Jungheinrich EZS 350 XL User manual

08.09 -
11.14
51133023
EZS 350 / 350 XL / C40
Operating instructions G
EZS 350 XL
EZS C40
EZS 350

3
11.14 EN
Declaration of Conformity
Jungheinrich AG, Am Stadtrand 35, D-22047 Hamburg
Manufacturer or agent acting in the European Union
Additional information
On behalf of
Date
GEU Conformity Declaration
The undersigned hereby declare that the powered industrial truck described below in
detail complies with the European Directives 2006/42/EC (Machinery Directive) and
2004/108/EEC (Electromagnetic Compatibility - EMC) including amendments as well
as the legislative decree to incorporate the directives in national law. The signatories
are in each case individually authorized to compile the technical documents.
Type Option Serial no. Year of
manufacture
EZS 350
EZS 350 XL
EZS C40
3
11.14 EN
Declaration of Conformity
Jungheinrich AG, Am Stadtrand 35, D-22047 Hamburg
Manufacturer or agent acting in the European Union
Additional information
On behalf of
Date
GEU Conformity Declaration
The undersigned hereby declare that the powered industrial truck described below in
detail complies with the European Directives 2006/42/EC (Machinery Directive) and
2004/108/EEC (Electromagnetic Compatibility - EMC) including amendments as well
as the legislative decree to incorporate the directives in national law. The signatories
are in each case individually authorized to compile the technical documents.
Type Option Serial no. Year of
manufacture
EZS 350
EZS 350 XL
EZS C40

11.14 EN
4
11.14 EN
4

5
11.14 EN
Foreword
Notes on the operating instructions
The present ORIGINAL OPERATING INSTRUCTIONS are designed to provide
sufficient instruction for the safe operation of the industrial truck. The information is
provided clearly and concisely. The chapters are arranged by letter and the pages are
numbered continuously.
The operator manual details different industrial truck models. When operating and
servicing the industrial truck, make sure that the particular section applies to your
truck model.
Our trucks are subject to ongoing development. Jungheinrich reserves the right to
alter the design, equipment and technical features of the system. No guarantee of
particular features of the truck should therefore be assumed from the present
operating instructions.
Safety notices and text mark-ups
Safety instructions and important explanations are indicated by the following
graphics:
DANGER!
Indicates an extremely hazardous situation. Failure to comply with this instruction will
result in severe irreparable injury and even death.
WARNING!
Indicates an extremely hazardous situation. Failure to comply with this instruction
may result in severe irreparable injury and even death.
CAUTION!
Indicates a hazardous situation. Failure to comply with this instruction may result in
slight to medium injury.
NOTE
Indicates a material hazard. Failure to comply with this instruction may result in
material damage.
ZUsed before notices and explanations.
tIndicates standard equipment
oIndicates optional equipment
5
11.14 EN
Foreword
Notes on the operating instructions
The present ORIGINAL OPERATING INSTRUCTIONS are designed to provide
sufficient instruction for the safe operation of the industrial truck. The information is
provided clearly and concisely. The chapters are arranged by letter and the pages are
numbered continuously.
The operator manual details different industrial truck models. When operating and
servicing the industrial truck, make sure that the particular section applies to your
truck model.
Our trucks are subject to ongoing development. Jungheinrich reserves the right to
alter the design, equipment and technical features of the system. No guarantee of
particular features of the truck should therefore be assumed from the present
operating instructions.
Safety notices and text mark-ups
Safety instructions and important explanations are indicated by the following
graphics:
DANGER!
Indicates an extremely hazardous situation. Failure to comply with this instruction will
result in severe irreparable injury and even death.
WARNING!
Indicates an extremely hazardous situation. Failure to comply with this instruction
may result in severe irreparable injury and even death.
CAUTION!
Indicates a hazardous situation. Failure to comply with this instruction may result in
slight to medium injury.
NOTE
Indicates a material hazard. Failure to comply with this instruction may result in
material damage.
ZUsed before notices and explanations.
tIndicates standard equipment
oIndicates optional equipment

11.14 EN
6
Copyright
Copyright of these operating instructions remains with JUNGHEINRICH AG.
Jungheinrich Aktiengesellschaft
Am Stadtrand 35
22047 Hamburg - Germany
Tel: [phone]
www.jungheinrich.com
11.14 EN
6
Copyright
Copyright of these operating instructions remains with JUNGHEINRICH AG.
Jungheinrich Aktiengesellschaft
Am Stadtrand 35
22047 Hamburg - Germany
Tel: [phone]
www.jungheinrich.com

7
11.14 EN
Table of contents
A Correct Use and Application ................................................... 9
1 General.................................................................................................... 9
2 Correct application................................................................................... 9
3 Approved application conditions.............................................................. 9
4 Proprietor responsibilities ........................................................................ 10
5 Adding attachments and/or accessories.................................................. 10
B Truck Description .................................................................... 11
1 Application ............................................................................................... 11
2 Assemblies and Functional Description................................................... 12
2.1 Assembly Overview ................................................................................. 12
2.2 Functional Description ............................................................................. 14
3 Technical Specifications .......................................................................... 16
3.1 Performance data .................................................................................... 16
3.2 Dimensions.............................................................................................. 17
3.3 Weights.................................................................................................... 19
3.4 Tyre type.................................................................................................. 19
3.5 EN norms................................................................................................. 20
3.6 Conditions of use..................................................................................... 21
4 Identification points and data plates ........................................................ 22
4.1 Data plate ................................................................................................ 23
C Transport and Commissioning ................................................ 25
1 Lifting by crane ........................................................................................ 25
2 Transport ................................................................................................. 26
3 Using the Truck for the First Time ........................................................... 27
D Battery - Servicing, Recharging, Replacement ....................... 29
1 Safety Regulations Governing the Handling of Lead-Acid Batteries ....... 29
2 Battery types............................................................................................ 30
3 Exposing the battery................................................................................ 32
4 Charging the battery ................................................................................ 33
5 Battery removal and installation .............................................................. 35
E Operation ................................................................................ 39
1 Safety Regulations for the Operation of the Forklift Truck....................... 39
2 Displays and Controls.............................................................................. 41
2.1 Battery discharge indicator ...................................................................... 43
3 Starting up the truck ................................................................................ 44
7
11.14 EN
Table of contents
A Correct Use and Application ................................................... 9
1 General.................................................................................................... 9
2 Correct application................................................................................... 9
3 Approved application conditions.............................................................. 9
4 Proprietor responsibilities ........................................................................ 10
5 Adding attachments and/or accessories.................................................. 10
B Truck Description .................................................................... 11
1 Application ............................................................................................... 11
2 Assemblies and Functional Description................................................... 12
2.1 Assembly Overview ................................................................................. 12
2.2 Functional Description ............................................................................. 14
3 Technical Specifications .......................................................................... 16
3.1 Performance data .................................................................................... 16
3.2 Dimensions.............................................................................................. 17
3.3 Weights.................................................................................................... 19
3.4 Tyre type.................................................................................................. 19
3.5 EN norms................................................................................................. 20
3.6 Conditions of use..................................................................................... 21
4 Identification points and data plates ........................................................ 22
4.1 Data plate ................................................................................................ 23
C Transport and Commissioning ................................................ 25
1 Lifting by crane ........................................................................................ 25
2 Transport ................................................................................................. 26
3 Using the Truck for the First Time ........................................................... 27
D Battery - Servicing, Recharging, Replacement ....................... 29
1 Safety Regulations Governing the Handling of Lead-Acid Batteries ....... 29
2 Battery types............................................................................................ 30
3 Exposing the battery................................................................................ 32
4 Charging the battery ................................................................................ 33
5 Battery removal and installation .............................................................. 35
E Operation ................................................................................ 39
1 Safety Regulations for the Operation of the Forklift Truck....................... 39
2 Displays and Controls.............................................................................. 41
2.1 Battery discharge indicator ...................................................................... 43
3 Starting up the truck ................................................................................ 44

11.14 EN
8
3.1 Checks and operations to be performed before starting daily operation . 44
3.2 Preparing the truck for operation ............................................................. 45
3.3 Parking the truck securely ....................................................................... 46
3.4 Battery discharge monitor........................................................................ 46
4 Industrial Truck Operation ....................................................................... 47
4.1 Safety regulations for truck operation...................................................... 47
4.2 Emergency Disconnect, Travel, Steering, Braking .................................. 49
4.3 Pedestrian mode ..................................................................................... 53
4.4 Coupling Types........................................................................................ 54
4.5 Travelling with trailers.............................................................................. 56
4.6 Seat (o) (XL and C40 only)..................................................................... 57
5 Troubleshooting....................................................................................... 58
5.1 Truck does not start................................................................................. 58
6 Operating the truck without its own drive system .................................... 59
7 Optional equipment ................................................................................. 60
7.1 CanDis display instrument....................................................................... 60
7.2 CanCode keypad..................................................................................... 62
7.3 Setting the truck parameters with CanCode............................................ 67
7.4 ISM access module (o)........................................................................... 68
7.5 Parameters .............................................................................................. 69
F Industrial Truck Maintenance .................................................. 77
1 Operational Safety and Environmental Protection................................... 77
2 Maintenance Safety Regulations............................................................. 77
3 Servicing and Inspection ......................................................................... 83
4 Maintenance checklist ............................................................................. 84
4.1 Owner ...................................................................................................... 84
4.2 Customer Service .................................................................................... 86
5 Lubricants and Lubrication Schedule ...................................................... 90
5.1 Handling consumables safely.................................................................. 90
5.2 Lubrication Schedule ............................................................................... 92
5.3 Consumables........................................................................................... 93
6 Maintenance and repairs ......................................................................... 94
6.1 Preparing the truck for maintenance and repairs .................................... 94
6.2 Tightening the wheel nuts........................................................................ 95
6.3 Removing the front panel ........................................................................ 96
6.4 Checking electrical fuses......................................................................... 97
6.5 Restoring the truck to service after maintenance and repairs ................. 98
7 Decommissioning the industrial truck ...................................................... 99
7.1 Prior to decommissioning ........................................................................ 99
7.2 During decommissioning ......................................................................... 100
7.3 Restoring the truck to service after decommissioning ............................. 101
8 Safety tests to be performed at intervals and after unusual incidents ..... 102
9 Final de-commissioning, disposal............................................................ 102
10 Human vibration measurement ............................................................... 102
11.14 EN
8
3.1 Checks and operations to be performed before starting daily operation . 44
3.2 Preparing the truck for operation ............................................................. 45
3.3 Parking the truck securely ....................................................................... 46
3.4 Battery discharge monitor........................................................................ 46
4 Industrial Truck Operation ....................................................................... 47
4.1 Safety regulations for truck operation...................................................... 47
4.2 Emergency Disconnect, Travel, Steering, Braking .................................. 49
4.3 Pedestrian mode ..................................................................................... 53
4.4 Coupling Types........................................................................................ 54
4.5 Travelling with trailers.............................................................................. 56
4.6 Seat (o) (XL and C40 only)..................................................................... 57
5 Troubleshooting....................................................................................... 58
5.1 Truck does not start................................................................................. 58
6 Operating the truck without its own drive system .................................... 59
7 Optional equipment ................................................................................. 60
7.1 CanDis display instrument....................................................................... 60
7.2 CanCode keypad..................................................................................... 62
7.3 Setting the truck parameters with CanCode............................................ 67
7.4 ISM access module (o)........................................................................... 68
7.5 Parameters .............................................................................................. 69
F Industrial Truck Maintenance .................................................. 77
1 Operational Safety and Environmental Protection................................... 77
2 Maintenance Safety Regulations............................................................. 77
3 Servicing and Inspection ......................................................................... 83
4 Maintenance checklist ............................................................................. 84
4.1 Owner ...................................................................................................... 84
4.2 Customer Service .................................................................................... 86
5 Lubricants and Lubrication Schedule ...................................................... 90
5.1 Handling consumables safely.................................................................. 90
5.2 Lubrication Schedule ............................................................................... 92
5.3 Consumables........................................................................................... 93
6 Maintenance and repairs ......................................................................... 94
6.1 Preparing the truck for maintenance and repairs .................................... 94
6.2 Tightening the wheel nuts........................................................................ 95
6.3 Removing the front panel ........................................................................ 96
6.4 Checking electrical fuses......................................................................... 97
6.5 Restoring the truck to service after maintenance and repairs ................. 98
7 Decommissioning the industrial truck ...................................................... 99
7.1 Prior to decommissioning ........................................................................ 99
7.2 During decommissioning ......................................................................... 100
7.3 Restoring the truck to service after decommissioning ............................. 101
8 Safety tests to be performed at intervals and after unusual incidents ..... 102
9 Final de-commissioning, disposal............................................................ 102
10 Human vibration measurement ............................................................... 102

1
0506.GB
Appendix
JH Traction Battery Operating Instructions
ZThese operating instructions apply only to Jungheinrich battery models. If using
another brand, refer to the manufacturer's operating instructions.
1
0506.GB
Appendix
JH Traction Battery Operating Instructions
ZThese operating instructions apply only to Jungheinrich battery models. If using
another brand, refer to the manufacturer's operating instructions.

0506.GB
2
0506.GB
2

9
11.14 EN
A Correct Use and Application
1 General
The truck described in the present operating instructions is an industrial truck
designed for towing trailer loads.
It must be applied, operated and serviced in accordance with the instructions
contained in the present manual. Any other type of use is beyond the scope of
application and can result in damage to personnel, the industrial truck or property.
2 Correct application
NOTE
The maximum tow load is shown on the data plate and must not be exceeded.
The load must be coupled to a trailer coupling or an attachment approved by the
manufacturer.
– Towing loads.
– Do not carry passengers.
– Loads may only be pushed with the trailer coupling.
3 Approved application conditions
– Operation in industrial and commercial environments.
– Permissible temperature range 5°C to 40°C.
– Operation only on secure, level surfaces with sufficient capacity.
– Operation only on routes that are visible and approved by the proprietor.
– Negotiating inclines up to a maximum of 15 %.
– Do not negotiate inclines crosswise or at an angle. Transporting loads downhill.
– Operation in partially public traffic.
WARNING!
Extreme conditions
Special equipment and authorisation are required if the truck is to be constantly
used in extreme conditions, especially in dusty or corrosive atmospheres.
The truck is not authorised for use in areas at risk of explosion.
In adverse weather conditions (thunder, lightning) the industrial truck must not be
operated outside or in endangered areas.
9
11.14 EN
A Correct Use and Application
1 General
The truck described in the present operating instructions is an industrial truck
designed for towing trailer loads.
It must be applied, operated and serviced in accordance with the instructions
contained in the present manual. Any other type of use is beyond the scope of
application and can result in damage to personnel, the industrial truck or property.
2 Correct application
NOTE
The maximum tow load is shown on the data plate and must not be exceeded.
The load must be coupled to a trailer coupling or an attachment approved by the
manufacturer.
– Towing loads.
– Do not carry passengers.
– Loads may only be pushed with the trailer coupling.
3 Approved application conditions
– Operation in industrial and commercial environments.
– Permissible temperature range 5°C to 40°C.
– Operation only on secure, level surfaces with sufficient capacity.
– Operation only on routes that are visible and approved by the proprietor.
– Negotiating inclines up to a maximum of 15 %.
– Do not negotiate inclines crosswise or at an angle. Transporting loads downhill.
– Operation in partially public traffic.
WARNING!
Extreme conditions
Special equipment and authorisation are required if the truck is to be constantly
used in extreme conditions, especially in dusty or corrosive atmospheres.
The truck is not authorised for use in areas at risk of explosion.
In adverse weather conditions (thunder, lightning) the industrial truck must not be
operated outside or in endangered areas.

11.14 EN
10
4 Proprietor responsibilities
For the purposes of the present operating instructions the “proprietor” is defined as
any natural or legal person who either uses the industrial truck himself, or on whose
behalf it is used. In special cases (e.g. leasing or renting) the proprietor is considered
the person who, in accordance with existing contractual agreements between the
owner and user of the industrial truck, is charged with operational duties.
The proprietor must ensure that the industrial truck is used only for the purpose for
which it is intended and that there is no danger to life and limb of the user and third
parties. Furthermore, accident prevention regulations, safety regulations and
operating, servicing and repair guidelines must be followed. The proprietor must
ensure that all users have read and understood these operating instructions.
NOTE
Failure to comply with the operating instructions shall invalidate the warranty. The
same applies if improper work is carried out on the truck by the customer or third
parties without the permission of the manufacturer.
5 Adding attachments and/or accessories
Adding accessories
The mounting or installation of additional equipment which affects or enhances the
performance of the forklift truck requires the written permission of the manufacturer.
Local authority approval may also need to be obtained.
Local authority approval does not however constitute the manufacturer’s approval.
11.14 EN
10
4 Proprietor responsibilities
For the purposes of the present operating instructions the “proprietor” is defined as
any natural or legal person who either uses the industrial truck himself, or on whose
behalf it is used. In special cases (e.g. leasing or renting) the proprietor is considered
the person who, in accordance with existing contractual agreements between the
owner and user of the industrial truck, is charged with operational duties.
The proprietor must ensure that the industrial truck is used only for the purpose for
which it is intended and that there is no danger to life and limb of the user and third
parties. Furthermore, accident prevention regulations, safety regulations and
operating, servicing and repair guidelines must be followed. The proprietor must
ensure that all users have read and understood these operating instructions.
NOTE
Failure to comply with the operating instructions shall invalidate the warranty. The
same applies if improper work is carried out on the truck by the customer or third
parties without the permission of the manufacturer.
5 Adding attachments and/or accessories
Adding accessories
The mounting or installation of additional equipment which affects or enhances the
performance of the forklift truck requires the written permission of the manufacturer.
Local authority approval may also need to be obtained.
Local authority approval does not however constitute the manufacturer’s approval.

11
11.14 EN
B Truck Description
1 Application
The truck is a three-wheel electric tow truck with an operator platform, equipped with
a Jet Pilot. It is designed for transporting goods on level surfaces in buildings.
The drawbar pull is indicated on the data plate.
11
11.14 EN
B Truck Description
1 Application
The truck is a three-wheel electric tow truck with an operator platform, equipped with
a Jet Pilot. It is designed for transporting goods on level surfaces in buildings.
The drawbar pull is indicated on the data plate.

11.14 EN
12
2 Assemblies and Functional Description
2.1 Assembly Overview
Item Description Item Description
1tFront panel 9 oStop button
2tBattery cover 10 oForward “pedestrian operation”
button
3tJetPilot 11 oTrailer coupling
4tEmergency Disconnect (main
switch) 12 tStorage compartment
5tTravel switch 13 tDrive wheel
on EZS C40 = CSE wheel
6oControl keypad (CanCode) oHeadlight (not shown)
7tKey switch oStrobe (not shown)
1234 567
8
9
10
12
11
13
11.14 EN
12
2 Assemblies and Functional Description
2.1 Assembly Overview
Item Description Item Description
1tFront panel 9 oStop button
2tBattery cover 10 oForward “pedestrian operation”
button
3tJetPilot 11 oTrailer coupling
4tEmergency Disconnect (main
switch) 12 tStorage compartment
5tTravel switch 13 tDrive wheel
on EZS C40 = CSE wheel
6oControl keypad (CanCode) oHeadlight (not shown)
7tKey switch oStrobe (not shown)
1234 567
8
9
10
12
11
13

13
11.14 EN
8oReverse “pedestrian operation”
button oRear view mirror
t= Standard version o= Option
13
11.14 EN
8oReverse “pedestrian operation”
button oRear view mirror
t= Standard version o= Option

11.14 EN
14
2.2 Functional Description
Safety Mechanisms
– An enclosed, smooth truck geometry with rounded edges ensures safe handling of
the truck.
– The wheels are surrounded by a solid skirt.
– Pressing the Emergency Disconnect switch rapidly cuts out all electrical functions
in hazardous situations.
Emergency Stop safety feature
– The emergency stop is activated by the traction controller.
– Each time the truck is switched on the system performed an automatic diagnosis.
Operator position
– Adjustable driver's seat o(EZS 350 XL and EZS C40 only).
– All travel and tow operations can be performed sensitively without having to reach.
– JetPilot for safe control of the truck.
Operator platform
– Travel functions are only released when the driver stands on the operator platform.
Drive system
– A fixed AC threephase motor actuates the drive wheel via a bevel spur gearbox.
– The electronic traction controller ensures smooth drive motor speed control and
hence smooth travel, powerful acceleration and electrically controlled braking with
energy regeneration.
– The driver can choose from 3 travel programs, depending on the load and the
environment. from maximum performance to energy saving.
Curve Control
– Automatic speed reduction for cornering.
– Curve Control limits the speed and acceleration when cornering.
– This reduces the risk of oscillation or tipover.
Steering
– The driver steers with a JetPilot.
– The steering motion is transmitted directly from the steering controller via a steer
motor directly to the ring gear of the pivoted drive system.
– The drive system can be pivoted +/- 90°.
Electrical System
– 24 volt system.
– Standard electronic traction, lift and steering control are standard.
Controls and Displays
– Ergonomic controls ensure fatigue-free operation for sensitive application of the
travel operations.
11.14 EN
14
2.2 Functional Description
Safety Mechanisms
– An enclosed, smooth truck geometry with rounded edges ensures safe handling of
the truck.
– The wheels are surrounded by a solid skirt.
– Pressing the Emergency Disconnect switch rapidly cuts out all electrical functions
in hazardous situations.
Emergency Stop safety feature
– The emergency stop is activated by the traction controller.
– Each time the truck is switched on the system performed an automatic diagnosis.
Operator position
– Adjustable driver's seat o(EZS 350 XL and EZS C40 only).
– All travel and tow operations can be performed sensitively without having to reach.
– JetPilot for safe control of the truck.
Operator platform
– Travel functions are only released when the driver stands on the operator platform.
Drive system
– A fixed AC threephase motor actuates the drive wheel via a bevel spur gearbox.
– The electronic traction controller ensures smooth drive motor speed control and
hence smooth travel, powerful acceleration and electrically controlled braking with
energy regeneration.
– The driver can choose from 3 travel programs, depending on the load and the
environment. from maximum performance to energy saving.
Curve Control
– Automatic speed reduction for cornering.
– Curve Control limits the speed and acceleration when cornering.
– This reduces the risk of oscillation or tipover.
Steering
– The driver steers with a JetPilot.
– The steering motion is transmitted directly from the steering controller via a steer
motor directly to the ring gear of the pivoted drive system.
– The drive system can be pivoted +/- 90°.
Electrical System
– 24 volt system.
– Standard electronic traction, lift and steering control are standard.
Controls and Displays
– Ergonomic controls ensure fatigue-free operation for sensitive application of the
travel operations.

15
11.14 EN
– The battery discharge indicator shows the available battery capacity.
– The optional CanDis displays show the key driver information and travel program,
service hours, battery capacity and event messages.
2.2.1 Hourmeter
ZPrepare the truck for operation, (see "Preparing the truck for operation" on
page 45) or (see "CanCode keypad" on page 62).
Service hours are counted while the truck is operational and the operator is standing
on the platform.
2.2.2 Hourmeter in Pedestrian Mode
ZPrepare the truck for operation, (see "Preparing the truck for operation" on
page 45) or (see "CanCode keypad" on page 62).
Service hours are counted while the truck is operational and one of the following
controls is applied:
– "Pedestrian - drive direction" button, (see "Pedestrian mode" on page 53).
– "Pedestrian - load direction" button, (see "Pedestrian mode" on page 53).
15
11.14 EN
– The battery discharge indicator shows the available battery capacity.
– The optional CanDis displays show the key driver information and travel program,
service hours, battery capacity and event messages.
2.2.1 Hourmeter
ZPrepare the truck for operation, (see "Preparing the truck for operation" on
page 45) or (see "CanCode keypad" on page 62).
Service hours are counted while the truck is operational and the operator is standing
on the platform.
2.2.2 Hourmeter in Pedestrian Mode
ZPrepare the truck for operation, (see "Preparing the truck for operation" on
page 45) or (see "CanCode keypad" on page 62).
Service hours are counted while the truck is operational and one of the following
controls is applied:
– "Pedestrian - drive direction" button, (see "Pedestrian mode" on page 53).
– "Pedestrian - load direction" button, (see "Pedestrian mode" on page 53).

11.14 EN
16
3 Technical Specifications
ZTechnical specification details in accordance with VDI 2198. Technical
modifications and additions reserved.
3.1 Performance data
EZS 350 EZS 350 XL
F Nominal drawbar pull 1000 1000 N
Travel speed
w / w.o. rated load 1
7,0 / 12,5 7,0 / 12,5 km/h
Traction motor,
output S2 = 60 min
2,8 2,8 kW
Max. drawbar pull S2 5 min 3200 3200 N
Battery voltage, nominal capacity K5 24 / 420 24 / 560 V/Ah
EZS C40
F Nominal drawbar pull 800 N
Travel speed
w / w.o. rated load 1
8,2 / 12,5 km/h
Traction motor,
output S2 = 60 min
2,8 kW
Max. drawbar pull S2 5 min 2600 N
Battery voltage, nominal capacity K5 24 / 560 V/Ah
11.14 EN
16
3 Technical Specifications
ZTechnical specification details in accordance with VDI 2198. Technical
modifications and additions reserved.
3.1 Performance data
EZS 350 EZS 350 XL
F Nominal drawbar pull 1000 1000 N
Travel speed
w / w.o. rated load 1
7,0 / 12,5 7,0 / 12,5 km/h
Traction motor,
output S2 = 60 min
2,8 2,8 kW
Max. drawbar pull S2 5 min 3200 3200 N
Battery voltage, nominal capacity K5 24 / 420 24 / 560 V/Ah
EZS C40
F Nominal drawbar pull 800 N
Travel speed
w / w.o. rated load 1
8,2 / 12,5 km/h
Traction motor,
output S2 = 60 min
2,8 kW
Max. drawbar pull S2 5 min 2600 N
Battery voltage, nominal capacity K5 24 / 560 V/Ah

17
11.14 EN
3.2 Dimensions
17
11.14 EN
3.2 Dimensions

11.14 EN
18
EZS 350 EZS 350 XL
y Wheelbase 980 1147 mm
h7 Seat height / standing height - / 132 - / 132 mm
h14 Tiller height
in travel position 1) 1400 1400 mm
h10 Coupling height 140 - 480 140 - 480 mm
l1 Overall length 2) 1350 1517 mm
b1 Overall width 810 810 mm
b11 Track width, rear (load section) 680 680 mm
m2 Ground clearance centre
wheelbase 50 50 mm
Wa Turning radius 1220 1370 mm
1) JetPilot height
2) Total length excluding coupling, as different coupling versions are available
EZS C40
y Wheelbase 1229 mm
h7 Seat height / standing height - / 182 mm
h14 Tiller height
in travel position 1) 1450 mm
h10 Coupling height 140 - 480 mm
l1 Overall length 2) 1517 mm
b1 Overall width 810 mm
b11 Track width, rear (load section) 680 mm
m2 Ground clearance centre
wheelbase
100 mm
Wa Turning radius 1470 mm
1) JetPilot height
2) Total length excluding coupling, as different coupling versions
are available
11.14 EN
18
EZS 350 EZS 350 XL
y Wheelbase 980 1147 mm
h7 Seat height / standing height - / 132 - / 132 mm
h14 Tiller height
in travel position 1) 1400 1400 mm
h10 Coupling height 140 - 480 140 - 480 mm
l1 Overall length 2) 1350 1517 mm
b1 Overall width 810 810 mm
b11 Track width, rear (load section) 680 680 mm
m2 Ground clearance centre
wheelbase 50 50 mm
Wa Turning radius 1220 1370 mm
1) JetPilot height
2) Total length excluding coupling, as different coupling versions are available
EZS C40
y Wheelbase 1229 mm
h7 Seat height / standing height - / 182 mm
h14 Tiller height
in travel position 1) 1450 mm
h10 Coupling height 140 - 480 mm
l1 Overall length 2) 1517 mm
b1 Overall width 810 mm
b11 Track width, rear (load section) 680 mm
m2 Ground clearance centre
wheelbase
100 mm
Wa Turning radius 1470 mm
1) JetPilot height
2) Total length excluding coupling, as different coupling versions
are available

19
11.14 EN
3.3 Weights
3.4 Tyre type
EZS 350 EZS 350 XL EZS C40
Net weight excl. battery 606 677 715 kg
Axle load, w.o. load
front/rear + battery 520 / 456 590 / 520 660 / 525 kg
Battery weight 370 470 470 kg
EZS 350 EZS 350 XL EZS C40
Tyre size, drive 230 x 77 230 x 77 310 x 105
Tyre size, load section 250 x 80 250 x 77 301 x 85
Wheels, number front/rear
(x = driven)
1x / 2 1x / 2 1x / 2
19
11.14 EN
3.3 Weights
3.4 Tyre type
EZS 350 EZS 350 XL EZS C40
Net weight excl. battery 606 677 715 kg
Axle load, w.o. load
front/rear + battery 520 / 456 590 / 520 660 / 525 kg
Battery weight 370 470 470 kg
EZS 350 EZS 350 XL EZS C40
Tyre size, drive 230 x 77 230 x 77 310 x 105
Tyre size, load section 250 x 80 250 x 77 301 x 85
Wheels, number front/rear
(x = driven)
1x / 2 1x / 2 1x / 2
