JVC
GR-AX30U/AX3 7U/AX70U
AX404U/AX606U/AX808U

INSTRUCTIONS
Thank you for purchasing the JVC Compact VHS VideoMovie. Learn about all the available features and take
advantage of them for your total moviemaking enjoyment. Before using this VideoMovie, read this instruction
booklet carefully so that you will obtain the best results from your VideoMovie.
CAUTION: | TO REDUCE THE RISK OF ELECTRIG SHOCK.
OO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Warning on lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated. Do not
recharge, disassemble, heat above 100°C (212°F)
or incinerate.
Replace battery with CR2025; use of another
battery may present a risk of fire or explosion.
= Dispose of used battery promptly.
@ Keep away from children.
® Do not disassemble and do not dispose of in
The lightning flash with arrowhead symbol, within an
equilateral iriangle, is intended to alert the user to ihe
presence of uninsulated "dangerous voltage” within the
product's enclosure that may be of sufficient magnitude fire.
{o constitute a risk of electric shock fo persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the Iderature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
The AA-V35U Multi AC Charger/Adapter should
be used with:
AC 120 VV, 60 Hz in the USA and Canada,
AC 110 — 240 V~\, 50/60 Hz in other countries.
CAUTION (applies to the AA-V35U)
TO PREVENT ELECTRIC SHOCK MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION (s'‘applique a !'AA-V35U)
Pour Eviter LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE
DE LA PRISE ET POUSSER JUSQU'AU FOND.
NOTES:
® The rating plate (serial number plate) and safety
caution are on the bottom and/or the back of the
main unit.
= The rating plate (serial number plate) of the AC
power adapter/battery charger is on its bottom.
This digital apparatus does not exceed the Class
B limits for radio noise emissions from digital
apparatus as set out in the interference-causing
equipment standard entitied "Digital Apparatus",
ICES-003 of the Department of Communications.
You are recommended to carefully read the
cautions on pages 48 and 49 before use.
When using the Multi AC Charger/Adapter in areas other than the USA
@ The provided Multi AC Charger/Adapter features automatic voltage selection in the AC range from 110 V to 240 V.
USING HOUSEHOLD AC PLUG ADAPTER Plug adapter (optional)
In case of connecting the unit's power cord to an AC wall outlet other than JVC's part number "PU55494"
American National Standard C73 series type use an AC plug adapter, calted a
“Siemens Plug", as shown,
For this AC plug adapter, consult your nearest JVC dealer.
[VHS] #—acsa_
Cassettes marked [VSI can be used with this
VideoMovie.
JVC COMPANY OF AMERICA
Division of US JVC CORP.
41 Stater Drive, Etmwood Park, New Jersey 07407
COPYRIGHT 1994 VICTOR COMPANY OF JAPAN, LTD.
@ Printed in Japan
2
This VideoMovie is designed to be used with NTSC-type
color television signals. It cannot be used for playback
with a television of a different standard. However, live
recording and viewfinder playback are possible
anywhere. Use the BN-V12U/V14U/V22U/V50U/V60U
battery packs and, to recharge them, the provided
multi-voltage Multi AC Charger/Adapter. (An appropriate
conversion adapter may be necessary to accommodate
different designs of AC outlets in different countries.)
INFORMATION
This device complies with Part 15 of FCC Rules.
Qperation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation. Change or modifications not approved by the
Party responsible for compliance could void the user's
authority to operate the equipment. This equipment has
been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
Protection against harmful interference in a residential
installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur ina
Particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
ATTENTION:
The product that you have purchased is powered by a
rechargeable battery. The battery is recyclable. At the
end of its useful life, under various state and loca! laws,
it may be iliegal to dispose of this battery into the
municipal waste stream. Check with your local solid
waste officials for details in your area for recycling
options or proper disposal,
| GONTENTS |
Major features
Controls and connectors
Preparations ....
HETORDING
Recording operation
Advanced videography techniques...
Focusing
ZOOMING .........ceccesersvereenees sents
Program AE with special effects
OE Tr ae
White balance adjustment
Self-timer
Animation .....
PLAYBACK
Playback ............ Statue sn ces Uixeecseasty Seaea 33
Connections to a VCR ora television ....
Editing techniques
Tape dubbing
Random Assemble Editing ...
Insert editing
Audio dubbing ......
ACCESSORIES
AND INFORMATION
After use
Viewfinder indicattons ........
Systems flexibility ........... sap
Helpful terms and information ....
Cautions

| MAJOR FEATURES |
make sure...
= ~~
it'S ae
“Compact VHS
No other compact cassettes can be played
back on your VHS VCR’.
JVC COMPACT VHS
ADVANTAGES
cx Convenience
Easy playback on your VHS deck* —- no hook-ups
necessary.
«> Conserve
You don't have to use the VideoMovie for playback —
this reduces the wear on the VideoMovie.
> Comfort
Can use the VCR's remote control and high speed
REW and FF from your easy chair.
«7 Communication
Can send your tapes to others who also own a VHS
VCR.
«> Choice
Can also playback recordings through the viewfinder or
connect directly to a TV.
“Using Cassette Adapter (VHS Playpak)
Full Function MBR
(Multi-Brand Remote)
cx P. 10, 39 — 43
Retractable Auto Light
(GR-AX808/AX606 only)
cr P. 21
2-Speed 12x Zoom with
3-Position Zoom Control
7 P. 16, 25
Cinema Mode
cr P. 28
Title Generators
> P, 22, 23
Automatic 8-Segment
Random Assemble Editing
cr P. 39 — 41
oS SNHAWAII
Character Generator
AofolfohoHol oll o Ho
a
[oo] © [9/09 ole HAHuaHAnA AA
“HOUR VACATION . -
‘Instant Titles
Program AE with Special
Effects c= P. 26, 27
Twilight
= Auto Mode Lock
m 15 sec. Seif-Timer
= Electronic Fog Filter
= High-speed Shutter
= Monotone
Auto Pause r= P. 19

QUICK OPERATION GUIDE
Ped
Align the marks. BATTERY RELEASE Set to "CAMERA’. LENS COVER
opervclose knob
A. Using the battery pack Ml Slide EJECT.
i Align mark on battery pack with similar mark Insert a video cassette.
on back of VideoMovie.(Charging procedure, Press PUSH.
cy
P,
12)
(For
more
details,
o>
P.15)
Slide the battery pack in the direction of the
arrow until it locks into place.
To remove the battery pack
Press BATTERY RELEASE and slide out the
battery pack.
B. Using the Multi AC
Charger/Adapter (cz P. 11)
Recording
Starv/Stop button
Il Slide the LENS COVER open/close knob to
open the lens cover.
Set the power switch to "CAMERA".
— The power indicator will light and image will
be seen in the viewfinder.
Set SP/EP as required.
@ Press the Recording Start/Stop button.
— Recording starts.
@ To stop recording temporarily, momentarily
press the Recording Start/Stop button once
again.
(For more details, (> P.18)
Set to "PLAY",
Ml Set the power switch to "PLAY".
Press REW.
~— The tape will automatically stop at the
beginning of the tape.
Press PLAY.
-- Playback starts and playback picture
appears in the viewfinder.
= To stop playback, press STOP.
(For more details, 7 P.34)
Or simply play back the tape on a VHS'VCR
using the Cassette Adapter (VHS -Playpak).
mP.33.0° Pee : Psy

No. Page
@ Built-in retractable light
(GR-AX808/AX606 only).
© LIGHT release knob (GR-
© Electronic viewfinder ...
© Diopter adjustment
@ LENS COVER open/close knob ................... 18, 44
© Microphone
@ Tally WAM o.oo eececseessssscsesecseecsessessesetenteaeencess 18
@ Infrared beam sensor window
Receives the transmitied beam signal from the remote
control unit.
“The transmitted beam may not be effective or may cause
misoperations when the infrared beam sensor window is
directly exposed to suntight or powerful tighting.
@ TITLES button
@ PROGRAM AE select dial..
Be Pees Coen
@ Cassette holder.
@ AUG butan.
8
@ EJECT switch oo. eee cc cceeeeeceeveeeereeenene
@ AUTO PAUSE ON/OFF switch
@ DISPLAY/R.A.EDIT CANCEL button ..
@ CINEMAVR.A.EDIT button.............. 8, 40
@ FADER/R.A.EDIT IN/OUT button
@® Power zoom buttons..........
@ COUNTER RESET button .
@ COUNTER MEMORY button
@ Clock battery compartment...
@® Battery pack mount
@ Eyelets for shoulder strap ..
Connectors
The jacks @ to ® are located beneath the jack cover.
® EDIT jack
@ REMOTE jack .
For connection of the HM-V20U wired remote contro} unit
(optional).
ODOD OG ©. @
No. Page
@ AUDIO out jack 36, 38, 41, 42
@ RF DC OUT jack..
For connection of the RF-V5U RF unit (optional).
@® VIDEO Out jack... ce eseceeeeeeee 36, 38, 41, 42
@ BATTERY RELEASE button oceans 11
@ LIGHT ON/AUTO select switch
(GR-AX808/AX606 only)
@ POWER switch and LED indicator.
® Recording Start/Stop button.............
© Gil SHA is... scsesedcadvexoneneressounbaestesze
© MWB (Manual White Balance) button
@ SP/EP recording mode select switch ...
@ Tape length select SWitCh ..........cccscsceserersseeeceees 17
Operation buttons
The buttons € to @ are located beneath the cover.
@ EDIT/ G) (Quick Review) button............. 19, 38, 41
@ DATE/TIME/CHAR. SELECT/TRACKING
EONS se cvccisadean sauaeiavxennasiddiscicea naanssntns 14, 23, 34
@ DATE/TIME/CHAR. SET button .
@ STOP button...
@ PLAY button..
@® PAUSE button...
@ REW/RETAKE R button eee
@ FF/RETAKE F button... cesseesececcecesceeeeee
Bottom
@® Tripod mounting socket.........cccssccessesecescesses cece 17

CONTROLS AND CONNECTORS (Cont'd
*RM-V700U REMOTE-CONTROL UN Wied
The RM-V700U Full-Function MBR (Multi-brand
Remote) can operate this VideoMovie from a distance
as well as the basic operations (PLAY, STOP, PAUSE,
FF, and REW) of your VCR. This remote control unit is
useful when dubbing from the VideoMovie to your
VCR, and it makes additional recording functions
possible.
go EAI See elt aa &
“inserting.the batteryysne hs. :
EE Pull out the battery holder according to the type of remote
controj unit you have.
Type @: Pull out the battery holder while sliding
the lock hole.
Type ®: Pinch the release tab and pull out the
battery holder.
@ Insert the lithium battery (CR2025), with its plus (+) side
up, into the battery holder.
8 Replace the battery holder until it clicks in place.
*Read warning on lithium battery. (7 P. 2)
wa ey
se
SPasest ege eeagd
ote eet
Movie's power switch sét to
pee
With the VideoMovie's power switch set to
. "CAMERA". ‘
"PLAY.
cP. 4i
FF/FF Shuttle Search
Rew/Rew Shuttle Search
Pause
BARRED crn he BEN tia be
@ PAUSE IN connector
+ @ Infrared beam transmitting window
@INT.TIME bution
@REC-TIME button.”
Transmits the beam signal.
Sell-Timer/Time lapse (> P. 30, 32)
Animation/Time lapse (Gr P. 31, 32)
Retake (Forward)
Retake (Rewind)
Functions same as the Recording Start/Stop button of the VideoMovie.
index code marking (C7 P. 20)
Slow-speed zoom (CF P. 25)
“@ZOOMTM)) buttons
@VCRCTLouton. ”
“@A. DUB bution. -
-@STOP button = -
Q@INSERT bution
@RA.A. EDIT buttons
P.39
Audio dubbing (I P. 43)
Stop
insert Editing (7 P. 42)
CF P.40
10
PREPARATIONS
Recording time
Video light OFF
approx. 55 min,
approx. 65 min.
Video light ON
approx. 30 min
approx. 40 min
BN-V22U
BN-V50U approx. 140 min. approx. 85 min
BN-V60U approx. 110 min. approx. 70 min
® The recording time per charge is influenced by the duration
of the recording standby, frequency of zooming, etc. It is
safer to have spare battery packs.
@ Video light is built-in only on the GR-AXB808/AX606.
BN-V12U
BN-V14U
To AC outlet
Muitl AC
Charger/Adapter
AA-V35U
To car's cigaretie
Car Battery Cord lighter socket
AP-V6U/V7U (optional)
Gar Battery Charger/Adapter
BH-V3U (optional)
<POWERISUPPLY-SYSTEM aie
The convenient 3-way power supply system gives you
a choice of the most appropriate power supply unit,
depending on the application.
@ No function is available without power supply.
= Do not use any power supply other than specified.
@ Never attempt to use these power supply units with
any equipment other than the VideoMovie.
= The provided Multi AC Charger/Adapter features
automatic voltage selection in the AC range from
110 V to 240 V.
oe
The battery pack has been kept in the uncharged state
for shipment. Therefore, before use, be sure to charge
it. (C7 See next page.)
“Attaching the batiery pac
& Before attaching the battery pack, insert the lithium
battery. (ce P. 14)
HB Align mark on battery pack with similar mark on
back of VideoMovie.
Slide the battery pack into place in the direction of
the arrow until it locks in place.
To remove the battery pack:
Slide off the battery pack while pressing BATTERY
RELEASE.
Use the Car Battery Cord or Car Battery Charger.
= Leave the car's engine idling when using the car
battery.
(For use with 12 V negative-grounded cars only.)
= The battery pack can also be recharged with the
BH-V3U. Refer to the instruction booklet of the BH-
V3U. (For use with 12 V or 24 V negative grounded
cars only.)
(Continued on next page.)
Il

Side B
CHARGE indicator
END indicator
Side A
POWER indicator Battery release switch
REFRESH switch
Discharging time
approx. 210 min
REFRESH indicator
Charging time
BN-V12U approx. 50 min.
BN-V14U approx. 55 min, approx. 270 min
BN-V22U approx. 100 min. approx. 420 min
BN-V50U approx. 120 min.
approx. 100 min.
approx. 540 min
approx. 420 min
= The diagrams above indicate the approximate charging
and discharging times of battery packs that are fully
charged.
® Charging time and discharging time will vary depending on
the ambient temperature and the status of the battery
pack.
Notes:
@ The REFRESH function is only available on side A.
® Only the A side can be used to charge/discharge
nickel-metal hydride battery packs ({i.e.,
BN-V50U) and the BN-V14U battery pack.
= The AA-V35U cannot discharge and charge battery
packs simultaneously.
12
ECHARGINGIDISCHARGING:
PACK wire eee a
{ Connect the AC power cord to a wail outlet.
—The POWER indicator lights.
Bi Align marks and push in the battery pack untit it
locks in place.
— The CHARGE indicator blinks.
— When charging has been completed, the
CHARGE indicator will go off and the END
indicator will light.
Slide the battery release switch in the direction of
the arrow to remove the battery pack.
charging tw Battery packs Zonseautivelyze es:
Hf Attach two battery packs; one to side A and one to
side B.
Charging starts from the side (A or B) on which a
battery pack was attached first.
— The CHARGE indicator blinks on the side where
charging is in process. The other CHARGE
indicator lights steadily while on stand-by.
Charging on one side is completed.
— On that side, the CHARGE indicator will go off
and the END indicator will light.
Then charging begins on the other side.
— The CHARGE indicator that has remained lit
starts blinking.
Ti When charging is over on both sides A and B, the
two END indicators will light.
Using the REFRESH teaturestecr tu cca see
The REFRESH feature on the Multi AC Charger/
Adapter AA-V35U allows you to completely discharge
the power from the battery pack before charging. After
charging the battery pack several limes, the actual
battery operating time will gradually decrease. For this
reason it is recommended to use the REFRESH
feature only after every 5 charges.
[1JAlign marks and push in the battery pack until it
locks in place.
[2] Push REFRESH.
— The REFRESH indicator will light, and
discharging will begin.
— When discharging is completed, the REFRESH
indicator will go off. Then charging will begin and
the CHARGE indicator will start to blink.
~— If two battery packs are attached, the one on
side A will always be discharaed first: then the
Hatlery on side B is charged before the one on
side A.
Notes:
= Do not repeatedly recharge a battery pack without
fully discharging it. Its service life will decrease. Use
the REFRESH feature after every 5 charges.
w Even if a battery pack is fully charged, but is not
used, it naturally discharges gradually. Be sure to
recharge the battery pack just before using it, or the
day before you intend to use it.
@ This unit is normally warm during operation. Operate
it in places having good ventilation. Do not allow it to
discharge in a container, such as a bag, etc.
Blocking the ventilation causes the temperature
inside the unit to rise, possibly resulting in a
damaged unit.
= If either recharging or discharging is stopped in the
middle of the process, remove the battery pack
before unplugging the AC cord.
@ This unit incorporates an over-discharging protection
circuit; however, immediately remove the battery
pack from this unit after discharging has been
completed to maintain the battery pack's capacity.
the caution attached to the battery pack.
Terminals
Do not
short-circuit.
een
<A
WORD-ON-THE,
EXCLUSIVE’BATTERYPACKS
:
Se
The
battery
packs
are
nickel-cadmium
batteries
and
nickel-metal
hydride
batteries.
Be
sure
to
carefully
read
Temperature ranges:
The recharging time is based on room temperature of 20°C.
The lower the temperature, the longer the recharging time.
For charging:10°C to 35°C(50°F to 95°F)
For operating:0°C to 40°C(32°F to 104°F)
For’storing:-10°C to 30°C(14°F to 86°F)
® If used near a radio, the Multi AC Charger/Adapter
may interfere with reception.
= Be sure to connect the AC power cord and unplug
the DC cord before charging or discharging the
battery pack.
™ Before storing the battery pack for a long period it is
recommended to discharge it.
= The REFRESH feature will not function if the power
status of a battery pack is discharged (No power
remaining).
& With a just-purchased battery pack, or with a battery
pack that has been stored for a long period, the
CHARGE indicator may not light properly. In such a
case, remove and reattach the battery pack again,
then do the recharging procedure. The CHARGE
indicator should light during recharging to indicate,
the battery pack is normal. If this is not the result,
consult your nearest JVC dealer.
13

| PREPARATIONS (Cont'd) |
Setto
"CAMERA".
Month/Day/Year
Date.....Date setting is performed.
DATE JAN 1.00,
TIME AM12:00 Time
12-hour indication with AM or PM
TIME.... Time setting is performed.
14
SCLOCK (LITHIUM) -BATTERYANSERTION:
Necessary for clock and date/time settings.
* Switch off the unit's power and remove the power
supply unit before inserting or removing the clock
battery.
Hl Open the clock battery compartment cover while
pressing the release tab.
Insert the provided lithium battery with the plus (+)
side up and push it in.
* When removing the battery, insert a pointed non-
metallic object between the battery and the
compariment (@) to pull it out.
Close the compartment cover until it clicks in place.
Waming on lithium battery :
® Dispose of.used battery promptly.
@ Keep away from children.
# Do not disassemble and do not dispose of it in
fire. ae
(See Warning on lithium battery, c7 P. 2)
{SETTING DATEFTIME
Before adjusting the date and time for the first time or
after replacing the clock battery.
Ol Set the power switch to "CAMERA”.
Press SET. — The month blinks.
Press SELECT to choose the correct month.
EI Repeat steps Ei and Ef to set the day, year, hour
and minute.
Press SET to start the clock.
— Now that the setting is completed, blinking stops.
Both the date and time will be displayed for
confirmation, after which the date remains
displayed by itself.
Notes:
@ While the date or time are blinking, the clock does
not keep time.
= When re-adjusting the data, press SET and
SELECT to correct them. After adjustment is
completed, both the date and time appear for
contirmation, then the display returns to the mode
before correcting.
™ When PROGRAM AE is set to "AUTO MODE
LOCK" (c7 P.26), the date and time are displayed
immediately after adjustments, after which the
display automatically changes to Auto Date record
mode.(cF P.22)
Turn to take up
stack.
Safety tab
i Storage of cassettes) 3 Seys
® Avoid exposing the cassettes to direct sunlight.
Keep them away from heaters.
® Avoid storing the cassettes in humid or dusty
places.
= Do not drop the cassettes. Do not expose them to
violent vibrations or shocks,
@ Do not expose the cassettes to strong magnetic
fields (near a motor, transformer or magnet).
® Place the cassettes in cassette cases and position
them vertically.
Set oy
2 EOS
. — The cassette holder opens.
insert the cassette with its label facing outward.
Press PUSH to close and lock the cassette holder.
ers eee
Unloading
§8 Slide EJECT. — The cassette holder opens.
Remove the cassette.
Press PUSH to close and lock the cassette holder.
= This VideoMovie employs only the cassettes
carrying the VHS-C mark,
= Recording onto prerecorded tapes
automatically erases the previously recorded
video and audio signals.
= An inverted cassette cannot be inserted.
= Do not toad and unload the cassette
repeatedly without allowing the tape to run at
all. This will slacken the tape and thereby
damage it. ; ;
aM tain before loadi te tk
: ;
a eee eee ee tte in the direction ol tt
® The cassette is equipped With a safety tab to
prevent accidental erasure. When the tab is
_ removed, recording is impossible. If you wish’.
~..to-record on a ‘cassette whose tab has been.
“ “removed adhesive tapé.to reséal the’.
~<slot. ; , om et ee
-™
Jo.
avoid
éxcessive
exposure
{0
‘dust
and
*
_-fingerprints,.do not open thé front tape-cover.
aaaees
15

| PREPARATIONS (Cont'd) |
Power zoom buttons
Zoom button
adjust switch
SP/EP recording mode
select switch
SP or EP
Recording mode indicator
iG
AD NGUEGRIA :
Il Separate the Velcro strip to expand the toop.
Pass your right hand through the loop and grasp
the grip.
Adjust the length of the strap so that your thumb
and fingers can easily manipulate the Recording
Start/Stop button and power zoom buttons.
i Refasten the Velcro strip.
® The power zoom buttons can be adjusted to one
of three positions: up, middie and down.
— Slide the zoom button adjust switch in the
direction of the arrow, and move the power
zoom button to the desired position.
vy oe a
® Positioning
The viewfinder can be positioned for best viewability
(@).
© Diopter adjustment
The viewfinder lens can be adjsuted to suit the
operator's eyesight.
Il Set the power switch to "CAMERA".
BW Turn the diopter adjustment control until the
indications in the viewfinder are clearly focused.
Set the recording mode select switch as required.
= SP: To maintain sound and picture quality.
Better for dubbing later.
= EP: To record 3 times longer than when in the
SP mode. For more economical use of tape.
Note:
Vf the recording mode is switched during actual
recording on the same tape, the playback picture will
be blurred at the point of switching.
Tape length select switch
Tape remaining time indicator
SOMIN—* 89MIN ------- > 3MIN
vt (Blinking) «— 2MiN (Btinking)
OMIN (Blinking)
*—MIN, (Now calculating)
pandas MBSE Dynan tir pec ee ReE
The tape remaining time is displayed in the viewfinder
as shown. Before shooting, set the tape length select
switch according to the tape being used.
® TC-20:When using a tape with 20-minute recording
time or fess.
® TC-30:When using a tape with recording time of
more than 20 minutes (SP).
Notes:
® The indication will start blinking when the remaining
tape time reaches 2 minutes.
= The indicated remaining time is approximate.
= The time required to calculate the remaining tape
length and accuracy of the calculation may vary
according to the type of tape used.
® "TAPE END" appears when the tape reaches its
end. "TAPE END” also appears when a cassette is
loaded whose tape is already at its end.
PUNTER Eas feos Sa nae
t WA ah A 8 laces esc eo
Ml Loop the end of the strap over the top of the eyelet
©, then, folding it back, thread the end of the strap
first through the keeper @, then the buckle @.
Making sure that the strap is not twisted, repeat the
above procedure to attach the other end of the
Strap to the other eyelet.
Adjust the shoulder strap to the desired length ©,
then slide both keepers up snug against the eyelets
to prevent the strap from slipping @.
Align the screw and camera direction stud of the tripod
with the camera's tripod mounting socket and stud
hole, and firmly tighten the screw.
17

RECORDING OPERATIONS
Preparations
@ Supply power.(c¥ P. 11.)
# Insert a video cassette correctly. (7 P. 15.)
™ Adjust the grip strap. (7 P. 16.)
@ Set SP/EP as required. (CF P. 16.)
SN ie
fl Slide the LENS COVER open/close switch to open
the lens cover.
BB Set the power switch to "CAMERA".
Na,
The power indicator lights ert
D
— The VideoMovie enters the Record-Standby
mode.
The aimed-at scene will appear on the viewfinder
screen,
Record-Standby mode indication
1-2. "To shéot thé scene:
Tally lamp
Press the Recording Start/Stop button to start
recording.
— The tally tamp lights while the recording is in
Mer Pers i progress.
Notes! (.-° . ‘ i Potioe
_ 8. For-a longer pause, set the power switch to "OFF" to
~_ $ave power... ie . Recording mode indication
“@:-When a tape reaches its end during recording, "TAPE
"END" indicator will appear in the-viewfinder. and power
~ itself off automatically if left for longer than 5.minutes. . .
If the. Record-Standby mode continues for longer than
about & minutes, the unit switches itself off
_', automatically. To restart recording, turn the power on
- afid press the Recording Start/Stop button. This
- makes clean assembted recordings possible even
after a long pause. :
When turning off the VideoMovie with the power
. “Switch set to "CAMERA", be sure to set the switch to
_ SOFF*" first. Then set it back to "CAMERA" to tum on
“++ the VideoMovie again.
Elapsed time counter
Wf To stop recording temporarily.
Press the Recording Start/Stop button once again.
To restart recording.
Press the Recording Start/Stop button.
= Repeating steps — and Ei produces assemble
recordings.
18
RETAKE
AUTO PAUSE
Record-Pause
If you want to review the end of the last recording for
confirmation, use this function.
& Press G) from the Record-Standby mode.
— The tape will be rewound for about 2 seconds of
program time and played back automatically for
this section, after which it will pause in the
Record-Standby mode for the next shot.
Note:
Distortion might occur when playback starts. This is
normal.
While recording, you may decide to re-record certain
segments. The Retake function is convenient for this.
Mi Make sure the VideoMovie is in the Record-
Standby mode. (If not, engage the mode.)
Hi Press either RETAKE to reach the point where you
wish a new recording to start.
@ When RETAKE is released, the camera will enter
the Record-Standby mode again.
Press the Recording Start/Stop button.
— Recording starts.
Note:
Noise may appear during Retake. This is normal.
With the Auto Pause system, the VideoMovie
automatically stops recording when it is pointed down.
This function prevents shooting the ground, your feet,
etc. by mistake.
= Set AUTO PAUSE to "ON".
—~ When the VideoMovie is tilted down by a large
degree (approx. 90°) from its horizontal position
during recording, it will automatically enter the
Record-Pause mode, and the "AUTO PAUSE"
indication will appear in the viewfinder.
® To shoot downward, set AUTO PAUSE to "OFF".
The Auto Pause system is also effective when the
VideaoMovie is tilted up.
19

RECORDING OPERATION (Cont'd
Viewlinder
START/STOP
RM-V700U.
(provided)
Recording StarvStop button = Power switch
20
NDEX‘CODE: MARKING «:
The VHS Index Search System (VISS) gives you
automatic access to any point you select on a
recording. Only the marking aspect of the Index
Search System is included in this unit. It allows index
codes to be placed on recorded tape for convenient
dubbing or editing on VCRs with an Index Search
function.
Auto marking
An index code is always marked at the beginning of
the first recording atter the date advances and a
cassette is inserted.
— "INDEX" blinks while marking.
Manual! marking
The RM-V700U remote control unit allows index codes
to be marked in any desired position.
Ii Press VISS once to put an index code onto the
tape.
— "INDEX" blinks during the marking process.
If VISS has been pressed in the Record-Pause
mode, an index code is put at the point where
START/STOP is pressed.
y warning (<2) blinks in the
viewlinder while recording, stop recording and set
the power switch to "OFF" to turn power off.
Bi Replace the battery pack with a charged one.
Set the power switch to "CAMERA".
—— The unit will be in the Record-Standby mode.
J Press the Recording Start/Stop button.
— Recording starts.
‘Jo,record onto.a partially recorded tape.
i Set the power switch to "PLAY" and press PLAY to
playback the tape to a point where you wish a new
recording to start.
@ Use REW or FF for faster location.
f Press PAUSE at the located point.
— The unit will enter the Still mode.
Set the power switch to "CAMERA".
@ Press the Recording Start/Stop button.
— Recording starts.
scene by using the built-in video light.
Mf Slide the LIGHT release knob to open the built-in
video light.
Set the LIGHT ON/AUTO as required.
ON: Always keeps the light on as long as the
VideoMovie is tumed on.
AUTO: Automatically turns on the light when the
VideoMovie senses insufficient lighting on
the subject.
= Push @ to retract the video light.
— The light automatically tums off.
@ The video light can be used with the VideoMovie's
power on.
= It is recommended to set the white balance to
indoor mode (4) (c7 P. 29) when you use the
video light.
= When not using the video light, retract it to save
battery power.
Notes:
™ Even if the battery warning indication (CS1) does
not appear in the viewfinder, if the battery pack's
charge is low, the VideoMovie may turn off
automatically when you turn on the video light, or
when you start recording with the video light turned
on.
= When the LIGHT ON/AUTO is set to "AUTO":
¢ Depending on the lighting condition, the video light
may not be stably turned on or off. In this case,
switch the fight on manually or retract it to turn it
off.
« While the Sports, High-Speed Shutter or Portrait
mode (CF P.27) is engaged, the light is likely to
stay on.
While the Twilight mode (= P.27) is engaged, the
light will not activate.
CAUTIONS: PO an asada sas
&
The
video
light
becomes
extremely
hot.
Do
not
touch
it
either
while
in
operation
or
soon
after
turning
it
off,
otherwise
serious
injury
may
result.
--
® Do not place the VideoMovie into the carrying case
immediately
after
using
the
video
light,
since
it
remains extremely hot.
m= When operating, keep a distance of about
30 cm (1 ft.) between the video fight and people or
object. © : : ;
®
Do
not
use
near
flammable
or
explosive
materials.
21

RECORDING OPERATION (Cont'd
PROGRAM AE DISPLAY
Auto Date Record mode
Oate display
Character Generator Auto date titler
Date-off mode «—— On-screen display ~——. Time display
Date display Auto Date record mode
+ DEG 25.04" “KUTO DATE: 8D pes aston!
Auto date
record executed
Auto date titler
DEG 25 1994:
Character Generator
SETCHAR GOODKIGHT . ,
No Characters
stored
Example of
stored characters
22
“DATE/TIME CHARACTER INSERT
The date/time/character can be displayed and
recorded according to the selected mode.
Wl Set the PROGRAM AE select dial to "AUTO MODE
RELEASE".
i Press DISPLAY while in the Record-Pause mode to
cycle through the modes in the order shown on the
left.
= Setting PROGRAM AE to “AUTO MODE LOCK"
always engages the Auto Date record mode.
(cx P.26)
ig HO display Loe Ch LS
The selected display mode can be recorded.
When no display is needed on the recorded tape,
select Date-off mode before shooting.
§ To delete the display during recording, press
DISPLAY.
— If the display is to be called back on the screen ,
put the VideoMovie into the Record-Pause mode
first. Then press DISPLAY to select the desired
mode.
Note:
@ The DISPLAY button does not work when PROGRAM AE
is set to "AUTO MODE LOCK”.
“Auto Date Record:function/Auto Date :Titler.
These functions allow the date (month, day and year)
to be automatically recorded for about 5 seconds
following the first operation of the Recording Start/Stop
button:
= after changing the date.
= after a cassette is loaded, or
= after its mode is selected by DISPLAY.
ain the Auto Date Record mode, the viewfinder
indication shows the date during the initial
5 seconds, then changes to “AUTO DATE".
@ In the Auto Date Titler mode, the date is displayed in
large characters in the center of the viewfinder
screen.
i'Screan Display Modes hice
The viewfinder indications can also be displayed on
the screen of a monitor connected to the VideoMovie.
= Connect the VideoMovie to a video monitor. Press
DISPLAY until the viewfinder indications (C= P. 45.)
appear on the monitor screen.
In the On-Screen Display mode, the date will be
displayed and recorded.
# The on-screen display is not available during
recording.
SELECT SET
CHARACTER
fae SET MODE
i screen
7 CHARACTER
BR) SET MODE
ian, SCreen
TITLES
Title indication
Example of Character
Generator& Title
Viewtinder
Title: OUR VACATION
“OUR VACATION ..-
“ON HAWAIE- 7 Character Generator:
IN HAWAII
ae mai.
i sav oll
You can make your own title, store it in advance and
superimpose it over the scene being shat.
How to store:
fl Prass DISPLAY until "SET CHAR" or a title you have
stored earlier appears in the viewfinder.
Press SET.
~— CHARACTER SET MODE screen will appear in the
viewtinder.
Press SELECT to move the cursor, and then press SET to
choose the desired characters.
1 Repeat step §§ to set all needed characters.
— After all the desired characters have been entered,
press SET. The CHARACTER SET MODE screen will
disappear, and the stored characters will be displayed.
Notes:
® Up to ten characters can be stored.
& Only one personally input title can be stored at a time. To
replace it with another title, proceed as above again.
One of them can be superimposed above the
Character Generator's stored title.
How to superimpose the Title:
Press TITLES as many times as required until the
desired Title is displayed. The Title changes in the
sequence below:
No indication (title off)
HAPPY BIRTHDAY
Character Generator title OUR VACATION
CONGRATULATIONS MERRY CHRISTMAS
se agi DAY A SPEGIAL DAY
OUR NEW BABY
HAPPY HOLIDAYS
= A personal title stored in the Character Generator
can be displayed in the same position as the Instant
Title.
— The Instant Title's function can be used along
with the Character Generator mode;
consequently, a pair of identical stored titles can
be superimposed.
Notes:
= The TITLES button is not effective during recording.
= The Instant Title cannot be displayed when
PROGRAM AE is set to "AUTO MODE LOCK".
(c> P.26)
™ When DISPLAY is pressed during recording, the
Title disappears.
23

Focus detection zone
LIN IO)
Mees pees
eee SOW e
ADVANCED VIDEOGRAPHY TECHNIQUES
Two subjects at different
distances overlap in the
same scene.
Low illumination.
PROGRAM AE
24
The subject has no contrast
(ditterences in brightness
and darkness), such as a
flat, one-color wall, or a
clear, blue sky, for instance.
Low-contrast warning.
A dark object is barely visible
in the viewfinder.
Minute patterns or identical
patterns that are regularly
repeated.
Focus lock indication
Aute-fo Zs
The VideoMovie's Full Range AF system can offer
continuous shooting ability from close-up to infinity.
The rectangular focus area detects focus. (No actual
indication provided in the viewfinder.)
Notes:
aif the lens is smeared with stains or blurred with
condensation, accurate focusing is not possible.
Keep them clean. If they become dirty, wipe with a
piece of soft cloth. When condensation occurs, dry
them by wiping with a soft cloth or wait for conditions
in which they become dry.
= Correct focus may not be obtained in these
situations on the left. In such case manual focusing
should be performed to obtain proper focus.
“Focus lock ° 50°: es
This VideoMovie's focus tock function is especially
useful in the following situations:
w When things pass between your subject and the
VideoMovie, make sure to engage the focus lock
function, to lock your subject in focus before
recording.
@ If you want your main subject to appear in a corner
of the screen, you should first center it at the desired
distance, then use the auto focus made for focusing,
engage the focus lack function, and move the
VideoMovie till the subject is where you want it.
To tock the focus:
Press FOCUS LOCK/MAN.
-~ The focus lock indication (»e<) appears in the
viewlinder.
To release the focus lock mode (To engage the
Auto Focus mode):
Press FOCUS LOCK/MAN. At the moment when the
button is released, the focus lock mode is canceled.
Note:
The Focus Lock function is not available when
PROGRAM AE is set to "AUTO MODE LOCK".
(> P. 26)
‘com-in
Notes:
™ Focusing may become unstable during the zooming-
in operation. In this case, first zoom in in the
Recording Standby mode then, after using the
manual focusing or the Focus Lock function to hold
the focus fixed, zoom in or out in the Record mode.
@ When shooting low-contrast subjects in the Zoom-in
mode, the Videomovie automatically zooms out with
the low contrast indicator blinking and focus being
performed.
® Zooming operation is not available while FOCUS
LOCK/MAN. is pressed.
~- Manual focus es
For manual focus operation, proceed as follows:
ER Press the power zoom buttons ("T” and "W") along
with FOCUS LOCK/MAN.
= To adjust the focus to a farther subject:
Press T. The Manual Focus indications
(a< &) appear, and <blinks.
= To adjust the focus to a closer subject:
Press W. The Manual Focus indications
(4 »&) appear, and & blinks.
™ When the focus level cannot be adjusted any
farther or closer, the indicator { a ) or the indicator
( .&) will blink.
Hi When finished with focus adjustment, release the
power zoom buttons.
— The Manual Focus indications change to the
FOCUS LOCK indication (me«), and the
adjusted focus is locked in.
= To release the Manual Focus mode (to engage the
Auto Focus mode):
Press FOCUS LOCK/MAN. At the moment when the
button is released, the Manual Focus mode is
canceled.
~~ FOCUS LOCK indication (»e@) disappears.
Notes:
= When you use the Manual Focus mode, be sure to
focus the fens in the maximum telephoto position. If
you focus in on a cerlain subject in the wide-angle
position, sharply-focused images cannot be
obtained when zoomed up because the depth- of-
field is reduced at longer focal tengths.
= When focusing manually, make neccessary
viewfinder adjustments (c>" P. 16), then focus in.
= Manual Focus operation is not available when
PROGRAM AE is set to "AUTO MODE LOCK".
(> P. 26)
Ber elol <fe84 yp ioatiaaee ‘
frat J af ; pte
Pressing the power zoom buttons ("T" and “W") will
vary the focal length of the lens.
Procedure
= Pressing T : Zoom in on the image (bring it nearer).
® Pressing W: Zoom out.
@ Two zooming speeds are available. For slow-speed,
press lightly. For regular-speed, press firmly.
25
Ce et et

| ADVANCED VIDEOGRAPHY TECHNIQUES (Cont'd) |
Tally famp PROGRAM AE select dial
he en.
Re, pr
One
¥
A.LOCK
Auto
Mode
Lock
:
S.TIMER
15sec. Salf-Timer
'
Ka
Electronic
Fog
Filter
ty
% chy
S 1/8000 High-Speed Shutter
MONOTONE Monotone
TWILIGHT Twilight
SPORTS
58
A variety of creative shooting effects are accessible
with the PROGRAM AE select dial.
To engage any of the effects:
Turn the PROGRAM AE select dial so that the desired
indication appears in the viewfinder.
— The chosen mode is activated approx. 1 second
later.
Note:
Only one Special effect can be activated at a time.
FAuto’ Mode Release.mode:-<
The mode for normal shooting.
«Abto:modé.Lockmode
Setting to this mode locks the VideoMovie in
Auto mode, eliminating the possibility of misoperation
by accidentally touching the following buttons while
shooting. It is convenient when asking someone else
to do the shooting.
These controls cannot be used in this mode:
TITLES, FOCUS LOCK/MAN., DISPLAY, CINEMA,
FADER, MWB (Manual! White Balance).
;, 18sec" Sell-Timet_mode =<. 52."
This mode lets you delay the start of recording after
the Recording Start/Stop button has been pressed. If
the VideoMovie has been secured, the operator can
enter the picture before actual recording begins.
Il Set the PROGRAM AE to ©.
— © 158" is displayed in the viewlinder.
SEPAUSEZS -
‘SATIMER mice Viewfinder
Press the Recording Start/Stop button.
= Recording begins automatically after 15 seconds.
= When performing Self-Timer shooting, the tally
lamp will start blinking approximately 10 seconds
before the actual recording begins. Then when
recording starts, the lamp lights normally to
indicate recording is in progress.
RL
Sa
Ea
2
EI
EE
TE
I
TE
I
a
I
A
RelectranierkoayEtern See
Makes the picture took misty white; similar to the effect
when an external fog filter is attached to the lens.
Useful when you want to soften an image slightly or
give it a "fancy" look.
F High-Speed Shutter mows. yon See a,
This mode sets the shutter speed to 1/8000 sec. to
clearly capture fast-moving action with less blur.
Clarity is especially noticeable during slow motion
playback on a video deck. Great for sports (i.e., golf
swing), races, etc. R
This mode can capture faster action than the Sports
mode can.
Note:
The screen becomes slightly dark with the High-Speed
Shutter mode. Use this mode in the daytime outdoors and in
other well-lighted situations.
“!Monotonéimodesg eo 3¢
The scene being shot will
brown monochrome, making it look like an old movie.
By using it in combination with Cinema mode (1c
P.28), you can recreate the authentic took of a classic
Hollywood movie.
Note:
The screen will become slightly reddish when the fader
function is used in the Monotone mode (C7 P. 28).
“Twilight mode ie
Disengages the auto gain control and auto focus, and
automatically locks the focus to infinity and white
balance to “# (outdoor) mode. Dusk and twilight
scenery, fireworks, etc. look more natural and
dramatic.
® Manual adjustment of white balance (i P. 29), and
focus (cx P, 25) is possible.
# Pressing FOCUS LOCK/MAN. re-engages the auto
focus mode.
SSBOHS pee ese Uap anmemnt ae
Uses high shutter speed to clearly capture fast-moving
action with fess blur. Clarity is especially noticeable
during slow motion playback on a video deck. Great
for sports, races, etc.
Rete
prow
atene
o
ctg
Rett
Na
Ste
Bi
wrt
a
Hat,
Reduces depth-of-field so the background becomes
blurry while the subject remains clearly focused. Use it
for beautiful portrait shots.
Note:
Picture color may be adversely affected in High-Speed
Shutter, Sports or Portrait mode when the subject is lit by
alternating discharge-type fight sources such as fluorescent
of mercury-vapor lights.
27

FADE-IN
FADE-OUT
Viewtinder
Cinema mode
28
ADVANCED VIDEOGRAPHY TECHNIQUES (Cont'd
SPADBR Es: ae :
This VideoMovie incorporates a fader function which
allows smooth video fade-in and fade-out to a black
blank screen.
(With the Electronic Fog filter mode (<> P. 27) engag-
ed, the image fades in/out to a white screen.)
hres t &
J Press FADER.
— The VideoMovie enters into the Fade-Standby
mode and "FADER" appears.
Press the Recording Start/Stop button.
— The screen immediately becomes blank and
recording begins. Fade-in starts at the moment
the Recording Start/Stop button is released.
aif the button is not released, the screen will
remain blank and be recorded as long as the
button Is kept pressed.
* Fade-out: ae
BB Press FADER in the Recording mode.
— The VideoMovie enters the Fade-Standby mode
and "FADER" appears.
fd Press the Recording Start/Stop button.
— The viewfinder indications start blinking. Fade-
out starts and will be completed in a few
seconds.
= When completed, the VideoMovie enters the
Record-Standby mode automatically. At this time,
if the button is not released, the screen will
remain blank and be recorded as jong as the
button is kept pressed.
Notes:
= The screen will become slightly reddish when the fader
function is used in the Monotone mode
(> P. 27).
® Fader operation is not possible when PROGRAM AE is set
to “AUTO MODE LOCK". («> P. 26).
‘ A {NODE ee =
This VideoMovie incorporates a "Cinema" mode
recording function which allows you to record black
bars at the top and bottom of the screen to produce a
cinema-like "wide-screen" effect.
To engage the Cinema mode:
Press CINEMA.
To restore the normai screen:
Press CINEMA again.
Notes:
The Cinema mode can be engaged only in the Record-
Pauce of Record mode.
= The Cinema mode is not available when PROGRAM AE is
set to "AUTO MODE LOCK". (cz P. 26).
White balance mode indicator
No indication (Auto) ———> %e
‘ Y
MWB <t——— 3 ~<e——.
PROGRAM AE
Useful tip:
It is helpful to connect your VideoMovie to a color
monitor when adjusting the white balance.
SWHITE-BALANCE ADJUSTMENT.
This VideoMovie’s Automatic Color Temperature
system senses the color temperature of the ambient
lighting for automatic white balance adjustment.
However, precise color temperature adjustment is not
possible under the following conditions:
& The object is in various shades of the same color.
= Predominantly red or brown object is being shot
outdoors.
In these cases, use the VideoMovie's built-in preset
filters for white balance adjustment.
“To adjust the white balance3-c3s0-5
Press MWB (Manual! White Balance) so that the
required indication appears in the viewfinder.
We cscave When you shoot in the daytime outdoors
(cloudy day)
“@: ...... When you shoot in the daytime outdoors
(sunny day)
P en When the source of illumination is a halogen
or tungsten lamp.
MWB ....{n the following situations.
How to use the MWB mode
In the MWB mode, the VideoMovie automatically
adjusts the color temperature of the subject's light
source and keeps that color temperature during
shooting. When shooting some subjects with different
color temperatures, use the MWB mode to set a color
temperature and you can shoot with natural colors that
are not affected by surroundings.
GB Press MWB until “MWB” appears in the viewfinder.
Ef Point the VideoMovie at a white, flat object such as
a sheet of white paper.
Adjust focus manually. (Cc P. 25)
Keep MWB pressed for more than about 3
seconds.
@ "MWB" blinks in the
viewlinder .... During adjustment
@ "MWB" is lit.. . Adjustment is finished
—The VideoMovie is now ready for shooting.
Notes:
= Re-adjust the MWB mode in the following conditions:
@ When the lighting has changed.
® When the VideoMovie has been turned off and on
again.
@ When PROGRAM AE's position has been changed.
= Manual White Balance adjustment is not possible when
PROGRAM AE is set to “AUTO MODE LOCK”. (cx P. 26)
To switch to automatic adjustment:
Press MWB until the indication disappears, or turn the
PROGRAM AE to “AUTO MODE LOCK".
29

30
ADVANCED
VIDEOGRAPHY
TECHNIQUES
(Cont'd
RM-V700U
(provided)
=HMER:. pit Ait
This Self-Timer function allows you to set the amount
of time delay before recording staris after Star/Stop
has been pressed. If the VideoMovie has been
secured, the operator can enter the picture before
actual recording begins.
Hl Put the VideoMovie into the Record-Pause mode.
Press INT. TIME to select the interval time.
—The following sequence of time setting is
displayed with each press of INT. TIME:
a “epause ==
Bot 15S —» 30S —>+ 1MIN —+ 5MIN
{regular recording mode)
Viewtinder
aif the VideoMovie's PROGRAM AE is set to
""(Self-Timer mode), the 15S mode will be
selected.
Press START/STOP.
@ When the selected time has elapsed, recording
begins automatically.
= When performing Self-Timer shooting, the tally
lamp will start blinking approximately 10 seconds
before the actual recording begins. Then when
recording starts, the lamp lights normally to
indicate recording is in progress.
To release the Selff-Timer mode:
When "-" ts not blinking:
Press INT. TIME continuously until” &)" goes off.
When "-" is blinking:
Press Start/Stop to stop the blinking, then press INT.
TIME continuously until" ©)" goes off.
= Turning the power olf and on once engages the regular
Record-Pause mode.
RM-V700U
(provided)
IMATION *
The Animation function produces the illusion of
movement in otherwise stationary scenes or objects.
This technique is accomplished by shooting a series of
slightly different pictures of the same scene or slightly
different poses of the same object for a brief period of
time.
I Set SP/EP to "SP".
Put the VideoMovie in the Record-Pause made.
Press REC TIME to select the recording time.
— The following sequence of time setting is
displayed with each press of REC TIME:
1/48. 12S ——_+1S
; {regutar recording mode)
Viewtinder
@ If the VideoMovie's PROGRAM AE is set to "%)"
(Self-Timer mode), Animation will be cancelled
and the VideoMovie will enter the Setf-Timer 15S
mode.
i Press START/STOP after focusing on the subject.
® Recording stops automatically in the Record-
Pause mode after the selected period of time.
Repeat steps EI-f9 for the required number of
pictures.
Gi Playback the recorded series to check if results
were satisfactory.
To release the Animation mode:
Press REC TiME until "tm" in the viewfinder
disappears.
& The Animation mode can only be engaged from the
Record-Pause mode.
Notes:
® Keep the VideoMovie steady in one position when
filming the series of shots for best results. Mounting
the VideoMovie on a tripod is recommended.
® Before recording in the Animation mode at the very
beginning of a tape, set the VideoMovie to the
Recording mode for about 5 seconds, so that the
tape runs smoothly. Using the Fade-in function at
this point is a good way to begin an animated
program.
® Fade-in/out is not possible during Animation or
Time-Lapse shooting.
@ When shooting in the Animation mode, the elapsed
time counter reading may be incorrect. This is not
due to any defect of the unit.
31

RM-V700U
(provided)
32
PUNRAM PRR RSC Race GNIS
The Time-Lapse function allows automatic sequential
on/off recording at preset time spans. With the
VideoMovie continuously focused on a specific scene
or object, the resulting recording will show subtle
changes (such as shifts in cloud formations, plant
growth etc.) over an extended period of time.
Ml Set SP/EP to "SP".
i Put the VideoMovie into the Record-Pause mode.
i Press REC TIME to select the recording time.
— The following sequence of time settings is
displayed with each press of REC TIME:
+ 1/4S + 1/25 —--» 1S
~--— (regular recording mode)
eee
Viewfinder
i Press INT. TIME to select the interval time.
— The following sequence of time settings is
displayed with each press of INT. TIME:
15S —» 30S —» {MIN —» 5MIN
: seni ay af
Viewfinder
(regular recording mode)
8 Press START/STOP to start the Time-Lapse
recording. The selected recording time and interval
will alternate automatically.
® The tally lamp functions in the same way as in
Self-Timer shooting.
To retease the Time-Lapse mode:
[ When "-" js not blinking:
Press INT. TIME and REC TIME continuously until
tm" and" &" go off.
When "~" is blinking:
Press Start/Stop to stop the blinking, then press the INT.
TIME and REG TIME continuously until "ta" and "©"
go off.
L
Notes:
@ When shooting in the Time-Lapse mode, the
elapsed time counter reading may be incorrect. This
is not due to any defect of the unit.
w During steps —] or @, if the VideoMovie's
PROGRAM AF is set to "SD" (Salf-Timar mada). the
Self-Timer 15S mode will be engaged.
Compartment door
Sliding jatch
| PLAYBACK |
By using the provided cassette adapter (VHS Playpak:
C-P6U), a VHS video cassette recorded with this
VideoMovie can be played back with any VHS video
recorder. When the VHS-C video cassette is installed
in the cassette adapter, it is fully compatible for both
recording and playback on any VHS video recorder.
The C-P6U cassette adapter is battery-powered and
will automatically perform tape loading and unloading.
Note:
Only compact video cassette tapes marked VHS-C
can be used with the cassette adapter.
"Inserting the battery into the cassette’
adapter a Sree oe .
Wi Remove the battery cover by sliding it up.
Install one "AA(R6)" size battery as shown.
EI Reattach the cover.
Playback‘on the VCR 0
(1] Open the compartment door by sliding the latch.
[2] Insert the compact video cassette.
[3] Close the compartment door. The tape is loaded.
[4] Insert the cassette adapter into the VCR.
[5] Playback the tape.
Note:
During special-effect playback (slow motion, still
frame, etc.), the picture may vibrate or noise bars may
appear on the screen.
Il Slide the sliding jatch.
— The tape will be unloaded and the compartment
door will open.
Insert your finger into the hole on the underside of
the adapter, push the cassette up from below and
remove it.

PLAYBACK (Cont'd
TRACKING (-/+}
34
REW OFF
The VideoMovie permits playback of recorded "VHS-
C” video cassettes.
For connections refer to pages 36 and 37.
“PLAYBACK:
OPERATION
@ Supply power. (Battery or AC
FSRATERS
operation: > P. 11)
fl insert a pre-recorded VHS-C cassette.
@ Ensure that tape is not stack inside the cassette,
then load the cassette correctly. c7 P, 15.
Saco playback dcnstesteren regres
Set the power switch to "PLAY".
— The power indicator lights.
Press PLAY.
-— Playback starts and playback picture appears on
the viewfinder screen and connected TV.
Ampere nets ‘r
nao ete RA Aare SE
A LES ROLES
i
agpeoroer
nae
~Satestop
play!
Press
STOP.
@ After about 5 minutes in Stop mode, the
VideoMovie switches itself off automatically.
(To turn on the VideoMovie again, set the power
switch to "OFF" first and then back to “PLAY".)
To rewind the tape:
When in the stop mode, press REW.
— For high speed rewind, hold REW for more than 2
seconds. (The elapsed time counter changes to
To fast-forward the tape:
When in the stop mode, press FF.
— For high-speed fast-forward, hold FF for more than
2 seconds. (The elapsed time counter changes to
"t—-")
Note:
The elapsed time counter indication and counter
memory function («7 P. 35) do not function when
using the high-speed REW or high-speed FF mode.
to be adjusted.
Hi Press either TRACKING to adjust to the best
picture possible.
® To reset the tracking back to its standard preset,
press both TRACKING (-/+) simultaneously.
Note:
The tracking adjustment may not be effective on tapes
recorded on another VCR's or VideoMovies.
PAUSE REW
STILL PLAYBACK..: | «--
Press PAUSE during playback.
— The power indicator lights.
™ To protect the tape and to conserve power, the
VideoMovie will enter the stop mode and turn itself
off after 5 minutes of stilt playback.
SSHUTTLE‘SEARCH "°° “-
Fast-speed forward playback:
Press FF during playback.
— Playback speed of the tape will be 3 times the
normal speed in the SP mode, and 7 times in the
EP mode.
Fast-speed reverse playback:
Press REW in the Play mode.
— Reverse playback speed of the tape will be 3 times
the norma! speed in ihe SP mode, and 7 times in
the EP mode.
Notes:
= For brief fast-speed searching, hold FF or REW for
more than 2 seconds. When the button Is released,
the search ends and the tape will play.
= Noise bars will appear and pictures may become
monochrome while in Still Playback or Shuttle
Search. This is not due to any defect of the unit.
SGOUNTER
MEMDRVIFUNCHTION:
This
VideoMovie
incorporates
a
counter
memory
function
which
facilitates
locating
a
specific
tape
segment.
MB Press COUNTER RESET.
~~ Resets the counter to "0:00:00".
Press COUNTER MEMORY. — "M” appears.
After recording or playback, press STOP, then REW.
— The tape will automatically stop at the counter
reading of around "0:00:00".
Press PLAY. — Playback starts.
Notes:
™ The counter memory functions in the Fast-Forward
and Rewind modes.
= The counter memory is reset when the high-speed
Fast-Forward or Rewind mode is used.
= To cancel the memory function, press COUNTER
MEMORY so that the "M" disappears.
u The counter memory is reset when power is
removed from the VideoMovie.
35

| CONNECTIONS TO A VCR OR A TELEVISION |
To AUDIO
and VIDEO
out connectors
AN output cable
(provided)
To AUDIO IN connector
fo VIDEO IN connector
Also refer to the instruction manual for your VCR or TV
when connecting the VideoMovie to them.
use the e.
Hi Connect the VideoMovie and the VCR as shown in
the diagram on the left.
Turn on the VideoMovie, the VCR and TV.
Correctly insert the VHS-C cassette into the
VideoMovie.
i Set the VCR to AUX(iliary) input mode, and the TV
to the VIDEO mode.
To VHF
Aerial antenna terminal
ANTENNA IN
SettoJor4
AVI AN Np aticonn:
In this situation, use the RF unit.
Bl Set the output channel select switch of the RF unit
to CH3 or CH4.
u The RF unit permits playback of the video and audio
recordings through a TV receiver. The signals from
the RF unit are viewed through a vacant channel not
used for broadcasting in your area.
= The RF unit has been set to CH4 prior to shipment.
if channet 4 is used for normal broadcasts in your
area, set the switch on the RF unit to channel 3.
This is your video channel. To view video cassettes,
set the TV channel selector to the channel number
you selected on the AF unit. (channel 3 or 4)
Remove the antenna cable from the TV receiver.
Connect the antenna cable to the ANTENNA IN
terminal of the RF unit.
i Connect the RF OUT terminal of the RF unit to the
75-ohm coaxial antenna terminal of the television
using the antenna cable.
Connect the VIDEO/AUDIO INPUT cable of the RF
unit to the AUDIO and VIDEO out connectors and
RF DC OUT of the VideoMovie.
LOPERATIONSRSEASS
Viewing video cassettes bein
the VideoMovie:
To view video cassettes or to monitor the recording,
set the TV channel selector to the channel number you
selected on the RF unit. (channel 3 or 4)
Viewing television programs:
To AUDIO and Your television will function the same as before. Just
VIDEO out
connectors and change your channel to the one you wish to watch.
AF DC OUT
To AUDIO
and VIDEO
out connectors
To AUDIO
and VIDEO IN i
connectors
aE
™ Connect the AUDIO and VIDEO out connectors of
the VideoMovie to the A/V input connector of the
television.
w Use the Video (or AV) mode specified in the TV's
instruction manual. (instead of tuning to channel 3 or
4)
Helpful hints:
@ It is recommended to use the Multi AC Charger/Adapter as the power supply rather than the battery pack.
Precautions for RF-unit:: 9.
= For exclusive use with the VideoMovia.
= Use only the RF-V5U.. 20 lo.
® Do not disassemble or modify the RF-unit.
# Do not expose it to'sttong shocks. :
u Unplug the connected equipment during
lightning storms.(Never touch the antenna
cable.) ea ae Ee, oi
= It is possible to monitor the picture and sound from the VideoMovie even when a cassette tape is not loaded.
Set the power switch to "CAMERA". When you select the television input from your VideoMovie, the audio
and video can be monitored.
37

EDITING TECHNIQUES
Yo EDIT (t) To AUDIO out
wy to VIDEO out
Editing cable AN output cable
(provided) (provided)
To To AUDIO IN
Remote PAUSE
To VIDEO IN
38
Preparations
™ Connect the VideoMovie and the VCR as shown in
the diagram on the left.
— The editing cable is used to connect the
VideoMovie and a JVC VCR with a Remote
PAUSE terminal.*
(If the VCR does not have a Remote PAUSE jack,
you can use the R.A. EDIT jack if one is
available. See additional notes on Dubbing using
the editing cable below.)
@ Set the power switch to "PLAY",
@ Turn on the VCR.
= Correctly insert the appropriate cassettes into the
VideoMovie and the VCR.
HI Engage the VCR's AUX{iliary) mode and Record-
Pause mode.
Engage the VideoMovie's play mode to locate a
position on the tape slightly before edit-in point.
When this point is reached, press PAUSE to enter
the still mode.
Press the VideoMovie's EDIT and set the VCR's
recording mode to start editing.
—The VideoMovie rolls back the tape a little before
it starts playback.
i When the tape reaches the edit-out point, put the
VCR's Record-Pause mode and the VideoMovie's
still mode.
= Repeat steps @ - Ei.
= Stop both the VideoMovie and the VCR when
dubbing is finished.
* Dubbing using the editing cable to connect
the VideoMovie and the JVC VCR with a
Remote PAUSE termina!
— When the VideoMovie's EDIT is pressed at
step El, the VCR automatically starts recording.
When the VideoMovie's PAUSE is pressed, the
VCR automatically enters the Record-Pause
~~ mode. f 2 ;
‘— Reset the VideoMovie's counter In advance to
"M0:00:00" at an edit-out-point. When the tape
. reaches the point (counter reading of 0:00:00)
during dubbing, the VideoMovie enters the Still
mode and the VCR.enters the Record-Pause
mode automatically. This function is called
"Master Edit Control System”.
Notes: : '
= There are some VCRs which are not compatible
with the Master Edit Control system.
® When the tape reaches the preset edit-out point
* ~-(M0:00:00)during the dubbing operation, it may
stop slightly before or after the designated point
on the tape. - : : .
MBR SET
VCR. CTL.
RM-V700U
(provided)
VCR CODE LIST
ZENITH
VCR.BRAND |BUTTONS | |..VCR BRAND | BUTTONS
NAME: Sf ANB] NAME. Ooo) (Ay)
eo PANASONIC | © @
oe 00
e°0 00
00 00
HITACHI ee oo
oe 2)
Jvc OA °° 60
B 00 60
c Om) oe
MAGNAVOX oo dibs
00 6o
e0 60oe
eo 0e
MITSUBISHI eo oo
eo SONY :)
NEG so)
anes 28
PHILIPS : talc
. TOSHIBA e0
o | @0
6
e
8
e
J
when your VideoMovie is used as the source player in
combination with your VCR. You can pre-select up to 8
scenes or "cuts" for automatic editing in the sequence
you have specified. Random Assemble Editing can be
more conveniently done if the RM-V700U MBR (Multi
Brand Remote, provided) has been set to correspond
to ihe brand of your VCR.
[J How to set the remote control unit to
correspond to the brand of your VCR:
Turn the VCR's power off before starting.
EE Point the remote control toward the VCR's
intrared beam sensor window.
Refer to the list on the left, and while pressing
MBR SET, press button (A), then press button
(B).
Release MBR SET.
= The code is set and the VCR's power
automatically comes on.
lf your VCR has more than one code, choose
the code with which you can turn the VCR's
power on.
(With some VCR brands, power won't come on
automatically. In this case, turn the VCR power
on manually and check to see if the remote
contro! buttons work with the VCR.)
(2} How to operate the VCR:
KB Turn the VCR's power ON.
Hi Press the button on the remote control unit
corresponding to the function you want to
Operate while pressing VCR CTL.
# Since the remote contro! unit has a number of
operation codes, determine the appropriate
code for operating your VCR by confirming
correct VCR operations according to the steps
above.
= The VCR functions that the RM-V700U can
control are PLAY, STOP, PAUSE, FF, REW
and VCR REC STBY. Among them, VCR REC
STBY button doesn't need to be pressed along
with VCR CTL.
aif the RM-V700U is not able to contro! the
VCR, use the controls on the VCR.
IMPORTANT: : i
Although the MBR (Multi-Brand Remote Control) is
compatible wilh JVC VCRs, as well as many VCR
models manufactured by others, it is possible that this
‘remote control will not work with your VCR or may offer
limited functions. nes :
(Continued on next page.)
39
