JOSEF DAVIDSSONS Idun no 1 Specification sheet

JD Idun No 1
Manual for installa on and maintenance
A

Technical informaon 4
Important before you get started! 4
What comes with the stove 5
Wood stove JD Idun No 1 6
Dimensions and installaon 7
About the JD Idun No 1 8
How your JD Idun No 1 works 8
Replaceable parts 9
How to change stove parts 9
Installaon distance 10-11
Installaon and connecon 12
Connecng outdoor air to the wood
burning stove
13
Maintenance, sweeping the stove 14
How to set a re correctly 15
Fire-lighng problems and soluons 17
Warranty Cercate 18

3
Congratulaons on your new wood burning stove!
All of us at Josef Davidssons hope that, like many others around the country, you
will have many wonderful hours in the kitchen.
The JD Idun No 1 is a ne wood stove which works equally well for cooking and
for cold winter evenings.
This manual contains instrucons on how to install your wood burning stove as
well as maintenance advice and ps on the best way to light the re.
Warm regards,
Josef Davidssons
It will soon be me for your rst re.

4
TECHNICAL FACTS JD IDUN NO 1
Efficiency (%) 79.2
Nominal Eect (kW) 4.4
Heang area (approx. m²) 30-60
Weight (kg) 130
Oven size (WxHxD mm) 270x155x400
Fireplace opening (WxH mm) 100x130
Log length (mm) Max 300
Flue pipe dimension (mm) Ø125
Distance to combusble material See pages 10-11
IMPORTANT BEFORE YOU GET
STARTED!
Professional installaon
The manual contains instrucons on how the JD Idun
No 1 should be assembled and installed. To ensure the
funcon and safety of the stove, we recommend that
installaon be carried out by a professional. Contact
one of our dealers who can assist with the installaon
or recommend a suitable installer.
Planning permission
When installing a replace and building a chimney,
planning permission must be applied for with the local
authority's planning oce. Contact your local planning
oce if you are unsure of the applicaon process.
Load-bearing surface
Make sure that the oor structure of your home has
sucient bearing capacity for a wood burning stove
and chimney. Normally, a wood burning stove and
chimney can be placed on a standard wooden-framed
oor in a family house if the total weight does not
exceed 400 kg.
Hearth plate
Embers falling from the stove represent a risk of re.
If you have a ammable oor in front of your wood
burning stove, it must be protected by a hearth plate
that covers at least 300 mm in front of the door and
100 mm to each side. The hearth plate may be made
of natural stone, concrete, sheet metal or glass, for
example.
The specied safety distances in this manual apply to
the Swedish market. If the wood burning stove is to be
installed in another country, the local regulaons must
be met.
WARNING! THE WOOD BURNING STOVE GETS VERY HOT
When burning, some areas of the stove become very hot and can cause burns when touched.
Use the p of the included poker hook to adjust the air supply air; this control becomes very hot.
If ammable material is placed closer than the specied safety distance, it may quickly catch re.
Smouldering res can quickly cause gas to ignite, with the risk of injury to persons and property.
NB!
It is very important that the installaon is
inspected by a competent chimney sweep
before the stove is taken into use.

5
WHAT COMES WITH THE STOVE?
Make sure all parts are included in the package.
1 2 3
NB!
The pallet should be recycled as untreated wood. Corrugated cardboard is sorted as corrugated
cardboard and the plas c tape should be disposed of in the  ammables container at the recycling centre.
5
4
6
1. Installa on instruc ons
Guide to the installa on and maintenance of your
wood burning stove.
2. Stove blacking
Black polish for maintenance of the stove.
3. Ash pan
Collects remaining ashes a er burning.
4. CE mark
Guarantees that the product meets all essen al health
and safety requirements de ned in the Construc on
Products Direc ve.
5. Baking tray
For use when baking in the oven.
6. Soot rake
Accessories for sweeping the stove.
7. Poker
Prac cal poker included.
8. Oven thermometer
Measures temperature in the oven.
22
NB0402
JDIdun No 1
DoPNr. JD__I1931_220307
EN 12815:2001/A1:2004
www.josefdavidssons.se/prestandadeklaration
SWE
/ EN/ DE
PRODUKT / PRODUCT / PRODUKT
Produkttyp / Product type / Produkttyp
Vedspis / Wood stove / Holzofen
Typbeteckning/ Product name / Produkt nam e
JD Idun No 1
Avsedd användning / Intended use / Verwendung
Rumsvärmare / Space heater / Raumheizung
Bränsle / Fuel / Brnnstoff
Ved / Wood / Holz
VÄSENTLIGA EGENSKAPER /
ESSENTIALPROPERTIES / WESENTLICHE EIGENSCHAFTEN
PRESTANDA / PERFORMANCE / LEISTUNG
Brandsäkerhet / Fire safety / Brandschutz
Klarar/ P ass / Zugelassen
Rökgastempetratur / Flue gas temperature / Rauchgastemperatur
190°C
Rökgaskanal / Flue gas duct / Rauchgaskanal
30mm
Rökgasstos / Diameter of the flue gas connector/
Rauchgasschluss Ø125 mm
Minsta avstånd tillbrännbart material /
Minimum distance to flammable material /
Mindestabstand zu brennbarem Material
Baktill / Back / Hinter: 500 mm
Sidan / Side / Seitlich: 500 mm
Framför / Front / Vor:1000 mm
Emissioner från förbränning/
Emissions of fluegases / R auchgasemissionen
CO = 0,09%
Angivning av farligaämnen / Release of dangerous substance /
Freisetzungvon gefährlichen Stoffen
NPD
Elektrisksäkerhet / Electrical safety / Elektrische Sicherheit NPD
Maximaltarbetstryck / Max. operating pressure / Maximaler
Arbeitsdruck
NPD
Mekanisk hållfasthet/ M echanical resistance/ M echanische
Festigkeit
Klarar/ P ass /Z ugelassen
Nominell effekt / Nominal heat output / Nennleistung
4,4kW
Verkningsgrad / Efficiency/ W irkungsgrad
79,2%
Yttertemperaturer / Surface temperatures / Oberflächentemperatur
Klararm ed hjälpmedel /Pass with instrument / Mit Hilfsmittel
zugelassan
Josef Davidssons Eftr. AB
Jättevägen 1
33375
Reftele
[phone]
[email protected]
Tillverkningsår/ Year of manufacture / Herstellungsjahr
Serienummer / Serial number / Seriennummer
7 8

6
WOOD BURNING STOVE JD IDUN NO 1
This manual contains information about the installation
and maintenance of the JD Idun No 1.
JD Idun No 1

7
Front view Back view
295
590
27,5
543
Ø60
434
94
205
74
595
57
54
345,5
80
40
590
Ø 160
Ø 220Ø 220
MEASUREMENTS AND INSTALLATION
Here are the most important dimensions required for proper
installation and optimal operation.
All measurements are given in millimetres.
View from above
Front view
Side view, rear connecon
Rear view

8
ABOUT YOUR WOOD BURNING
STOVE
Manufacturer's declaration
The product meets the requirements of, and is CE
marked according to, EN12815 standard. Instrucons
for installaon and maintenance are included in an
addional document. For CE marking, see page 19.
General
The wood stove is made of heavy cast iron and is
equipped with vermiculite as protecon. The oven
ceiling is clad with soapstone for addional heat
protecon and for a more even temperature in the oven.
The heat retaining property of the material means the
stove emits residual heat for several hours aer use.
Owing to the airght doors and the special supply of
air to the re, the stove maintains a maximum heang
eect and low wood consumpon. The wood is burned
when the supply of secondary air ows through the
holes in the vermiculite and by means of the primary air
which is supplied when the combuson chamber door is
ajar during the ignion phase.
HOW YOUR WOOD BURNING STOVE
WORKS
Combustion air
Primary air is supplied when lling with rewood and by
means of leaving the door ajar during the ignion phase.
The secondary air is supplied through a fresh air intake
under the stove; this damper is also referred to as the
outside air connecon. You adjust the supply using
a regulator on the front of the stove. This air supply
regulator should always be fully open when lighng the
re and may be closed back to 50% when the stove is
thoroughly warm. The secondary air is then heated in
the stove and nds its way into the via the holes in the
vermiculite in the combuson chamber. The combuson
air passes through the rebox then circulates across the
oven roof and down on the stove’s right-hand side. It
then moves towards the rear and leaves the stove at the
rear or at the top depending on the connecon to the
chimney.
Regulate the secondary air supply
here by turning the knob downwards
to increase the oxygen supply.
NB! This regulator becomes very hot
when the re is lit. Use the poker to
adjust the air supply regulator.
Secondary air & outdoor air
connecon**
On installaon, the space
below the stove must be
unimpeded to allow the
oxygen supply to the stove.
** The connecon adapter is an opon and is included in the outdoor air connecon kit. Read more about how to mount this on page 12.

9
REPLACEABLE PARTS JD IDUN NO 1
The JD Idun No 1 is built to last decades of use but do
not forget to replace worn parts when necessary. Keep
an eye on the vermiculite plates, grates and seals and
replace them when they become worn. Spare parts
and other accessories can be ordered on our website
josefdavidssons.se.
HOW TO CHANGE STOVE PARTS
1. Remove the hobs and half-moon.
2. Start by removing the rear vermiculite plate (3).
Next, li out the right vermiculite plate (2) at the back
edge, then angle it upwards to li it out. Repeat for the
le vermiculite plate (1).
3. To install the new parts, begin by pung in the le
vermiculite plate (1), then the one on the right (2) and
nally the plate at the back (3).
4. The grate is loose. The grate may be easily pried up
with a screwdriver or similar.
1101931101 Outer plate (vermiculite)
2101931102 Inner plate (vermiculite)
3101931301 Rear vermiculite plate
4100227302 Grate frame
5100227303 Grate
6990000202 Hob diam. 220
7101931310 Half-moon
8990000203 Hob diam. 220
9990000201 Hob diam. 165
10 9900007 Soapstone roof
11 101931201 Seal set Hobs diam. 3mm
12 101931202 Seal set Door diam. 3mm
13 101931105 Guide plate
6
7
8
9
10
11
13
12
1
4
5
2
3

10
Installaon distance
Please consider the safety installaon distance.
The lowest possible ceiling height is 2000 mm for a
safe distance. At least 1000 mm between hob and
combusble material.
There must be at least 1000 mm to combusble
material in front of the wood burning stove.
The distances refer to installaon with insulated ue.
Non-insulated ue pipes must have a distance of at
least 500 mm to combusble material.
The stove is tested and approved with a 100 mm
rewall, lightweight concrete or similar material for
insulaon.
If you choose a diagonal posion, bear in mind that
measurement is always made from the centre of the
ue pipe.
Between the stove and any wall cabinet there must
be a safety distance of at least 1000 mm and 200 mm
laterally.
Always contact your chimney sweep if you are unsure
of how to place and install your stove.
IMPORTANT!
Between the stove and insulang material (light concrete or similar) there must be an air gap of 5-10 mm.
500 mm
100 mm
100 mm
5–10mm
100 mm
100 mm
5–10mm
Grey = Combusble wall
Striped = Firewall
White = Air
Air gap
Air gap
