Jl audio Ps-swmcp User manual

Installation Instructions for all

PS-SWMCP

swivel fixtures for flat surfaces

SURFACE MOUNTING FIXTURES (SWIVEL)

FOR PS650-VEX™ ENCLOSED SPEAKER SYSTEMS

Hand tighten one M6 x 16 mm Socket Cap Machine

Screw and Split Lock Washer to temporarily secure the

Mounting Base to the Fixture Base of the enclosure, as

illustrated.

Place the enclosure at its desired location with the speaker

and Set Screw aimed in the desired direction. Use a pencil

to draw an outline of the Mounting Receiver’s base and

location of the Set Screw on the mounting surface. Next,

while holding the Mounting Receiver with one hand,

rotate and pull the enclosure away to separate it.

Partially thread the M6 x 20 mm Set Screw into the

Mounting Receiver. Align the keys of the Mounting

Base with the keyways in the Mounting Receiver, then

insert fully.

Mark the three mounting hole locations with a pencil,

and drill pilot holes on the marks with an appropriate

drill bit. Install the Mounting Receiver with three #10 x 1”

Flat Head Phillips Sheet Metal Screws. Insert the

Mounting Base into the Mounting Receiver, rotate the

enclosure to the desired position, and tighten the Set

Screw.

•

Remove the fasteners from Step 1, and rotate the Mounting

Base to align with either the next or previous mounting

hole in the Fixture Base. Slide a Split Lock Washer over

each of three M6 x 16 mm Socket Cap Machine Screws,

apply Loctite® Red read Locking Compound to the

screws, and fully tighten into the Fixture Base.

Slide a Split Lock Washer over each of two M6 x 16 mm

Socket Cap Machine Screws, apply Loctite® Red read

Locking Compound, and fully tighten into the Fixture

Base. Repeat for the third fastener. Continue to Step 8.

Align the keys of the Mounting Base with the keyways in

the Mounting Receiver, then insert fully. Aim the speaker

in the desired direction, and tighten the Set Screw in the

Mounting Receiver. Remove adhesive backing and install

the JL Audio logo badge.

Determine if the M6 x 20 mm Set Screw is fully recessed

into the Mounting Receiver as shown. Loosen the Set

Screw, separate the enclosure, and proceed to the

appropriate step as noted.

Continue to Step 6

Continue to Step 7

Fully Recessed

Not Fully

Recessed

c:6

If you wish to rotate the speaker’s grille/logo badge

alignment, remove the six #8 x 1-1/4” speaker mounting

screws and #8 Flat Washers.

Rotate the speaker to the desired angle. Reinstall the

speaker and speaker mounting screws and washers.

Hand-tighten in a criss-cross pattern.

Remove the backing from the rear logo appliqué. With

the logo positioned at the desired angle, attach the

appliqué to the back of the enclosure.

Gently press on the appliqué from the center out to

remove any air pockets.

Steps 11-12 are for Standard Models Only

• For marine installations, do not connect the speaker’s LED lights to the vessel’s navigational lighting circuits.

• For short-circuit protection, install a supplied fuseholder onto EACH speaker’s BLUE (+12V) LED power connection lead.

• Connect all BLUE (+12V) leads together (parallel) and connect to a switched +12V supply. Connect all YELLOW (GND)

leads together and connect to a negative ground or to the NEGATIVE battery post.

• We recommend activating the speakers’ LEDs thru a lighting circuit that supplies +12V via an existing switch. If an

existing switched circuit is not available, you may install a dedicated toggle/rocker style switch that will supply positive

(+12V) power. Fuse this connection according to how many LED circuits you have (LED circuits x 150 mA).

[GND]

LED

[+12V]

Blue

Yellow

Blue

Yellow

Blue

Yellow

Blue

Yellow

LED

Fuse

Example: One speaker pair of

LED circuits connected in parallel.

Clean the inside of the aluminum cap with acetone (not

included) prior to attaching it to the enclosure. Apply a

circular bead of silicone adhesive to the inside of the

aluminum logo cap, 1/2-inch (13 mm) from the outer edge.

Align the aluminum logo cap to the desired angle of

rotation, and press it onto the back of the enclosure.

Apply masking tape (not included) to hold the cap in

place until the silicone cures (at least 24 hours).

Steps 13-14 are for Premium Models Only

O~o-

Og--o-

NOTE: The PS-SWMCP-B-SM Fixture and PS650-VeX-SG-TMB Enclosed Speaker System

are used in this manual for illustrative purposes only. The fixture installation steps are

the same for all PS650-VeX Enclosed Speaker Systems and all PS-SWMCP swivel fixtures

for flat surfaces.

Included Hardware:

(hardware pictured for one)

......

BOM ID Quantity Description

1 2 Mounting Receiver

22 M6 x 20 mm Set Screw

3 6 #10 x 1” Flat Head Phillips Sheet Metal Screw

4 6 M6 Split Lock Washer

5 6 M6 x 16 mm Socket Cap Machine Screw

6 2 Mounting Base

7 1 Loctite® Red read-Locking Compound

8* 1 Silicone Adhesive

9* 2 Fixture Base

10* 12 #8 Flat Washer

11* 12 #8 x 1-1/4” Pan Head Screw

Note: Not all wires may be used in normal applications.

Wire Size Wire Color Use

16 AWG Red/Stripe Speaker Positive (+)

Black/Stripe Speaker Negative (–)

20 AWG

Red Not Used

Green Not Used

Blue LED Positive (+)

Yellow LED Negative (–)

* Included with VeX™ speaker enclosures.

Wire Size Wire Label Use

16 AWG “+”Speaker Positive (+)

N/A Speaker Negative (–)

For Premium Models:

For Standard Models:

LIMITED WARRANTY - MARINE PRODUCTS (USA)

JL AUDIO warrants this product to be free of defects in materials and workmanship for a period of two (2) years from the

original date of purchase.

This warranty is not transferable and applies only to the original purchaser from an authorized JLAUDIO dealer. Should service

be necessary under this warranty for any reason due to manufacturing defect or malfunction, JL AUDIO will (at its discretion),

repair or replace the defective product with new or remanufactured product at no charge. Damage caused by the following is not

covered under warranty: accident, misuse, abuse, product modification or neglect, failure to follow installation instructions,

unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover incidental or consequential damages

and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear and tear is not

covered under warranty.

Any applicable implied warranties are limited in duration to the period of the express warranty as provided herein beginning

with the date of the original purchase at retail, and no warranties, whether express or implied, shall apply to this product

thereafter. Some states do not allow limitations on implied warranties, therefore these exclusions may not apply to you. This

warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

For Service Information in the U.S.A. please call

JL Audio Customer Service: (954) 443-1100

9:00 AM – 5:30 PM (Eastern Time Zone)

JL Audio, Inc

10369 North Commerce Pkwy.

Miramar, FL 33025, USA

International Warranties:

Products purchased outside the United States of America are covered only

by that country’s distributor and not by JL Audio, Inc.

w w w . j l a u d i o . c o m

JL Audio® and the JL Audio logo are registered trademarks of JL Audio, Inc. “Ahead of the Curve” and its respective logo is a trademark of JL Audio, Inc.

©2016 JLAudio, Inc. • For more detailed information please visit us online at www.jlaudio.com. Due to our policy of continuous product development, all specifications are subject to change without notice.

SKU# 011499

Printed in U.S.A. • 092817
