1-2 (No.YF074)
SPECIFICATION
AC Adapter
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice.
General Format VHS (GR-AXM287 only) / S-VHS NTSC standard
Power source DC 11 V (Using AC Adapter)
DC 6 V (Using battery pack)
Power consumption Viewfinder on 3.5 W
LCD monitor on 4.3 W
Video light* 0.4 W
* Applicable models only.
Signal system NTSC-type
Video recording system Luminance FM recording
Colour Converted sub-carrier direct recording Conforms to VHS standard
Cassette / cassette
Tape speed SP 33.35 mm/sec.(1-5/16 ips)
EP 11.12 mm/sec.(7/16 ips)
Recording time (max.) SP 40 minutes
EP 120 minutes (with TC-40 cassette)
Operating temperature 0°C to 40°C(32°F to 104°F)
Operating humidity 35% to 80%
Storage temperature -20°C to 50°C(-4°F to 122°F)
Weight Approx. 770 g
Dimensions (W ×H ×D) 81 mm ×125 mm ×216 mm(3-1/4” ×4-15/16” ×8-9/16”)
(with the LCD monitor closed and with the viewfinder fully tilted downward)
Pickup 1/6" format CCD
Lens F1.8 f = 2.2 mm to 44 mm, 20:1 power zoom lens with auto iris and macro con-
trol filter diameter 30.5 mm(GR-AXM287 only) /
F1.8 f = 2.2 mm to 55 mm, 25:1 power zoom lens with auto iris and macro con-
trol filter diameter 30.5 mm
Viewfinder Electronic viewfinder with black/white LCD
White balance adjustment Auto/Manual adjustment
Connectors Video 1 V (p-p), 75 Ωunbalanced, analogue output (via Video output connector)
Audio 300 mV (rms), 1 kΩ, analogue output (via Audio output connector)
S-Video* Y : 1 V (p-p), 75 Ω, analog output
C : 0.29 V (p-p), 75 Ω, analog output
* Applicable models only.
Power requirement U.S.A and Canada AC 120 V to 60 V~
Other countries AC 110 V to 240 V~, 50 Hz/60 Hz
Output DC 11 V, 1 A
