Jumper JPD-FR203 User manual

JPD-FR203
Infrared Thermometer
Instruction Manual
Shenzhen Jumper Medical Equipment Co., Ltd
Manual Version: 1.0
Date of Issue: 2018/09/18
0482

Product Information
Product Name: Infrared Thermometer
Model: JPD-FR203
Manufacturer: Shenzhen Jumper Medical Equipment Co., Ltd
Address: D Building, No. 71, Xintian Road, Fuyong Street, Baoan,
Shenzhen, Guangdong, China.
Copyright
Copyright © Jumper Medical.
All rights reserved.
Statement
Shenzhen Jumper Medical Equipment Co., Ltd. owns and reserves all of
the rights comprised in the copyright of this document. No part of this
document may be changed, excerpted, copied, reproduced, or imitated in
any form or by any means without the prior consent of Shenzhen Jumper
Medical Equipment Co., Ltd.
All statements, information, and recommendations in this document are
provided "AS IS" without warranties, guarantees or representations of any
kind, either express or implied. The information in this document is
subject to change without notice. Shenzhen Jumper Medical Equipment
Co., Ltd. reserves the right of final interpretation of this document.
Introduction
Thank you for purchasing this Infrared Thermometer. Please read the
Instruction Manual carefully to make sure safe and proper use of this
thermometer.
Please read and fully understand the Safety Precautions before use.
Keep the Instruction Manual with this thermometer for future
reference.

Contents
Unpacking Check.............................................................................................1
Package Contents............................................................................................. 1
Safety Precautions............................................................................................1
Warning.............................................................................................................2
Symbols............................................................................................................ 3
Body Temperature Basics................................................................................4
Product Description......................................................................................... 5
Features.............................................................................................................6
Product Structure..............................................................................................7
Display Description......................................................................................... 7
Sounds and Backlight Instructions..................................................................8
Display and Operating Instructions................................................................ 8
Measuring Forehead Temperature................................................................ 15
Measuring Object Temperature.....................................................................16
Replacing Batteries........................................................................................17
Cleaning and Disinfection.............................................................................18
Maintenance................................................................................................... 20
Troubleshooting............................................................................................. 21
Specifications................................................................................................. 22
Security Class.................................................................................................23
Storage and Transportation............................................................................23
EMC Information-Guidance and Manufacture’s Declaration.....................24
Warranty and After-Sale Service...................................................................28

1
Unpacking Check
Please open the package carefully before use, check whether all
accessories are available or not and whether any component is damaged
during transportation, and perform installation and operation following this
user manual. In case of any damage or operation problem, please contact
the dealer or contact Jumper directly. You will need the following
information when making your claim: device model, serial number,
purchase date, and your contact information and address.
Package Contents
No.
Name
Quantity
1
Infrared Thermometer
1
2
Pouch
1
3
Battery (AAA)
2
4
Instruction Manual
1
Safety Precautions
Read the following precautions carefully before using the
thermometer.
Attention
Take care of the temperature probe lens, which is fragile.
Dispose used batteries with care. To protect the environment,
you are recommended to send the used batteries to a designated
collection point.
Remove the batteries if the thermometer will not be used for
more than two months.
Do not immerse the thermometer in water or expose it to direct
sunlight.
Do not subject the thermometer to vibration or impact.
Do not take body temperature readings within 20 minutes after

2
you do physical exercises or get excited.
Do not use the thermometer for continuous temperature
monitoring purposes.
Do not immerse the thermometer into water or other liquid. Clean
and disinfect the thermometer as described in the "Cleaning and
Disinfection" chapter.
Do not touch the tip of the temperature probe, on which a
precise temperature sensor resides.
The ambient temperature must not be extremely high or low. To
make sure accurate readings, keep the thermometer under room
temperature for more than 30 minutes before use.
Do not use the thermometer under an ambient temperature
higher than 40°C (104°F) or lower than 10°C (50°F), which is
beyond the operating temperature range of the thermometer.
Risk of pollution! The user is recommended to send the
overdue thermometer to local garbage disposal site or send it
back to us.
2 AAA batteries of 1.5V are the only replaceable accessories of
the thermometer. Please do not use the batteries of other
voltages or specifications.
Warning
Warning
The thermometer is not intended to diagnose or treat any health
problem or disease. The measurement results are for reference
only.
It is dangerous to make a self-diagnosis or self-treatment based
on the obtained measurement results. For such purposes, please
consult a physician or other medical professionals.
Do not charge an alkaline dry-cell battery or throw it in fire.
Otherwise, the battery may explode.
Do not disassemble the thermometer or attempt to repair it.

3
Otherwise, the thermometer may be damaged permanently.
During measurement, do not use a mobile phone or any other
device that may cause electromagnetic interference.
Do not use the thermometer in an environment where
flammable anesthetic mixture with air or with oxygen, or
nitrous oxide is available.
Please keep the thermometer out of the reach of children.
The result may be inaccurate if you use the overdue
thermometer.
Symbols
Symbol
Description
Type BF applied part.
Attention must be paid.
The action is prohibited.
Information about the manufacturer.
Date of manufacture.
Consult the instructions for use.
This product complies with the MDD93/42/EEC
requirements.
Waste electrical materials should be sent to a
dedicated collection point for recycling.

4
Symbol
Description
IPX0
Degree of protection against the Ingress of water.
Warning
A personal injury or damage to the thermometer
may occur if the thermometer is not used correctly.
Attention
Inaccurate reading or damage to the thermometer
may occur if the thermometer is not used correctly.
Body Temperature Basics
You can take a body temperature on the forehead, in the ear canal, under
the armpit, in the mouth, or in the anus. The temperature measured at
different parts of the body may differ slightly.
Body Part
Normal Temperature Range
Forehead
36.1°C–37.5°C / 97.0°F–99.5°F
Ear canal
35.8°C–38.0°C /
96.44°F–100.40°F
Mouth
35.5°C–37.5°C / 95.9°F–99.5°F
Armpit
34.7°C–37.3°C / 94.46°F–99.14°F
Anus
36.6°C–38.0°C /
97.88°F–100.40°F
The normal body temperature range slightly varies with age and gender.
Generally, newborns or children have higher body temperature than adults,
and adults have higher body temperature than the elderly. Women's body
temperature are appropriately 0.3°C higher than men's.

5
Variation in body temperature
Product Description
1) Overview
Infrared Thermometer JPD-FR203 measures the human body or an object
temperature based on the infrared energy emitted by the forehead or an
object (such as milk and water). You can quickly get measurement results
after pointing the temperature probe to the target.
2) Structure
The thermometer consists of a shell, an LCD, buttons, a beeper, an
infrared temperature sensor, and a Microprocessor.
3) Operating principle
The infrared temperature sensor collects infrared energy emitted by the
forehead. After being focused by a lens, the energy is converted into a
temperature reading by the thermopiles and the measurement circuit.
4) Intended use
The Infrared Thermometer JPD-FR203 is a non-contact infrared
thermometer intended to obtain the body temperature from the forehead. It
may be used by medical professionals or by consumers in a home
environment.
5) Contraindications
None
Normal body temperature varies
by the time of day and is also
affected by external factors.
The body temperature of an
individual is the lowest between
2:00 a.m. and 4:00 a.m. and the
highest between 14:00 p.m. and
20:00 p.m. An individual's body
temperature typically changes by
less than 1°C each day.

6
Features
1. Good safety
● Passive infrared receiving technology
● Non-contact measurement, preventing cross-infection
2. Easy operation
● Handheld design, easy operation
● One-click automatic temperature measurement
3. Quick response
1-second measurement
4. High accuracy
● Advanced infrared temperature sensor, with high sensitivity
● Enhanced accuracy with automatic temperature calibration
5. Diverse functions
● 20 temperature readings stored in memory
● Forehead/Object temperature measurement
● Fever alert, with a configurable alert threshold
● Switching between ºC and ºF
● Switching between mute/un-mute mode (measuring sound
notification)
● Automatic power-off, power-saving
6. Extensive application scope
Applicable to all groups of people
7. Child Mode
This mode is recommended for people under 12 years of age.

7
Product Structure
1、LCD display
2、Power button / Measure button
3、Sound switch button
4、Memory button
5、Mode button(Adult forehead temperature 、Child's forehead
temperature 、Object temperature)
6、Battery cover
Display Description
1. Object temperature mode
2.Adult forehead temperature mode
3.Child's forehead temperature
4. Low power indicator
5.Mute / un-mute
6. Temperature unit (˚C / ˚F)
7. Memory mode
8. Temperature value

8
Sounds and Backlight Instructions
Range
Sounds
Backlight
Forehead temperature
35.0℃-37.5℃/95.0℉-99.5℉
A long beep
Green
37.6 ℃-37.9 ℃/99.7 ℉ -100.2 ℉
A long beep
Orange
38.0℃-42.2℃/100.4℉-108.0℉
3 short double beeps
Red
Object temperature
0℃-100℃/32.0℉-212.0℉
A long beep
Green
Note: When the temperature is between 35.0℃-37.5℃（95.0℉-99.5℉）,
there will be a long beep and a Green backlight, Indicates normal body
temperature.
When the temperature is between 37.6°C/99.6℉and 37.9°C/100.2℉,
there will be a long beep and a orange backlight. This indicates that the
body temperature is slightly elevated .
When the temperature is between 38.0°C/100.4℉and 42.2°C/108.0℉,
there will be 3 short double beeps and a red backlight. This indicates that
the body temperature is a little high and you may have a fever. Please
consult your doctor if you are not sure.
Display and Operating Instructions
Screen Display
Operating Instructions/ Displayed
State
Description

9
Screen Display
Operating Instructions/ Displayed
State
Description
Measuring Forehead temperature(Adult/child)
Adult forehead
temperature
Child forehead
temperature
Press the power button,then press the
mode button, the thermometer enters
the forehead mode, and the screen
display .
Switch to adult or child measurement
mode according to your measurement
needs
point the IR sensor to the center of
the forehead. Move the thermometer
towards the forehead. For effective
measurement, the distance between
the thermometer and the forehead
must be ½”to 2”(1-5 cm). Press and
release the Measure button. The
forehead temperature will be
displayed on the screen.
See the table in
the “Sounds and
Backlight
Instructions”
section
Measuring Object temperature

10
Screen Display
Operating Instructions/ Displayed
State
Description
In a power-on state, press the “Mode
button”, the thermometer enters the
Object mode.
Object temperature mode
displayed on the screen.
Point the IR sensor to the center of
the object, then press and release the
Measure button. the object
temperature will be displayed on the
screen.
See the table in
the “Sounds and
Backlight
Instructions”
section
Out of the measuring range display
In Object mode, a
temperature reading of more than
100ºC (212.0ºF)
A long beep and
the backlight is
red
In Forehead mode, a temperature
reading of more than 42.2ºC
(108.0ºF)
In Object mode, a temperature
reading of less than 0ºC (32.0ºF)
A long beep and
the backlight is
red.
In Forehead mode, a temperature
reading of less than 35.0℃（95.0℉）
Switching between ºC and ºF

11
Screen Display
Operating Instructions/ Displayed
State
Description
In a power-on state, Press the
measurement button for about 3
seconds. You can switch units
Silent
Switching between forehead temperature and object temperature
In a power-on state, press the Mode
button to switch between adult
forehead temperature , child
forehead temperature
and object temperature .Each
time you press to switch one mode,
Cycle switching
Silent,the
backlight is
green
Switching between mute and un-mute

12
Screen Display
Operating Instructions/ Displayed
State
Description
In a power-on state,
Press the sound switch button to
switch the sound on or off, a long
beep will be sounded when the sound
is turned on, and a mute symbol
will be displayed when the sound is
turned off.
A long beep
will be sounded
when the sound
is turned on. The
backlight is
green
Recall 20 memories

13
Screen Display
Operating Instructions/ Displayed
State
Description
In a power-on state, press the
Memory button, Enter the memory
mode.
When leave memory button
LCD display“01” followed by the
recorded reading.
Press the “Memory button” again
for the next recorded ,data 02 will be
shown, followed by the recorded
reading.a maximum of 20
temperature readings can be recalled.
Note:
01 represents the newest data.
Silent,the
backlight is
green
No memory data / Clear memory data

14
Screen Display
Operating Instructions/ Displayed
State
Description
When the memory data is queried,
when there is no memory data under
the current serial number, the display
is as shown.
Remove 2 dry batteries and re-install
the power to clear all memory data.
When the power
is turned back
on, a long beep,
the backlight is
green, then turn
red
Error information & low battery
The ambient temperature is higher
than 40.0ºC (104.0ºF) or lower than
10.0ºC (50.0ºF).
A long beep,the
backlight is red.
An error occurs when data is being
read from or written to the memory,
or the temperature correction is not
complete.
A long beep,the
backlight is
red.
When the battery voltage is lower
than 2.5V ± 0.1V, the low battery
symbol will appear on the display.
Please replace the batteries.
Silent

15
Measuring Forehead Temperature
1. When using the thermometer for the first time, move the battery’s
insulating piece away.
2. Press the Power button to power on the thermometer.
3. When measuring adults, place the switching device in the "adult" mode.
When measuring children, place the switching device in "child" mode
and the symbol is displayed on the screen.
4. Point the thermometer probe to the center of the forehead, about
(1-5cm) away from the skin surface.
5. Press and release the Measure button for 1 second. The temperature
reading will be displayed on the screen instantly.

16
6. If no activity is detected, the thermometer will power off automatically
in 10 seconds.
Measuring Object Temperature
1. Press the Power button to power on the thermometer.
2. Press the Mode button, the thermometer enters the Object mode.
The “ ” symbol is displayed on the screen.
3. Point the thermometer probe to the center of the object, about
1-5cm away from the object surface.
4. Press and release the Measure button for 1 second. The
temperature reading will be displayed on the screen instantly.
5. If no activity is detected, the thermometer will power off
automatically in 10 seconds.
After a measurement
(1) After each measurement, you can enter the recall mode and query
earlier temperature readings. For more details, see "Recall 20
memories" in the preceding table.
(2) After each measurement, clean the temperature probe with a soft cloth,
and put the thermometer in a dry and well-ventilated place.

17
It is dangerous to make a self-diagnosis or self-treatment based on
the obtained measurement results. For such purposes, please consult a
doctor.
Notes:
(1) The thermometer is suitable for an indoor environment without strong
air convection between the thermometer and the target. For example,
winds from a fan, an air-conditioner, or a heater.
(2) Do not hold the thermometer for a long time, because it is sensitive to
the ambient temperature.
(3) Make sure the sense head is free of foreign matters before use;
(4) Make sure the forehead has no sweat and no hairs covered before
measure the forehead temperature; otherwise, the result could be
incorrect;
(5) No intense emotion or strenuous exercises before measuring;
(6) After measuring the data once, you should wait for the backlight to
turn off and measure the next data.
Replacing Batteries
1、Slide the battery cover off along the marked direction and take it off.
2、Insert the two AAA batteries into the compartment according to the
stated polarities.
