ANTENNA UHF YAGI
13 ELEMENTS CH 28...69 WITH FERRITE BALUN
Specifications AKUY13
Elements 13
Channels UHF 28 … 69
Frequency Range 530 … 820 MHz
Antenna Gain
7 dBi ... 10 dBi
Reception / Usage
Digital
Front to Back Ratio
19 dB Typical
Impedance
75 Ω
Mounting Pole
25 mm to 38 mm
Balun Type
Integrated F Type Ferrite
AKUY13
Site Selection, Inspection and Safety
The section of the roof selected for placement of the antenna must be thoroughly inspected and confirmed to be structurally sound and in good
condition. Installers must be aware that this antenna installation may expose them to physical hazards like working at heights for example. Please
also be aware of the danger of live electrical cables either above or beneath the roof and building cladding. An approved earth leakage protection
safety device must be used when drilling into the roof structure.
If in doubt, please do not carry out this installation. Please consult a qualified antenna installation technician, who is a professional, endorsed and
has the right equipment to conduct the installation safely.
Assembly - Step 1
Unpack all items from the sealed gift
box and ensure all of the parts supplied
have been included.
Use the M4 x 40 screws along with the
M4 flat gasket, M4 flange nut to fix the
back reflectors to the centre boom.
AKUY13
INSTALLATION
INSTRUCTIONS
HORIZONTAL MOUNTING
Ensure the Ferrite F Type Balun is on the
underside of the antenna. The elements
should be on top of the boom to ensure
the antenna is not mounted upside down.
VERTICAL MOUNTING
Ensure the Ferrite F Type Balun is pointing
downwards.
IMPORTANT: MOUNT THE ANTENNA IN LINE OF SIGHT OF THE NEAREST TRANSMITTER
Specifications are subject to change without notice - Copyright © 2015 Jonsa Australia Pty Ltd. All Rights Reserved.
DISTRIBUTED BY:
JONSA AUSTRALIA PTY LTD
Assembly - Step 2 Option A
HORIZONTAL MOUNTING
Finger tighten the U-Bolt to the mast.
Once the best signal reception has been
obtained by aiming the antenna at the
transmitter, the U-Bolt can then be
securely fastened to the mounting pole.
Assembly - Step 2 Option B
VERTICAL MOUNTING
Used in areas where the antenna must
be mounted vertically as apposed to
horizontally as shown in Step 2 Option A.
Warranty
Any claim under this warranty must be made within 12 months of the date of purchase of the product. To make a claim under the warranty, take
the product (with proof of purchase) to the store where you purchased the product or contact Jonsa Australia Pty. Ltd.
If the product is found to be defective, Jonsa Australia Pty. Ltd. will pay your reasonable, direct expenses of claiming under this warranty. You may
submit details and proof of your expense claim to Jonsa Australia Pty. Ltd. for consideration. If the product is found not to be defective, you will be
responsible for your expenses of claiming under this warranty.
This warranty is given by Jonsa Australia Pty. Ltd. - ABN 15097501105
Unit D2, Lidcombe Business Park, 3-29 Birnie Avenue, Lidcombe NSW 2141
Tel: 1300 660 155 – Email: sales@jonsa.com.au
This warranty is provided in addition to other rights and remedies you have under law: Our goods come with guarantees which cannot be excluded
under the Australian Consumer Law. You are entitled to replacement or refund for a major failure and to compensation for other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Assembly - Step 3
Trim the rubber boot to suit your particular
type of coaxial cable. Please refer to the
diagram below, where the rubber boot
needs to be trimmed to suit RG6 Quad
Shield cable.
Note: A nice neat trim of the rubber boot
will minimise water ingress.
RG6 Quad Shield.
We recommend the use of RG6 Quad Shield. Slide the rubber boot onto the cable. Connect the
F Male connector (not included) to the antenna balun above. Put a loop in the cable as shown
above so water does not travel down the cable. Then proceed to tie off the cable to the mast
and connect the antenna to the distribution system or directly to the television outlet.
