JRC GPS 112 User manual

●12-Channel Parallel for simultaneous
reception of 12 satellites.
●Quick Position Fixing
●NMEA0183 Output
GPS RECEIVER

GPS 112

GPS 112
GPS RECEIVER
■FEATURES
12-Channel Parallel for Receiving 12 Satellites
Simultaneously
The GPS112 is designed to simultaneously receive signals from 12
orbiting satellites, ensuring the most accurate positioning.
Quick Position Fixing
Typically 45 seconds for first position fixing without GPS almanac
data.
Conversion to NMEA0183 Output
Since the NMEA0183 output data is changeable between version
1.5 and version 2.1, you can connect the GPS112 to various Marine
Electronics Equipment such as Marine Radars, Fishfinders,
Plotters, or others.
Internal DGPS Function
By using a Beacon Receiver simultaneously, the GPS112 provides
very highly accurate positioning.
■SPECIFICATIONS
Receiver type :Multichannel (12-CH) all-in-view
Frequency :1575.42MHz ±1MHz(C/A code)
Sensitivity : -130dBm for acquisition, -133dBm for tracking
Accuracy :15mRMS(C/A code, HDOP＜4)
Time to first fix :Typically 45 seconds (cold start fix)
Typically 30 seconds (warm start fix)
Position update :Normally every 1 second
DGPS input :
RTCM SC-104 ver. 2.0 type 1,2,7,9 available
Data output :Signal output port
NMEA0183ver.1.5 or 2.1 selectable
ver1.5 GGA, RMC, GLL, VTG,
PJRCDGP0,PJRCDGP1,
PJRCDGP2
ver2.1 GGA, RMC, GLL, VTG, GSV, GSA,
PJRCDGP3, DTM, MSS
Geodetic datum :46 (WGS-84, WGS-72, Japan, America,
Canada / Alaska, Europe, Australia,
England, NAD-83, other 37 selectable)
Input voltage :10.8〜16VDC (less than 3W)
(Power Consumption)
Data cable :6-core cable, 15m
Operating temprature :-25℃to 70℃
Water proof :USCG CFR-46/IEC60945
■SYSTEM CONFIGURATION
■OUTLINE DRAWING
JLR-4330E
6-pin connector
(6-282-6SG-522)
option
FF30
FF50
JFV-250
RADAR 1000
RADAR 1500
RADAR 2000
RADAR 3000
NWU-800
PLOT 700FX
J-NAV 500
NWZ-4570
JRC Radar
JRC Fish Finder
JRC Plotter
JRC GPS Display
104
φ126
φ40 1"-14 UNS-2B
（Unit:mm）
Seattle Branch : 1011 SW Klickitat Way, Bldg. B,
Suite 100, SEATTLE WA 98134, U.S.A.
Telephone:[phone]
Facsimile: [phone]
Homepage:http://www.jrcamerica.com
JRC (UK)Limited : 1st Floor, Friars House,
157/168, Blackfriars Road,
London SE1 8EZ, U.K.
Telephone:[phone]
Facsimile: [phone]
(JLR-4330E)
Weight: less than 1.2kg
●Specifications subject to change without notice.
■COMPONENTS
Name
GPS Receiver
Instruction manual
No.
1
2
Type
JLR-4330E
Remarks
include 15m cable
Q'ty
1
1
For further information, contact:
Since 1915
PrintedinJapan2000.5  CAT.No.Y3-129（No.431-1-3）A
Main Office: Akasaka Twin Tower(Main), 17-22,
Akasaka 2-chome, Minato-ku, Tokyo 107-8432, JAPAN
Telephone: Tokyo(03)3584-8833
Facsimile: Tokyo(03)3584-8757
Overseas Branches : Seattle, London
Liaison Offices : Kaohsiung, Manila, Bangkok,
Singapore, Jakarta, New Delhi, New York, Rotterdam,
Piraeus, Las Palmas
19EM
ISO9001
，
ISO14001 Certified
URL
Caution
Before attempting to operate this unit, read the instruction
manual thoroughly to correctly and safty operate the unit.
●Option :15m Extension Cable CFQ-8773
