Juniper AXIS User manual

Black (-)
Red (+)
Wire Nuts - C
Junction Box
(Optional)
Lighting Fixture - B
+ Wire from Driver
- Wire from Driver
Channel for wires - A
Green (Ground)
FIgure 1: Wiring Detail
#8 Decorative
Wood Screws - D
Wall
Anchor
(Optional - Not Provided)
Figure 2: Wall-Mounting Detail
If cutting fixture wires is required, please make sure the length of wire runs at least halfway through the groove
(A) in the wall-mount plate (B).
Installation with a junction box (shown in the illustrations below) is optional. The fixture can be installed without
a junction box using the same instructions.
Make connections between ± terminals of the fixture wire pair (C) and the driver wire pair using the provided 1.
wire nuts (D). See "Figure 1" for wiring detail.
OPTIONAL:
When using a junction box, connect ground wire of the fixture (C) to the ground screw present in
the junction box.
Install anchors inthe wall, if necessary. 2.
Push the connected wires inside the junction box. If the fixture is being installed without a junction box, push 3.
unsecured wires and wire nuts (D) into the channel (A) and secure them using tape, making sure that nothing
is pressed between the wall and wall-mount plate (B).
Install the lighting fixture (B) on the wall using provided wood screws (D). Check that the loose wires and wire 4.
nuts (C) are not pressed between the wall-mount plate of the fixture (B) and wall. Loose wires and wire nuts
(C) should either be pushed inside the junction box (if possible) or inside the channel (A)and secured using
tape. See "Figure 2" for details.
INSTALLATION INSTRUCTIONS
INSTRUCTIONS MEANT FOR AN INDEPENDENT REMOTE DRIVER RATED CLASS 2 24V DC AT THE
CONNECTIONS ONLY (NOT 120V AC)
DISCONNECT MAIN POWER AT THE SOURCE PRIOR TO INSTALLATION
ONLY A LICENSED ELECTRICIAN SHOULD PERFORM INSTALLATION
NOTE:
WARNING:
Publishing Date : 5/04/2018 [email protected] [phone]rd Street, Unit 11 Brooklyn, NY 11232
1
AXIS WALL SCONCE INSTALLATION GUIDE JUNIPER
KEEPING IT CLEAN
Gentle care is required in order to retain the quality metal finish of Axis Wall Sconce for years to come. Like other natural metals, brass will patina over time, with natural yellow hues
intensifying over time. Juniper protects its brass with a mild matte lacquer to delay coloration of the metal,and to protect it from exposure to humidity and natural oils.
In order to remove dirt, dust and fingerprints; gently wipe the wall sconce with a damp cloth. Do not use any chemical cleaning solutions; especially those containing ammonia, as this
will damage the surface finish of the brass.

13"
5"
8.8"
3.125"
37"
5"
3.125"
32.8"
49"
44.8"
5"
3.125"
25"
20.8"
3.125"
5"
Axis Wall Sconce 12 Inch
Specifications:
4W LEDs, 270 Lumens
Class 2, 24 VDC Remote Driver
Dimming determined by driver type
Metropolis Wall Sconce 36 Inch
Sconce Specifications:
61W LEDs, 5000 Lumens •
Class 2, 24 VDC Remote Driver •
Dimming determined by driver type •
Metropolis Wall Sconce 48 Inch
Sconce Specifications:
81W LEDs, 6800 Lumens •
Class 2, 24 VDC Remote Driver •
Dimming determined by driver type •
Axis Wall Sconce 24 Inch
Specifications:
9W LEDs, 650 Lumens
Class 2, 24 VDC Remote Driver
Dimming determined by driver type
Axis Wall Sconce 36 Inch
Specifications:
13W LEDs, 900 Lumens
Class 2, 24 VDC Remote Driver
Dimming determined by driver type
Axis Wall Sconce 48 Inch
Specifications:
17.5W LEDs, 1200 Lumens
Class 2, 24 VDC Remote Driver
Dimming determined by driver type
Publishing Date : 5/04/2018 [email protected] [phone]rd Street, Unit 11 Brooklyn, NY 11232
2
AXIS WALL SCONCE INSTALLATION GUIDE
JUNIPER
KEEPING IT CLEAN
Gentle care is required in order to retain the quality metal finish of Axis Wall Sconce for years to come. Like other natural metals, brass will patina over time, with natural yellow hues
intensifying over time. Juniper protects its brass with a mild matte lacquer to delay coloration of the metal,and to protect it from exposure to humidity and natural oils.
In order to remove dirt, dust and fingerprints; gently wipe the wall sconce with a damp cloth. Do not use any chemical cleaning solutions; especially those containing ammonia, as this
will damage the surface finish of the brass.
