JVC GR-DF460 User manual

ENGLISH
GR-DF560
GR-DF460
GR-DF430
LYT1421-001B EN
TERMS
Dear Customer,
Thank you for purchasing this digital
video camera. Before use, please
read the safety information and
precautions contained in the pages
3 – 4 and 10 to ensure safe use of
this product.
Please visit our Homepage on the World Wide Web for
Digital Video Camera:
For Accessories:
http://www.jvc.co.jp/english/cyber/
http://www.jvc.co.jp/english/accessory/
INSTRUCTIONS
DIGITAL VIDEO CAMERA
The camcorder illustrations appearing in this instruction manual are
of the GR-DF560.
The D.S.C (Digital Still Camera) features are available on
GR-DF560 and GR-DF460.
GETTING STARTED 6
VIDEO RECORDING &
PLAYBACK 19
28
ADVANCED FEATURES 37
REFERENCES 57
To deactivate the demonstration,
set “DEMO MODE” to “OFF”.
(墌pg. 37, 40)
66
DIGITAL STILL CAMERA
(D.S.C.) RECORDING &
PLAYBACK (GR-DF560/460
only)
GR-DF560_460PAL_01Cover.fm Page 1 Tuesday, March 8, 2005 11:25 AM

2 EN
MasterPage: Left
Wipe/Fader Effects
You can use the Wipe/Fader Effects to make
pro-style scene transitions. (墌pg. 48)
Program AE with Special Effects
For example, “SPORTS” mode allows fast-
moving images to be captured one frame at a
time, for vivid, stable slow-motion. (墌pg. 48)
Biphonic Recording/Playback*
Put on the Mic for Biphonic (connected to the
camcorder) to your ears like in-the-ear type
headphones during shooting, and activate
Biphonic feature during playback. No special
audio systems are not required and any
conventional TV, VCR, or stereo system is
enough to reproduce real three-dimensional
acoustic fields utilizing Biphonic Recording
and Playback features. (墌pg. 24, 51)
Backlight Compensation
Simply pressing the BACK LIGHT button
brightens the image darkened by backlight.
(墌pg. 46)
●You can also select a spot metering area so
that more precise exposure compensation
is available. (墌pg. 46, Spot Exposure
Control)
Navigation Function*
The Navigation Function helps you check
tape contents by making thumbnail images
on a memory card. (墌pg. 49)
E-Mail Clip Recording*
You can record video clips on the memory
card as files which can be sent via e-mail.
(墌pg. 32)
* GR-DF560/460 only
Major Features of this Camcorder
Fade in
Fade out
ONITNAV I GA
1 2 3
4 5
TC : 13 : 23 : 15
.54DATE : 2 ’04 3:29
GR-DF560_460PAL.book Page 2 Wednesday, January 19, 2005 6:06 PM

EN 3
MasterPage: Start_Right
SAFETY PRECAUTIONS
IMPORTANT (for owners in the U.K.)
Connection to the mains supply in the United
Kingdom.
DO NOT cut off the mains plug from this
equipment.
If the plug fitted is not suitable for the power
points in your home or the cable is too short to
reach a power point, then obtain an appropriate
safety approved extension lead or consult your
dealer.
BE SURE to replace the fuse only with an
identical approved type, as originally fitted,
and to replace the fuse cover.
If nonetheless the mains plug is cut off be sure to
remove the fuse and dispose of the plug
immediately, to avoid possible shock hazard by
inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains
plug then follow the instructions given below:
DO NOT make any connection to the Larger
Terminal coded E or Green.
The wires in the mains lead are coloured in
accordance with the following code:
If these colours do not correspond with the
terminal identifications of your plug, connect as
follows:
Blue wire to terminal coded N (Neutral) or
coloured black.
Brown wire to terminal coded L (Live) or coloured
Red.
If in doubt — consult a competent electrician.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
CAUTIONS:
●To prevent shock, do not open the cabinet. No
user serviceable parts inside. Refer servicing to
qualified personnel.
●When you are not using the AC Adapter for a
long period of time, it is recommended that you
disconnect the power cord from AC outlet.
Blue to N (Neutral)
or Black
Brown to L (Live)
or Red
CAUTION:
To avoid electric
shock or damage to
the unit, first firmly
insert the small end
of the power cord into
the AC Adapter until it
is no longer wobbly,
and then plug the
larger end of the
power cord into an
AC outlet.
CAUTIONS:
●This camcorder is designed to be used with
PAL-type colour television signals. It cannot be
used for playback with a television of a different
standard. However, live recording and LCD
monitor/viewfinder playback are possible
anywhere.
●This product includes patented and other
proprietary technology and will operate only
with JVC Data Battery. Use the JVC
BN-VF707U/VF714U/VF733U battery packs
and, to recharge them or to supply power to the
camcorder from an AC outlet, use the provided
multi-voltage AC Adapter. (An appropriate
conversion adapter may be necessary to
accommodate different designs of AC outlets in
different countries.)
Caution on Replaceable lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Replace battery with Panasonic (Matsushita
Electric), Sanyo, Sony or Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
●Dispose of used battery promptly.
●Keep away from children.
●Do not disassemble and do not dispose of in
fire.
NOTES:
●The rating plate (serial number plate) and
safety caution are on the bottom and/or the
back of the main unit.
●The rating information and safety caution of the
AC Adapter are on its upper and lower sides.
GR-DF560_460PAL.book Page 3 Wednesday, January 19, 2005 6:06 PM

4 EN
MasterPage: Left
SOME DO’S AND DON’TS ON THE SAFE USE
OF EQUIPMENT
This equipment has been designed and
manufactured to meet international safety
standards but, like any electrical equipment,
care must be taken if you are to obtain the
best results and safety is to be assured.
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections (including
the mains plug, extension leads and
interconnections between pieces of equipment) are
properly made and in accordance with the
manufacturer’s instructions. Switch off and withdraw
the mains plug when making or changing
connections.
DO consult your dealer if you are ever in doubt
about the installation, operation or safety of your
equipment.
DO be careful with glass panels or doors on
equipment.
DON’T continue to operate the equipment if you are
in any doubt about it working normally, or if it is
damaged in any way — switch off, withdraw the
mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose
dangerous voltages.
DON’T leave equipment switched on when it is
unattended unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off using the switch on the equipment
and make sure that your family knows how to do
this. Special arrangements may need to be made
for infirm or handicapped people.
DON’T use equipment such as personal stereos or
radios so that you are distracted from the
requirements of road safety. It is illegal to watch
television whilst driving.
DON’T listen to headphones at high volume, as
such use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for
example with curtains or soft furnishings.
Overheating will cause damage and shorten the life
of the equipment.
DON’T use makeshift stands and NEVER fix legs
with wood screws — to ensure complete safety
always fit the manufacturer’s approved stand or legs
with the fixings provided according to the
instructions.
DON’T allow electrical equipment to be exposed to
rain or moisture.
ABOVE ALL
●NEVER let anyone especially children push
anything into holes, slots or any other opening in
the case — this could result in a fatal electrical
shock;
●NEVER guess or take chances with electrical
equipment of any kind — it is better to be safe
than sorry!
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on
all sides to allow for ventilation (10 cm or more on
both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a
newspaper, or cloth etc. the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental
problems must be considered and the local rules
or laws governing the disposal of these batteries
must be followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroom or
places with water.
Also do not place any containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lens or the viewfinder directly into
the sun. This can cause eye injuries, as well as
lead to the malfunctioning of internal circuitry.
There is also a risk of fire or electric shock.
CAUTION!
The following notes concern possible physical
damage to the camcorder and to the user.
When carrying, be sure to always securely attach
and use the provided strap. Carrying or holding
the camcorder by the viewfinder and/or the LCD
monitor can result in dropping the unit, or in a
malfunction.
Take care not to get your finger caught in the
cassette holder cover. Do not let children operate
the camcorder, as they are particularly
susceptible to this type of injury.
Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious
damage to the camcorder.
CAUTION!
Connecting cables (Audio/Video, S-Video, etc.) to
the camcorder and leaving it on top of the TV is
not recommended, as tripping on the cables will
cause the camcorder to fall, resulting in damage.
GR-DF560_460PAL.book Page 4 Wednesday, January 19, 2005 6:06 PM

MasterPage: TOC_Heading0_Right
EN 5
CONTENTS
GETTING STARTED 6
Index................................................................. 6
Provided Accessories ..................................... 11
Power.............................................................. 13
Operation Mode.............................................. 15
Language Settings.......................................... 16
Date/Time Settings ......................................... 16
Grip Adjustment.............................................. 16
Viewfinder Adjustment.................................... 16
Brightness Adjustment Of The Display........... 17
Tripod Mounting.............................................. 17
Loading/Unloading A Cassette ....................... 17
Loading/Unloading A Memory Card (GR-DF560/
460 only)..................................................... 18
VIDEO RECORDING & PLAYBACK 19
VIDEO RECORDING ........................................... 19
Basic Recording.............................................. 19
Tape Remaining Time ................................ 19
LCD Monitor And Viewfinder ...................... 19
Zooming...................................................... 20
Journalistic Shooting .................................. 20
Self Recording ............................................ 20
Time Code .................................................. 21
Quick Review.............................................. 21
Recording From The Middle Of A Tape...... 21
VIDEO PLAYBACK ............................................. 22
Normal Playback............................................. 22
Still Playback .............................................. 22
Shuttle Search ............................................ 22
Blank Search .............................................. 22
Connections To A TV Or VCR........................ 23
Biphonic Playback (GR-DF560/460 only)....... 24
Playback Using The Remote Control.............. 25
DIGITAL STILL CAMERA (D.S.C.) RECORDING
& PLAYBACK (GR-DF560/460 only) 28
D.S.C. RECORDING (GR-DF560/460 only) ......... 28
Basic Shooting (D.S.C. Snapshot).................. 28
Interval Shooting......................................... 29
D.S.C. PLAYBACK (GR-DF560/460 only)............ 30
Normal Playback Of Images........................... 30
Auto Playback Of Images ............................... 30
Playback Of Video Clips ................................. 30
Index Playback Of Files.................................. 31
Viewing File Information ................................. 31
Removing On-Screen Display ........................ 31
ADDITIONAL FEATURES FOR D.S.C. (GR-DF560/460
only) ................................................................ 32
E-Mail Clip Recording ..................................... 32
Dubbing Still Images Recorded On A Tape To A
Memory Card.............................................. 33
Resetting The File Name................................ 33
Protecting Files ............................................... 33
Deleting Files.................................................. 34
Setting Print Information (DPOF Setting)........ 35
Initialising A Memory Card.............................. 36
ADVANCED FEATURES 37
MENUS FOR DETAILED ADJUSTMENT.................. 37
Changing The Menu Settings ......................... 37
Recording Menus............................................ 38
Playback Menus ............................................. 41
FEATURES FOR RECORDING............................... 43
LED Light (GR-DF560/460 only)..................... 43
Live Slow (GR-DF560/460 only)..................... 43
5-Second Recording....................................... 43
Night-Scope.................................................... 44
Snapshot (For Video Recording) .................... 44
Manual Focus ................................................. 45
Exposure Control ............................................ 45
Iris Lock .......................................................... 46
Backlight Compensation ................................. 46
Spot Exposure Control.................................... 46
White Balance Adjustment.............................. 47
Manual White Balance Adjustment................. 47
Wipe Or Fader Effects .................................... 48
Program AE With Special Effects ................... 48
Navigation Function (GR-DF560/460 only)..... 49
Biphonic Recording (GR-DF560/460 only) ..... 51
EDITING............................................................ 52
Dubbing To Or From A VCR........................... 52
Dubbing To Or From A Video Unit Equipped With
A DV Connector (Digital Dubbing).............. 53
Connection To A Personal Computer............. 54
Audio Dubbing ................................................ 55
Insert Editing................................................... 56
REFERENCES 57
TROUBLESHOOTING.......................................... 57
USER MAINTENANCE......................................... 61
CAUTIONS ........................................................ 62
SPECIFICATIONS................................................ 65
TERMS 66
GR-DF560_460PAL_03Toc.fm Page 5 Thursday, January 20, 2005 9:36 AM

6 EN
MasterPage: Left
GETTING STARTED
Index
L
KS
X
W
V
U
PQR
aZ
lkY
b
c
d
e
hig
fOT
onm
MN
j
1C
9
J
G
D
E
F
B
8
GR-DF560_460PAL.book Page 6 Wednesday, January 19, 2005 6:06 PM

EN 7
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
AMenu Button [MENU] (墌pg. 37)
Data Battery Button [BATT. DATA] (墌pg. 14)
BE-Mail Clip Recording Button [E-MAIL]*
(墌pg. 32)
Index Button [INDEX]*
(墌pg. 31)
CD.S.C. Playback Select Button [SEL]*
(墌pg. 30)
Thumbnail Storing Button [STORE]*
(墌pg. 49)
DBiphonic Button [BIPHONIC]*
(墌pg. 24)
Information Button [INFO]*
(墌pg. 31)
ESet Button [SET] (墌pg. 37)
FFast-Forward Button [ 5 ] (墌pg. 22)
LED Light Button [LIGHT]*
(墌pg. 43)
Right Button [>] (墌pg. 37)
GStop Button [8] (墌pg. 22)
Backlight Compensation Button [BACK
LIGHT] (墌pg. 46)
Down Button [ ] (墌pg. 37)
HRewind Button [ 3 ] (墌pg. 22)
Quick Review Button [Q.REVIEW] (墌pg. 21)
Left Button [<] (墌pg. 37)
IVIDEO/MEMORY Switch*
(墌pg. 15)
JPlay/Pause Button [4/9] (墌pg. 22)
Manual Focus Button [FOCUS] (墌pg. 45)
Up Button [ ] (墌pg. 37)
KDioptre Adjustment Control (墌pg. 16)
LBattery Release Button [BATT. RELEASE]
(墌pg. 14)
MSnapshot Button [SNAPSHOT]
(墌pg. 28, 44)
Live Slow Button [SLOW]*
(墌pg. 37, 43)
NPower Zoom Lever [T/W] (墌pg. 20)
Speaker Volume Control [VOL. +, –]
(墌pg. 22)
OCassette Open/Eject Switch [OPEN/EJECT]
(墌pg. 17)
PRecording Start/Stop Button (墌pg. 19)
QPower Switch [A, M, PLAY, OFF] (墌pg. 15)
RLock Button (墌pg. 15)
Connectors
The connectors are located beneath the covers.
SS-Video Input**/Output Connector [S]
(墌pg. 23, 52)
TMicrophone connector [MIC] (墌pg. 38, 55)
UUSB (Universal Serial Bus) Connector*
(墌pg. 54)
VDigital Video (i.Link) Connector [DV IN**/OUT]
(墌pg. 53, 54)
i.Link: i.Link refers to the IEEE1394-1995
industry specification and extensions
thereof. The logo is used for products
compliant with the i.Link standard.
WAudio/Video Input**/Output Connector [AV]
(墌pg. 23, 52)
XDC Input Connector [DC] (墌pg. 13)
Indicators
YPOWER/CHARGE Lamp (墌pg. 13, 19)
Other Parts
ZLCD Monitor (墌pg. 19, 20)
aShoe
(Before you purchase optional shoe
accessories, make sure the items are
compatible and can attach to the shoe on
your camcorder. There may be cases where a
part of an accessory item obtrudes onto the
camcorder’s body, preventing attachment to
your unit.)
bViewfinder (墌pg. 16)
cSpeaker (墌pg. 22)
dBattery Pack Mount (墌pg. 14)
eCassette Holder Cover (墌pg. 17)
fLens
gLED Light*
(墌pg. 43)
(When using an optional conversion lens, it
may cover this area and block the light.)
hRemote Sensor (墌pg. 25)
iCamera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
jStereo Microphone (墌pg. 55)
kShoulder Strap Eyelet (墌pg. 12)
lGrip Strap (墌pg. 16)
mCard Cover [MEMORY CARD]*
(墌pg. 18)
nTripod Mounting Socket (墌pg. 17)
oStud Hole (墌pg. 17)
* GR-DF560/460 only
** GR-DF430 only
GR-DF560_460PAL_04Start.fm Page 7 Monday, March 7, 2005 8:09 PM

GETTING STARTED
8 EN
MasterPage: Left
LCD Monitor/Viewfinder Indications
During Video Recording Only
aNavigation Indicator*
(墌pg. 49)
BSelected Wipe/Fader Effect Indicator
(墌pg. 48)
CTape Running Indicator (墌pg. 19)
(Rotates while tape is running.)
DSelected Wide Mode Indicator (墌pg. 39)
E: Live Slow Indicator*
(墌pg. 43)
: Snapshot Indicator*
(墌pg. 44)
FRecording Speed Mode (SP/LP) (墌pg. 38)
GTape Remaining Time (墌pg. 19)
HREC: (Appears during recording.) (墌pg. 19)
PAUSE: (Appears during Record-Standby
mode.) (墌pg. 19)
IInsert Editing/Insert Editing Pause Mode
(墌pg. 56)
J5S/Anim.: Displays the 5-Second Recording
mode or Animation recording mode.
(墌pg. 39)
KWind Cut Indicator (墌pg. 39)
LTime Code (墌pg. 40, 42)
MDigital Image Stabiliser (“DIS”) (墌pg. 39)
NSOUND 12BIT/16BIT: Sound Mode Indicator
(墌pg. 38) (Appears for approx. 5 seconds
after turning on the camcorder.)
: Auxiliary Microphone Level
Indicator
(Appears when an optional microphone is
connected. 墌pg. 40, “AUDIO LEV.”)
O: Biphonic Recording Mode Indicator*
(墌pg. 51)
* GR-DF560/460 only
During D.S.C. Recording Only (GR-DF560/
460 only)
aImage Size: 1600 (1600 x 1200)*, 1152
(1152 x 864)*, 1024 (1024 x 768) or 640
(640x480)(墌pg. 41)
* GR-DF560 only
B: Interval Shooting Icon (墌pg. 28)
: Focus Icon (墌pg. 28)
CShooting Icon
(Appears and blinks during shooting.)
DCard Icon
: Appears during shooting.
: Blinks in white when a memory card is
not loaded.
: Blinks in yellow while the camcorder is
reading the data in the memory card such as
Navigation thumbnail images, video clips, still
images, etc.
EPicture Quality: (FINE) and
(STANDARD) (in order of quality) (墌pg. 41)
FRemaining Number Of Shots (墌pg. 28)
(Displays the approximate remaining number
of shots that can be stored during D.S.C.
recording.)
GClock Icon (墌pg. 28)
During E-Mail Clip Recording (GR-DF560/
460 only)
aImage Size: 160 (160 x 120)
bShooting Icon (墌pg. 28, 32)
cE-Mail Clip Recording Indicator (墌pg. 32)
dMemory Card Remaining Time For E-Mail
Clip Recording (墌pg. 32)
eE-Mail Clip Recording Time (墌pg. 32)
SOUND 12 BIT
1h40m
e
w
2
13467
8
9
0
q
5
r
t
15:55
REC
L
R
51
1024
INTERVAL
634 5
7
PILC - E
00 : 15
160
0 hm
:10
GR-DF560_460PAL_04Start.fm Page 8 Thursday, March 10, 2005 12:01 PM

EN 9
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
During Both Video And D.S.C.*Recording
aOperation Mode (墌pg. 15)
B: Gain Up Mode (墌pg. 38)
CLED Light Indicator*
(墌pg. 43)
DWhite Balance Indicator (墌pg. 47)
E: Spot Exposure Control Indicator
(墌pg. 46)
: Backlight Compensation Indicator
(墌pg. 46)
±: Exposure Adjustment Indicator (墌pg. 45)
FSelected Program AE With Special Effects
Indicator (墌pg. 48)
: Night-Scope Indicator (墌pg. 44)
GIris Lock Indicator (墌pg. 46)
HApproximate Zoom Ratio (墌pg. 20)
IZoom Indicator (墌pg. 20)
JO: (Appears when taking Snapshot.)
(墌pg. 29, 44)
SLOW : (Appears when using Live Slow.)*
(墌pg. 43)
KBrightness Control Indicator (LCD monitor/
Viewfinder) (墌pg. 17)
LBattery Remaining Power Indicator
(墌pg. 59)
MDate/Time (墌pg. 16)
NManual Focus Adjustment Indicator
(墌pg. 45)
During Video Playback
aSound Mode Indicator (墌pg. 41)
BBlank Search Indicator (墌pg. 22)
C: Live Slow Indicator*
(墌pg. 43)
: Snapshot Indicator*
(墌pg. 44)
DTape Speed (墌pg. 38)
E4: Playback
5 : Fast-Forward/Shuttle Search
3 : Rewind/Shuttle Search
9: Pause
9U: Forward Frame-By-Frame Playback/
Slow-Motion
Y9: Reverse Frame-By-Frame Playback/
Slow-Motion
D: Audio Dubbing
9D: Audio Dubbing Pause
(Appear while a tape is running.)
FSound Input For Audio Dubbing (墌pg. 55)
GBattery Remaining Power Indicator
(墌pg. 59)
HDate/Time (墌pg. 40, 42)
IVOLUME: Volume Level Indicator (墌pg. 22)
BRIGHT: Brightness Control Indicator (LCD
monitor/Viewfinder) (墌pg. 17)
JTime Code (墌pg. 40, 42)
K: Auxiliary Microphone Level
Indicator
(Appears when an optional microphone is
connected during Audio Dubbing. 墌pg. 55)
* GR-DF560/460 only
O
5
6
7
1 5
x
W
T
1 0 1
1
1
0
.
:
0
0
5
0
.
50m
BRIGHT
1
2
3
4
89
0
q
w
er
1
L
2
2 0 :
/
2
M
V
1
I
O
:
X
L
2
1 0 1
1
1
0
.
:
0
0
5
0
.
BIT
U
5
M E
MIC
L
R
1243 5
8
9
0
7
6
q
BLANK SEARCH
PUSH "STOP" BUTTON
TO CANCEL
50m
L
R
GR-DF560_460PAL_04Start.fm Page 9 Thursday, March 10, 2005 12:01 PM

GETTING STARTED
10 EN
MasterPage: Left
During D.S.C. Playback (GR-DF560/460
only)
aOperation Mode Indicator (墌pg. 31)
BFolder/File Number (墌pg. 31)
CBattery Remaining Power Indicator
(墌pg. 59)
DBrightness Control Indicator (LCD monitor/
Viewfinder) (墌pg. 17)
Before Using This Camcorder
Make sure you only use cassettes with the Mini
DV mark .
Make sure you only use memory cards*with the
mark or .
This camcorder is designed exclusively for the
digital video cassette, SD Memory Card and
MultiMediaCard. Only cassettes marked “ ” and
memory cards marked “ ” or
“ ” can be used with this unit.
* Memory cards can be used with GR-DF560 and
GR-DF460 only.
Remember that this camcorder is not
compatible with other digital video formats.
Remember that this camcorder is intended for
private consumer use only.
Any commercial use without proper permission is
prohibited. (Even if you record an event such as a
show, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Before recording important video, be sure to
make a trial recording.
Play back your trial recording to make sure the
video and audio have been recorded properly.
We recommend cleaning your video heads
before use.
If you haven’t used your camcorder for a while, the
heads may be dirty. We recommend periodically
cleaning the video heads with a cleaning cassette
(optional).
Be sure to store your cassette tapes and
camcorder in the proper environment.
Video heads can become dirty more easily if your
cassette tapes and camcorder are stored in a dusty
area. Cassette tapes should be removed from the
camcorder and stored in cassette cases. Store the
camcorder in a bag or other container.
Use SP (Standard) mode for important video
recordings.
LP (Long Play) mode lets you record 50% more
video than SP (Standard) mode, but you may
experience mosaic-like noise during playback
depending on the tape characteristics and the
usage environment.
So, for important recordings, we recommend using
SP mode.
It is recommended that you use JVC brand
cassette tapes.
Your camcorder is compatible with all brands of
commercially available cassette tapes complying
with the MiniDV standard, but JVC brand cassette
tapes are designed and optimized to maximize the
performance of your camcorder.
Also read “CAUTIONS” on pages 62 – 64.
●Microsoft®and Windows®are either registered
trademarks or trademarks of Microsoft
Corporation in the United States and/or other
countries.
●Macintosh is a registered trademark of Apple
Computer, Inc.
●QuickTime is a registered trademark of Apple
Computer, Inc.
BR I GHT
1
100-0013
2
3
4
50m
GR-DF560_460PAL.book Page 10 Wednesday, January 19, 2005 6:06 PM

EN 11
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
aAC Adapter AP-V14E
bPower Cord
cBattery Pack BN-VF707U
dAV Cable
eAudio Extension Cable (for optional
microphone, 墌pg. 13 for connection)
fUSB Cable*
gCore Filter [large]*
(for USB cable 墌pg. 13 for attachment)
hCore Filter [small] x 3 (GR-DF560 only)/
x 2 (GR-DF460/430 only)
(for Audio extention cable and AC Adapter’s
cable** 墌pg. 13 for attachment)
iCore Filter
(for AV cable 墌pg. 13 for attachment)
jCD-ROM
kCable Adapter
lRemote Control Unit RM-V720U
mLithium Battery CR2025***
(for remote control unit)
nShoulder Strap (墌pg. 12 for attachment)
oLens Cap (see the right column for
attachment)
pMic for Biphonic*
* GR-DF560/460 only
** GR-DF560 only
***A lithium battery is pre-installed in the Remote
Control Unit at time of shipment (with insulation
sheet). To use the Remote Control Unit, remove
the insulation sheet.
NOTES:
●In order to maintain optimum performance of the
camcorder, provided cables may be equipped with
one or more core filter. If a cable has only one core
filter, the end that is closest to the filter should be
connected to the camcorder.
●Make sure to use the provided cables for
connections. Do not use any other cables.
How To Attach The Lens Cap
To protect the lens, attach
the provided lens cap to the
camcorder as shown in the
illustration.
NOTE:
To confirm the lens cap is on
correctly make sure the cap is
flush to the camcorder.
Provided Accessories
Place here during
shooting.
CONTINUED ON NEXT PAGE
GR-DF560_460PAL_04Start.fm Page 11 Tuesday, March 15, 2005 2:31 PM

GETTING STARTED
12 EN
MasterPage: Left
How To Attach The Shoulder Strap
Follow the illustration.
1Thread the strap through the eyelet.
2Fold it back and thread it through the strap
guide and the buckle.
●To adjust the length of the strap, loosen and then
tighten the strap in the buckle.
3Slide the strap guide fully towards the eyelet.
How To Use The Audio Extension Cable
When using an optional external microphone,
connect to the provided Audio extension cable
(with a core filter attached), then connect the
Audio extension cable to the camcorder. The
core filter reduces interference. (墌pg. 13)
2
13
Strap guide Buckle
Eyelet Audio extension
cable (provided)
Core filter
Open the
cover.
Stereo
microphone
To MIC
GR-DF560_460PAL.book Page 12 Wednesday, January 19, 2005 6:06 PM

EN 13
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
How To Attach The Core Filter
Attach the core filters to the cables. The core
filter reduces interference.
1Release the stoppers on both ends of the
core filter.
2Run the cable through the core filter, leaving
approx. 3 cm of cable between the cable plug
and the core filter.
Wind the cable once around the outside of the
core filter as shown in the illustration.
3Close the core filter until it clicks shut.
NOTES:
●Take care not to damage the cable.
●When connecting a cable, attach the end with the
core filter to the camcorder.
This camcorder’s 2-way power supply system
lets you choose the most appropriate source of
power. Do not use provided power supply units
with other equipment.
Charging The Battery Pack
1Set the Power Switch to “OFF”.
2With the arrow on the battery pack pointing
right, push the battery pack slightly against the
battery pack mount a.
3Slide the battery pack to the right until it locks
in place b.
4Connect the AC Adapter to the camcorder.
5Connect the Power Cord to the AC Adapter.
6Plug the AC Adapter into an AC outlet. The
POWER/CHARGE lamp on the camcorder
blinks to indicate charging has started.
7When the POWER/CHARGE lamp goes out,
charging is finished. Unplug the AC Adapter
from the AC outlet. Disconnect the AC Adapter
from the camcorder.
Stopper
3 cm
Wind once.
Core filter
Power
Arrow
BATT. RELEASE
Battery pack mount
Battery pack
POWER/CHARGE
lamp
Power switch
To AC outlet
mark
To
DC connector
AC Adapter
Open the cover.
Power cord
CONTINUED ON NEXT PAGE
GR-DF560_460PAL.book Page 13 Wednesday, January 19, 2005 6:06 PM

GETTING STARTED
14 EN
MasterPage: Left
To detach the battery pack
Slide the battery pack to the left while pressing
BATT. RELEASE to detach it.
* Provided
NOTES:
●This product includes patented and other
proprietary technology and will operate only
with JVC Data Battery. Use the JVC BN-
VF707U/VF714U/VF733U battery packs. Using
generic non-JVC batteries can cause damage
to the internal charging circuitry.
●If the protective cap is attached to the battery
pack, remove it first.
●During charging, the camcorder cannot be
operated.
●Charging is not possible if the wrong type of
battery is used.
●When charging the battery pack for the first time
or after a long storage period, the POWER/
CHARGE lamp may not light. In this case, remove
the battery pack from the camcorder, then try
charging again.
●If the battery operation time remains extremely
short even after having been fully charged, the
battery is worn out and needs to be replaced.
Please purchase a new one.
●Since the AC Adapter processes electricity
internally, it becomes warm during use. Be sure to
use it only in well-ventilated areas.
●Using the optional AA-VF7 Battery Charger, you
can charge the BN-VF707U/VF714U/VF733U
battery pack without the camcorder.
●After 5 minutes has elapsed in Record-Standby
mode with the cassette inserted, the camcorder
will automatically turn off its power supplied from
the AC adapter. In this case, the battery charge
starts if the battery is attached to the camcorder.
Using The Battery Pack
Perform steps 2– 3in “Charging The Battery
Pack”.
Maximum continuous recording time
* Provided
** GR-DF560 only
NOTES:
●Recording time is reduced significantly under the
following conditions:
•Zoom or Record-Standby mode is engaged
repeatedly.
•The LCD monitor is used repeatedly.
•The playback mode is engaged repeatedly.
•The LED Light is used.
●Before extended use, it is recommended that you
prepare enough battery packs to cover 3 times the
planned shooting time.
A
TTENTION:
Before detaching the power source, make sure that
the camcorder’s power is turned off. Failure to do so
can result in a camcorder malfunction.
Data Battery System
You can check the remaining battery power and
the recordable time.
1) Make sure the battery is attached and the
Power Switch is set to “OFF”.
2) Open the LCD monitor fully.
3) Press BATT. DATA, and the battery status
screen appears.
●It can be displayed on the viewfinder when the
LCD monitor is closed.
●It is displayed for 5 seconds if the button is
pressed and released quickly, and for 15
seconds if the button is pressed and hold for
several seconds.
●If “COMMUNICATION ERROR” appears
instead of the battery status even though you
tried to press BATT. DATA several times, there
may be a problem on the battery. In such a
case, consult your nearest JVC dealer.
Battery pack Charging time
BN-VF707U* Approx. 1 hr. 30 min.
BN-VF714U Approx. 2 hr. 40 min.
BN-VF733U Approx. 5 hr. 40 min.
Battery pack LCD monitor on Viewfinder on
BN-VF707U* 1hr.5min.
(1 hr.**)
1 hr. 25 min.
(1 hr. 15 min.**)
BN-VF714U 2 hr. 20 min.
(2 hr. 5 min.**)
3hr.
(2 hr. 35 min.**)
BN-VF733U 5 hr. 25 min.
(4 hr. 50 min.**)
7hr.5min.
(6 hr. 5 min.**)
GR-DF560_460PAL.book Page 14 Wednesday, January 19, 2005 6:06 PM

EN 15
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Using AC Power
Perform steps 4– 5in “Charging The Battery
Pack”.
NOTE:
The provided AC Adapter features automatic
voltage selection in the AC range from 110 V to
240 V.
About Batteries
DANGER! Do not attempt to take the batteries
apart, or expose them to flame or excessive
heat, as it may cause a fire or explosion.
WARNING! Do not allow the battery or its
terminals to come in contact with metals, as this
can result in a short circuit and possibly start a
fire.
To resume the original function of the
accurate battery power indication
If the battery power indication differs from the
actual operating time, fully charge the battery, and
then run it down. However this function may not
turn back if the battery was used for a long period
of time under extremely high/low temperature
condition or charged too many times.
To turn on the camcorder, set the Power Switch
to any operation mode except “OFF” while
pressing down the Lock Button located on the
switch.
Choose the appropriate operation mode
according to your preference using the Power
Switch and VIDEO/MEMORY Switch.*
* GR-DF560/460 only
Power-Linked Operation
When the Power Switch is set to “A” or “M”, you
can also turn on/off the camcorder by opening/
closing the LCD monitor or pulling out/pushing in
the viewfinder.
INFORMATION:
The following explanations in this manual
supposes the use of LCD monitor in your
operation. If you want to use the viewfinder,
close the LCD monitor and pull out the
viewfinder fully.
Operation Mode
Power Switch Position
A(Full Auto Recording):
Allows you to record using NO special effects
or manual adjustments. Suitable for standard
recording.
The “A” indicator appears on the display.
POWER/
CHARGE lamp
VIDEO/MEMORY*
Power Switch
Lock Button
M(Manual Recording):
Allows you to set various recording functions
using the Menus. (墌pg. 37)
If you want more creative capabilities than Full
Auto Recording, try this mode.
OFF:
Allows you to switch off the camcorder.
PLAY:
●Allows you to play back a recording on the
tape.
●Allows you to display a still image stored in
the memory card or to transfer a still image
stored in the memory card to a PC.
(GR-DF560/460 only)
●Allows you to set various playback functions
using the Menus. (墌pg. 37)
VIDEO/MEMORY Switch Position
(GR-DF560/460 only)
VIDEO:
Allows you to record on a tape or play back a
tape. If “REC SELECT” is set to “ / ”
(墌pg. 41), still images are recorded both on
the tape and the memory card.
MEMORY:
●Allows you to record in a memory card or
access data stored in a memory card.
●When the Power Switch is set to “A” or “M”,
the currently selected image size appears.
GR-DF560_460PAL.book Page 15 Wednesday, January 19, 2005 6:06 PM

GETTING STARTED
16 EN
MasterPage: Left
The language on the display can be changed.
(墌pg. 37, 40, 42)
1Set the Power Switch to “M” while pressing
down the Lock Button located on the switch.
2Open the LCD monitor fully. (墌pg. 19)
3Press MENU. The Menu Screen appears.
4Press or to select
“n”, and press SET. The
CAMERA DISPLAY Menu
appears.
5Press or to select
“LANGUAGE”, and press
SET.
6Press or to select
the desired language, and
press SET.
7Press or to select
“BRETURN”, and press
SET twice. The Menu
Screen closes.
The date/time is recorded onto the tape at all
times, but its display can be turned on or off
during playback. (墌pg. 37, 42)
1Perform steps 1–4in “Language Settings”
above.
2Press or to select “CLOCK ADJ.”, and
press SET. The parameter for “Day” is
highlighted.
3Press or to input
the day, and press SET.
Repeat to input the month,
year, hour and minute.
4Press or to select
“BRETURN”, and press
SET twice. The Menu
Screen closes.
1Adjust the velcro strip.
2Pass your right hand
through the loop and grasp
the grip.
3Adjust your thumb and
fingers through the grip to
easily operate the
Recording Start/Stop
Button, Power Switch and
Power Zoom Lever. Be
sure to fasten the velcro strip to your preference.
1Set the Power Switch to “A” or “M” while
pressing down the Lock Button located on the
switch.
2Make sure the LCD monitor is closed and
locked. Pull out the viewfinder fully and adjust it
manually for best viewability.
3Turn the Dioptre Adjustment Control until the
indications in the viewfinder are clearly focused.
CAUTION:
When retracting the viewfinder, take care not to
pinch your fingers.
Language Settings
Date/Time Settings
ON
D–OLEV.AU
NRETUR
LA
DASERACM I
YP
BRIGHT
LC
–
T/D
AU
MET–/TIDA E OT
OF
DEM–COTI E F
V
–
2
OKCL C
I210.
JAD . 7
1
. 0 5
:30
NCREON S E
LANGUAGE ENGLISH
LA
DASERACM I YP
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
NEDERLANDS
PORTUGUÊS
РУССКИЙ
LANGUAGE –
ex. for GR-DF560/
460
LA
D
ASERACM IY
P
2
OKCL C 210.
JAD . 7
1
. 0 5
:30
Grip Adjustment
Viewfinder Adjustment
PAUSE
Dioptre Adjustment Control
Example:
GR-DF560_460PAL.book Page 16 Wednesday, January 19, 2005 6:06 PM

EN 17
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
1Set the Power Switch
to “M” or “PLAY” while
pressing down the Lock
Button located on the
switch.
2Open the LCD monitor
fully. (墌pg. 19)
●To adjust the brightness of
the viewfinder, pull out the
viewfinder fully and set
“PRIORITY” to “FINDER”
(墌pg. 37, 40).
3Press MENU. The
Menu Screen appears.
4Press or to select “n”, and press SET.
The CAMERA DISPLAY or VIDEO DISPLAY
Menu appears.
5Press or to select “BRIGHT”, and press
SET. The Menu Screen closes and the
brightness control indicator appears.
6Press <or >until the appropriate brightness
is reached.
7Press MENU to clear the brightness control
indicator from the display.
To attach the camcorder
to a tripod, align the
direction stud and screw
to the mounting socket
and stud hole on the
camcorder. Then tighten
the screw clockwise.
●Some tripods are not
equipped with studs.
The camcorder needs to be powered up to load
or eject a cassette.
1Slide and hold OPEN/EJECT in the direction
of the arrow, then pull the cassette holder cover
open until it locks. The cassette holder opens
automatically.
●Do not touch internal components.
2Insert or remove a tape and press “PUSH
HERE” to close the cassette holder.
●Be sure to press only the section labelled “PUSH
HERE” to close the cassette holder; touching
other parts may cause your finger to get caught in
the cassette holder, resulting in injury or product
damage.
●Once the cassette holder is closed, it recedes
automatically. Wait until it recedes completely
before closing the cassette holder cover.
●When the battery pack’s charge is low, you may
not be able to close the cassette holder cover. Do
not apply force. Replace the battery pack with a
fully charged one or use AC power before
continuing.
3Close the cassette holder cover firmly until it
locks into place.
To protect valuable recordings
Slide the erase protection tab on the back of the
tape in the direction of “SAVE”. This prevents the
tape from being recorded over. To record on this
tape, slide the tab back to “REC” before loading
it.
Brightness Adjustment Of The
Display
Tripod Mounting
BRIGHT
MENU
SET
>
<
Loading/Unloading A Cassette
Make sure the window
side is facing out.
Cassette holder cover
Cassette holder
PUSH HERE
OPEN/EJECT
Erase
protection tab
CONTINUED ON NEXT PAGE
GR-DF560_460PAL_04Start.fm Page 17 Monday, March 7, 2005 8:10 PM

GETTING STARTED
18 EN
MasterPage: Left
NOTES:
●If you wait a few seconds and the cassette holder
does not open, close the cassette holder cover
and try again. If the cassette holder still does not
open, turn the camcorder off then on again.
●If the tape does not load properly, open the
cassette holder cover fully and remove the
cassette. A few minutes later, insert it again.
●When the camcorder is suddenly moved from a
cold place to a warm environment, wait a short
time before opening the cassette holder cover.
1Make sure the camcorder’s power is off.
2Open the card cover (MEMORY CARD).
3To load a memory card, firmly insert it with
its clipped edge first.
To unload a memory card, push it once. After
the memory card comes out of the camcorder,
pull it out.
●Do not touch the terminal on the reverse side of
the label.
4Close the card cover.
To protect valuable files (available only for
SD Memory Card)
Slide the write/erase protection tab on the side
of the memory card in the direction of “LOCK”.
This prevents the memory card from being
recorded over. To record on this memory card,
slide the tab back to the position opposite to
“LOCK” before loading it.
NOTES:
●Some brands of memory cards are not compatible
with this camcorder. Before purchasing a memory
card, consult its manufacturer or dealer.
●Before using a new memory card, it is necessary
to format the card. (墌pg. 36)
A
TTENTION:
Do not insert or remove the memory card while the
camcorder is turned on, as this may cause the
memory card to be corrupted or cause the
camcorder to become unable to recognise whether
or not the card is installed.
Loading/Unloading A Memory
Card (GR-DF560/460 only)
Memory card
(optional)
Card Cover
(MEMORY CARD)
Label
Write/erase protection tab
Clipped edge
GR-DF560_460PAL.book Page 18 Wednesday, January 19, 2005 6:06 PM

MasterPage: Video_Heading0_Right
EN 19
VIDEO RECORDING & PLAYBACK
VIDEO RECORDING
NOTE:
Before continuing, perform the procedures listed
below:
●Power (墌pg. 13)
●Loading A Cassette (墌pg. 17)
1Remove the lens cap. (墌pg. 11)
2Open the LCD monitor fully.
3Set the VIDEO/MEMORY Switch to
“VIDEO”.*
4Set the Power Switch to “A” or “M” while
pressing down the Lock Button located on the
switch.
●The POWER/CHARGE lamp lights and the
camcorder enters the Record-Standby mode.
“PAUSE” is displayed.
●To record in LP (Long Play) mode, 墌pg. 38.
5To start recording, press the Recording Start/
Stop Button. “TREC” appears on the display
while recording is in progress.
6To stop recording, press the Recording Start/
Stop Button again. The camcorder re-enters the
Record-Standby mode.
* GR-DF560/460 only
Approximate recording time
NOTES:
●If the Record-Standby mode continues for
5 minutes, the camcorder’s power shuts off
automatically. To turn the camcorder on again,
push back and pull out the viewfinder again or
close and re-open the LCD monitor.
●When a blank portion is left between recorded
scenes on the tape, the time code is interrupted
and errors may occur when editing the tape. To
avoid this, refer to “Recording From The Middle Of
A Tape” (墌pg. 21).
●To turn the beep sounds off, 墌pg. 37, 39.
Tape Remaining Time
Approximate tape remaining
time appears on the display.
“–h––m”meansthe
camcorder is calculating the
remaining time. When the
remaining time reaches 2 minutes, the indication
starts blinking.
●The time required to calculate and display the
remaining tape length, and the accuracy of the
calculation, may vary according to the type of tape
used.
LCD Monitor And Viewfinder
While using the LCD monitor:
Make sure the viewfinder is pushed back in. Pull
on the end of the LCD monitor and open the
LCD monitor fully. It can rotate 270° (90°
downward, 180° upward).
While using the viewfinder:
Make sure the LCD monitor is closed and
locked. Pull out the viewfinder fully.
Basic Recording
Tape Recording mode
SP LP
30 min. 30 min. 45 min.
60 min. 60 min. 90 min.
80 min. 80 min. 120 min.
POWER/CHARGE Lamp
VIDEO/MEMORY*
Recording Start/Stop Button
Power Switch
Lock Button
Power Zoom Lever
180˚
90˚
VIDEO RECORDING & PLAYBACK
CONTINUED ON NEXT PAGE
GR-DF560_460PAL.book Page 19 Wednesday, January 19, 2005 6:06 PM

VIDEO RECORDING
20 EN
MasterPage: Left
NOTES:
●The image will not appear simultaneously on the
LCD monitor and the viewfinder. When the
viewfinder is pulled out while the LCD monitor is
opened, you can select which one to use. Set
“PRIORITY” to the desired mode in SYSTEM
Menu. (墌pg. 37, 40)
●Coloured bright spots may appear all over the
LCD monitor or the viewfinder. However, this is not
a malfunction. (墌pg. 58)
Zooming
Produces the zoom in/out effect, or an
instantaneous change in image magnification.
Zoom In
Slide the Power Zoom Lever towards “T”.
Zoom Out
Slide the Power Zoom Lever towards “W”.
●The further you slide the Power Zoom Lever, the
quicker the zoom action.
NOTES:
●Focusing may become unstable during Zooming.
In this case, set the zoom while in Record-
Standby, lock the focus by using the manual focus
(墌pg. 45), then zoom in or out in Record mode.
●Zooming is possible to a maximum of 700X, or it
can be switched to 15X magnification using the
optical zoom. (墌pg. 38)
●Zoom magnification of over 15X is done through
Digital image processing, and is therefore called
Digital Zoom.
●During Digital zoom, the quality of image may
suffer.
●Digital zoom cannot be used when the VIDEO/
MEMORY Switch is set to “MEMORY”.
(GR-DF560/460 only)
●
Macro shooting (as close as approx. 5 cm to the
subject) is possible when the Power Zoom Lever is
set all the way to “W”. Also see “TELE MACRO” in
MANUAL Menu on page 39.
●When shooting a subject close to the lens, zoom
out first. If zoomed-in in the auto focus mode, the
camcorder may automatically zoom out
depending on the distance between the
camcorder and the subject. This will not occur
when “TELE MACRO” is set to “ON”. (墌pg. 39)
Journalistic Shooting
In some situations,
different shooting
angles may provide
more dramatic results.
Hold the camcorder in
the desired position
and tilt the LCD
monitor in the most
convenient direction. It
can rotate 270° (90°
downward, 180°
upward).
Self Recording
Open the LCD
monitor and tilt it
upward to 180° so
that it faces forward,
point the lens toward
yourself and start
recording.
10 x W T
1 x W T
10 x W T
20 x W T
40 x W T
Digital zoom zone
Zoom in (T: Telephoto)
Zoom out (W: Wide angle)
15X (optical) zoom zone
Approximate zoom ratio
Self
Recording
GR-DF560_460PAL.book Page 20 Wednesday, January 19, 2005 6:06 PM
