JVC Product Launch: March 2009
Specification
:: 1/6-inch 800k Pixel CCD
:: 16GB Built-In Flash Memory
:: 35x Optical Zoom / 800x Digital Zoom
:: Memory Card Slot for SDHC/SD
:: Remote Control provided
:: KONICA MINOLTA LENS
:: Gigabrid Engine
:: Dual Memory Continuous Recording
:: One Touch Upload to YouTubeTM
:: One Touch iTunes Export
:: Laser Touch Operation with Sub-Trigger
and Zoom Function
:: Digest Playback
:: 2.7" 16:9 Widescreen Clear LCD Monitor
:: Auto LCD Backlight Control
:: Auto Illumi. Light
:: Data Battery
:: Direct DVD burning with
SHARE STATION (optional)
:: USB2.0 High-Speed Transfer
:: Pixela EverioTM MediaBrowser for
Windows®provided
JVC EverioTM GZ-MS130
Ultra-slim and compact Memory Camcorder
with dual memory (16GB Internal Flash
Memory and an SD/SDHC Card Slot), KONICA
MINOLTA LENS, 35x Optical Zoom, Laser
Touch Operation, and convenient "One Touch"
buttons for easy sharing and viewing.
LAUNCHING MARCH 2009
GZ-MG645 (60GB)
GZ-MG630 (60GB)
GZ-HD300 (60GB)
GZ-MG680 (120GB)
The new JVC EverioTM GZ-MS130
Memory Camcorder
GZ-MS120
GZ-HM200
GZ-MS130

www.jvclatest.co.uk
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
JVC Product Launch: March 2009
Specification
:: Double SD Card slot for SDHC/SD
:: 3 Megapixel CMOS
:: Full HD 1920x1080 Recording
:: 20x Optical Zoom / 200x Digital Zoom
:: 24Mbps High Bit-Rate Recording
:: HD Gigabrid Premium Engine
1920x1080/50P Output
:: Dual Memory Continuous Recording
:: HDMITM (V.1.3 with x.v.ColourTM)
:: KONICA MINOLTA HD LENS
:: One Touch Upload to YouTubeTM
:: One Touch iTunes Export
:: Face Detection
:: Laser Touch Operation with Sub-Trigger
and Zoom Function
:: Digest Playback
:: Focus Assist Function
:: Auto Illumi. Light
:: PC-less Archiving and Viewing with
SHARE STATION (optional)
:: Remote Control provided
:: Pixela EverioTM MediaBrowser for
Windows®provided
JVC EverioTM GZ-HM200
Ultra-compact Full HD 1920x1080 Memory
Camcorder with dual SD/SDHC Card Slot,
featuring 24Mbps High Bit-Rate Recording,
KONICA MINOLTA HD LENS, 1920x1080/50P
Output, and Face Detection.
LAUNCHING MARCH 2009
GZ-MG645 (60GB)
GZ-MG630 (60GB)
GZ-HD300 (60GB)
GZ-MG680 (120GB)
The new JVC EverioTM GZ-HM200
Memory Camcorder
GZ-MS120
GZ-HM200
GZ-MS130

www.jvclatest.co.uk
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
JVC Product Launch: March 2009
Specification
:: WXGA (1366 x 768) Eco Panel
:: HD Ready
:: DynaPix Plus Picture Engine
:: 160GB HDD PVR (Digital TV Recorder)
:: Dynamic Contrast:
30,000:1 (LT-32DE1)
25,000:1 (LT-26DE1)
:: Twin IDTV Tuners with simultaneous
recording for Two Digital programmes
and One Analogue Tuner
:: 8-Day EPG
:: HDMITM Input x 3 (LT-32DE1)
HDMITM Input x 2 (LT-26DE1)
:: Component Input
:: SCART x 2
:: Digital (Optical) Audio Output
:: HDD Functions: 2 DVB-T Recording,
Time Shift Recording, Timer Recording,
Variable Speed Playback, Recorded File
Editing, and Instant Replay
:: Hyper Sound
:: Swivel Stand
JVC LT-32DE1
HD Ready LCD TV with Freeview (DVB-T)
Tuner (x2), 160GB HDD PVR, DynaPix Plus
Picture Engine, and HDMITM Input (x3).
DA2 SERIES
Coming soon
DD1 SERIES
Coming soon
DV1 SERIES
WX SERIES
Coming soon
The new JVC LT-32DE1
HDD PVR LCD TV
Also available in 26"
LAUNCHING MARCH 2009
160GB
160GB
DE1 SERIES
DA1 SERIES
Coming soon
DR1 SERIES

www.jvclatest.co.uk
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
JVC Product Launch: March 2009
Specification
:: Full HD (1920 x 1080) Eco Panel
:: HD Ready 1080p
:: DynaPix HD Picture Engine
:: Dynamic Contrast 25,000:1
:: Freeview (DVB-T) Tuner
:: 8-Day EPG
:: HDMITM (CEC) Input x 3
:: Component Input
:: SCART x 2
:: PC Input
:: USB 2.0 Photo & Media Viewer
(JPEG/MP3)
:: Digital (Optical) Audio Output
:: Real Bit Driver
(12-Bit Signal Generator: x RGB = 36-Bit)
:: 3D Cinema Surround
:: Picture & Text
:: Eco Mode
:: Radio Mode
:: Swivel Stand
:: Multi-Brand Remote
JVC LT-37DR1
Full HD 1080p LCD TV with Freeview (DVB-T)
Tuner, DynaPix HD Picture Engine, Eco Mode,
and HDMITM (CECx3)/PC/USB 2.0 Input.
The new JVC LT-37DR1
Full HD LCD TV
Also now available in 32" and 42"
LAUNCHING MARCH 2009
DA2 SERIES
Coming soon
DD1 SERIES
Coming soon
DV1 SERIES
WX SERIES
Coming soon
DE1 SERIES
DA1 SERIES
Coming soon
DR1 SERIES

www.jvclatest.co.uk
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
JVC Product Launch: March 2009
Specification
:: Full HD (1920 x 1080) Slim Panel
:: HD Ready 1080p
:: DynaPix HD Picture Engine
:: Dynamic Contrast 1,000,000:1
:: Freeview (DVB-T) Tuner
:: 8-Day EPG
:: HDMITM (CEC) Input x 3
:: Component Input
:: SCART x 2
:: PC Input
:: USB 2.0 Photo & Media Viewer
(JPEG/MP3)
:: Digital (Optical) Audio Output
:: Super Slim Airy Design
:: 100Hz Clear Motion Drive II
:: Real Bit Driver
(12-Bit Signal Generator: x RGB = 36-Bit)
:: MaxxAudio®
:: Hand Clap Function
:: Picture & Text
:: Eco Mode
:: Radio Mode
:: Zero Watt Power Switch
:: Touch Sensor Panel Operation
:: Swivel Stand
:: Multi-Brand Remote
JVC LT-42DV1
Full HD 1080p Slim LCD TV with Freeview
(DVB-T) Tuner, DynaPix HD Picture Engine,
100Hz Clear Motion Drive II, MaxxAudio®,
Hand Clap Function, Eco Mode, and HDMITM
(CECx3)/PC/USB 2.0 Input.
The new JVC LT-42DV1
Full HD Slim LCD TV
LAUNCHING MARCH 2009
DA2 SERIES
Coming soon
DD1 SERIES
Coming soon
DV1 SERIES
WX SERIES
Coming soon
DE1 SERIES
DA1 SERIES
Coming soon
DR1 SERIES
USB2.0
Also now available in 37"
47" coming soon

Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
www.jvclatest.co.uk
JVC Product Launch: March 2009
JVC NX-F30
DVD Front Surround System featuring
HDMITM Output, Touch Panel Operation
and USB Music Recording.
The new JVC NX-F30
DVD Compact Component System
Specification
:: Plays DVD, MP3/WMA/WAV/JPEG and
MPEG-4 (ASF)/-2/-1/DivX®
:: 400W Total Power
:: HDMITM with 1080p Up-Conversion
and HDMI-CEC
:: HDMITM Output
:: Touch Panel Operation
:: USB Music (CD) Recording
:: Dolby Digital/DTS
:: Radio Data System FM Tuner
:: Front Surround System
:: Advanced Anisotropic Speaker Diaphragm
with Kraft Pulp Aramid Fibre Cone
:: Wall-Mountable Speakers with Stands
:: 16cm Subwoofer
LAUNCHING MARCH 2009
Key Technology
Advanced Anisotropic Speaker Diaphragm
JVC’s advanced speakers effectively create
a realistic three-dimensional sound field,
making you feel enveloped in sound.
Anisotropy Creates
3D Sound Field
High Sound Speed/
Sound Spreads Out
TH-BD50
Coming soon
TH-G31
Coming soon
TH-BD30
Coming soon
TH-G61
Coming soon
NX-F40
NX-F30
NX-T10
Coming soon
XV-BP1B
Coming soon

Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
www.jvclatest.co.uk
JVC Product Launch: March 2009
TH-BD50
Coming soon
JVC NX-F40
DVD Front Surround System featuring
HDMITM Output, Touch Panel Operation
and USB Music Recording.
Key Technology
The new JVC NX-F40
DVD Compact Component System
Advanced Anisotropic Speaker Diaphragm
JVC’s advanced speakers effectively create
a realistic three-dimensional sound field,
making you feel enveloped in sound.
LAUNCHING MARCH 2009
Specification
:: Plays DVD, MP3/WMA/WAV/JPEG and
MPEG-4 (ASF)/-2/-1/DivX®
:: 400W Total Power
:: HDMITM with 1080p Up-Conversion
and HDMI-CEC
:: HDMITM Output
:: Touch Panel Operation
:: USB Music (CD) Recording
:: Dolby Digital/DTS
:: Radio Data System FM Tuner
:: Front Surround System
:: Advanced Anisotropic Speaker Diaphragm
with Kraft Pulp Aramid Fibre Cone
:: Wall-Mountable Speakers with Stands
:: 16cm Subwoofer
Anisotropy Creates
3D Sound Field
High Sound Speed/
Sound Spreads Out
TH-G31
Coming soon
TH-BD30
Coming soon
TH-G61
Coming soon
NX-F40
NX-F30
NX-T10
Coming soon
XV-BP1B
Coming soon

www.jvclatest.co.uk
JVC Product Launch: March 2009
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
LAUNCHING MARCH 2009
UX-GN6
Coming soon
UX-GN7
Coming soon
NX-D4
Coming soon
The new JVC UX-G355
CD Micro Component System
JVC UX-G355
CD Micro Component System featuring
USB Music Recording, Front Audio Input
and MP3/WMA Playback.
Specification
:: Plays MP3/WMA with Tags
:: 60W Total Power
:: FM Tuner with Radio Data System
:: 2-Way Speakers
:: Clock/3-Preset Timer
:: USB Music (CD) Recording
:: Front Audio Input
:: Sound Turbo
Key Technology
USB Music (CD) Recording
USB Music Recording lets you make direct
recordings onto a USB device during CD
playback, without having to use your PC.
Take favourite songs from your CDs and
record onto DAP, USB memory or SD Card
(via SD Adaptor).
REC
UX-L5V
UX-LP5
UX-G355

www.jvclatest.co.uk
JVC Product Launch: March 2009
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
LAUNCHING MARCH 2009
The new JVC UX-LP5
CD Micro Component System
JVC UX-LP5
Slant-style CD Micro Component System
featuring "Flip Dock" for iPod, USB Host
and MP3/WMA Playback.
Specification
:: Slant-Style Design
:: iPod "Flip Dock" with iPod Video Out
:: Plays MP3/WMA with Tags
:: FM Tuner with Radio Data System
:: 60W Total Power
:: 2-Way Speakers
:: Clock/3-Preset Timer
:: USB Host
:: Front Audio Input
:: Sound Turbo
Key Technology
Flip down the front cover and a dock for
your iPod appears with cool blue
illumination. You can easily operate the
remote control’s “iPod Zone” as if you
were using the iPod’s click wheel.
UX-GN6
Coming soon
UX-GN7
Coming soon
NX-D4
Coming soon
UX-L5V
UX-LP5
UX-G355

www.jvclatest.co.uk
JVC Product Launch: March 2009
Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
LAUNCHING MARCH 2009
The new JVC UX-L5V
DVD Micro Component System
JVC UX-L5V
Slant-style DVD Micro Component System
Featuring USB Music Recording.
Specification
:: Slant-Style Design
:: Plays DVD, MP3/WMA/JPEG,
MPEG-2 and DivX®
:: USB Music (CD) Recording
:: FM Tuner with Radio Data System
:: 60W Total Power
:: 2-Way Speakers
:: Clock/3-Preset Timer
:: Front Audio Input
:: Dolby Digital Decoder (2ch)
:: Clear Voice Function
:: Sound Turbo II
Key Technology
USB Music (CD) Recording
USB Music Recording lets you make direct
recordings onto a USB device during CD
playback, without having to use your PC.
Take favourite songs from your CDs and
record onto DAP, USB memory or SD Card
(via SD Adaptor).
REC
UX-GN6
Coming soon
UX-GN7
Coming soon
NX-D4
Coming soon
UX-L5V
UX-LP5
UX-G355

Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
www.jvclatest.co.uk
JVC Product Launch: March 2009
JVC HA-F240
Secure and comfortable-fitting in-ear
headphones with Air Cushion. A new,
9-colour line-up completely matches the
4th Generation iPod nano & shuffle.
Specification
:: Powerful 11mm Neodymium Driver Unit
:: Secure Fit with Uniquely-Designed
Air Cushion
:: Wide colour selection with nine body and
cord colour variations
:: Colour coordination with iPod nano and
shuffle 4G
:: 1.0m Friction Noise Reduction Colour
Cord with Gold-Plated iPhone-Compatible
Slim Plug
LAUNCHING MARCH 2009
Key Feature
Air Cushion
JVC’s innovative Gumy Air phones are
designed with a soft silicon rubber air
cushion, delivering the most comfortable
and secure fitting.
HA-SA150
Coming soon
HA-FX66
HA-F140
The new JVC Gumy Air HA-F240
In-Ear Headphones
HA-F240
HA-FX34

Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
www.jvclatest.co.uk
JVC Product Launch: March 2009
JVC HA-FX34
Colourful and soft Marshmallow Phones. A
new, 9-colour line-up completely matches
the 4th Generation iPod nano & shuffle.
Specification
:: Softer earpieces including two sizes of
just-fit soft earpieces
:: Wide colour selection with nine body
and cord colour variations
:: Colour coordination with iPod nano
and shuffle 4G
:: Gold-Plated iPhone-Compatible Slim Plug
:: 1.0m Friction Noise Reduction Cord
LAUNCHING MARCH 2009
Key Feature
Softer fit. Sweeter sound.
JVC’s Marshmallow phones, with supersoft
ear buds, offer an incredibly snug fit.
Sound has never been sweeter!
HA-F140
The new JVC Marshmallow HA-FX34
High Quality In-Ear Canal Headphones
HA-SA150
Coming soon
HA-FX66
HA-F240
HA-FX34

Contact your local
Area Sales Manager now
or call JVC on 0208 208 7676
www.jvclatest.co.uk
JVC Product Launch: March 2009
JVC HA-FX66
Colourful in-ear canal Headphones with
secure fit.
Specification
:: Powerful 8.5mm Neodymium Driver Unit
:: Secure fit design with "Air Cushion"
:: Excellent isolation from background noise
with in-ear canal design
:: Comfortable fit with Soft Silicon Rubber
Ear Pieces (3 Pairs) and Memory Foam Ear
Pieces (1 Pair)
:: 1.0m Friction Noise Reduction Cord
:: Wide colour choices from 4 variations
:: Compact Carrying Case provided
LAUNCHING MARCH 2009
Key Feature
Air Cushion - Ideal for Sports
JVC’s high-quality in-ear phones are perfect
for when you’re on the go. These Air
Cushion buds provide a superb, secure fit,
whilst the in-ear design ensures excellent
isolation from background noise.
The new JVC Air Cushion HA-FX66
High Quality In-Ear Canal
Headphones
HA-SA150
Coming soon
HA-FX66
HA-F140
HA-F240
HA-FX34
