JRC Alphatron Marine AlphaScreen26 User manual

AlphaScreen19 & 26
Color & Touch Panel Color LCD Monitors
User Manual
www.jrc.am

Contents
I Preface..........................................................................................................4
I.1 Revision History........................................................................................................................................................4
I.2 Points of Attention.....................................................................................................................................................4
II Cautions...................................................................................................... 5
1 Introduction.................................................................................................6
I Features....................................................................................................................................................................... 6
II Alphatron Marine LCD Utility Disk..............................................................................................................................7
II.1 Disk Contents and Software Overview..............................................................................................................7
III Basic Operations and Functions................................................................................................................................7
III.1 Basic Adjustment Menu Operations................................................................................................................. 8
III.2 Showing Button Guide......................................................................................................................................8
III.3 Functions...........................................................................................................................................................9
IV Warranty Conditions................................................................................................................................................ 10
2 Installation Instructions...........................................................................11
2.1 Transportation........................................................................................................................................................ 11
2.2 Unpacking and Checking.......................................................................................................................................11
3 Operation...................................................................................................12
3.1 Adjusting Screens.................................................................................................................................................. 12
3.1.1 Setting the Resolution...................................................................................................................................12
3.1.1.1 Display Resolution................................................................................................................................12
3.1.1.2 Setting Resolution................................................................................................................................12
3.1.2 Displaying Screen Correctly..........................................................................................................................13
3.1.2.1 Digital Signal Input...............................................................................................................................13
3.1.2.2 Analog Signal Input..............................................................................................................................13
3.1.3 Adjusting Color..............................................................................................................................................15
3.1.3.1 Adjusting Brilliance (brightness)...........................................................................................................15
3.1.3.2 Adjusting Color Temperature...............................................................................................................16
3.1.3.3 Adjusting Gamma.................................................................................................................................16
3.1.3.4 Adjusting Hue.......................................................................................................................................17
3.1.3.5 Adjusting Color Saturation................................................................................................................... 17
3.1.3.6 Enhancing Image Outline.....................................................................................................................17
3.1.3.7 Adjusting Gain......................................................................................................................................17
3.1.4 Selecting Screen Size...................................................................................................................................18
3.1.5 Enabling / Disabling Auto Sharpness...........................................................................................................19
3.2 Setting Monitor.......................................................................................................................................................19
3.2.1 Setting Brightness of Front Button............................................................................................................... 19
3.2.2 Setting Language..........................................................................................................................................19
3.2.3 Changing Adjustment Menu Display Position...............................................................................................19
3.2.4 Setting the Adjustment Menu Orientation.....................................................................................................20
3.2.5 Enabling/Disabling DDC/CI Communication.................................................................................................20
3.2.6 Locking Buttons.............................................................................................................................................20
3.2.7 Setting Backlight Off Mode...........................................................................................................................22
3.2.8 Turning the ECDIS Indicator ON/OFF..........................................................................................................22
2 | Contents

3.2.9 Return to Default Setting..............................................................................................................................23
3.2.9.1 Resetting the Color Adjustment Value.................................................................................................23
3.2.9.2 Resetting All Adjustments To The Default Settings.............................................................................23
3.2.9.3 Resetting Brightness (Brilliance)..........................................................................................................23
3.3 Touch Panel Settings (FDS1904T / FDU2603WT)................................................................................................24
3.3.1 Calibrating the Monitor..................................................................................................................................24
3.3.2 Configuring Touch Panel Operation Settings............................................................................................... 25
3.3.3 Setting Touch Sound.................................................................................................................................... 25
3.4 Power Saving Fuctions..........................................................................................................................................26
3.4.1 Setting Power Saving....................................................................................................................................26
3.4.2 Setting the Automatic Power Off Function................................................................................................... 27
3.5 Reference...............................................................................................................................................................28
3.5.1 Connecting Multiple PCs...............................................................................................................................28
3.5.1.1 Switching Among Input Signals...........................................................................................................29
3.5.1.2 Setting Input Signal Selection..............................................................................................................29
3.5.2 Displaying Monitor Information......................................................................................................................29
3.5.2.1 Displaying Signal Information...............................................................................................................29
3.5.2.2 Displaying Monitor Information.............................................................................................................30
3.5.3 Replacing the Cooling Fan........................................................................................................................... 31
3.5.4 Preset Timing................................................................................................................................................35
4 Specifications............................................................................................36
4.1 FDS1904 / FDS1904-OP.......................................................................................................................................36
4.2 FDS1904T / FDS1904T-OP...................................................................................................................................38
4.3 FDU2603W/FDU2603W-OP...................................................................................................................................40
4.4 FDU2603WT/FDU2603WT-OP.............................................................................................................................. 42
4.5 Pin Assignment......................................................................................................................................................45
5 Maintenance..............................................................................................47
5.1 Troubleshooting......................................................................................................................................................47
5.1.1 No Picture..................................................................................................................................................... 47
5.1.2 Imaging Problems (for both digital and analog)........................................................................................... 49
5.1.3 Imaging Problems (for analog only)..............................................................................................................51
5.1.4 Other Problems.............................................................................................................................................51
5.1.5 Touch Panel Problems (for FDS1904T/FDU2603WT only)..........................................................................52
5.2 Recycling Information.............................................................................................................................................53
6 Appendices................................................................................................54
6.1 Drawings.................................................................................................................................................................54
6.2 Testing Standard....................................................................................................................................................55
6.3 Type Approval of Ship Classification.....................................................................................................................55
6.4 CE...........................................................................................................................................................................55
6.5 Annex A..................................................................................................................................................................56
3 | Contents

I Preface
This document describes the functionality, the intended use and the most important product specifications of the
AlphaScreen 19 and 26.
I.1 Revision History
Revision Nr. Description Date
V0.9 Preliminary May 2016
V1.0 First release September 2018
I.2 Points of Attention
• This product may not be covered by warranty for uses other than those described in the Setup Manual.
• Only use optional products manufactured or specified in the manual with this product.
• It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
• Monitors should be set to a lower brilliance to reduce changes in luminosity caused by long-term use and maintain a
stable display.
• When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of
time.
• Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
Cleaning on page 4).
• The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please
contact Alphatron Marine BV.
• Cautions for the use of the Touch Panel.
During touchoperation, be careful of the following points. Otherwise, damage may occur to the monitor.
• Do not strongly press, scratch, or poke the panel.
• Do not touch the panel with hard objects such as ballpoint pens or metals.
Cleaning
Attention
• • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the
panel, and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage thepanel.
• Do not allow liquid to enter the clearance between the panel and the panelframe.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the
environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
4 | Preface

II Cautions
To safely install and operate this instrument, so as not to adversely affect the warranty, the WARNINGS and CAUTIONS
must be adhered to.
• Caution damage.
• This symbol is used to highlight information that if not followed can result in damage to a product or
equipment.
• Warning injury / death
• This symbol is used to highlight information that if not followed can result in personal injury or death.
• Damage
• Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do
not attempt to brush with tissues as this may scratch the panel.
• Damage
• When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
5 | Cautions

1 Introduction
I Features
The AlphaScreen 19 and 26 have the following features
19.0″ LCD (FDS1904 / FDS1904T)
25.5″ LCD (FDU2603W / FDU2603WT)
Provides a display area (vertical: over 340 mm) required for radar on large ships.
Applicable to the resolution of 1280 × 1024. (FDS1904 / FDS1904T).
Applicable to the resolution of 1920 × 1200. (FDU2603W / FDU2603WT)
Panel with a wide field of view adopted.
• Horizontal : 178°, vertical : 178°(FDS1904 / FDS1904T).
• Horizontal : 176°, vertical : 176°(FDU2603W / FDU2603WT).
Dimming down to the low brightness.
Dimming down to the low brightness.
(You can set the brightness when “Brilliance” in the Adjustment menu is set to the lower limit value.) See Setting
Backlight Off Mode on page 22
The buttons on the front of the monitor light up.
The buttons on the front of the monitor (operation buttons) light up orange to enable the monitor to be operated in a
dark environment as well. Their brightness can also be adjusted. See Setting Brightness of Front Button on page 19
Cooling fan replacement is possible. See Replacing the Cooling Fan on page 31
Built-in warning buzzer.
Controlled on the system side.
Equipped with AC/DC power supplies.
Both AC power input and DC power input are provided to enable installation in various environments. In addition,
connecting both power inputs can provide a helpful backup if the AC power supply fails. (The AC power supply takes
priority during operation when both power inputs are connected.)
HDCP (High-bandwidth Digital Content Interface).
Type approval of ship classification.
This product has been approved for the following types of ship classifications:
• NK (Nippon Kaiji Kyokai)
• DNV GL (DNV GL AS)
• ABS (American Bureau of Shipping)
• LR (Lloyd’s Register of Shipping)
For the latest information on approvals for ship classifications, please refer to our website. http://www.eizoglobal.com
Testing Standards.
This product complies with the IEC60945 4th edition standard.
6 | Introduction

Optical bonding for increased screen strength and visibility *1
(option: FDS1904-OP / FDS1904T-OP,FDU2603W-OP / FDU2603WT-OP)
*1 A technique in which a layer of resin is used to fill the gap (layer of air) between the LCD panel and clear panel/touch
panel, adhering the two together.
(FDS1904T / FDU2603WT only)
Touch Panel provided
• Projected capacitive technology.
• Supports the Windows Touch function (multi-touch) of Windows 10 / Windows 8.1 / Windows 7.
Table 1: Features
II Alphatron Marine LCD Utility Disk
An “Alphatron Marine LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk
contents and the overview of the software programs.
II.1 Disk Contents and Software Overview
The disk includes adjustment software, touch panel software, and user manuals. Refer to Readme. txt file on the disk for
software start-up procedures or file access procedures.
Item Overview
Screen adjustment pattern files. Used when adjusting the image of analog signal input manually.
Touch Panel Driver ¹ Driver software for the touch panel. ²
If the following
conditions are
satisfied, use the
standard Windows
driver.
The PC and monitor are connected with a USB cable.
The OS is Windows 8.1or Windows 7.
For setup details please refer to Touch Panel Settings (FDS1904T / FDU2603WT)
on page 24
TPOffset ¹ Software for adjusting the sensitivity of the touch panel ²
Use this software when touch operations are not registered or only registered after
pressing hard.
User’s Manual of this monitor (PDF file).
Readme.txt file.
¹ Used only for the FDS1904T / FDU2603WT.
² Refer to the corresponding User’s Manual on the CD-ROM for details on installation and use.
III Basic Operations and Functions
Note
• The language is set to English in the default settings. To change the language, please refer to Setting
Language on page 19.
7 | Introduction

III.1 Basic Adjustment Menu Operations
1. Displaying Adjustment Menu
1. Press . The Adjustment menu appears.
Figure 1: Adjustment Menu
2. Adjusting/Setting
Figure 2: Choose Menu Figure 3: Choose Item Figure 4: Adjust / Set selected item
1. Choose a menu to adjust/set with and then press .
2. Choose an item to adjust/set with and then press .
3. Adjust/set the selected item with and then press .
3. Exiting
1. Press a few times. The Adjustment menu finishes.
III.2 Showing Button Guide
Press the front buttons other than , and the button guide appears above the button.
Figure 5: Button Guide
8 | Introduction

Note
• The Button Guide will continue to appear while the Adjustment menu is showing.
• The Button Guide is displayed differently depending on the selected menu or status.
III.3 Functions
The following table shows all the Adjustment menus adjustment and setting menus.
Main menu Setting Reference
Adjusting Color on page 15
.
.
.
.
.
Return to Default Setting on page 23
Selecting Screen Size on page 18
Displaying Screen Correctly on page 13
.
.
.
.
Setting Power Saving on page 26
Setting Brightness of Front Button on page 19
Setting the Automatic Power Off Function on page 27
Setting Language on page 19
Changing Adjustment Menu Display Position on page
19
Switching Among Input Signals on page 29
Setting Input Signal Selection on page 29
Enabling / Disabling Auto Sharpness on page 19
Displaying Monitor Information on page 29
Return to Default Setting on page 23
Table 2:
9 | Introduction

¹ Depending on which display mode has been applied to the product, the adjustable items under "Color" may vary.
² Adjustments are not possible in the three ECDIS Standard compatible modes (Day, Dusk, Night).
Attention Display Mode has three ECDIS Standard compatible modes (Day, Dusk, Night) and a mode where
you can make settings of your choice (Custom). However, the Display Mode cannot be changed using the
monitor. Changes can be made on the system side.
IV Warranty Conditions
Contact Alphatron Marine for warranty conditions.
10 | Introduction

2 Installation Instructions
Important Please read this User Manual and the Setup Manual (separate volume) carefully to familiarize
yourself with safe and effective usage.
• Please refer to the Setup Manual for basic information ranging from monitor installation to using the monitor.
2.1 Transportation
The AlphaScreens 19 - 26 are sensitive instruments and must be handled with care when transported, or moved.
As long as the product is packed in its standard Alphatron Marine box it can be transported anywhere at any distance.
• During transport protect boxes from moisture, movement and fall.
• During transport handle boxes with care and in accordance with instructions on the box.
• During transport ambient temperature should be between range of -20 ~ 60 °C (-4 ~ 140 °F).
2.2 Unpacking and Checking
• Carefully unpack the screens, inspect for damage and notify Alphatron Marine if any damage has been noticed.
11 | Installation Instructions

3 Operation
3.1 Adjusting Screens
3.1.1 Setting the Resolution
3.1.1.1 Display Resolution
For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual.
3.1.1.2 Setting Resolution
When the monitor is connected to the PC and the resolution is inferior, or when the resolution requires to be changed,
follow the procedure below:
Windows 10
1. Right-click the mouse anywhere on the desktop except foricons.
2. From the displayed menu, click “DisplaySettings”.
3. On the “Customize your display” dialog box, click “Advanced displaysettings”.
4. Select a monitor, then choose a resolution from the “Resolution” pull-downmenu.
5. Click the “Apply” button.
6. When a confirmation dialog box is displayed, click “Keepchanges”.
Windows8.1 / Windows 7
1. Click the “Desktop” tile on the Start Screen to display the desktop for Windows 8.1/ Windows 8, .
2. Right-click the mouse anywhere on the desktop except for icons.
3. Click SCREEN RESOLUTION on the displayed menu.
4. Select the monitor on the SCREEN RESOLUTION dialog box.
5. Click RESOLUTION to select the desired resolution.
6. Click the OK button.
7. Click KEEP CHANGES when a confirmation dialog box is displayed, .
Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. Click PROPERTIES on the displayed menu.
3. Click the “Settings” tab and select desired resolution for SCREEN RESOLUTION under “Display” on the “Display
Properties” dialog box displayed.
4. Click the OK button to close the dialog box.
Mac OS X
1. Select “System Preferences” from the Apple menu.
2. Click DISPLAYS for “Hardware” when the “System Preferences” dialog box is displayed.
3. Select the DISPLAY tab and select desired resolution in the RESOLUTIONS” field on the displayed dialog box. The
selection will be shown immediately.
4. Close the window, when the resolution is satisfactory.
12 | Operation

3.1.2 Displaying Screen Correctly
3.1.2.1 Digital Signal Input
When digital signals are entered, images are displayed correctly based on the preset data of the monitor.
When performing advanced adjustment, see Adjusting Color on page 15 and subsequent pages.
3.1.2.2 Analog Signal Input
Attention
• It takes about 30 minutes for the performance of electrical parts to stabilize. Wait 30 minutes or more after the
monitor power has been turned on and then adjust the monitor.
• The self adjustment function does not work for the images under the vertical resolution of 480 or less.
• The self adjustment and auto adjustment functions work correctly when an image is fully displayed over the Windows
or Macintosh display area. They do not work properly in the cases below:
• When an image is displayed only on a part of the screen (command prompt window, for example).
• When a black background (wallpaper, etc.) is in use.
Also, these functions will not work properly in some graphic boards.
The monitor screen adjustment is used to suppress flickering of the screen, or adjust screen position and screen size
correctly according to the PC to be used.
Note
The self adjustment function
works when all of the
following conditions are
satisfied:
When a signal is input into the monitor for the first time, or
when a resolution or vertical / horizontal scan frequency not used before is
set.
If the screen is not displayed correctly even after performing the self adjustment operation, adjust the screen according to
the procedures on the following pages to use the monitor comfortably.
1. Prepare to use analog screen adjustment patterns.
Load the “Alphatron Marine LCD Utility Disk” to your PC, and then open the “Screen adjustment pattern files”.
Note For details and instructions on opening the “Screen adjustment pattern files”, refer to the Readme.txt file.
2. Perform the auto adjustment with the analog screen adjustment pattern displayed.
To adjust flickering, screen
position, and screen size
automatically
1. Display Pattern 1 in full screen on the monitor using the “Screen adjustment
pattern files”.
2. Choose SCREEN from the Adjustment menu and press .
3. Choose ANALOG ADJUSTMENT from the “Screen” menu, and press .
4. Choose AUTO ADJUSTMENT and press .
Note The auto adjustment function works (the message “In Progress”
appears) to adjust the flickering, screen position, and screen size
correctly.
13 | Operation

Note When the auto adjustment is completed, a message appears.
5. Select OK to confirm the new settings or CANCEL to restore the previous
settings, and press .
Attention If the screen is not displayed correctly even after performing
auto adjustment, perform the adjustments according to the procedures on
the following pages. If the screen is displayed correctly, go to Adjusting
Color on page 15.
3. Perform advanced adjustments for the following using “Analog Adjustment” of “Screen”.
Adjust the clock, phase and position, in this order.
To eliminate vertical bars 1. Choose CLOCK from the “Analog Adjustment” menu, and press .
2. Adjust the clock with or to eliminate vertical bars.
Press or slowly so as not to miss the adjustment point.
3. Press to exit the adjustment.
When blurring, flickering or bars appear on the screen after adjustment,
proceed to “To remove flickering or blurring”.
To remove flickering or blurring 1. Choose PHASE from the “Analog Adjustment” menu, and press .
2. Adjust the phase with or to minimize flickering or blurring.
3. Press to exit the adjustment.
Attention Flickering or blurring may not be eliminated depending on
your PC or graphics board.
To correct the screen position Note Since the number of pixels and the pixel positions are fixed on the
LCD monitor, only one position is provided to display images correctly.
The position adjustment is made to shift an image to the correct position.
1. Choose HOR.POSITION or VER.POSITION from the "Analog Adjustment"
menu and press .
2. Adjust the position with or .
3. Press to exit the adjustment.
When vertical bars appear on the screen after adjustment, go back to
"Eliminate Vertical Bars". (Clock →Phase →Position)
14 | Operation

4. Close pattern 1.
4. Adjusting Color Gradation
To adjust color gradation
automatically Every color gradation (0 to 255) can be displayed by adjusting the signal output level.
1. Display Pattern 2 in full screen on the monitor using the “Screen adjustment
pattern files”.
2. Choose SCREEN from the Adjustment menu, and press .
3. Choose ANALOG ADJUSTMENT from the “Screen” menu, and press .
4. Choose RANGE ADJUSTMENT from the “Analog Adjustment” menu, and
press .
The color gradation is adjusted automatically.
When the auto adjustment is completed, a message appears. Select OK to
confirm the new settings or CANCEL to restore the precious settings, and press
.
5. Close Pattern 2.
3.1.3 Adjusting Color
Attention
• It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
• The same image may be seen in different colors on multiple monitors due to their monitor-specific characteristics.
Make fine color adjustment visually when matching colors on multiple monitors.
Note The values shown in “%” or “K” are available only as reference.
3.1.3.1 Adjusting Brilliance (brightness)
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).
1 to 100% When “Backlight Off Mode” is set to OFF, see Setting Backlight Off Mode on page 22
0 to 100% When “Backlight Off Mode” is set to ON, see Setting Backlight Off Mode on page 22
Table 3: Adjustable Range
15 | Operation

Procedure
1. Choose COLOR from the Adjustment menu, and press .
2. Choose BRILLIANCE from COLOR, and press .
3. Use or for adjustment.
4. Press to exit.
Note
•The brightness can be set by directly pressing or (For the setting value, display and check COLOR.)
•When adjusting brilliance by long pressing or , adjustment terminates when the default setting is
reached. Adjustment may be continued by pressing or again (When “ECDIS indicator” is ON and the
monitor Display Mode is set to “Day”, “Dusk”, “Night”.)
3.1.3.2 Adjusting Color Temperature
The color temperature can be adjusted.
The color temperature is normally used to express the hue of “White” and/or “Black” by a numerical value. The value is
expressed in degrees “K” (Kelvin).
The screen becomes reddish at a low color temperature and bluish at a high color temperature, like the flame
temperature. The gain preset values are set for each color temperature setting value.
Adjustable Range
Native, 4000K-10000K (specified by every 500K unit, including 9300K)
Procedure
1. Choose COLOR from the Adjustment menu, and press .
2. Choose TEMPERATURE from COLOR, and press .
3. Use or for adjustment.
4. Press to exit.
Note
• GAIN allows you to perform more advanced adjustment (seeAdjusting Gain on page 17 ).
• If NATIVE is set, the image is displayed in the preset color of the monitor (Gain: 100% for each RGB).
• When gain is changed, the color temperature is changed to USER.
3.1.3.3 Adjusting Gamma
Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the variation rate
is not proportional to the input signal. To keep the balance between the input signal and the brightness of the monitor is
called as “Gamma correction”.
Adjustable Range
1.8, 2.0, 2.2, 2.4, 2.6
Procedure
1. Choose COLOR from the Adjustment menu and press .
2. Choose GAMMA from COLOR and press .
3. Use or for adjustment.
4. Press to exit.
16 | Operation

3.1.3.4 Adjusting Hue
This function allows you to adjust the hue.
Adjustable Range
-100 to 100
Procedure
1. Choose COLOR from the Adjustment menu and press .
2. Choose ADVANCED SETTINGS from COLOR and press .
3. Choose HUE and press .
4. Press to exit.
Attention Using this function may make some color gradations unavailable for display.
3.1.3.5 Adjusting Color Saturation
This function allows you to adjust color saturation.
Adjustable range
-100 to 100
Procedure
1. Choose COLOR from the Adjustment menu and press .
2. Choose ADVANCED SETTINGS from COLOR and press .
3. Choose SATURATION and press .
4. Use or for adjustment.
5. Press to exit.
Attention Using this function may make some color gradations unavailable for display.
Note The minimum value (-100) changes the screen to monochrome.
3.1.3.6 Enhancing Image Outline
Outline Enhancer functions to emphasize outline of the images by emphasizing the color difference between pixels
composing the images. This may improve the texture of the material and its feel of the images. On the other hand, it also
functions to reproduce the images smoothly by gradating its outline.
Procedure
1. Choose COLOR from the Adjustment menu and press .
2. Choose ADVANCED SETTINGS from COLOR and press .
3. Choose OUTLINE ENHANCER and press .
4. Select the display status in the range from -3 to 3 (soft to sharp) with or as desired.
5. Press to exit.
3.1.3.7 Adjusting Gain
The brightness of each color component red, green, and blue is called “Gain”. You can change the hue of “white” by
adjusting gain.
Adjustable range
0 to 100%
17 | Operation

Procedure
1. Choose COLOR from the Adjustment menu and press .
2. Choose ADVANCED SETTINGS from COLOR and press .
3. Choose GAIN and press .
4. Choose the color to adjust from “Red”, “Green”, and “Blue” and then press .
5. Use or for adjustment.
6. Press to exit.
Attention Using this function may make some color gradations unavailable for display.
Note
• The value of gain changes with that of color temperature.
• When gain is changed, the color temperature is changed to USER.
3.1.4 Selecting Screen Size
The image with the resolution, other than the recommended resolution, is displayed in full screen automatically. You can
change the screen size by using the SCREEN SIZE function from SCREEN.
Setting Function
Full Displays an image in full screen. Images are distorted in some cases because the vertical rate
is not equal to the horizontal rate.
Enlarged Displays an image in full screen. In some cases, a blank horizontal or vertical border appears
to equalize the vertical rate and the horizontal rate.
Normal Displays images with the specified resolution.
Table 4: Screen Size
Example: Image size 1024 × 768.
Procedure
1. Choose SCREEN from the Adjustment menu and press .
2. Choose AUTO SHARPNESS from TOOLS and press .
3. Select FULL, ENLARGED, or NORMAL with or .
4. Press to exit.
Attention Selecting NORMAL may make some color gradations unavailable for display.
18 | Operation

3.1.5 Enabling / Disabling Auto Sharpness
By enabling Auto Sharpness, outlines will be adjusted according to the displayed image, which can improve its feel and
texture.
Procedure
1. Choose TOOLS from the Adjustment menu and press .
2. Choose AUTO SHARPNESS from TOOLS and press .
3. Select ON or OFF with or .
4. Press to exit.
Note The extent of adjustment depends on the setting value of “Outline Enhancer”.
3.2 Setting Monitor
3.2.1 Setting Brightness of Front Button
The brightness of the front buttons (control button and power button) can be set.
Note They are set to light up under the following condition and are set to “4” by default.
• Power button: When the power cord is connected to the power outlet.
• Control button: When the power button is turned on.
Procedure
1. Choose POWERMANAGER from the Adjustment menu and press .
2. Choose INDICATOR from POWERMANAGER and press .
3. Set the brightness so it is in the range from 1 to 7 with Set the brightness so it is in the range from 1 to 7 with or as
desired. as desired.
4. Press to exit.
3.2.2 Setting Language
This function allows selecting a language for the Adjustment menu and messages.
Selectable languages
English, German, French, Spanish, Italian, Swedish, Japanese, Simplified Chinese, Traditional Chinese.
Procedure
1. Choose MENU SETTINGS from the Adjustment menu and press .
2. Choose LANGUAGE from MENU SETTINGS and press .
3. Select a language with or .
4. Press to exit.
3.2.3 Changing Adjustment Menu Display Position
The display position of the Adjustment menu can be changed.
19 | Operation

Procedure
1. Choose MENU SETTINGS from the Adjustment menu and press .
2. Choose MENU POSITION from MENU SETTINGS and press .
3. Choose the position with or .
4. Press to exit.
3.2.4 Setting the Adjustment Menu Orientation
When the monitor is set to the portrait display mode, the orientation of the Adjustment Menu can be changed as well.
Default setting: Landscape.
Procedure
1. Press for five seconds or more to turn off the monitor.
2. Holding down , press for at least two seconds to turn on the monitor.
The “Optional Settings” menu appears.
3. Choose ORIENTATION from OPTIONAL SETTINGS and press .
4. Select LANDSCAPE or PORTRAIT with or , and press .
5. Select FINISH with or .
6. Press . THE OPTIONAL SETTINGS menu is closed.
Note When using the monitor screen in a portrait position, the graphics board supporting portrait display
is required. When placing the monitor in a portrait position, the settings of your graphics board need to be
changed. Refer to the User Manual of the graphics board for details.
3.2.5 Enabling/Disabling DDC/CI Communication
This function allows you to enable/disable the DDC/CI communication (see Definitions).
Procedure
1. Press for five seconds or more to turn off the monitor.
2. Holding down , press for at least two seconds to turn on the monitor.
The “Optional Settings” menu appears.
3. Choose DDC/CI from OPTIONAL SETTINGS and press .
4. Select ON or OFF with or and press .
5. Select FINISH with or .
6. Press . THE OPTIONAL SETTINGS menu is closed.
3.2.6 Locking Buttons
This function allows you to lock the adjusted/set status to prevent changing them.
Procedure
1. Press for five seconds or more to turn off the monitor.
2. Holding down , press for at least two seconds to turn on the monitor.
20 | Operation
