Herschel HAWAII WAVE User manual

1x Base with feet ed 1x Boom Straight Pole 1x Top Curved Pole 1x Hawaii 2000
1x M8 Eye Bolt 4x M6x10mm Allen screws 4x M6 Split washers 1x M5x12mm Allen screw
1x Carabina clip
1x 4mm Allen Key
1x 3mm Allen Key
TOOLS REQUIRED
PARTS INCLUDED
1x Cable with plug ed Page 1 of 2
HAWAII WAVE INSTALLATION GUIDE

Exploded View
Hawaii 2000
Curved Top Pole
M5x12mm Allen
Screw
Boom Pole
4x M6x10mm
Allen Screws
Base Plate
Clip
M8 Eye Bolt
4x M6 Split
Washers
Feed the cable up through the hole in the boom
of the base plate. Feed the end with the small
connector not the 3-pin plug end.
Now feed the cable up through the boom pole
so that it end up hanging our of the top. Start at
the end with the xing plate.
Fix the boom pole to the base plate using the
four M6x10mm screws and the M6 split washers.
Step 1
The top curved pole will arrive with the cable and
plug ed. Connect the cable from the boom
pole to the cable from the top pole and then slot
the top pole into the boom pole.
Using the M5x12mm allen screw locate the hole
on the back below the join and t the screw. You
will require a 3mm allen key for this.
Step 2
Insert the M8 eye bolt into the threaded hole
located at the top of the curved pole.
Using the clip, aach the Hawaii 2000 to the eye
bolt.
Plug in the top of the cable to the Hawaii making
sure to line up the pins correctly. Screw the two
halves together sealing the inside of the plug.
Step 3
Page 2 of 2
