Jorlink Varga VA 10 User manual

Varga Mo
d
e
l
VA 1 0
Circular Saw
“With Safety in Mind!”
Operating Instructions
1. Chip collection bag with velcro at the bottom for emptying chips.
2. Spring clip for holding the chip collection bag in place.
3. Chip collection delivery hose.
4. Main saw handle.
5. “T” handle for lifting saw casing.
6. Back stop guide for repetitive cuts of the same size (as measured from the back of the blade).
7. Back stop guide actuating lever.
8. Table top measuring scale (as measured from the front of the blade).
9. Optional stop guide for the table top measuring scale (Part number VA 5).
10. Locking knob for back stop guide.
11. Measuring scale for back stop guide.
12. Holding bracket for optional drip lubricating bottle
TM
1.
2.
3.
4.
5.
6. 7.
9.
8.
10.
11.
12.
The Varga VA 10 is perfect for cutting standard plastic engraving stock, laser
engraving material, all types of plastics, non-ferrous metals (aluminum &
brass), wood, rubber, felt, cardboard and more. Not for use on steel, materials
containing steel, or magnetic materials.
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

Introduction:
Congratulations
on your purchase of a
Varga VA 10 Circular
Saw! It is state of the art
for precision material
cutting, and has
applications in many
different industries,
including Sign Making,
Engraving, Industrial
Panel Production, Trophy
& Awards, Advertising
Specialty, and a variety of
other applications
requiring sizing of plastic,
non-ferrous metal, and
other sheet material (not for use on steel, or magnetic material). The Varga VA 10 requires very
little assembly, is pre-aligned, and is extremely easy to use. The safety features incorporated in
this equipment make it one of the most “worry free” machines on the market, and while it is very
important to follow all standard safety procedures during operation, it was truly designed with
safety in mind. You will find this product to be extremely accurate, and of high quality
construction, which will provide a long service life, if properly maintained. Your new Varga VA
10 is warranted for one year from date of sale against defects in manufacturing, parts or
workmanship. Your distributor welcomes your comments or suggestions.
Assembly:
1. Remove the main body of the saw from the cardboard container, and locate the small box
or boxes containing the saw accessories.
2. The accessory box will include a chip collection
bag, chip collector mounting bracket, mounting screw, and
chip collector bag spring clip for holding the bag in place.
Install the chip collector, mounting bracket on the bottom
of the saw base using the screw included. The mounting
hole is on the bottom left, front side of the base as shown
in the picture on the front of this manual (#2). The
cylindrical part of the bracket should be in the up position.
3. Insert the top opening of the blue chip collector bag up through the center of the
mounting bracket, fold the cloth down over the cylindrical part of the bracket, and secure it by
bringing the spring clip down over the cloth and cylindrical part of the bracket. Insert the plastic
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

chip collection delivery hose down into the center of the cloth bag opening, noting that there is a
plastic ring on the hose, which will indicate the correct depth.
4. Place your saw on a convenient table or workbench (approximately waist high) so that
the chip collection bag hangs off the end. Be careful not to obstruct the opening of the hose
inside the bag. When it is time to empty the saw chips, it is easy to place a trash can under the
bag, and then pull the VelcroTM apart, thus allowing the chips to fall into the can without having
to remove the bag from the mounting bracket. When empty, re-close the bag by pressing the
VelcroTM together.
5. Remove the electrical power cord for the saw
from the accessory box. Insert the female end of the
cord into the receptacle located on the top of the motor
housing. The cord plug is shaped so that it will only fit
the correct way, and if it does not go in easily, look
carefully to see that it is oriented properly. For future
reference, please note that the motor does have a
protective electrical fuse, which is located under a
plastic flap next to the cord receptacle. To reveal the
fuse, disconnect the electrical cord and insert a
fingernail or small screwdriver under the flap, and
gently lift up. The active fuse, and a spare fuse will
then be visible.
6. If the main handle and “T-handle” (#4 and #5)
are not already installed on the saw motor block, remove them from the accessory box, and
install the “T-handle” first, followed by the main handle, with the screws provided.
7. Lastly make sure that all packing materials are removed from the machine, and that the
motor block moves freely back and forth on the guide rod, before plugging the electrical cord
into the power source. With very few exceptions, all saws sold in the United States of America
are 110Volt, 60 Hz. Make sure that the power outlet you wish to use, matches the power
requirements and plug type of your saw. If you have made a special purchase of a 220 Volt
model, or if you live in a country other than the U.S.A., it will be necessary for you to add the
correct plug to your power cord, in order to match your power source and type of wall outlet.
(Special plugs are not included.)
8. Your new saw is now completely assembled and ready for use. Plug the electrical cord
into your power source. Prior to attempting to make a cut, turn on the motor to make sure that it
is receiving power and running smoothly.
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

Operating Procedures:
Basic Operation:
Operation of the Varga VA 10 is very straight forward, as follows:
1. Face the right side of the saw (the side where the 13 ½ inch measuring scale is found).
The palm of the operator’s right hand will rest on the main handle on the saw motor block, and
the fingers of the right hand will grasp the “T-handle” underneath. Squeezing the fingers of the
right hand will raise the motor block, relaxing the fingers will allow the motor block to lower.
The operator’s left hand is used to position
and move the material being cut.
2. With the right hand move the motor
block/saw casing away from the operator in
preparation for making a cut. Position a
piece of material to be cut on the saw table
(measuring procedures will be discussed in
a subsequent section).
3. Now move the motor block near the
material to be cut, and raise the saw blade
casing so that the bottom casing rests on
the top of the material. You will note a
white or silver line on the front of the black
saw blade casing which indicates the point where the saw blade starts cutting. Do not allow the
edge of the material to being cut to go past this line without the motor running, otherwise the
material could jam the blade, resulting in a blown fuse when the motor is turned on.
4. With the motor running, smoothly draw the motor across the material until it reaches its
built in stop, then smoothly reverse the direction, thus placing the motor/casing in a position that
is ready for the next cut. Important Note: The bottom of the saw blade casing should ride on the
top surface of the material being cut, thereby preventing material “chatter”, fracturing, or
chipping.
Important Operating Notes:
1. The circular saw cuts from the bottom upwards, and the bottom of the saw blade casing
acts as a hold-down device. Therefore, it is very important that the sawing unit is allowed to
presses down on the material being cut by its own weight, so that it rides on the surface of the
material as a cut is being made.
2. The saw is capable of making very narrow width cuts (strips), which could fall into the
guiding slot underneath the blade. These must be removed before making the next cut.
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

3. During cutting, the edge of the material being cut should be held firmly against the side
rail (the rail on the right side, top of the saw table, where the 13 ½” scale is located) to avoid
slippage.
4. Do not use this saw for cutting steel, other ferrous metals, or magnetic sheet stock. Use
on this type of material will ruin the saw blade, and may void the warrant on this equipment.
Non-observance of these important operating notes could lead to saw blade fracture and damage
to the guard plates.
Measuring Procedures:
The Varga VA 10 has two different methods available for measuring the material to be cut in
order to obtain the desired size, the primary measuring scale, located on the top of the right side
rail, and the back material stop guide, which has measuring scales located on each of the two
rods which extend out of the front of the saw table.
The primary measuring scale is marked in inches,
with its smallest division being 1/16th of an inch. This
scale measures from the inside cutting edge of the saw
blade outward, so that placing the back edge of the
material next to the desired measurement on the scale
will produce highly accurate results. Note: An
optional stop guide (Part # VA 5) is available for the
primary measuring scale, as shown on the front cover
of this manual (# 9). The optional VA 5 stop guide
has a thumb screw stop which makes very fine
adjustments possible.
The back material stop guide is most often used to
obtain repetitive cuts. It is set by lining up the
desired length of cut on the measuring rods
extending out the front of the saw table with the edge
of the saw table. This measurement is then locked in
place by means of the black thumb screw (#10)
located on the front, right hand corner of the saw
table. This will position
the actual stop guide so
that the piece which is cut off is the desired length. The stop guide
measurement is from the outside cutting edge of the saw blade to the
stop on the back side of the table. The operator will note a lever (#7)
on the back material stop guide. Pressing down on this lever raises
the stop guide so that when material is pushed along the side rail, it
cannot go past this barrier. When the lever is released, then the stop
guide is out of the way, or it can act as a support for long material
cuts. If the operator wants the stop guide to stay up continuously,
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

this may be accomplished by pressing down on the lever, and then inserting a piece of plastic in
the gap.
Changing the Saw Blade
1. Disconnect the electrical power cord from thmotor block to prevent accidents.
2. Make sure that the optional lubricating device
is not installed.
3. Remove the four slot screws in the front of
the saw casing, thus exposing the saw blade to
view.
4. Remove the two blade mounting slot screws
and the fixing ring (fan).
5. Remove the saw blade. Clean the interior of
the saw blade housing to remove any chips or
debris.
6. Insert the new saw blade. Pay close attention
to the direction of rotation, which is counter
clockwise when facing the blade. The direction of rotation is marked on the outside of the
saw casing that was removed to expose the blade.
7. Replace the fixing ring, and the two blade mounting slot screws.
8. Replace the saw casing cover, and the four saw casing slot screws.
9. Reconnect the electrical power cord.
10. Turn on the saw for a test to make sure that the saw blade turns smoothly and freely, then
make a test cut. If the blade does not operate freely, review the above captioned steps again.
Attentiion: The saw blade mounting flange, and the guiding tongue which fits in the groove in
the top of the saw table are precisely adjusted and should never be dismantled.
Maintenance and Service
Keep the saw clean. Oil the guiding rod a little from time to time. We recommend Tri-Flow
lubricant, but any light machine oil can be used. Have dull blades resharpened by an expert.
Your dealer can advise you on blade resharpening. A reserve saw blade is recommended so that
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com

a dull blade can be replaced while it is being resharpened. Should you experience problems that
you cannot correct, call your dealer for advise.
Technical Data:
Motor 110 Volt 60 Hz.
Output 350 Watts
Speed 15,000 R.P.M.
Maximum Cutting Length 24 3/8”
Maximum Material Thickness ¼”
Maximum Light and Non-ferrous Metal Thickness .157” (5/32”)
Maximum Stop Guide Cut length 8 ½”
Maximum Primary Top Scale Measurement 13 ¾”
Saw Blade 36 Tooth Carbide Tipped,
(4.72” X .067”)
Gross Shipping Weight in Box 57 lbs.
Outside Dimensions in Box 10” X 32” X 37”
Accessories:
VA 5 Stop Guide for Top Primary Measuring Scale
Drip Lubricator Device
VARGOL special lubricant – ½ Liter Bottle
Warranty:
The Varga Model VA 10 is warranted for one year from date of purchase against
Manufacturer’s defects in material or workmanship.
Distributed & Supported by:
Jorlink USA, Inc. | Tel: [phone]
[email protected] | www.JORLINK.com
