Juling Electronics HE05 User manual

Dongguan Juling Electronics Technology Co., Ltd
Manual
BLUETOOTH HEADPHONES
HE05

2
1. Introduction...........................................................................................................................3
1.1 Foreword.........................................................................................................................3
1.2 Package Contents ..........................................................................................................3
1.3 Warnings.........................................................................................................................3
2. Specifications .......................................................................................................................3
3. Use Instructions ...................................................................................................................4
3.1 Charging the Headphones..............................................................................................4
3.2 Basic Functions ..............................................................................................................4
4. Connections..........................................................................................................................6
4.1 Supported Bluetooth End Devices..................................................................................6
4.2 Bluetooth Connection .....................................................................................................6
4.3 Connection via Audio Cable ...........................................................................................6
5. Warranty................................................................................................................................6
6. Copyright and Trademarks..................................................................................................6

3
1. Introduction
1.1 Foreword
Thank you for choosing the Bluetooth stereo headphones. We wish you lots of enjoyment with this home electronic device.
Below all functions and features of the device are described.
Note: All information in this manual was complete and correct at the time of publishing. However, since the product is
continuously updated and developed by our engineers it can occur that the software of your device deviates in appearance or
has modified functions from this manual.
1.2 Package Contents
Item Quantity
Headphones 1
USB cable 1
Audio cable 1
Warranty card 1
Manual 1
Please note: The actual package contents may deviate from this list.
1.3 Warnings
Please read the following information before first use for safe and efficient use of the Bluetooth headphones.
1.3.1 Use Information
Do not try to modify the device hardware, since this will lead to the expiration of your warranty. The ambient temperature during
use should be between +5°C and +35°C.
1.3.2 Radio Interferences
- If not particularly shielded nearly all electric appliances are disturbed by radio interferences. Under certain conditions your
device could be disturbed.
- The design of theses headphones follows FCC/CE standards and is governed by following regulations:
(1) These Bluetooth headphones create no harmful radio interferences.
(2) The Bluetooth headphones may be affected by radio interference of other devices.
1.3.3 Repair
In case of problems with the Bluetooth headphones contact a certified repair workshop and have the repairs done by authorized
specialists. Never repair the device yourself, you may damage the Bluetooth headphones and endanger yourself.
1.3.4 Disposal of Bluetooth Headphones
Ensure proper disposal of your Bluetooth headphones. In some countries provisions for the disposal of waste electronic devices
are in place. Please observe the local laws.
1.3.7 Miscellaneous
Protect your Bluetooth headphones from water and other liquids. Wipe splashing water with a dry cloth from your Bluetooth
headphones.
Electronic devices are delicate. Avoid vibration and impact, especially during operation and do not press the buttons forcefully.
Protect the device from magnetic fields.
2. Specifications
Bluetooth version: V3.0 + EDR
Bluetooth profile: Hands-free headphones, A2DP, AVRCP
A2DP Advanced Audio Distribution Profile (audio transmission)
(volume control, remote control Play/Pause as well as previous/next track)
AVRCP Audio/Video Remote Control Profile (remote control function)
HSP Headset Profile (headset functions)
HFP Hands-free Profile (hands-free functions)
(answer/ end/ volume control)
Range: up to 10m
Music playback duration: up to 15 hours
Input voltage: DC +5.0V ±0.25VA
Capacity: 400mA
Charging duration: 3 hours
Weight: 174g

4
3. Use Instructions
3.1 Charging the Headphones
3.1.1 First Charging Cycles
Please fully charge your headphones before first use. The first two charging cycles should take approx. 12 hours, afterwards 3
hours are sufficient.
3.1.2 Charging
Ensure before use that the headphones are fully charged. Connect the device via the supplied USB cable with a free USB port
of your computer (500mA). While connected the LEDs will light up blue, depending on charge status.
3.1.3 Parallel Use
We do not recommend using the headphones during the charging cycle.
3.2 Basic Functions

5
1. Previous track* 2. Multifunctional button 3. Status LED
4. Next track* 5. USB port 6. Adjustable headphones head band
7. Volume + 8. Volume - 9. Microphone
10. Input jack
1. Skip to previous track.*
2. Multifunctional button for:
a) ON/OFF
b) Play/Pause during music playback*
c) Answer/end calls
d) Start pairing with other Bluetooth devices
3. LED for ON/OFF, Bluetooth connection and pairing.
4. Skip to next track.*
5. USB charging port.
6. You can adjust the headphones with the adjustable headband to your head size; to save space the headphones can be
folded inward.
9. Built-in microphone to use headphones as headset.
10. Alternatively connect the headphones via the supplied cable to audio output jack.
*During background music playback the function may not work properly.
Function Operation
ON/OFF ON: Press and hold the multifunctional button for approx. 5 seconds to switch on the
headphones; the LED flashes red and blue.
OFF: Press and hold the multifunctional button for approx. 3 seconds to switch off the
headphones; the LED lights up purble, a signal sounds and switches off.
Pairing Press and hold the multifunctional button for approx. 5 seconds. The LED flashes
alternately blue and red for approx. 3 minutes; during this period you can pair the
headphones with your Bluetooth device.
Start pairing Start pairing on your Bluetooth device (e.g. tablet, smartphone, computer, etc.) and search
for available devices. You should find a device named “HE05 V3.0”.
Complete pairing and set the Bluetooth headphones as standard audio output device. Enter
“0000” if the device prompts you to enter a code.
Answer / End calls Press the multifunctional button to answer a call and press again to end the call.
Play / Pause* Press the multifunctional button to pause music playback. Press again to continue
playback. *During background music playback the function may not work properly.
Previous* / Next Track* Press the |<</>>| buttons to skip to the previous or next track. *During background music
playback the function may not work properly.
Volume + / - Press the -/+ buttons to decrease or increase the headphones volume.

6
4. Connections
4.1 Supported Bluetooth End Devices
1. Pairing with mobile phone, smartphones such as iPhone, Android devices or similar, PDA.
2. Pairing with Bluetooth dongle or computer with MS Windows, Mac OS, Linux.
3. Pairing with tablet- such as iPad, Android devices or similar.
4. Pairing with video game consoles such as Playstation III or similar.
4.2 Bluetooth Connection
Pair the headphones with a smartphone or other device. You can only use your Bluetooth headphones after pairing with a
smartphone or computer. As soon as your Bluetooth headphones are paired with a particular smartphone both devices stay
paired and recognize each other within the range.
1. Turn on the headphones and start pairing.
2. Turn on your smartphone and ensure that the Bluetooth function is activated.
3. Search for available Bluetooth devices according to the instructions for your smartphone. You will find details in the
smartphone’s manual.
4. After a few seconds the smartphone should detect “HE05 V3.0” as an available device. Select it and follow the smartphone’s
directions to pair with “HE05 V3.0”.
5. Now you can play music on your smartphone, watch TV or movies and play games and you can hear the sound via the
headphones. You can control the smartphone via the headphones and automatically switch between hands-free telephony and
music playback; never again miss incoming calls.
Note: Please check if the headphones are set as standard audio output device if you cannot hear the sound after pairing the
Bluetooth headphones.
4.3 Connection via Audio Cable
Use the supplied audio cable to connect the headphones to a normal audio output jack.
5. Warranty
Our warranty excludes:
- Damage due to natural impact such as fire or electrostatic discharge.
- Damage due to improper repair, modification or accident.
- Damage due to improper use, wrong installation or negligence.
- Damage due to institutional or commercial use.
6. Copyright and Trademarks
Copyrights
All rights reserved. It is prohibited to reproduce this manual, store on data storage system or record electronically,
mechanically, by photocopy or distribute in any other way without prior written consent of the copyright owner. According to
copyright law recorded data are only for personal use.
Trademarks
Bluetooth ® is a registered trademark of Bluetooth ® SIG.
iPad is a registered trademark of Apple Inc., Cupertino, CA, U.S.A.
All other trademarks are the rightful property of their copyright owners.

7
FCC FCC warning statement:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to
operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
