Joy-it SEN-KY052 User manual

3
SEN-KY052
Temperature and air pressure sensor

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 2
3SEN-KY052
TABLE OF CONTENT
1. Introducon
2. Use with the Raspberry Pi
2.1 Connecon
2.2 Installaon
2.3 Program example
3. Use with the Arduino
3.1 Connecon
3.2 Installaon
3.3 Program example
4. Informaon and take-back obligaons
5. Support

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 3
3SEN-KY052
1. Introduction
Dear customer,
Thank you for choosing our product.
In the following, we will show you what to consider during commissioning and use.
If you experience any unexpected problems during use, you are welcome to contact us.

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 4
3SEN-KY052
2. Use with the Raspberry Pi
2.1 Connection
Raspberry Pi KY052
3v3 (Pin1,17) VCC, SDO, CSB
GND (Pin 6) GND
SCL (Pin 5) SCL
SDA (Pin 3) SDA

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 5
3SEN-KY052
2.2 Installation
First, you need to install git on your Raspberry Pi, this is done with the following command:
Now you can download the required library for the sensor as follows:
Next you have to go to the directory of the library:
And with the next command install the library:
Finally, you need to acvate I2C by entering the following command in the console:
Go to Interfacing Opons and enable I2C
2.3 Program example
cd Adafruit_Python_BMP/
git clone https://github.com/bastienwirtz/Adafruit_Python_BMP.git
#!/usr/bin/python
# Author: Bastien Wirtz <[e-mail]>
# Can enable debug output by uncommenting:
#import logging
#logging.basicConfig(level=logging.DEBUG)
import Adafruit_BMP.BMP280 as BMP280
sensor = BMP280.BMP280()
print ('Temp = {0:0.2f} *C'.format(sensor.read_temperature()))
print ('Pressure = {0:0.2f} Pa'.format(sensor.read_pressure()))
print ('Altitude = {0:0.2f} m'.format(sensor.read_altitude()))
print ('Sealevel Pressure = {0:0.2f} Pa'.format(sensor.read_sealevel_pressure()))
sudo apt-get git
sudo python setup.py install
sudo raspi-config

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 6
3SEN-KY052
3. Usewith the Arduino
3.1 Connection
Arduino KY052
5V SDO, CSB, VCC
GND GND
A4 SDA
A5 SCL

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 7
3SEN-KY052
3.2 Installation
In order to use the sensor with the Arduino, you must rst download the required library here. Unpack
the folder and save it in your Libraries folder.
This is usually located under Documents / Arduino / Libraries.
3.2 Program example
/***************************************************************************
This is a library for the BMP280 humidity, temperature & pressure sensor
Designed specifically to work with the Adafruit BMEP280 Breakout
----> http://www.adafruit.com/products/2651
These sensors use I2C or SPI to communicate, 2 or 4 pins are required
to interface.
Adafruit invests time and resources providing this open source code,
please support Adafruit andopen-source hardware by purchasing products
from Adafruit!
Written by Limor Fried & Kevin Townsend for Adafruit Industries.
BSD license, all text above must be included in any redistribution
***************************************************************************/
#include <Wire.h>
#include <SPI.h>
#include <Adafruit_BMP280.h>
#define BMP_SCK 13
#define BMP_MISO 12
#define BMP_MOSI 11
#define BMP_CS 10
Adafruit_BMP280 bmp; // I2C
//Adafruit_BMP280 bmp(BMP_CS); // hardware SPI
//Adafruit_BMP280 bmp(BMP_CS, BMP_MOSI, BMP_MISO, BMP_SCK);
void setup() {
Serial.begin(9600);
Serial.println(F("BMP280 test"));
if (!bmp.begin()) {
Serial.println(F("Could not find a valid BMP280 sensor, check wiring!"));
while (1);
}
}

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 8
3SEN-KY052
3.2 Program example
void loop() {
Serial.print(F("Temperature = "));
Serial.print(bmp.readTemperature());
Serial.println(" *C");
Serial.print(F("Pressure = "));
Serial.print(bmp.readPressure());
Serial.println(" Pa");
Serial.print(F("Approx altitude = "));
Serial.print(bmp.readAltitude(1013.25)); // this should be adjusted to your local for-
case
Serial.println(" m");
Serial.println();
delay(2000);
}

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 9
3SEN-KY052
Our informaon and take-back obligaons according to the ElektroG
Symbol on electrical and electronic equipment
This crossed-out dustbin means that electrical and electronic equipment does not belong in the household
waste. You must return the old appliances to a collecon point. Before handing over waste baeries and
accumulators that are not enclosed by waste equipment must be separated from it.
Return opons
As an end user, you can return your old appliance (which essenally fulls the same funcon as the new
appliance purchased from us) free of charge for disposal when you purchase a new appliance. Small
appliances with no external dimensions greater than 25 cm can be disposed of in normal household quanes
independently of the purchase of a new appliance.
Possibility of return at our company locaon during opening hours
Simac GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn
Possibility of return in your area
We will send you a parcel stamp with which you can return the device to us free of charge. Please contact us
by e-mail at [e-mail] or by telephone.
Informaon on packaging
If you do not have suitable packaging material or do not wish to use your own, please contact us and we will
send you suitable packaging.
4. INFORMATION AND TAKE-BACK OBLIGATIONS

Veröffentlicht: 21.05.2019 Copyright by Joy-IT 10
3SEN-KY052
5. Support
We also support you aer your purchase. If there are any quesons le or if you encounter any problems,
please feel free to contact us by mail, phone or by our cket-supportsystem on our website.
Mail: [e-mail]
Ticket-System: hp://support.joy-it.net
Phone: [phone] – 66 (10- 17 o‘clock)
For more informaons, please visit our website:
www.joy-it.net
