JVC GZ-HD10AA User manual

INSTRUCTIONS EN
HD HARD DISK CAMCORDER
ENGLISH
Dear Customers
Thank you for purchasing this hard
disk camera. Before use, please read
the safety information and precautions
contained on pages 6 and 7 to ensure
safe use of this product.
AA
GZ-HD10

2EN
Easy Start Guide
CAUTION
•Charge the battery pack before use. (墌p. 16)
•Be sure to use JVC battery packs. If you use any other battery packs besides
JVC battery packs, safety and performance can not be guaranteed.
ACCESS
POWER
/CHARGE
The power turns on if you open the LCD
monitor
Close the LCD monitor after you finish recording.
Charge the battery before recording
Turn off the camera and attach the battery pack.
Power/charge lamp
blinks: Charging
goes out: Charging finished
Battery Pack
To AC Outlet
(110V to 240V)
AC Adapter
Open the cover

3
EN
Before recording, charge the battery and set the date/time.
See the next page for recording videos.
Preparation
QOpen the LCD monitor to turn on the camera
RSelect [YES] within
10 seconds
T
Power Button
SET DATE/TIME!
YES
NO
SELECT SET
SELECT SET QUIT
DATE TIME
31 1 11 07
2008
CLOCK ADJUST
SSet the date and time
Select
Set
Select
Set
When the message disappears, press the
power button for at least 2 seconds to turn
off the power, and then press it again for at
least 2 seconds.
To change the date and time (墌p. 17)
Open the lens cover USelect video mode

4EN
Video recording Before recording an important scene, it is
recommended to conduct a trial recording.
QSelect recording mode
PLAY/REC
SELECT When recording
The mode changes when
you press the button
RSelect auto mode
/
INFO
AUTO
The mode changes when
you press the button
(recording mode only)
The auto recording
indicator appears.
SStart recording
START
/STOP
Press the START/STOP
button to start recording,
and press it again to stop
[4h59m]
XP
0:01:30
REC
Remaining space on
the hard disk
Picture Quality Record-standby
Recording
CAUTION
•This camera records video in accordance with the AVCHD format.
•Try recording with easy [AUTO] mode first.

5
EN
Playing back
QSelect playback mode
PLAY/REC
SELECT
The mode changes when
you press the button
RSelect the desired file
VIDEO
1/1
SELECT SET SORT
Index screen
SPress down the set lever Playback screen
Press down the set lever to
start playback, and press it
again to stop
To perform operations such as fast forwarding or fast rewinding (墌p. 24)
To view video/still image on TV (墌p. 26)
䡵
䡵
CAUTION
Don’t forget to make copies after recording!
•To copy files onto DVD discs (墌p. 31)
•To dub files using a VCR/DVD recorder (墌p. 33)
•To play back a created DVD disc (墌p. 32)
•To edit files on your computer (墌p. 9)

6EN
Safety Precautions
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
CAUTIONS:
• If you notice smoke or a peculiar smell coming
from the camcorder or AC Adapter, shut it down
and unplug it immediately. Continue using the
camcorder or AC Adapter under these conditions
could lead to fire or electric shock. Contact
your JVC dealer. Do not attempt to repair the
malfunction yourself.
•To prevent shock, do not open the cabinet. No
user serviceable parts inside. Refer servicing to
qualified personnel.
•When you are not using the AC adapter for a
long period of time, it is recommended that you
disconnect the power cord from AC outlet.
•In certain areas, use the conversion plug
depending on the type of your AC wall outlet..
NOTES:
•The rating plate and safety caution are on the
bottom and/or the back of the main unit.
•
The serial number plate is on the battery pack mount.
•The rating information and safety caution of the
AC adapter are on its upper and lower sides.
WARNING:
The battery pack, the camera with battery installed,
and the remote control with battery installed should
not be exposed to excessive heat such as direct
sunshine, fire or the Iike.
CAUTION:
The mains plug shall remain readily operable.
Caution on Replaceable lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Replace battery with Panasonic (Matsushita
Electric), Sanyo, Sony or Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
•Dispose of used battery promptly.
•Keep away from children.
•Do not disassemble and do not dispose of in fire.
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on
all sides to allow for ventilation (10 cm or more on
both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a
newspaper, or cloth etc. the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental problems
must be considered and the local rules or laws
governing the disposal of these batteries must be
followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroom or places
with water.
Also do not place any containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this equipment,
fire or electric shock may be caused.)

7
EN
CAUTION:
To avoid electric shock or
damage to the unit, first
firmly insert the small end
of the power cord into the
AC Adapter until it is no
longer wobbly, and then
plug the larger end of the power cord into an AC outlet.
Remember that this camera is intended for
private consumer use only.
Any commercial use without proper permission
is prohibited. (Even if you record an event such
as a show, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Trademarks
•AVCHD and AVCHD logotype are trademarks of
Matsushita Electric Industrial Co., Ltd. and Sony
Corporation.
•Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
•x.v.Colour™ is a trademark of
Sony Corporation.
•HDMI is a trademark of HDMI
Licensing, LLC.
•Windows®is either registered
trademark or trademark of Microsoft Corporation
in the United States and/or other countries.
•Macintosh is a registered trademark of Apple Inc.
•Other product and company names included in
this instruction manual are trademarks and/or
registered trademarks of their respective holders.
Do not point the lens directly into the sun. This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There is also a
risk of fire or electric shock.
CAUTION!
The following notes concern possible physical
damage to the camera and to the user.
Carrying or holding the camera by the LCD monitor
can result in dropping the unit, or in a malfunction.
Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious damage
to the camera.
CAUTION!
Connecting cables (Audio/Video, S-Video, etc.) to
the camera and leaving it on top of the TV is not
recommended, as tripping on the cables will cause
the camera to fall, resulting in damage.
If this symbol is shown, it is only valid
in the European Union.

8EN
Contents
GETTING STARTED
Accessories ............................................10
Preparing the Remote Control...................... 11
Attaching the Core Filter to the DC cord....... 11
Index ........................................................12
Indications on LCD Monitor...................14
Necessary Settings before Use.............16
Charging the Battery Pack............................ 16
Checking the Remaining Battery Power....... 16
Date/Time Setting......................................... 17
Language Setting ......................................... 17
Other Settings.........................................18
Grip Adjustment............................................ 18
Attaching the Shoulder Strap........................ 18
Lens Cover ................................................... 18
Tripod Mounting............................................ 18
When Using a microSD Card ....................... 19
Changing the Menu Settings ........................ 19
RECORDING
Recording Files.......................................20
Video Recording........................................... 20
Still Image Recording ................................... 21
Zooming........................................................ 22
LED Light...................................................... 22
Registering Files to Events........................... 22
Manual Recording ..................................23
To Change to Manual Recording Mode ........ 23
Program AE .................................................. 23
Manual Setting in Menu................................ 23
PLAYBACK
Playing Back Files ..................................24
Video Playback ............................................ 24
Still Image Playback ..................................... 25
Watching Images on TV..........................26
Connection with TV....................................... 26
Playback Operation ...................................... 27
EDITING/PRINTING
Managing Files........................................28
To Capture a Still Image from a Video.......... 28
Deleting/Protecting Files............................... 28
Changing the Event Registration.................. 29
Dividing Files ................................................ 29
Playlists ...................................................30
Creating Playlists.......................................... 30
COPYING
Copying Files ..........................................31
Copying/Moving Files ................................... 31
Using a DVD Burner to Copy Files from the
Camera ....................................................... 31
Standard-definition Dubbing ......................... 33
FURTHER INFORMATION
Troubleshooting......................................34
Warning Indications ...............................36
Specifications .........................................37
Cautions ..................................................39
Terms .......................................................44

9
EN
Read This First!
Make a backup of important recorded data
It is recommended to copy your important
recorded data to a DVD or other recording
media for storage. (墌p. 31) JVC will not be
responsible for any lost data.
Make a trial recording
Before the actual recording of important data,
make a trial recording and play back the
recorded data to check that the video and
sound have been recorded correctly.
Reset the camera if it does not operate
correctly
This camera uses a microcomputer. Factors
such as background noise and interference
can prevent it from operating correctly. If the
camera does not operate correctly, reset the
camera.
Precautions on handling batteries
•Be sure to use the JVC BN-VF808U/
VF815U/VF823U battery packs.
•If the camera is subjected to electrostatic
discharge, turn off the power before using it
again.
If a malfunction occurs, stop using the
camera immediately and consult your local
JVC dealer
•If a problem occurs when using the microSD
card, take the card together with the camera
for repair. If one of them is not included,
the cause of the malfunction cannot be
diagnosed, and the camera cannot be
repaired.
•Recorded data may be erased while the
camera is being repaired or inspected. Back
up all data before requesting repairs or
inspections.
Because cameras may be used
for demonstration in a shop, the
demonstration mode is set to on by default
To deactivate the demonstration mode, set
[DEMO MODE] to [OFF].
Do not cover the fan (墌p. 12 (, /)
If the camera becomes too hot inside it may
cause a malfunction.
For Windows
Refer to the PC OPERATION GUIDE in the
supplied CD-ROM.
!Load the provided CD-ROM into the PC.
After a moment, the [Software Setup] screen
appears. If the [Software Setup] screen does
not appear, double-click the CD-ROM icon
in [My Computer].
NOTE
Refer to the PC OPERATION GUIDE for the
system requirements of the provided software.
For details, refer to the User’s guide or Help of
the software.
For Macintosh
!Load the provided CD-ROM into the
Computer.
#Double-click the CD-ROM icon.
$Double-click “Start.pdf” in the “PC guide”
folder.
%Click the desired language.
NOTES
• Adobe®Acrobat®Reader™ or Adobe®
Reader®must be installed to read PDF
files. Adobe®Reader®can be located from
Adobe’s web site: http://www.adobe.com/
•For more details on the operations, refer to
the GUIDEBOOK and the PC OPERATION
GUIDE in the supplied CD-ROM.
䡵
䡵
#Click
PC OPERATION

10 EN
Accessories
GETTING STARTED
or
AC Adapter
AP-V14E/ AP-V20M
Power Cord Battery Pack
BN-VF808U
Component Cable
(墌p. 26)
Audio/Video Cable
(墌p. 27, 33)
USB Cable Shoulder Strap
(墌p. 18)
CD-ROM
(墌p. 9)
Remote Control
RM-V750U (墌p. 11)
Lithium Battery
CR2025
Pre-installed in the
remote control unit.
Core Filter
(墌p. 11)
NOTE
Make sure to use the provided cables for connections. Do not use any other cables.

11
EN
Preparing the Remote Control
A battery is included inside the remote control at the time of purchase.
Remove the insulation sheet before use.
Beam Effective Area To Reinsert the Battery
NOTE
The transmitted beam may not be effective
or may cause incorrect operation when the
remote sensor is directly exposed to sunlight
or powerful lighting.
Pull out the battery holder by pressing the lock
tab.
Attaching the Core Filter to the DC cord
The core filter reduces interference. Connect the end of the cable with the core filter to the camera.
Effective distance:
Max. 5 m
Remote Sensor
Lock Tab
Lithium Battery
(CR2025)
Release the stopper. 3 cm Wind twice

12 EN
Index
NOTES
•The LCD monitor can rotate 270°.
•Power-linked operation
You can also turn on/off the camera by
opening/closing the LCD monitor.
•Be careful not to cover sensors 7, >and ?
during shooting.

13
EN
9HDMI Connector [HDMI] (墌p. 26)
:DC Connector [DC] (墌p. 16)
;Microphone Input Connector [MIC]
<LED Light
=USB Connector [ 2]
>Remote Sensor (墌p. 11)
?Lens Cover/Lens
@Shoe (for external microphone, etc)
AShoe Cover
BLens Cover Switch [=, >] (墌p. 18)
CmicroSD Card Slot (墌p. 19)
DTripod Mounting Socket (墌p. 18)
EBattery Release Button [BATT.] (墌p. 16)
FBattery Pack Mount
Remote Control
QInfrared Beam Transmitting Window
RZOOM (T/W) Buttons
(Zoom in/out during playback.)
SUp Button
Rotate Button (counterclockwise)
TSkip Backward Button
ULeft Button
VBack Button
WPLAYLIST Button
XSTART/STOP Button
YSNAPSHOT Button
ZINFO Button
aSkip Forward Button
bPLAY/PAUSE Button
cRight Button
dNext Button
eDown Button
Rotate Button (clockwise)
fINDEX Button
gDATE Button
NOTE
You can move the zooming area with the up/
down/left/right button during zoom in playback
mode.
Camera
! Index Button [INDEX]/Remaining Space
Button/Data Battery Button
[ 0/ 1] (墌p. 16)
#Set Lever
Move to ¡:
Reverse Skip (墌p. 24)/Up/Backlight
Compensation Button [ -]
Move to ¢:
Forward Skip (墌p. 24)/Down/Manual
Focus Button [FOCUS]
Move to £:
Reverse Search (墌p. 24)/Left/Light
Button [LIGHT] (墌p. 22)
Move to ¤:
Forward Search (墌p. 24)/Right/Program
AE Button [PROGRAM AE] (墌p. 23)
Press down:
Play/Pause (墌p. 24)
$Menu Button [MENU]
%LCD Monitor
&Speaker
(Fan outlet
)Access Lamp [ACCESS] (Blinks when you
access files. Do not turn off the power or
remove the battery pack/AC adapter while
accessing files.)
Power/Charge Lamp [POWER/CHARGE]
(Blinks when you charge the battery.)
*Zoom Lever [W 7,T ,] (墌p. 22)
Speaker Volume Control [–VOL+] (墌p. 24)
+Still Image Shooting Button [SNAPSHOT]
(墌p. 21)
,Auto/Manual Mode Button [AUTO] (墌p. 23)/
Information Button [INFO]
-Power Button (You can turn off the camera
by pressing and holding this button.)
.Direct Disc Button [DIRECT DISC]/
Focus Assist Button [FOCUS ASSIST]
/Fan inlet
0Direct Backup Button [DIRECT BACK UP]/
Quick Review Button [QUICK REVIEW]
(墌p. 20, 21)
1Delete Button [ *]
2Playback/Recording Mode Switching Button
[PLAY/REC] (墌p. 20, 21)
3Audio/Video Connector [AV] (墌p. 27, 33)
4Component Connector [COMPONENT]
(墌p. 26)
5Mode Switch [!, #]
6Video Recording Start/Stop Button [START/
STOP] (墌p. 20)
7Stereo Microphone
8Grip Strap (墌p. 18)

14 EN
Indications on LCD Monitor
During both Video and Still Image
Recording
WT
0
FOCUS
200X
1/4000
LCD
1080p
16:55
20.01.2008
!Selected Recording Mode Indicator
(墌p. 23)
#Tele Macro Mode Indicator
$Approximate Zoom Ratio
%Output with 1080p
&Quick Review Indicator
(Zoom Indicator
)Focus Assist Indicator
*Shutter Speed
+Brightness/Sharpness Control Indicator
,Battery Indicator
-Date/Time
.Manual Focus Adjustment Indicator
/Monitor Backlight
0Selected Recording Medium Indicator
1Drop Detection Indicator (Appears when
[DROP DETECTION] is set to [OFF].)
2Effect Mode Indicator
3Program AE Mode Indicator (墌p. 23)
4White Balance Indicator
5LED Light Indicator (墌p. 22)
6±0 : Exposure Adjustment Indicator
-: Backlight Compensation Indicator
.: Spot Exposure Control Indicator
C: Iris Lock Indicator
During Video Recording Only
REC
0:04:01
[4h59m]
XP
xvC
!Mode Indicator (墌p. 20)
#Wind Cut Indicator
$x.v.Colour™
%Picture Quality
&Remaining Time (墌p. 20, 38)
(Counter
)MREC : (Appears during recording.)
(墌p. 20)
MQ: (Appears during record-standby
mode.)
*Shooting Indicator (墌p. 20)
+Microphone Input Level Indicator
,Event Indicator (墌p. 22)
-Digital Image Stabiliser (DIS) Indicator
(Appears when [DIS] is set to [OFF].)
During Still Image Recording Only
[9999]
FINE
10
1920
F4.0
!Mode Indicator (墌p. 21)
#ISO Sensitivity
(GAIN): When set to [AUTO], there is no
indication.
$Focus Indicator (墌p. 21)
%Image Size
&Picture Quality
(Remaining Number of Shots (墌p. 38)
){: Continuous Shooting Mode Indicator
J: Bracket Shooting Mode Indicator
*Shooting Indicator (墌p. 21)
+Self-Timer Indicator
,Aperture Value (F-number)

15
EN
During Video Playback
1:55:01
X-60
XP
xvC1080p
16:55
20.01.2008
!Mode Indicator (墌p. 24)
#6: Playlist Playback Indicator (Appears
when playing back a playlist.)
$Output with 1080p
%x.v.Colour™
&Picture Quality
(Playback Mode (墌p. 24)
F:Playback
Q:Pause
K:Forward Search
J:Reverse Search
QF : Forward Slow-Motion
PQ : Reverse Slow-Motion
(The number on the left shows speed.)
)Counter
*Volume Level Indicator
+Battery Indicator
,Date/Time
-Effect Mode Indicator
.Wipe/Fader Effect Indicator
During Still Image Playback
101-0098
16:55
20.01.2008
1080p
!Mode Indicator (墌p. 25)
#Output with 1080p
$Folder/File Number
%Slide Show Playback Indicator (墌p. 25)
&Battery Indicator
(Date/Time
Operation guide display
The operation guide is displayed at the
bottom of the screen during menu display
etc.
SELECT SET QUIT

16 EN
Necessary Settings before Use
Charging the Battery Pack
1Close the LCD monitor to turn off the
camera.
2Attach the battery pack.
BATT.
3Connect the AC adapter.
•The power/charge lamp blinks to indicate
charging has started.
•When the lamp goes out, charging is
finished.
Required charging/recording time (approx.)
* When the LED light is off and the monitor
backlight is set to [STANDARD] mode.
Battery pack Charging time Recording
time
BN-VF808U
(Provided) 1 hr. 30 min. 1 hr. 00 min.*
BN-VF815U 2 hr. 40 min. 2 hr. 00 min.*
BN-VF823U 3 hr. 50 min. 3 hr. 05 min.*
NOTE
The actual recording time may shorten
depending on the recording environment, such
as when recording scenes with fast moving.
䡵
To detach the battery pack
Slide and hold BATT. (step 2), then remove
the battery pack.
NOTES
•You can also use the camera with just the AC
adapter.
•Please do not pull or bend the AC adapter
plug and cable. This may damage the AC
adapter.
Checking the Remaining Battery
Power
Preparation:
•Close the LCD monitor to turn off the
camera.
•Attach the battery pack.
!mode: press INDEX twice.
#mode: press INDEX.
INDEX
BATTERY CONDITION
MAX TIME
min
Battery information is displayed for approx.
3 seconds if the button is pressed and
released quickly, and for approx. 15 seconds
if the button is pressed and held for several
seconds.
To return to the normal screen
Press INDEX.
NOTE
The recordable time display should only be
used as a guide. It is displayed in 10 minute
units.
䡵
䡵
DC Connector
AC Adapter
To AC Outlet
(110V to 240V)

17
EN
Date/Time Setting
1Open the LCD monitor to turn on the
camera.
2Press MENU.
MENU
3Select [BASIC SETTINGS].
Select
Set
x.v.Color
REGISTER EVENT
BASIC SETTINGS
GAIN UP
SET QUIT
4Select [CLOCK ADJUST].
Select
Set
SET DATE/TIME
BASIC SETTINGS
LANGUAGE
DATE DISPLAY STYLE
CLOCK ADJUST
MONITOR BRIGHT
RETURN SET QUIT
5Set the date and time.
Select
Set
CLOCK ADJUST
SELECT SET QUIT
DATE TIME
31 1 11 07
2008
Repeat this step to input the day, month,
year, hour and minute.
To return to the previous screen
Move the set lever to £.
To quit the screen
Press MENU.
NOTE
If you do not set the date and time, the [SET
DATE/TIME!] screen appears every time you
turn on the camera.
䡵
䡵
Language Setting
The language on the display can be changed.
1Open the LCD monitor to turn on the
camera.
2Press MENU.
MENU
3Select [BASIC SETTINGS].
Select
Set
x.v.Color
REGISTER EVENT
BASIC SETTINGS
GAIN UP
SET QUIT
4Select [LANGUAGE].
Select
Set
BASIC SETTINGS
LANGUAGE
DATE DISPLAY STYLE
CLOCK ADJUST
MONITOR BRIGHT
SELECT LANGUAGE
RETURN SET QUIT
5Select the desired language.
Select
Set
BASIC SETTINGS
LANGUAGE
DATE DISPLAY STYLE
CLOCK ADJUST
MONITOR BRIGHT
RETURN SET QUIT
To return to the previous screen
Move the set lever to £.
To quit the screen
Press MENU.
䡵
䡵

18 EN
Other Settings
Grip Adjustment
Open the pad and make grip adjustments.
Attaching the Shoulder Strap
Lens Cover
When not using the camera, close the lens
cover to protect the lens.
NOTE
Do not push the lens cover strongly. Doing so
may cause damage to the lens.
Tripod Mounting
Align the camera stud hole with the tripod stud,
and the mounting socket with the screw, and
then rotate the camera clockwise to mount it to
the tripod.
NOTE
Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious
damage to the camera.
Eyelet
Strap Guide
Buckle
Lens Cover
Switch
Lens Cover

19
EN
When Using a microSD Card
If you want to record to a microSD card, the
following 3 operations need to be performed.
•Operations are confirmed on the following
microSD cards.
- Panasonic
- TOSHIBA
- SanDisk
- ATP
Video recording:
Class 4 or 6 compatible microSDHC card
(4 GB, 8 GB)
Still image recording:
microSD card (256 MB to 2 GB) or
microSDHC card (4 GB, 8 GB)
•If other media are used, they may fail to
record data correctly, or they may lose data
that had already been recorded.
•MultiMediaCards are not supported.
QInsert a microSD card
Preparation:
Close the LCD monitor to turn off the camera.
1Open the microSD card cover.
2Firmly insert the card with its clipped
edge first.
3Close the microSD card cover.
To remove a microSD card
Push the microSD card once.
After the card comes out a little, pull it out.
NOTES
•Insert and remove the microSD card only
while the power is turned off. Otherwise, data
on the card may be corrupted.
•Do not touch the terminal on the reverse side
of the label.
䡵
RChange the recording medium
The camera is programmed to record on the
built-in hard disk when it is shipped from the
factory. You can change the recording medium
to microSD card.
Set [REC MEDIA FOR VIDEO] and [REC
MEDIA FOR IMAGE] to [SD].
SFormat a microSD card when using it
for the first time
This will also ensure stable speeds and
operation when accessing the microSD card.
Select [FORMAT SD CARD] to format the
card.
Changing the Menu Settings
1Press MENU.
MENU
2Select the desired menu.
Select
Set
ZOOM
DIS
MANUAL SETTING
COMPENSATE FOR HAND SHAKE
VIDEO QUALITY
XP
SET QUIT
3Select the desired setting.
Select
Set
ZOOM
DIS
MANUAL SETTING
COMPENSATE FOR HAND SHAKE
VIDEO QUALITY
XP
OFF
ON
RETURN SET QUIT
To return to the previous screen
Move the set lever to £.
To quit the screen
Press MENU.
䡵
䡵

20 EN
Video Recording
Preparation: Open the LCD monitor to turn on the camera.
Recording Files
RECORDING
Press PLAY/REC to select the
recording mode.
PLAY/REC
SELECT
Press START/STOP to start
recording.
START
/STOP
REC
[4h59m]
XP
0:01:30
To stop recording
Press START/STOP again.
To view the last recorded scene
Press QUICK REVIEW while recording is
paused. Pressing DELETE during playback
deletes that scene.
To change the picture quality
Change the settings in [VIDEO QUALITY].
䡵
䡵
䡵
Slide the mode switch to select !
(video) mode.
NOTES
•If the camera is not operated for 5 minutes while the power is on, it turns itself off automatically
to conserve power. To turn on the camera again when using the battery pack, close the LCD
monitor and open it again. When using the AC adapter, perform any operation such as zooming.
•A new file will be created for every 4 GB.
•Do not move or shake the camera suddenly during recording. If you do so, the driving sound
(hum) of the hard disk may be recorded.
To record a still image during video
recording
Press SNAPSHOT (Up to 3 times in a row).
䡵
Approximate remaining
time for recording
