Julabo Magio Installation instructions

Original operating manual
1.950.1760.us.V01 02/2023

2
JULABO USA, Inc.
884 Marcon Boulevard
Allentown, PA 18109
Phone: [phone]
Fax.: [phone]
[e-mail]
www.julabo.us

3
Contents
1Foreword ............................................................................................. 5
2About this manual .............................................................................. 5
2.1 Original JULABO spare parts .......................................................... 5
2.2 Warnings ......................................................................................... 6
2.3 Symbols used .................................................................................. 7
3Intended use ....................................................................................... 7
4Safety ................................................................................................... 8
4.1 General Safety Instructions for the operating company .................. 8
4.2 Safety instructions ........................................................................... 8
4.3 Safety symbols .............................................................................. 10
4.4 Safety function............................................................................... 10
5Product description.......................................................................... 11
5.1 Function description ...................................................................... 11
5.2 Operating and functional elements ............................................... 12
5.3 Operating interface........................................................................ 13
5.3.1 Softkeys and status icons ........................................................ 13
5.4 Technical data ............................................................................... 13
6Transport and installation ............................................................... 15
6.1 Transporting the device................................................................. 15
6.2 Install the device at the operating location .................................... 15
7Initial operation................................................................................. 16
7.1 Connect the device to the power supply ....................................... 16
7.1.1 Connect bridge mounted or heating circulator ......................... 16
7.1.2 Connect refrigerated circulator................................................. 17
7.2 Fill device ...................................................................................... 18
7.3 Set high temperature safety function ............................................ 19
8Operation........................................................................................... 20
8.1 Enable booster heater ................................................................... 20
8.2 Manual refilling of unit ................................................................... 20
8.3 Automatic refilling of unit ............................................................... 21
8.4 Remote control device................................................................... 22

4
9Maintenance ...................................................................................... 23
9.1 Check the functionality of high temperature cut-off....................... 23
9.2 Clean device.................................................................................. 23
9.3 Device storage............................................................................... 24
9.4 Technical Service .......................................................................... 24
9.5 Warranty ........................................................................................ 25
10 Disposal............................................................................................. 27
11 Appendix ........................................................................................... 28
11.1.1 IN commands ........................................................................... 28
11.1.2 OUT commands ....................................................................... 28
11.2 Modbus TCP/IP register ................................................................ 28
11.2.1 Holding registers ...................................................................... 28

Foreword
5
1 Foreword
Congratulations!
You have made an excellent choice.
JULABO would like to thank you for the trust you have placed in our company
and products.
This operating manual will help you become acquainted with the use of our
units. Read the operating manual carefully. Keep the operating manual handy at
all times.
2 About this manual
This manual is intended for the equipment specified on the cover page.
Read the operating manual together with the operating manual for the
circulator used, and follow the safety instructions and warnings for this
circulator.
NOTE
Observe the safety instructions!
Read the Safety section of this manual before using the equipment for the
first time.
2.1 Original JULABO spare parts
Hassle-free continuous operation and safety also depend on the quality of the
spare parts used.
Only original JULABO spare parts guarantee the highest possible quality and
safety. Original JULABO spare parts are available directly from JULABO or your
specialist dealer.
Please note that JULABO cannot provide a warranty service if non-original
JULABO spare parts are used.

About this manual
6
2.2 Warnings
The manual contains warnings to increase safety when using the device.
Warnings must always be observed.
A warning sign displayed in signal color precedes the signal word. The signal
word, highlighted in color, specifies the severity of the hazard.
DANGER
This signal word designates a danger with a high level of risk which, if it not
prevented, will result in death or serious injuries.
WARNING
This signal word designates a danger with a medium level of risk which, if it
not prevented, may result in death or serious injuries.
CAUTION
This signal word designates a danger with a low level of risk which, if it not
prevented, may result in minor to moderate injuries.
NOTE
This signal word designates a possibly harmful situation. If it is not avoided,
the system or objects in its vicinity may be damaged.

Intended use
7
2.3 Symbols used
Various symbols are used throughout this manual to aid reading
comprehension. This list describes the symbols used.
Tools needed for the following approach
Prerequisite to be met for the following procedure
1. Numbered action steps
Interim result for individual action steps
Additional note for individual action steps
Final result of a procedure
<> Terms in angle brackets denote control menu
[] Terms in square brackets denote keys, softkeys and buttons
3 Intended use
This section defines the purpose of the unit so that the operator can operate the
unit safely and avoid misuse.
The booster heater is an auxiliary heater that can be combined with MAGIO
circulators and suitable cooling machines or baths.
Only use the unit if it is in technically perfect condition and only use it in
accordance with its intended use. Be aware of safety issues or hazards and
comply with the operating manual! In particular, always immediately rectify
malfunctions that could impair safety!
The booster heater is not suitable for direct temperature control application of
food, other consumables or pharmaceutical or other medical products.
The unit must not be used outside a cooling machine or a bath.
The unit must not be used in a different circulating medium loop than the
connected circulator.
The unit is not suitable for use in an explosive environment.
The unit is not intended for use in residential areas.

Safety
8
4 Safety
4.1 General Safety Instructions for the operating company
• The operator is responsible for the qualifications of its operating personnel.
• The operator must ensure that the operating personnel has been instructed
in use of the device.
• The device operators must receive regular training about the dangers
involved in their work and measures to prevent such dangers.
• The operator must ensure that persons entrusted with the operation,
installation and maintenance have read and understood the operating
manual.
• The device may only be configured, installed, maintained and repaired by
trained personnel with appropriate qualifications.
• If hazardous substances or substances that may become hazardous are
used, the device may only be used by personnel who are qualified to handle
these substances and the device.
• The operator must ensure that the device is checked for safety and
functionality at regular and usage-related intervals.
• The operator must ensure that the mains supply has a low impedance to
prevent influencing other devices powered by the same supply.
4.2 Safety instructions
The unit is built in accordance with state of the art technology and recognized
safety regulations. Despite this, its use may pose a risk to life and limb for the
user or third parties.
Therefore, always read and observe the following safety instructions before
using the product.
Hot surfaces!
The following parts and elements may become hot during operation:
– Bath fluid
– Heating element
– Bath lid
– Bath surface
– Connections for external application
Contact may cause severe burns or scalds to hands and arms, face and limbs.
• Keep sufficient distance from hot surfaces and fluids.
• Wear suitable protective gloves.

Safety
9
Electric shock from electrical system!
Touching damaged live parts can cause severe electric shocks and lead to injury
or even death.
• Have damaged insulation and parts of the electrical system immediately
repaired by JULABO service technicians or a qualified specialist workshop
• Immediately replace damaged power cords
• When connected with a mains plug, this mains plug must always be readily
accessible
Wear personal protective equipment!
Lacking or unsuitable personal protective equipment increases the risk of health
damage and injury.
Personal protective equipment includes, for example:
– Work gloves
– Safety shoes
- Protective clothing
– Breathing protection
- Hearing protection
– Face and eye protection
• Specify and provide personal protective equipment for the respective
application.
• Use only personal protective equipment that is in good condition and
provides effective protection.
• Adapt personal protective equipment to the person, e.g., by size.
Keep safety symbols legible!
Safety symbols on the unit warn of dangers in hazardous areas and are an
important part of the unit’s safety equipment. Missing safety symbols increase
the risk of injury to persons.
• Clean dirty safety symbols.
• Replace damaged and unrecognizable safety symbols immediately.
Maintenance and repair work!
Improper maintenance and repair work jeopardizes operational safety. This can
result in serious injury or death.
• Only carry out work described in this operating manual. Switch off the unit
and disconnect it from the power supply before carrying out any work.
• All other maintenance and repair work may only be carried out by a JULABO
service technician or a qualified specialist workshop.

Safety
10
4.3 Safety symbols
There are safety symbols included with the device, which should be attached to
the device before initial operation.
Read operating manual before switching on
Warning of a danger zone. Note operating manual
Warning about hot surface
4.4 Safety function
Technical protective devices provide for safe operation. If a safety function is
triggered, the operator is alerted with a message on the display and an acoustic
signal.
Adjustable high temperature cut-off
The high temperature cut-off prevents overheating of the heater.
• If the measured temperature rises above the set protective temperature, an
error message is shown on the display. The pump and heater are switched
off. A restart is required.
Produc t desc ri pti on

Product description
11
5 Product description
5.1 Function description
This section describes the function of the device.
The booster heater is an auxiliary heater for MAGIO circulators and consists of a
heater unit with two heating elements as well as a control unit.
The heater unit is placed on a suitable bath or a cooling machine instead of the
bath lid. The bath tank must be filled with bath fluid. An external application
connected to the circulator is required, as the bath tank can no longer be used
for temperature control of samples.
The control unit can be placed on or next to the circulator. The heating capacity
of the booster heater is added to the heating capacity of the circulator. The
booster heater communicates with the circulator via the CAN bus interface and,
if necessary, with a connected cooling machine. The status of the booster heater
is indicated by status symbols on the circulator display.
• At up to 33% heating capacity, only the circulator heater is enabled.
• From 33% heating capacity, the booster heater is switched on. Then both
heaters are actuated equally.
• When the booster heater is active, the pump is run at a minimum of 60%
rotational speed.

Product description
12
5.2 Operating and functional elements
The following figure shows the operating and functional elements and their
position on the unit.
Control and function elements
1
Heater unit housing
2
Connection cable between control unit and heater unit
3
Control unit housing
4
CAN bus plug
5
Circuit breaker
6
Supply main
7
Mains output socket
8
CAN bus plug
9
High temperature cut-off setting
10
Heating element
11
Safety temperature sensor
12
Safety temperature sensor
13
End plate

Product description
13
5.3 Operating interface
5.3.1 Softkeys and status icons
This section describes the softkeys and status icons found on the operating
interface.
Symbol Description
Booster heater is not detected by the circulator or is not
connected.
Booster heater is detected by the circulator and is enabled.
Booster heater is detected by the circulator and is disabled.
Booster heater is detected by the circulator and is enabled.
Only the circulator is heating.
Booster heater is detected by the circulator and is enabled.
Both the circulator and booster heater are heating.
Booster heater is detected by the circulator and is disabled.
Only the circulator is heating.
5.4 Technical data
This section describes the technical data of the unit.
Grouping of the device acc. to CISPR 11:
• The device is an ISM device of group 1, which uses high frequency for
internal purposes
• Class A: Use in an industrial electromagnetic environment
Classified in accordance with DIN 12876-1:
• Class II
Protection class according to EN 60 529:
• Protection class IP21

Product description
14
In accordance with IEC 61010-1, the device is designed for safe operation under
the following ambient conditions:
• Indoor use
• Altitude up to 2000 m above sea level
• Ambient temperature +5 … +40 °C
• Maximum relative humidity 80% for temperatures up to 31 °C, decreasing
linearly down to 50% relative humidity at 40 °C
• Mains voltage fluctuations up to ±10 % of the nominal voltage permissible
if not otherwise specified
• Contamination level 2
• Overvoltage category II
Technical data Booster Heater
Performance values
Working temperature range °C -50 … 300
Heating capacity kW 2 x 3
Viscosity max. cSt 70
Dimensions
Control unit (W x D x H) cm 20 x 17 x 19
Heater unit (W x D x H) cm 24 x 23 x 17
Total weight kg 8
Mains connection
208-230 V 3PPE
50/60 Hz
400 V 3PNPE
50 Hz
Current consumption A 28 16
Mains fuse, resettable
A
30
16

Transport and installation
15
6 Transport and installation
6.1 Transporting the device
This section describes how to transport the device safely.
CAUTION
Burn hazard on the heating element!
The heating element may still be hot even after the device has been switched
off, and may cause burns if touched.
• Allow the device to cool down to room temperature after switching off
• Wear protective gloves
The unit is switched off and cooled to room temperature.
1. Disconnect the power supply cable.
2. Before transport, disconnect all lines between the booster heater and the
circulator or cooling machine.
3. Remove the heater unit from the bath.
4. Place the unit on the center of a transport wagon.
5. Secure the unit against falling off.
6. Place loose parts for the unit, such as cables, on the transport trolley.
The unit is then ready for transport and can be safely transported to its
installation location.
6.2 Install the device at the operating location
This section describes how the device is set up at the installation location.
The unit has been transported to the operation location.
The circulator is switched off.
1. Place the control unit on the circulator or directly next to the unit.
2. Remove the bath lid from the bath or cooling machine.
3. Place the heater unit in the bath opening with the rounded corners facing
forward.
4. Make sure that the connection line between the heater unit and the control
unit is laid without tension or kinks.
The unit is set up at the operation location.

Initial operation
16
7 Initial operation
The operating manual of the corresponding circulator is required for initial
operation of the booster heater.
7.1 Connect the device to the power supply
A load-break switch is required for the booster heater.
The 400V variant requires a 3x16A load-break switch. The 208–230V variant
requires a 3x32A load-break switch.
In addition, the building must have a ground-fault circuit interrupter.
7.1.1 Connect bridge mounted or heating circulator
This section describes how to connect the booster heater to a bridge mounted
circulator or a circulator.
a
The circulator is mounted as a bridge mounted or heating circulator.
The connection cable, mains cable and CAN bus cable are ready for use.
Back

Initial operation
17
1. Connect the booster heater to the circulator using the connection cable [1].
2. Use the CAN bus cable to connect a CAN plug of the booster heater to the
CAN plug of the circulator.
3. Connect the booster heater to the mains using the mains cable [3].
The booster heater is connected to the circulator. Alternatively, the units
can be connected to separate circuits. If necessary, the power supply must
be set up in the unit setting of the circulator.
7.1.2 Connect refrigerated circulator
This section describes how to connect the booster heater to a refrigerated
circulator.
The unit is transported and set up.
The connection cable, mains cable and CAN bus cable are ready for use.
Back

Initial operation
18
1. Connect the connection cable [1] of the circulator with the cooling machine.
2. Connect the booster heater to the cooling machine using the second
connection cable [2].
3. Connect a CAN plug of the booster heater to the circulator using a CAN bus
cable [3].
4. Use the second CAN bus cable [4] to connect the second CAN plug of the
booster heater to the cooling machine.
5. Connect the booster heater to the mains using the mains cable [5].
The booster heater is connected to the refrigerated circulator. Alternatively,
all three units can be connected to separate circuits. If necessary, the power
supply must be set up in the unit setting of the circulator.
7.2 Fill device
This section describes what to pay attention to when filling the bath when the
booster heater is put into operation. The procedure takes into account a
connected external application.
The drain valve on the bath or cooling machine is closed.
The circulator is switched off.
1. Switch the circulator on.
The circulator indicates low liquid level alarm after starting.
2. Disable the booster heater in the menu [Install unit].
3. Turn the circulator off at the mains switch.
4. Remove the heater unit.
5. Half fill the bath with bath fluid.
The bath fluid expands with increasing temperature and can overflow.
With decreasing temperature, the low liquid level protection can be
triggered and interrupt the temperature control process.
6. Switch the circulator on.
The removed heater unit must be disabled. Check the status icon on the
home screen of the circulator: the two lowest dashes of the heater icon
must be crossed out.
7. Start the temperature control application.
The pump starts.
8. Watch the level indicator and, if necessary, adjust the level by refilling or
draining.
Once the working temperature has been reached and the sample inserted,
the level of bath fluid in the bath tank should cover the heating coil of the
heating circulator or the cooling coil of the cooling machine.
9. When the required fill level has been reached, place the heater unit in the
bath opening.
10. Enable the booster heater in the menu [Install unit].
The unit is filled with bath fluid.

Initial operation
19
7.3 Set high temperature safety function
Before each new temperature application, the temperature must be set for the
tank and internal reservoir high temperature cut-off. Set a value that is at least
25 K below the flash point of the bath fluid being used. The surface temperature
of the bath fluid must not exceed the flash point at any time. An alarm is
triggered when the set value is exceeded.
Slotted screwdriver, size 3
The unit is connected and ready for operation.
1. Switch the circulator on.
2. Call up the <Main menu>.
3. Scroll in the submenu <Adjust safety> to the menu option
[High temperature cut-off Booster Heater].
The currently set value is displayed here.
4. Use the screwdriver to adjust the high temperature cut-off on the booster
heater control unit and check the indicated value.
5. Set a value that is at least 25 K under the flash point of the bath fluid being
used.
The set value is immediately active.
The high temperature cut-off is set.
B

Operation
20
8 Operation
8.1 Enable booster heater
The booster heater is enabled via the circulator control menu.
The circulator is switched on.
The booster heater is placed in the filled bath and ready for operation.
1. Call up the <Main menu>.
2. In the submenu <Install unit> press the [Booster Heater] button to
enable or disable the booster heater.
The enabled booster heater heats up if required. On the home screen, the
current status of the booster heater is indicated by an icon.
8.2 Manual refilling of unit
In the case of low liquid level, the booster heater is disabled. An operator
message appears on the display of the circulator. The bath fluid should be
topped up.
CAUTION
Burn hazard on the heating element!
The heating elements of the booster heater become very hot during
operation and can cause burns if touched.
• DO NOT remove the heater unit from the bath during operation.
• Only switch on the booster heater if the heater unit is placed in a filled
bath.
• After switching off, allow the unit to cool down to room temperature
before removing the heater unit from the bath.
The circulator indicates low liquid level. The booster heater has been
disabled by the circulator.
An operator message prompts refilling.
1. You can acknowledge the operator message on the display with [OK].
The operator message is also automatically hidden if bath fluid has been
topped up.
2. Allow the unit to cool down to room temperature.
3. Remove the heater unit of the booster heater from the bath.
4. Refill the bath fluid.
5. When the required fill level has been reached, place the heater unit back
into the bath opening.
