Jumbuck Astro 4 User manual

900(L) x 540(W) x 460(H) mm
Built
4
Astro
Front Removable Grease Tray
●
Large glass viewing window
4

1
BBQ ASSEMBLY & OPERATION INSTRUCTIONS
4 BURNER BULIT IN – MODEL SYGP 4BB

2

3

4

5

6

7

8
1 Hood 2 Warming rack 3 Cooking grill 4 Hotplate
5 Firebox rear panel 6 Firebox 7 Firebox side panel
- left
8 Firebox side panel
- right
9 Flame tamer X 2 12 Control knob X 4
13 Grease tray
10 Support plate
- left
11 Support plate
- right

Hardware Pack
No. Description Image Qty
9
A8
M6x10 Screws ( Silver )
13
M5x10 Screws ( Black )
B
13
M5 Flat Washer ( Black )
C
4
M5 Nuts ( Black )
D
E
F
G
R pin
Screwdriver
M8x20 Hinge Pin 2
2
1

NOTE:
- Always wear gloves during assembly of this BBQ.
- Assemble the BBQ on a flat level surface
STEP 1
Assemble the ' Support plate-left' (10) 1pc & ' Support plate-right' (11) 1pc to the 'Firebox'(6)
using Screw (A) 8pcs as shown.
STEP 2
Assemble the 'Fire box side panel - left' (7) and 'Firebox side panel - right' (8) to the 'Firebox'
(6) using Screw (B) 6pcs and Flat washer (C) 6pcs as shown.
10

STEP 4
Assemble the 'hood' (1) to the 'firebox' (6) using'Hinge pin'(E) 2pcs and'R pin'(F) 2pcs as
shown.
11
STEP 3
Assemble the 'Fire box rear panel' (5) to the 'Firebox'(6) using Screw (B) 7pcs, Flat washer
© 7pcs and nut (D) 4pcs as shown.

STEP 6
Put the'Hotplate'(4) 1pc,'Cooking grill'(3) 1pc and'Warming rack'(2) 1pc into the firebox as
shown.
12
STEP 5
Put the 'Flame tamer' (9) 2pcs into the fire box as shown.
NOTE: Flame tamers should be located under the cooking grill.

STEP 8
Assemble the 'Control knob' (12) 4pcs to the 'Firebox' as shown.
13
STEP 7
Insert the Grease tray (13) into the firebox as shown.

14
STEP 9
Your BBQ is now fully assembled.

21

22

860mm
505mm
160mm min.
220mm
110mm x 110mm
hole for hose access
INSTALLATION
400mm
CUT OUT DIMENSIONS
The cut out must be made from non-combustible material only.
The 400mm tall, non-combustible rear splashback is not necessary provided there
is no combustible material within 500mm of the rear of the BBQ.
If the BBQ is supplied with a duplicate data label, apply this label in the immediate
vicinity of the BBQ in an easily accessible area.
Combustion air openings are located at various locations around the BBQ firebox.
The cutout dimensions explained above must be met to ensure there is adequate
space for entry of air for satisfactory combustion.
Gas vapour is highly explosive and can cause serious bodily injury or damage to
property if allowed to accumulate in a confined space and ignited. If you choose to
build an enclosure to house an LPG cylinder, at least one side of the enclosure
shall be completely open, and ventilation must meet the minimum requirements of
AS5601.1.
