5-inch C1-650x, C2-650x, C5-650x C1-650, C2-650, C3-650, C5-650, C7-650cw(2)
Rear Doors /
6.5-inch C1-650x, C2-650x, C5-650x C1-650, C2-650, C3-650, C5-650, C7-650cw(2)
1 - Installation may require adaptor, 2 - Component woofer only
STEP 28
Reinstall the cargo floor panel.
STEP 27
Reinstall the cargo sill panel and the two foam
storage inserts.
STEP 26
Plug in the cargo light, and reinstall the cargo
side panel.
Reinstall the rear door sill panel.
STEP 25
Align the Grille Assembly with the opening on
the front of the cargo side panel. Secure the
Grille Assembly to the panel by turning each of
the retaining clips from the back, as shown.
SB-F-EDG2G/10TW1 INSTR_SKU# 011507
