New JVC PIXSTAR Camera Generation with superior WDR
Features:
690 HTVL, High performance 17-bit DSP
JVC quality “S-WDR” 120 dB smart wide dynamic range
Precise custom mode for wide dynamic performance
Super LoLux Sensitivity 0.25 lx colour (25%)
3D Noise reduction (3DNR)
Super low power consumption
Monitor output for spot adjustment
16:9 mode / 4:3 mode selectable
24VAC/12VDC Dual voltage
MTBF 150,000 H
TK-WD9602E
WIDE DYNAMIC RANGE COLOUR CAMERA
* Lens not included
NEW

Specications:
Information in this document is subject to change without notice.
Copyright 2013 JVC KENWOOD Corporation. All rights reserved.
All product names stated in this document are trademarks or registered trademarks of their
respective companies. Marks such as TM, ®, and © are omitted in this document.
TK-WD9602E
Camera/lens
Image device 1/3” WDR CMOS
Lens mount CS
Iris DC iris
Dynamic range 120 dB Smart wide dynamic range (multi shutter system)
Sync system Internal
Video S/N ratio 52 dB (AGC OFF)
Resolution 690 HTVL (540 TV lines)
Minimum illumination
B&W
0.5 lx (50%), 0.25 lx (25%),
0.3 lx (50%), 0.15 lx (25%)
Day/Night Easy Day/Night
White balance ATW (wide/narrow) / AWC / One push / Manual
AGC OFF / MID / HIGH
Shutter speed 1/50 to 1/10,000
Sens up OFF, x2, x4, x8, x18
3D Noise Reduction OFF / LOW / MID / HIGH
Privacy Masking Yes (4 areas)
WDR level setting -10 to 10, Custom (Priority / BIAS / LIMIT / EXP BIAS)
WDR area setting Normal, Area 1 to 4, Custom (Free area setting)
Display mode Mode 1 / Mode 2 / Mode 3 / 16:9 Mode
Other settings AGC, Brightness, Contrast, Color level, Enhance, Focus adjust mode
General
Output PAL Composite video signal: 1.0V (p-p) 75ohms (BNC), Monitor out for setup (RCA)
Power supply 24VAC (50Hz/60Hz) / 12VDC
Power consumption 250 mA
Operation Temperature -10 to 50°C
Weight / Dimensions Approx. 300g / 55x61x125 mm
