JMB GSPDVD2001 User manual

1
IMPORTANT
TABLE OF CONTENTS
UNIT
REMOTE CONTROL
INSTALLING REMOTE CONTROL BATTERIES
REGION CODE
CONNECTION
PLAYING A DVD OR VCD DISC
PLAYING AN AUDIO CD
PLAYING A JPEG DISC
SAFETY INFORMATION ...................................2
IDENTIFICATION OF CONTROLS ..........................................5
...........................................................................................................................5
..................................................................................................... 6
GETTING STARTED ..............................................................7
............................................................... 7
............................................................................................................. 7
.............................................................................................................. 8
BASIC OPERATION ..............................................................9
.................................................................................... 9
............................................................................................ 12
............................................................................................ 12
SETUP MENU SETTING ...................................................... 13
PARAMETERS AND MAINTENANCE................................... 18
TROUBLESHOOTING ......................................................... 19
GUARANTEE ..................................................................... 20

Important Safety Information
Mains adapter
The power adapter supplied is compatible with a standard mains socket.
If the power adapter or its lead gets damaged it must be replaced by a qualified
service agent with an approved adapter of the same type and rating.
Symbols
2
This equipment is double
insulated and an earth
connection is not
required.
Dangerous voltage constituting
a risk of electric shock is
present inside this equipment.
This mark is applied to show
the equipment conforms to
European safety and
electro-magnetic compatibility
standards.
There are important operating
and maintenance instructions
in the literature accompanying
this equipment.
Battery handling and usage
BATTERY WARNING: Only adults should handle the batteries. Do not allow a child to use
this product unless the Battery Compartment Cover is securely attached to the Battery
Compartment in accordance with all product usage instructions.
Follow the battery manufacturer's safety and usage instructions.
Keep the batteries away from children and pets.
Insert the batteries observing the polarity marking inside the battery compartment.
Failure to properly align the battery polarity can cause personal injury and/or damage.
The battery compartment is located on the bottom of the remote.
To protect the environment please use local recycling facilities for battery disposal.
To prevent the risk of electrolyte leakage or explosions, never recharge
non-rechargeable battery.
The battery type used in the remote is two AAA size batteries. The batteries are located
internally and are readily accessible.
Remove the battery compartment cover located on the rear of the remote control to
remove the batteries.

The battery type used in the unit is one Polymer Li-ion battery. This
battery is located internally and is not readily accessible.
The battery must be disposed of at your local recycling point.
WARNING:
The mains plug shall be the main disconnect device and shall remain operable at all
times.
To save power: switch off mains power or pull out the mains power plug when you
are not using the equipment.
Never let anyone push objects into holes and ventilation slots.
This product is intended for domestic use only, commercial or any other use may
invalidate the warranty and might be dangerous.
Do not expose this product to dripping or splashing or place any objects filled with
liquids on or near the product.
Do not place a naked flame source such as lighted candles on or near this product.
Do not attempt to repair this product yourself, always get a qualified service agent
carry out adjustments or repairs.
Never dispose of batteries in a fire, danger of explosion.
Never operate the equipment and try to view video while driving a vehicle.
To prevent injury, this equipment must be securely attached to the car seats as in
accordance with the installation instructions.
Never operate the equipment and try to view video while driving a vehicle.
Class 1 laser product
This product contains a low power laser device. Invisible laser radiation when
open and interlocks defeated.
Avoid exposure to beam.
This digital video disc player employs a laser system. Use of controls, adjustments, or the
performance of procedures other than those specified herein may result in hazardous
radiation Exposure.
To prevent direct exposure to laser beam, do not open the enclosure. Invisible laser
radiation when opening.
Never stare directly into the laser beam.
Do not install this product in a confined space such as a book case or similar unit.
3

Notes on Discs
Handling Discs
Do not touch the play side of the disc. Hold the disc by the edges so that fingerprints do
not get on the surface. Never stick paper or tape on the disc.
Storing Discs
After playing, store the disc in its case. Do not expose the disc to direct sunlight or source
of heat and never leave it in a parked car exposed to direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and sound distortion.
Before playing, clean the disc with a clean cloth. Wipe the disc from the centre out.
Do not use strong solvents such as alcohol, benzine, thinner, commercially available
cleaners, or anti-static spray intended for older vinyl records.
4
Contents
1. 1×7" LCD DVD Player with built-in battery
2. 1×Remote control
3. 1×Audio/Video Cable
4. 1×Car charger
5. 1× Instruction Manual
6. 1×12V DC adaptor

Identification of Controls
5
FAST REVERSE
FAST FORWARD
PREVIOUS
AUDIO
POWER / CHARGE
VOLUME
DCIN12V
16
Unit

6
1
1. ANGLE button
2. PROG button
3. Numeric buttons
4. RETURN button
5. SUBTITLE button
6. SETUP button
7. Up button
8. Left button
9. ENTER button
10. ZOOM button
11. Down button
12. Fast backward button
13. Fast forward button
14. PLAY/PAUSE button
15. STOP button
16. MUTE button
17. DISPLAY button
18. GOTO button
19. TITLE button
20. AUDIO button
21. MENU/PBC button
22. VOL+ button
23. VOL- button
24. Right button
25. SLOW button
26. L/R button (Left/right channel)
27. NEXT button
28. PREV button
29. REPEAT button
30. A-B button
Remote Control

Getting Started
Always point the remote control directly at the remote sensor on the front of the DVD
player, not the TV.
1. Remove the battery compartment cover on the rear of the remote control.
2. Place two AAA batteries inside the battery compartment observing the polarity
markings.
3. Replace the battery compartment cover.
CAUTION:
Danger of damage or injury if the battery is replaced incorrectly. Replace only with
the same or equivalent type.
Do not dispose of battery in a fire as this constitutes an explosion hazard.
7
This DVD player is designed and manufactured for playing of region “2”
encoded DVD discs only.
Playable discs
DISC TYPE DVD VCD SVCD CVD CD
TIME DVD5
4.7GB=2 hours
DVD9
8.5GB=4 hours
DVD10
9.4GB=4.5 hours
DVD18
18GB=9 hours
650MB
74 minutes
650MB
45 minutes
650MB
74 minutes
DISC SIZE 12 cm / 8 cm 12 cm 12 cm 12 cm / 8 cm
CAPTION MAX 32 - 8 -
LANGUAGE MAX 8 2 4 -
MARKS
Installing Remote Control Baeries
Region Code

Note:
- The product is designed to playback discs that conform to the Compact Disc (CD)
standard.
- Damaged or badly scratched discs and some writeable media may not play.
- DVD-R/RW discs and CD-R/RW discs in DVD-video format can be played.
Compatibility may vary under different software systems and conditions.
8
1. Connect the single-connector end of the audio/video cable to the AVOUT jack
of the unit.
2. Connect the triple-connector end of the audio/video cable to the
corresponding jacks of the TV display.
Match the color of the AV cable with the jacks of TV display. The yellow cable
is for the yellow video jack, the red/white cable is for the red/white audio jacks.

Basic Operation
Buttons on the unit function the same as the corresponding buttons on the remote
control.
Playing a DVD or VCD Disc
1. Slide the power switch on the DVD player to the ON position. The blue power
indicator comes on.
2.
3.
4. Turn the VOLUME knob to adjust the desired volume.
5. To interrupt playing, press . To resume playing, press again.
6. To stop playing, press . Press to resume playing. To complete stop the
playback, press twice.
7. Press MENU/PBC to return to the menu screen. Some discs do not support
menus and start to play automatically.
Notes:
1. If parental control is set and the disc isn’t fit for the rating setting you must input the
password. (See “Parental Ctrl”).
2.
●Moving to another CHAPTER/TRACK DVD
When a title on a disc has more than one chapter or a disc has more than one track,
you can move to another chapter/track as follows:
1. Press or briefly during play to select the next or previous chapter/track.
2. To go directly to any chapter / track during playback, input the chapter/track
number. If the track / chapter number is greater than 9, use the 10+ button to
enter the first digit then use the numeric buttons to enter the second digit.
9
●Fast forward and backward
Press or to fast forward or backward during playback. Fast forward/backward
playback has five speeds: x2, x4, x8 and x16.
To return to normal playback, press .
Press
facing up in the compartment.
the OPEN button of the unit to open the disc cover. Put the disc label side
The player does not play anydisc with a region code which is different from the player
setting.
Close the tray. Press button disc will be played automatically.

●Muting
Press MUTE to turn off the sound. To resume the sound, press MUTE again.
●Repeat
Press REPEAT repeatedly during play to select a desired repeat mode.
Repeat Chapter: Repeats the current chapter.
Repeat Title: Repeats the current title.
Repeat All: Repeat all the content.
Repeat off: Repeat is deactivated.
●Using the display feature
Press DISPLAY repeatedly during playback to show play information. To stop
displaying the information, press DISPLAY until the information disappears on the
screen.
●Selecting the Audio Language
For DVDs that contain two or more audio languages, during play press AUDIO
repeatedly until the desired language is selected.
●Selecting the Subtitle Language
For DVDs that contain two or more subtitle languages, during play press SUBTITLE
repeatedly until the desired language is selected.
●Title
Press TITLE to select the preferred title.
Note: This function works only for discs that have title contents.
●Menu
If the DVD disc has a menu, press MENU/PBC to return to the root menu.
●PBC
During VCD playback, press MENU/PBC to turn the unit on or off.
●RETURN
During VCD playback (PCB is on), press RETURN to display the root menu.
●L/R (Compatible with VCD discs)
Press L/R repeatedly to select the desired audio channel.
Left Right Mix Stereo
10

●Repeat a Specific Segment on the Disc that You Define’
During the normal playback,
Press A-B once and “Rep A-” will appear on the screen. This indicates the start of the
loop to be repeated.
Press A-B again and “Rep A-B” will appear on the screen. It indicates the end of the
loop.
Press A-B a third time to cancel playback repeat.
●Multi Speed Slow Motion Playback
Press SLOW repeatedly to select the desired slow motion playback speed.
Slow motion playback has four speeds: 1/2, 1/4, 1/6 and 1/8.
●Zoom In on the Image
The zoom function allows you to enlarge the video image.
Press ZOOM repeatedly to change the zoom setting. The zoom setting are zoom 1,
zoom 2 and zoom 3.
Use to pan across the screen.
●GOTO
11
Press GOTO to display as below:
During DVD playback During VCD/CD playback
Use to select the desired track or chapter then enter numeric button to input time
you want to play. Press ENTER to start playing the selected track/time of title or
chapter.
●Program Play
1. Press PROG to enter program menu.
2. Press to highlight the next blank box.
3. Press numeric buttons to enter Track or Title then the chapter.
4. Repeat the above steps to add more chapters.
5. Use to select Play to start play.
NOTES：
- To clear the programmed order, use to highlight Clear program then
press ENTER.
- To modify the programmed order, use to highlight the item to modify
then enter the new chapter/track you want to program.

Playing an Audio CD
Once an Audio CD is inserted it will be played automatically. Press or to move
to the next / previous tracks or press or repeatedly to play (search) the current
track at different speeds, each press will select 2X, 4X, 8X or 16X and back to play, the
sound will be distorted during search, press to return to normal play from any
selected speed.
1. Press during play.
2. To return to play, press .
3. Press to return to the audio
CD menu.
Playing a JPEG Disc
When playing JPEG disc, a navigation menu will display automatically.
In the menu, use to select a file, then press ENTER, the file will be play with a
slide-show. Press to pause the current picture for enjoying, when press again,
it will return to normal playing. Press ZOOM to start zoom function. Press MENU/PBC
to display thumbnail size pictures. Press to return to the JPEG menu.
Image Rotation
There are four modes to rotate a picture: "Invert", "Mirror", Left", and "Right". These
operations are allowed only when a picture is being displayed normally and will be
cancelled automatically when a new picture is displayed. The arrow key is used to
select the different rotation modes:
Up - Invert/Normal Left - Turn left
Down - Invert/Normal Right - Turn right
12

SETUP Menu Setting
●General Operation
Make sure DVD player is in complete stop mode.
1. Press SETUP to enter the setup menu.
2. Press / to highlight the desire menu.
3. Press /to enter the submenu or return to the previous menu.
4. Press / to highlight the desired option in the submenu.
5. Press ENTER to enter the next level of submenu or confirm your selection.
To exit from the menu
Press SETUP.→The settings will be stored in the player’s memory.
●General Setup Page
The options included in General Setup page are: “Language”, “Video”, “Audio”, “Rating”
and “Misc”.
●Language Setup
You can select your own preferred language settings. This DVD system will
automatically switch to the selected language whenever you load a disc. If the
language selected is not available on the disc, the disc’s default language will be used
13
instead. The OSD language in the system menu will remain once selected.
1. Press / to highlight an option.
2. Enter its submenu by pressing or ENTER.
3. Press /to highlight the selected language.
4. Press ENTER to confirm.

14
●Video Setup
Aspect Ratio
1. Press / to highlight “Aspect Ratio”.
2. Enter its submenu by pressing or ENTER.
3. Press / to highlight the selected item.
4. Press ENTER to confirm.
4:3 Normal
→ If you have a normal TV
16:9 Wide
→ If you have a wide-screen TV.
View Mode
This function enables you to select the following options: Fill, original, Auto fit or Pan
Scan picture.
Fill: Choose this mode and the picture will fill the screen.
Original: Choose this mode and the picture will appear in its original size.
Auto Fit: Choose this mode and the picture displayed on screen is the same size as
that in the disc.
Pan Scan: Choose this mode and the picture will be extended horizontally.
1. Press / to highlight “View Mode”.
2. Enter its submenu by pressing or ENTER.
3. Press / to highlight the selected item.
4. Press ENTER to confirm.
TV System
Select the colour system that corresponds to your TV when AV outputs.This DVD
Player is compatible with NTSC, PAL and Auto. In order for a DVD disc to play on this
Player, the colour system of the Disc, the TV and the DVD Player should match.
1. Press / to highlight “TV System”.
2. Enter its submenu by pressing or ENTER.
3. Use / to highlight a TV system suitable for your TV.
4. Press ENTER to confirm.

NTSC- Select this if the connected TV is NTSC system. It will change the video signal
of a PAL disc and output in NTSC format.
PAL - Select this if the connected TV is PAL system. It will change the video signal of a
NTSC disc and output in PAL format.
Smart Picture
This function enables you to select the desired picture effect from the following options:
Standard, Bright, Soft and Dynamic.
1. Press / to highlight “Smart Picture”.
2. Enter its submenu by pressing or ENTER.
3. Use /to highlight the desired option.
4. Press ENTER to confirm.
- Standard is for general viewing.
15
- Bright is for a stronger view.
- Soft is for a weaker view.
- When Dynamic is selected, the window pops up
to let you adjust Brightness, Contrast and Color.
Highlight the desired option then press ENTER to confirm.
Use /to set then press ENTER to confirm. To exit the window, use
/to highlight “close” then press ENTER to return to the video menu.
●Audio Setup
1. Press / to highlight “Audio”.
2. Enter its submenu by pressing or ENTER.
3. Enter Night mode options by pressing or ENTER.
4. Press / to select the night mode On or Off.
5. Press ENTER to confirm.

●Rating Setup
Parental Ctrl
Some DVDs may have a parental level assigned to the complete disc or to certain
scenes on the disc. This feature lets you set a play limitation level. The rating levels are
from 1 to 8 and are country dependent. You can prohibit the playing of certain discs
that are not suitable for your children or have certain discs played with alternative
scenes.
VCD, SVCD, CD have no level indication, so parental control function has no effect on
those kinds of discs. This applies to most illegal DVD discs.
Input the password (initial password: 8888) then press ENTER to enter the submenu
from which you can select the preferred rating option.
Set Password
You can change the password, type 4 digits as new password.
Helpful Hint:
Some DVDs are not encoded with a rating though the movie rating may be printed on
the Disc cover. The rating level feature does not work for such Discs.
16

●Misc Setup
Default
1. Press / to highlight “Use Default Settings”.
2. Press ENTER to see a window pops up.
3. Press /to select “Yes” or “No” then press ENTER to confirm.
Caution!
When “Yes” is selected, all settings except the password will be reset to factory
defaults.
17
Screen Saver
If the screen saver is On, there will be an animated picture on the screen whenever the
DVD player is idle for a certain time.
Disc Resume
The function is convenient when you want to continue viewing a disc from the point
where you were watching before. Unlike the resume function, the Disc Resume
function is effective even the DVD is removed from the player.
Disc Resume may not work reliably with some VCD that feature PBC.

18
Parameters and Maintenance
Signal System PAL/AUTO/NTSC
Power Source DC 12V
Power Consumption 10W
Dimensions (L x W x H) 208(mm)X160(mm)X38(mm)
Supported Disc DVD / VCD/CD
Maintenance and Service
●Refer to the information in this chapter before contacting a service technician.
●When shipping the unit
Please save the original shipping carton and packing materials. If you need to ship the
unit, for maximum protection, re-pack the unit as it was originally packed at the factory.
●Keeping the exterior surfaces clean
Do not use volatile liquids such as insecticide spray near the unit. Do not leave rubber
or plastic products in contact with the unit for a long period of time since they leave
marks on the surface.
●Cleaning the unit
To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent solution. Do not use strong solvents such
as alcohol, benzine or thinner, as these might damage the surface of the unit.
●Maintaining the unit
The DVD player is a high-tech, precision device. If the optical pick-up lens and disc
drive parts are dirty or worn, the picture quality could be diminished. Depending on the
operating environment, regular inspection and maintenance are recommended after
every 1,000 hours of use. For detaiIs, please contact your nearest authorized service
centre.
