SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.MA021
2003/7
CAR STEREO SPEAKER
MA02120037CS-VP428
SPECIFICATION
Design and specifications are subject to change without notice.
Type 10cm (4") 2-Way Coaxial Speaker, Door/Rear mounting
Power Handling Capacity 100 watts (MAX. MUSIC POWER)
Impedance 4 Ω
Magnet Mass 153 g (5.4 oz)
Mass 0.54 kg (1.2 lbs)
4- 4.8 HOLES
114.8
45.5 19.9
UNIT : mm
140.4
70
101.5
Area Suffix
UF ------ China
Service maintenance does not
apply to this product.

1-2 (No.MA021)
SECTION 1
PRECAUTION
1.1 Safety Precautions
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 ACCESSORIES
!Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Speaker Cord (4 m) -------------------- x 2
Speed Nut -------------------------------- x 8
Metal Net --------------------------------- x 2
Grille --------------------------------------- x 2
Screw ( 4 x 25 mm) ------------------ x 8

(No.MA021)1-3
SECTION 3
DISASSEMBLY
This service manual does not describe DISASSEMBLY.
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLE SHOOTING
This service manual does not describe TROUBLE SHOOTING.

(No.MA021)
AV & MULTIMEDIA COMPANY MOBILE ENTERTAINMENT CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
