JVC CS-V623 User manual

SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.MA008
2003/7
CAR STEREO SPEAKER
MA00820037CS-V623
SPECIFICATION
Design and specifications are subject to change without notice.
Type 16 cm (6-1/2") 2-Way Coaxial Speaker, Door/Rear mounting
Power Handling Capacity 150 watts (MAX. MUSIC POWER)
Impedance 4 Ω
Magnet Mass 228 g (8 oz)
Mass 0.85 kg (1.9 lbs)
46.528 UNIT : mm
124
7- 5 HOLES
142
173.6
80
Area Suffix
U ------ Other Areas
Service maintenance does not
apply to this product.

1-2 (No.MA008)
SECTION 1
PRECAUTION
1.1 Safety Precautions
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 ACCESSORIES
!Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Speaker Cord (4 m) -------------------- x 2
Grille Ass'y -------------------------------- x 2
Screw ( 4 x 25 mm) ------------------ x 8
Speed Nut -------------------------------- x 8

(No.MA008)1-3
SECTION 3
DISASSEMBLY
This service manual does not describe DISASSEMBLY.
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLE SHOOTING
This service manual does not describe TROUBLE SHOOTING.

(No.MA008)
AV & MULTIMEDIA COMPANY MOBILE ENTERTAINMENT CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
