JVC GY-HM250UG User manual

.
4K MEMORY CARD CAMERA RECORDER
GY-HM250U/GY-HM250E
GY-HM180U/GY-HM180E
GY-HM170U/GY-HM170E
INSTRUCTIONS
.
The illustration here shows how the handle unit is attached using the unit supplied.
The specifications and appearance of this product are subject to changes for further improvement
without prior notice.
Please check the latest version of the INSTRUCTIONS from the following Mobile User Guide. You can
also download the PDF from the Mobile User Guide.
Mobile User Guide
When you are outside, you can refer to the instructions from your Android phone or iPhone.
http://manual3.jvckenwood.com/pro/mobile/global/
You can view the Mobile User Guide using the browser on your Android phone or iPhone.
GY-HM250U(G)/GY-HM250E(G)
GY-HM180U(G)/GY-HM180E(G)
GY-HM170U(G)/GY-HM170E(G)
Thank you for purchasing this product.
Before operating this unit, please read the
instructions carefully to ensure the best
possible performance.
In this manual, each model number is
described without the last letter (U/E) which
means the shipping destination.
(U: for USA and Canada, E: for Europe)
Only “U” models (GY-HM250U/GY-HM180U/
GY-HM170U) have been evaluated by UL.
Please read the following before getting started:
For Customer Use:
Model No.
Serial No.
Enter below the Serial No. which is located
on the body.
Retain this information for future reference.
GY-HM250U/GY-HM180U/GY-HM170U
IM 1.05 B5A-3921-00

2

.
1. Read these instructions.
2. Keep these instructions.
IMPORTANT SAFEGUARDS
4.
5.
6.
7.
8.
These are general IMPORTANT SAFEGUARDS and certain items may not
apply to all appliances.
3.
FOR USA
9.
10.
11.
12.
13.
For USA-California Only
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate
Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
CAN ICES-3 A / NMB-3 A
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
IMPORTANT SAFEGUARDS 3
Introduction

Safety Precautions
.
CAUTION
FOR USA AND CANADA
CAUTION:
TO REDUCE THE RISK OF
ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR
BACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The lightning flash with
arrowhead symbol, within
an equilateral triangle is
intended to alert the user to
the presence of uninsulated
“dangerous voltage” within
the product’s enclosure that
may be of sufficient
magnitude to constitute a
risk of electric shock to
persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompanying
the appliance.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
.
This device complies with Part 15 of
FCC Rules. Operation is subject to the
following two conditions: (1) This
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Changes or modifications not
approved by JVC could void the
user’s authority to operate the
equipment. This equipment has been
tested and found to comply with the
limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is
operated in a commercial
environment.
This equipment generates, uses, and
can radiate radio frequency energy
and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. Operation of this
equipment in a residential area is
likely to cause harmful interference in
which case the user will be required
to correct the interference at his own
expense.
4Safety Precautions
Introduction

.
POUR CANADA
RISQUE
D’ELECTROCUTION
NE PAS OUVRIR
CAUTION:
The mains plug shall remain readily
operable.
Remove the mains plug immediately if
the camera functions abnormally.
WARNING:
The battery pack, the camera with
battery installed, and the remote control
with battery installed should not be
exposed to excessive heat such as direct
sunlight, fire or the like.
ATTENTION:
POUR EVITER TOUT RISQUE
D’ELECTROCUTION NE PAS
OUVRIR LE BOITER. AUCUNE
PIECE INTERIEURE N’EST A
REGLER PAR L’UTILISATEUR. SE
REFERER A UN AGENT QUALIFIE
EN CAS DE PROBLEME.
ATTENTION
Le symbole de l’éclair à
l’intérieur d’un triangle
équilatéral est destiné à
alerter l’utilisateur sur la
présence d’une “tension
dangereuse” non isolée dans
le boîtier du produit. Cette
tension est suffisante pour
provoquer l’électrocution de
personnes.
Le point d’exclamation à
l’intérieur d’un triangle
équilatéral est destiné à
alerter l’utilisateur sur la
présence d’opérations
d’entretien importantes au
sujet desquelles des
renseignements se trouvent
dans le manuel
d’instructions.
Ces symboles ne sont
utilisés qu’aux Etats-Unis.
.
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
AVERTISSEMENT : POUR EVITER
LES RISQUES D’INCENDIE OU
D’ELECTROCUTION, NE PAS
EXPOSER L’APPAREIL A LA
PLUIE NI A L’HUMIDITE.
NOTES:
The rating plate and safety caution are
on the bottom and/or the back of the
main unit.
The serial number plate is on the
bottom of the unit.
The rating information and safety
caution of the AC adapter are on its
upper and lower sides.
REMARQUES :
La plaque d’identification et
l’avertissement de sécurité se trouvent
sous l’appareil et/ou au dos.
La plaque du numéro de série est
située sur la partie inférieure de
l’appareil.
Les informations d’identification et
l’avertissement de sécurité de
l’adaptateur secteur sont situés sur ses
côtés supérieur et inférieur.
Caution on Replaceable lithium
battery
The battery used in this device may
present a fire or chemical burn hazard if
mistreated.
Do not recharge, disassemble, heat
above 100°C (212°F) or incinerate.
Replace battery with Panasonic, Sanyo,
Sony or Maxell CR2025.
Danger of explosion or risk of fire if the
battery is incorrectly replaced.
Dispose of used battery promptly.
Keep away from children.
Do not disassemble and do not dispose
of in fire.
Safety Precautions 5
Introduction

.
When the equipment is installed in a
cabinet or on a shelf, make sure that it
has sufficient space on all sides to allow
for ventilation (10 cm (3-15/16") or more
on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a
newspaper, or cloth etc. the heat may not
be able to get out.)
No naked flame sources, such as lighted
candles, should be placed on the
apparatus.
When discarding batteries,
environmental problems must be
considered and the local rules or laws
governing the disposal of these batteries
must be followed strictly.
The apparatus shall not be exposed to
dripping or splashing and that no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
Do not point the lens directly into the
sun. This can cause eye injuries, as well
as lead to the malfunctioning of internal
circuitry. There is also a risk of fire or
electric shock.
CAUTION!
The following notes concern possible
physical damage to this unit and to the
user.
Carrying or holding this unit by the LCD
monitor can result in dropping the unit,
or in a malfunction.
Do not use a tripod on unsteady or
unlevel surfaces. It could tip over,
causing serious damage to the unit.
CAUTION!
Connecting cables (Audio/Video, etc.) to
this unit and leaving it on top of the TV is
not recommended, as tripping on the
cables will cause the unit to fall, resulting
in damage.
.
When using the AC adapter in
areas other than the USA
The provided AC adapter features
automatic voltage selection in the AC
range from 110 V to 240 V.
USING HOUSEHOLD AC PLUG
ADAPTER
In case of connecting the unit’s power
cord to an AC wall outlet other than
American National Standard C73 series
type, use an AC plug adapter called a
“Siemens Plug” as shown.
For this AC plug adapter, please contact
the local dealers in your area.
Remove the AC adapter from the AC
wall outlet when not in use.
Do not leave dust or metal objects
adhered to the AC wall outlet or AC
adapter (power/DC plug).
Plug Adapter
6Safety Precautions
Introduction

.
IMPORTANT (for owners in the U.K.)
Connection to the mains supply in
the United Kingdom.
DO NOT cut off the mains plug from
this equipment.
If the plug fitted is not suitable for the
power points in your home or the cable is
too short to reach a power point, then
obtain an appropriate safety approved
extension lead or contact the local
dealers in your area.
BE SURE to replace the fuse only with
an identical approved type, as originally
fitted, and to replace the fuse cover.
If nonetheless the mains plug is cut off
be sure to remove the fuse and dispose
of the plug immediately, to avoid possible
shock hazard by inadvertent connection
to the mains supply.
If this product is not supplied fitted with a
mains plug then follow the instructions
given below:
DO NOT make any connection to the
Larger Terminal coded E or Green.
The wires in the mains lead are coloured
in accordance with the following code:
If these colours do not correspond with
the terminal identifications of your plug,
connect as follows:
Blue wire to terminal coded N (Neutral)
or coloured black.
Brown wire to terminal coded L (Live) or
coloured Red.
If in doubt —consult a competent
electrician.
CAUTIONS:
 To prevent shock, do not open the
cabinet. No user serviceable parts
inside.
Refer servicing to qualified personnel.
When you are not using the AC
adapter for a long period of time, it is
recommended that you disconnect the
power cord from AC outlet.
Blue to N
(Neutral) or Black
Brown to L (Live)
or Red
.
FOR EUROPE
This equipment is in conformity with the
provisions and protection requirements of
the corresponding European Directives.
This equipment is designed for professional
video appliances and can be used in the
following environments:
Controlled EMC environment (for
example, purpose-built broadcasting or
recording studio), and rural outdoors
environments.
In order to keep the best performance and
furthermore for electromagnetic
compatibility we recommend to use cables
not exceeding the following lengths:
The inrush current of this apparatus is
11.0 A.
Exclusive
Cable
Exclusive
Cable
Exclusive
Cable
Exclusive
Cable
Coaxial
Cable
Shielded
Cable
Shielded
Cable
Shielded
Cable
Shielded
Cable
DC 1.8 m
1.4 m
1.2 m
1.8 m
2 m
2 m
3 m
1 m
1 m
USB Mini
AV OUT
HDMI
REMOTE
SDI OUT
AUX
HEADPHONE
AUDIO INPUT 1/2
O
Port Cable Length
CAUTION:
Where there are strong electromagnetic
waves or magnetism, for example near a
radio or TV transmitter, transformer,
motor, etc., the picture and the sound
may be disturbed. In such case, please
keep the apparatus away from the
sources of the disturbance.
Safety Precautions 7
Introduction

.
WARNING
Operation of this equipment in a
residential environment could cause
radio interference.
CAUTION:
To avoid electric
shock or damage to
the unit, first firmly
insert the small end
of the power cord into the AC Adapter
until it is no longer wobbly, and then plug
the larger end of the power cord in to an
AC outlet.
FOR EUROPEAN
Dear Customer
This apparatus is in conformance with
the valid European directives and
standards regarding electromagnetic
compatibility and electrical safety.
European representative of
JVCKENWOOD Corporation is:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
GERMANY
Sehr geehrter Kunde, sehr geehrte
Kundin, dieses Gerät stimmt mit den
gültigen europäischen Richtlinien und
Normen bezüglich elektromagnetischer
Verträglichkeit und elektrischer
Sicherheit überein.
Die europäische Vertretung für die
JVCKENWOOD Corporation ist:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
DEUTSCHLAND
.
The plastics packaging bags may cause
suffocation when they are covered over the
head. Tear them open, and keep them away
from the reach of infants and children by
ensuring that they are disposed of properly.
.
Battery Pack
The supplied battery pack is a lithium-ion
battery. Before using the supplied battery
pack or an optional battery pack, be sure
to read the following cautions:
zTo avoid hazards
... do not burn.
zTo prevent damage and prolong
service life
... do not subject to unnecessary shock.
... charge within the temperature range
of 10°C to 30°C (50°F to 86°F). Cooler
temperatures require longer charging
time, or in some cases stop charging
at all. Warmer temperatures prevent
complete charging, or in some cases
stop charging at all.
... store in a cool, dry place. Extended
exposure to high temperatures will
increase natural discharge and
shorten service life.
... keep a 30% battery level if the
battery pack is not to be used for a
long period of time.
... remove from charger or powered unit
when not in use, as some machines
use current even when switched off.
... do not drop or subject to strong
impact.
... do not short-circuit the
terminals. Keep it away
from metallic objects
when not in use.
When transporting,
carry the battery in a
plastic bag.
... do not modify or
disassemble.
... do not expose the
battery to
temperatures
exceeding 60°C (140°F), as this may
cause the battery to overheat, explode
or catch fire.
... use only specified chargers.
Terminals
Terminals
8Safety Precautions
Introduction

.
Para Brasil
Informação sobre eliminação de
baterias
Este produto não deverá ser eliminado
como lixo doméstico em geral.
Devolva a bateria velha ao comerciante
ou para a rede autorizada, para que seja
devolvida ao fabricante ou importador.
A reciclagem e eliminação de lixo em
uma maneira adequada, ajudarão para
preservar recursos, prevenindo, ao
mesmo tempo, contra efeitos prejudiciais
sobre a nossa saúde e o meio ambiente.
o
Para Retirar a Bateria Recarregável
Pressione botão e puxe a bateria para fora.
.
GY-HM250U/GY-HM250E
GY-HM180U/GY-HM180E
GY-HM170U/GY-HM170E
Empurre
Empurre
Safety Precautions 9
Introduction

Contents
Introduction
Safety Precautions ............................................ 4
Contents .......................................................... 10
Main Features ................................................. 13
Precautions for Proper Use ............................. 16
Operation Modes ............................................. 20
Names of Parts ................................................ 22
Side Control Panel ....................................... 23
Side Terminal Section .................................. 24
Rear Terminal .............................................. 24
LCD Monitor ................................................ 25
Handle Unit Section ..................................... 26
Lens Section ................................................ 27
Basic System Diagram .................................... 28
Preparations
Settings and Adjustments Before Use ............. 29
Attaching the Handle Unit ............................ 29
Adjusting the Grip Belt ................................. 29
Attaching the External Microphone O ...... 29
Attaching/Detaching the Lens Cap .............. 30
Attaching/Detaching the Hood ..................... 30
Attaching the Anti-reflective Film .................. 31
Attaching the Tripod ..................................... 31
Power Supply .................................................. 32
Using a Battery Pack .................................... 32
Using AC Power (DC IN Power) ................... 34
Power Status Display ...................................... 34
Turning On/Off the Power ................................ 35
Initial Settings .................................................. 36
Displays on the LCD Monitor and Viewfinder .. 38
Display Screen ............................................. 38
Status Screen .............................................. 39
USB Mode Screen ....................................... 39
Remote Edit Mode Screen n ................... 39
Warning Display ........................................... 39
Adjusting the LCD Monitor and Viewfinder ...... 40
Adjusting the LCD Monitor ........................... 40
Adjusting the Viewfinder .............................. 41
Assignment of Functions to User Buttons ........ 42
Tally Lamp ....................................................... 42
SD Card ........................................................... 43
Usable Cards ............................................... 43
Formatting (Initializing) SD Cards ................ 45
Restoring the SD Card ................................. 46
Clips Recorded to SD Cards ........................ 47
Operation Lock Feature ................................... 48
Shooting
Basic Shooting Procedures ............................. 49
Selecting System Definition, File Format and Video
Format ............................................................. 50
Zoom Operation .............................................. 53
Focus Operation .............................................. 54
Adjusting the Focusing by Face Detection ...... 56
Adjusting the Brightness .................................. 58
Adjusting the Iris .............................................. 59
Setting the Gain ............................................... 60
Setting the Electronic Shutter .......................... 61
Setting the ND Filter ........................................ 63
Adjusting the White Balance ............................ 64
Adjusting the Camera Image ........................... 67
Using the Image Stabilizer ............................... 68
Audio Recording .............................................. 69
Monitoring Audio Sound During Recording Using a
Headphone ...................................................... 71
Time Code and User’s Bit ................................ 72
Setting Time Code Generator .......................... 73
Setting the User’s Bit ....................................... 75
Setting Zebra Pattern ...................................... 76
Viewing Recorded Videos Immediately (Clip
Review) ........................................................... 77
Using the Histogram ........................................ 78
Recording Simultaneously at Two Different
Definitions ....................................................... 78
Series Rec ....................................................... 78
Dual Rec .......................................................... 79
Backup Rec ..................................................... 80
Special Recording ........................................... 82
Pre Rec ........................................................ 82
Clip Continuous Rec .................................... 83
Frame Rec ................................................... 85
Interval Rec .................................................. 86
Splitting the Clips Freely (Clip Cutter Trig) ....... 87
Playback
Playing Recorded Clips ................................... 88
Thumbnail Screen ........................................ 88
Actions ......................................................... 90
Playing back ................................................ 91
Deleting Clips .................................................. 92
Appending/Deleting OK Mark .......................... 93
Selecting and Performing Operations on Multiple
Clips ................................................................ 94
Selecting Multiple Clips Randomly ............... 94
Selecting Multiple Clips Consecutively ........ 95
Trimming Recorded Clips ................................ 96
10 Contents
Introduction

Menu Display and Detailed Settings
Basic Operations in Menu Screen ................... 97
Display and Description of the Menu Screen
..................................................................... 98
Text Input with Software Keyboard .............. 99
Menu Screen Hierarchical Chart ................... 100
Overlay Settings Menu n .......................... 101
Camera Function Menu ................................. 102
User Switch Set Item .................................. 105
Camera Process Menu .................................. 107
Detail/Adjust Item ....................................... 110
White Balance Item .................................... 110
TC/UB Menu ................................................. 111
LCD/VF Menu ................................................ 112
Shooting Assist Item .................................. 113
Marker Settings Item .................................. 113
Display Settings Item ................................. 114
A/V Set Menu ................................................ 116
Video Set Item ........................................... 116
Audio Set Item ........................................... 118
System Menu ................................................ 121
Record Set Item ......................................... 123
Network/Settings Item n ........................ 127
Adding/Editing Frequently Used Menu Items
(Favorites Menu) ........................................... 135
Adding Menu Items to Favorites Menu ...... 135
Editing Favorites Menu .............................. 136
Display/Status Screen
Display Screen in Camera Mode ................... 139
Display Screen in Media Mode ...................... 145
Status Screen ................................................ 147
Camera Features
Marker and Safety Zone Displays (Camera Mode
Only) .............................................................. 148
Color Bar Output ........................................... 148
Adjusting Color Matrix ................................... 149
Configuring Setup Files ................................. 150
Saving Setup Files ..................................... 150
Loading a Setup File .................................. 151
Connecting External Devices
Connecting External Monitor ......................... 152
Connecting the Headphone ........................... 153
Connecting Wired Remote Control ................ 154
Loading Clips to the PC ................................. 154
Connecting to the Network n
Functions of Network Connection n .......... 156
Preparing Network Connection n .............. 157
Operating Environment .............................. 157
Camera Setup for Network Connection ..... 157
Connecting via Wireless LAN .................... 158
Connecting via Wired LAN ......................... 159
Connecting via Cellular Adapter ................ 160
Importing Metadata n ............................... 160
Preparing Metadata ................................... 160
Configuring the Server for Downloading .... 161
Importing Metadata .................................... 161
Uploading a Recorded Video Clip n ......... 162
Configuring the FTP Server for Uploading . 162
Uploading Video Clip ................................. 162
FTP Resume Feature n ............................ 165
Connecting from a Web Browser n ........... 165
Editing Metadata n ................................... 166
Planning Metadata ..................................... 166
Clip Metadata ............................................ 167
Uploading a Recording Clip via a Web Browser
n ............................................................... 170
View Remote Feature n ............................ 173
Operating Procedure ................................. 173
Registering/Deleting Preset Zoom ............. 174
Camera Control Function n ...................... 176
Configuring Settings via a Browser n ........ 177
Changing View Remote Function Settings . 178
Changing Connection Setup ...................... 179
Changing Metadata Server Settings .......... 180
Changing Clip Server Settings ................... 180
Changing Streaming Settings .................... 180
Managing the Network Connection Settings File
n ............................................................... 180
Saving the Connection Settings File .......... 181
Reading the Connection Settings File ........ 182
Deleting Connection Settings .................... 182
Performing Live Streaming n .................... 183
Setting Distribution ..................................... 184
Starting Distribution ................................... 185
Setting the FEC Matrix ............................... 186
Logging in to Facebook n ......................... 186
Preliminary Configuration ........................... 186
Connection Setup ...................................... 186
Live Streaming on Facebook Live n ......... 188
Live Streaming ........................................... 188
Logging in to YouTube n .......................... 189
Preliminary Configuration ........................... 189
Connection Setup ...................................... 189
Live Streaming on YouTube Live n ........... 191
Live Streaming ........................................... 191
Contents 11
Introduction

Broadcast Overlay n ................................. 192
Importing and Configuring Settings for SDP Files
for Broadcast ............................................. 192
Displaying Watermark Images ................... 194
Displaying Images on the Whole Screen (Full
Screen Graphic Function) .......................... 195
Protecting Overlay Settings with a Password
................................................................... 197
Specifying Text and Images ....................... 197
Others
Error Messages and Actions ......................... 198
List of FTP Transfer Errors n ................. 199
List of Live Streaming Error Displays n . 201
Blinking of the Tally Lamp .......................... 202
Warning Tone ............................................ 202
Troubleshooting ............................................ 202
Specifications ................................................ 204
Index ............................................................. 207
Software License Agreement ........................ 209
Important Notice concerning the Software ..... 210
.
12 Contents
Introduction

Main Features
Supports 4K high-definition recording,
realizing more advanced Full HD
recording quality
Recording and playback at 30p/25p/24p are
possible in 4K resolution (3840x2160 pixels),
which contains information that is about four times
larger than Full HD. And in addition to recording at
150 Mbps for 4K shooting with H.264 codec, this
camera recorder also supports a recording mode
of 70 Mbps. Videos can also be recorded in Class
10 SDHC/SDXC memory cards.
In addition to the 50 Mbps 4:2:2 color sampling
recording in conventional HD shooting, the camera
recorder also supports 4:2:2 recording mode in 4K
30p/25p/24p n, thus achieving even finer color
representation.
F1.2, 29.6 mm wide-angle, 12x optical
zoom lens
The 12x optical zoom supports zooming from 29.6
mm at the wide-angle end, and dynamic zoom up
to 24x with the use of a high-resolution sensor
(during HD/SD recording), allowing the faces of
distant portrait subjects to be captured.
High-performance CMOS sensor with a
sensitivity of F5.6
This camera recorder is built in with a high-
performance 1/2.3-inch (effective pixels of 9.03
megapixels, 1/2.5-inch) CMOS sensor with a
resolution of 12.4 megapixels, achieving a
significantly enhanced sensitivity of F5.6 with the
high-definition and advanced noise-reduction
technology. You can produce recordings with
excellent gradation even when shooting in a low-
light scene or at a location where lighting cannot be
used.
JVC image processor “FALCONBRID II”
The image processor employed supports both 4K
codec developed by JVC and simultaneous dual
stream encoding, achieving a high image quality
that maximizes the potential of next-generation
high-resolution sensors.
Enhanced network functions n
This camera recorder can be operated from
network devices such as PC and tablet during 4K
shooting.
It supports video and audio streaming via the
network during HD/SD shooting through a
combination of compatible decoders and PC
applications.
In addition to the RTMP and RTMPS protocols
suitable for distribution to SNS, the camera
recorder also supports Facebook Live, YouTube
Live, as well as the “SMPTE 2022-1” protocol
which allows high-definition data transmission
easily at low cost.
Zixi, which is a cloud service that enables highly-
reliable and stable data transmission, is also
supported.
Overlay on broadcast video n
Station name, program name, or news title
according to the recorded content can be entered
easily by using a smartphone or tablet, and this
information can be superimposed on the recording
clip or streaming images. The color of the text bar
can be selected from several pre-installed colors
and you can even customize to your preferred
image using a free PC application.
Full Screen Graphic Function n
Announcement and advertising images can be
superimposed on the shooting screen for live
distribution and for recording onto an SD card. Up
to 50 image files can be saved in the camera
recorder and they can also be used as a slide show.
Zero Config Function n
The camera recorder can be automatically
detected using the Streamstar X series from
Streamstar connected to the same LAN, making it
easier to connect multiple units.
Control from RM-LP100 n
This camera recorder can be controlled by using a
remote camera controller RM-LP100. Control from
external devices is indicated as a tally display on
the LCD and VF.
Main Features 13
Introduction

Color Matrix Adjustment Function
With the detailed settings of the Color Matrix
Adjustment, when shooting is performed using
multiple cameras, colors in different cameras can
be adjusted, and a color of the user’s preference
can be set on this camera recorder.
The “Setup Files” saved on the SD card can also
be used to enable the same setup status for other
GY-HM250/GY-HM180/GY-HM170.
High Luminance Priority Mode n
Equipped with a high luminance priority recording
mode that reduces overexposure of brightly lit
images. By making the brightly lit areas high
contrast, the images will appear more natural.
Equipped with Histogram Function to
Check the Brightness of the Subject and
Assist in Determining Exposure Level
Allows users to check the overall trend of the
exposure level on a histogram and assists in
preventing overexposure and blocked-up
shadows.
High-Speed Recording Function
A moving subject can be effectively portrayed by
shooting smooth slow motion images.
Supports QuickTime and AVCHD
formats
Inheriting the concept of our past memory camera
recorders, this camera recorder supports
QuickTime (MOV) and AVCHD file formats that can
be directly edited on “Final Cut Pro”, an editing
software from Apple Inc.
Equipped with double SD card slots
allowing various recording options
The most common SDHC/SDXC card recording
system is used as the memory card. This ensures
high reliability and operation at low running cost.
Various user friendly recording options are
available. These include series recording which
enables seamless long hour continuous
recordings over the slots, dual recording of the
same file to two slots, and backup recording of
recording only the preferred scenes to one slot
using the record and stop operations while the
other slot is continuously recording.
In addition, Web files with resolution suitable for
distribution over the network can be created. HD
files and Web files can also be recorded
simultaneously.
For GY-HM250, it is also possible to perform
streaming while the recording is ongoing. n
Equipped with progressive-compatible
3G-SDI and HDMI output
[SDI OUT] and [HDMI] terminals are equipped for
digital output. 3G-compatible SDI output is
supported, and external output including 4K from
the [HDMI] terminal is possible. Uncompressed
Full HD signals and audio signals can be output
simultaneously from the [SDI OUT] and [HDMI]
terminals.
* GY-HM170U/GY-HM170E come only with the
[HDMI] terminal. [SDI OUT] terminal is not
available.
3.45-inch 2.76-megapixel LCD display
and 0.24-inch 1.56-megapixel color
viewfinder
The 3.45-inch 16:9 LCD display and 0.24-inch 16:9
LCOS color viewfinder provides support for critical
focusing during 4K shooting. Other assist functions
are also available, including magnified focus on a
manually selected point.
14 Main Features
Introduction

Auto focus/Optical and electronic
image stabilizer
The camera recorder is equipped with a face
detection auto focus function that covers the entire
screen. Switching to manual focus is also possible.
A built-in optical and electronic image stabilizer
feature is also available which supports shooting
for various occasions.
Professional-style switch layout and
diverse video parameters
Switches for Gain and White Balance are available
on the side panel to enable quick switching
according to the shooting scene. Image quality
parameters such as gamma and color matrix are
also available in the menu for adjustment to the
preferred tones.
User button/ring assignable with
different functions for greater ease of
use
Menu items corresponding to each of the 9 buttons
and 2 rings are available to assign the buttons and
rings with different functions.
Built-in 3-position ND filter
ND filters are built into this camera recorder. You
can adjust the amount of light according to the
brightness during shooting by switching the 3-
position ND filter (OFF, 1/4, 1/16).
Detachable handle unit with 2-channel
XLR audio input terminal
The handle unit is built in with recording button and
zoom switches, and supports microphones for
business use. The recording level can also be
adjusted, and connection of a phantom
microphone is also supported.
Content of this Manual
Symbols used
Caution : Describes precautions concerning the operation
of this product.
Memo : Describes reference information, such as
functions and usage restrictions of this product.
A
: Indicates the reference page numbers and
reference items.
n
: Feature available on GY-HM250U/GY-HM250E
only.
m
: Feature available on GY-HM180U/GY-HM180E
only.
M
: Feature available on
GY-HM170U/GY-HM170E only.
O
: Function that operates only when the handle unit
is attached.
Content of this manual
0All rights reserved by JVCKENWOOD Corporation.
Unauthorized duplication or reprinting of this manual, in
whole or in part, is strictly prohibited.
0Illustrated designs, specifications and other contents of
this manual are subject to change for improvement without
prior notice.
0AVCHD Progressive and the AVCHD Progressive logo are
trademarks of Panasonic Corporation and Sony
Corporation.
0SDXC and SDHC logos are trademarks of SD-3C, LLC.
0The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.
0QuickTime, Final Cut Pro, Finder, iPhone, iPad, iPod
touch, iOS, Mac OS and Safari are registered trademarks
of Apple Inc. in the U.S. and other countries.
0iOS is a trademark or registered trademark of Cisco in the
U.S. and other countries and is used under license.
0Android, Google Chrome, YouTube, YouTube logo and
Nexus are trademarks and/or registered trademarks of
Google LLC.
0QR Code is a registered trademark of Denso Wave
Incorporated.
0Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
0Microsoft, Windows and Internet Explorer are either
registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
0Surface is the trademarks of Microsoft Corporation in the
United States and/or other countries.
0The company name of Fontworks, Fontworks, and the
name of the fonts are registered trademarks of Fontworks
Inc.
0Zixi and the Zixi logo are trademarks of Zixi LLC.
0“Facebook” and the “Facebook” logo are trademarks and
registered trademarks of Facebook, Inc.
0Other product and company names included in this
instruction manual are trademarks and/or registered
trademarks of their respective companies. Marks such as
™ and ® have been omitted in this manual.
This manual is for (G) products manufactured after June
2021.
Main Features 15
Introduction

Precautions for Proper
Use
Storage and Usage Locations
oAllowable ambient temperature and humidity
Be sure to use this unit within the allowable
temperature range of 0 °C to 40 °C (32 °F to
104°F) and a relative humidity of 30 % to 80 %.
Using this unit at a temperature or humidity
outside the allowable ranges could result not
only in malfunction but also serious impact on
the CMOS elements as small white spots may
be generated. Please exercise care during use.
oStrong electromagnetic waves or magnetism
Noise may appear in the picture or audio and/or
the colors may be incorrect if this unit is used
near a radio or television transmitting antenna,
in places where strong magnetic fields are
generated by transformers, motors, etc., or near
devices emitting radio waves, such as
transceivers or cellular phones.
oUse of wireless microphone near this unit
When a wireless microphone or wireless
microphone tuner is used near this unit during
recording, the tuner could pick up noise.
oAvoid using or placing this unit in the following
places.
0Places subject to extreme heat or cold
0Places with excessive dirt or dust
0Places with high humidity or moisture
0Places subject to smoke or vapor such as near
a cooking stove
0Places subject to strong vibrations or unstable
surfaces
0In a parked car under direct sunlight or near a
heater for long hours
oDo not place this unit at places that are subject
to radiation or X-rays, or where corrosive gases
occur.
oProtect this unit from being splashed with water.
(Especially when shooting in the rain)
oProtect this unit from getting wet when shooting
on a beach. In addition, salt and sand may
adhere to the body. Be sure to clean the unit after
use.
oProtect this unit against penetration of dust
when using it in a place subject to sandy dust.
Carrying the Camera
oDo not drop or hit this unit against a hard object
when transporting.
Power Saving
oWhen this unit is not in use, be sure to set the
[POWER ON/OFF] switch to “OFF” in order to
reduce power consumption.
Maintenance
oTurn off the power before performing any
maintenance.
oWipe the external cabinet of the unit with a soft
cloth. Do not wipe the body with benzene or
thinner. Doing so may cause the surface to melt
or turn cloudy. When it is extremely dirty, soak
the cloth in a solution of neutral detergent, wipe
the body with it, and then use a clean cloth to
remove the detergent.
Rechargeable Battery
oBe sure to use only the specified batteries.
We do not guarantee the safety and
performance of this device if an unspecified
battery is used.
om M
0Charge the battery first before using.
0If you are not using the battery for a prolonged
period of time, remove and keep the battery at
a 30 % to 40 % charge level to prevent
deterioration.
0Recharge the battery to a level of 10 % to 20 %
once every six months when storing the
battery.
Storing the battery at a fully discharged state
will result in over discharging and inability to
charge the battery.
0Store the removed battery with the battery cap
attached in a dry place between 15 °C and
25 °C (59 °F and 77 °F).
on
0For details, refer to the “INSTRUCTIONS” of
the battery.
oATTENTION:
The product you have purchased
is powered by a rechargeable
battery that is recyclable.
Please call 1-800-8-BATTERY for
information on how to recycle this
battery.
16 Precautions for Proper Use
Introduction

Regular Inspection (Maintenance)
oUnder normal environment, dust will
accumulate on the camera recorder when it is
used over a long period. Dust may enter the
camera recorder especially if it is used outdoors.
This may affect the image and sound quality of
the camera recorder. Check and replace the fan
after every 9000 hours (suggested guideline).
You can check the usage time of the fan in
[System] B [System Information] B [Fan Hour].
(A P123 [ Fan Hour ] )
If the fan is used for more than 9000 hours
without replacement, “Fan Maintenance
Required” will be displayed every time you turn
on the power.
SDHC/SDXC Cards
oSDHC/SDXC card is referred to as SD card in
this manual.
oThis camera recorder saves the recorded
images and audio sound on the SD card (sold
separately) in the card slot.
oIf the SD card contains files recorded by devices
other than this camera recorder or files that are
saved from a PC, the recordable time may be
shorter or data may not be properly recorded. In
addition, the remaining space on the card may
not increase even when files are deleted using
a PC.
oFor details on the combinations of usable SD
card and format setting, refer to the following.
(A P43 [Format Setting and Usable SD Card
Combinations] )
* Using cards other than those from Panasonic,
TOSHIBA or SanDisk may result in recording
failure or data loss.
Handling of SD Cards
oThe status indicator lights up in red when data
on the SD card is being accessed.
Do not remove the SD card during data access
(such as recording, playback, or formatting). Do
not turn off the power or remove the battery and
AC adapter during access either.
oDo not use or store the SD card in a place that
is subject to static electricity or electrical noise.
oDo not place the SD card near locations that are
exposed to strong magnetic fields or radio
waves.
oInserting the SD card incorrectly may result in
damage of this unit or the SD card.
oWe are not liable for any accidental loss of data
stored on the SD card. Please back up any
important data.
oMake use of the SD card within the prescribed
conditions of use.
Do not use it at the following locations.
Places that are subject to direct sunlight, high
humidity or corrosion, places near thermal
equipment, sandy or dusty places, or in a car
under the sun with the doors and windows
closed.
oDo not bend or drop the SD card, or subject it to
strong impact or vibration.
oDo not splash the SD card with water.
oDo not dismantle or modify the SD card.
oDo not touch the terminals with your hands or
with a metal object.
oDo not allow dust, dirt, water, or foreign objects
to adhere to the terminals.
oDo not remove the labels or stick other labels or
stickers on the SD cards.
oDo not use pencils or ballpoint pens to write on
the SD cards. Always use oil-based pens.
oIf you format (initialize) the SD card, all data
recorded on the card, including video data and
setup files, will be deleted.
oYou are recommended to use cards that are
formatted (initialized) on this camera recorder.
0The SD card may be damaged if the camera
recorder is not operated correctly. Formatting
(Initializing) the SD card may allow it to
operate correctly.
0SD cards that have been formatted
(initialized) on other cameras, computers or
peripheral equipment may not operate
correctly. In this case, format (initialize) the SD
card on this camera recorder.
oIf you want to wipe out all information by
completely erasing the data, we recommend
either using commercially available software
that is specially designed for that purpose, or by
physically destroying the SD card with a
hammer, etc. When formatting or erasing data
using the camera recorder, only the file
administration information is changed. The data
is not completely erased from the SD card.
oSome commercially available SD cards may be
harder to be removed from this unit. Remove
them by hooking onto the groove on the cards.
0It will be easier to remove the cards after
several times.
0Do not stick any stickers on the cards.
.
Groove
oThe SD card may pop out when it is being
removed. Be careful not to lose the card.
Precautions for Proper Use 17
Introduction

LCD Monitor and Viewfinder
oThe LCD monitor and viewfinder screen are
manufactured using high-precision technology.
Black spots may appear on the LCD monitor and
viewfinder screen, or red, blue, and/or white
spots may not disappear. However, this is not a
malfunction and these spots are not recorded on
the SD card.
oIf you use this unit continuously for a long period
of time, the characters displayed in the
viewfinder may temporarily remain on the
screen. This is not recorded on the SD card.
They will not appear after you turn the power off
and then on again.
oIf you use this unit in a cold place, the images
may appear to lag on the screen, but this is not
a malfunction. Retained images are not
recorded on the SD card.
oDo not press against the surface with force or
subject it to strong impact. Doing so may
damage or break the screens.
oNoise may appear in the viewfinder when
switching between the live video and playback
images.
oDue to the characteristic of the viewfinder
display device, colors may appear on the
images when you blink your eyes. It does not
affect the recorded images, SDI output, or HDMI
output.
Copyright
oAny recordings made on this camera recorder
that are played back for profit or public preview
may infringe on the rights of the owner of the
recordings.
Do not use the recordings for purpose other than
personal enjoyment without prior consent from
the owner.
License Notices
oMPEG LA AVC
THIS PRODUCT IS LICENSED UNDER THE
AVC PATENT PORTFOLIO LICENSE FOR
THE PERSONAL USE OF A CONSUMER OR
OTHER USES IN WHICH IT DOES NOT
RECEIVE REMUNERATION TO
(i) ENCODE VIDEO IN COMPLIANCE WITH
THE AVC STANDARD (“AVC VIDEO”) AND/OR
(ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO.
NO LICENSE IS GRANTED OR SHALL BE
IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM
MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
Encryption in Network Connection n
oWireless LAN connections make use of an
encryption function.
This encryption is designed for commercially-
sold equipment, and it cannot be altered.
18 Precautions for Proper Use
Introduction

Others
oDo not insert objects other than the memory card
into the card slot.
oDo not block the vent on the unit.
Blocking of the vent causes internal heating and
may lead to burns and fires.
oDo not turn off the [POWER ON/OFF] switch or
remove the power cable during recording or
playback.
oThe camera recorder may not show stable
pictures for a few seconds immediately after the
power is turned on, but this is not a malfunction.
oWhen the video signal output terminals are not
in use, put on the covers to prevent damage to
the terminals.
oDo not drop this unit or subject it to strong impact
or vibration as it is a precision equipment.
oOptical performance of lens
Due to the optical performance of the lens, color
divergence phenomena (magnification
chromatic aberration) may occur at the
periphery of the image. This is not a camera
malfunction.
oNoise may appear in the image when switching
modes.
oIf placed on its side, heat release efficiency will
deteriorate.
oUse the supplied AC adapter as the power
supply. Do not use the supplied AC adapter on
other devices.
oUse the supplied power cord. And do not use the
supplied power cord for any other devices.
oWhen the connectors that come with connector
covers are not in use, put on the covers to
prevent damage to the connectors.
oThis camera recorder makes use of fonts by
Fontworks Inc.
oThis camera recorder makes use of M+FONTS.
Precautions for Proper Use 19
Introduction

Operation Modes
This camera recorder has four operation modes - Camera mode, Media mode, USB mode and Remote
Edit mode.
.
MODE
Set Button
(R)
Set Button (R)
Trimming Playback
Normal Playback
[CANCEL/STOP]/[MENU/THUMB] Button
FTP in Progress
FTP in Progress
Exit FTP
Operation
(Successful)
Camera Input
*
* Selecting a mode other than the Metadata Edit mode via the web
browser, or selecting [Exit] on the [Remote Edit Mode] screen
Upon access via a web browser and selecting [Change] on the
[Change to Remote Edit Mode?] screen on the camera or the web browser
Connection to PC
with USB Cable
Press and hold [MODE]
[MODE]
Button
Press and hold [MODE]
[MODE] Button
Execute [FTP Upload]
Exit/Cancel FTP Operation (Successful/Failed/Stopped)
(Actions)
Execute [Delete Clips] File Deletion in Progress
Exit/Cancel File Delete Operation (Successful/Failed/Stopped)
Trimming in Progress
Exit Trimming Operation
(Successful/Failed/Stopped)
[ZEBRA/5]
Button
Execute
[Trim This Clip]
Media Mode
Thumbnail Display
USB Connection (When the confirmation to change
to USB mode appears and [Change] is selected)
(USB Mass Storage Class)
USB Mode
Connection disabled on PC
Camera Mode
Remote Edit Mode
Playback
GY-HM250U/
GY-HM250E only
20 Operation Modes
Introduction
