JVC
CD RECEIVER
RECEPTOR CON CD
RECEPTEUR CD
IVIP3
WMA
KD-APD89/KD-PDR80
KD-APD89/KD-PDR80
KD-APD89/KD-PDR80
[illDO~i <:SA ;~ u?)' Rd·@
OIOITALAUO'O :ADIO rv a 10
I TEXT I READY READY
For canceling the display demonstration, see page 5.
Para cancelar la demostraci6n en pantalla, consulte la pagina 5.
Pour annuler la demonstration des affichages, referez-vous a la page 5.
For installation and connections, refer to the separate manual.
Para la instalaci6n y las conexi ones, refierase al manual separado.
Pour I'installation et les raccordements, se referer au manuel separe.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information forfuture
reference.
Model No.
Serial No.
GET0519-001A
[J)

Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION {For U.S.A.}
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
1S of the FCC Rules. These limits are designed to prOVide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consuit the dealer or an experienced radiolTV technician for help.
Caution:
Changes or modifications not approved by JIJ.C could void the user's authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all serVicing to
qualified service personnel.
3. CAUTION: (For U.s.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
CAUTION IrTTENTION
AVISO
VARNING ttt CAUTION
VISIBLE AND/OR RAYDNNEMENT LASER RAOIACION LASER
SYNUG OCH/EllER .:.:HII< cc;tI V1S1BLE AND/OR
INVISIBLE CLASS 1M VISIBLE ET IOU
DE ClASE 1M OSYNlIG &fJ./lt:1HiiJtl INVISIBLE CLASS n
LASER RADIATION INVISIBLE DE ClASSE VISIBlE VIO INYISIBlE LASERSTRALNING. 0')'5;:t.1M
LASER RADIATION
WHEN OPEN. DO NOT 1M UNf FQIS OUVERT. CUANOO ESTA
KLASS 1M. NAR DENNA v-<f-ttttb
l
WHEN OPEN.
VtEW DIRECTLY WITH HE PAS AEGARDER
ABIERTO. NO MIRAR
DEL.i.R QF'PNAO.
l:Ilt:t. 00
NOT STARE
OPTICAlINSTAUMENTS.
DIRECTEMENT AVEC DIRECTAMENTE BETRAKTA EJ
~".It'11i
INTO BEAM.
IEC60825-1:2001 DES INSTRUMENTS CON INSTRUMENTAL STRA!..EN MEG OPTISKA
IfiL\-e(t':~~1,
FDA 21 CFR
(ENG)
OPTIQUES
IFRAi
6P11CO.
(ESP)
INSTRUMENT. ISW8 IJl'NI
(ENG)
2
[European Union only]
KD-APD89 is equipped with the steering wheel
remote control function.
See the Installation/Connection Manual (separate
volume) for connection.

More about this unit 34
Troubleshooting........................................... 39
~ M.
alOtenance 45
..(-
SpeCIficatIons 46
Selecting a preset sound mode ..
General settings-PSM ..
Bluetooth settings .
Title assignment : ; ..
REFERENCES
OPERATIONS
Preparation ..
Basic operations , · 6
•
Using the control paneL ,....................... 6
•
Using the remote controller (RM·RKSO)...... 7
listening to the radio :..................... 8
Disc operations.. 10
listening to the USB.device.......................... 11
EXTERNAL DEVICES
SETTINGS
· Using the Bluetooth
e
devices .
•
Using the Bluetooth cellular phone ..
~ .• U~ing the ~luetooth ~u~o player .
llstemng to the HO RadiO Broadcast :.
listening to the CO changer ..
listening to the satellite radio ..
· listening to the iPod :.
listening to the other external
components .
r-CONTENTS -
I.
· INTRODUCTIONS
How to reset your unit
How to forcibly eject a disc
SOURCE
O+SEL
. [Hold] C -/.
• Your preset adjustments will also be erased (except the
registered Bluetooth device, see pages 12 and 13).
• Be careful not to drop the disc when it ejects.
•If this does not work,reset your unit.
For safety ...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car ...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
"Please Eject" appears on the display.
3 _

How to use the M MODE and SEL
buttons
If you use M MODE or SEL (select), the display and some
controls (such as the number buttons,
~ v /~ A buttons, A/T buttons, and the
control dial) enter the corresponding control mode.
Ex.: When you press number button 1 after pressing
M MODE, to operate the FM tuner.
MODE
To use these controls for original functions, press
M MODE again .
•
However, pressing SEL makes the unit enters a
different mode .
•
Waiting for about 1S seconds (or 30 seconds for
Bluetooth sources) without pressing any of these
buttons will automatically cancels the control.
Caution:
If the temperature inside the car is below O°C (3n),
the movement of animation and text scroll will be
halted on the display to prevent the display from being
blurred .. J'EMJ!! appears on the display.
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
Detaching the control panel
Avoid touching the connectors.
Attaching the control panel
Warning:
If you need to operate the unit while driving, be sure to
look around carefully or you may be involved in a traffic
accident.
Caution on volume setting:
Digital devices (CD/USB) produce very little noise
compared with other sources. Lower the volume before
playing these digital sources to avoid damaging the
speakers by sudden increase of the output level.
_ 4

Preparation
• Cancel the display demonstration and set the clock
• See also pages 27 and 28.
Turn on the power.
Enter the PSM settings.
Cancel the display demonstrations
Select "Demo,t' then "Off."
Set the clock
Select "Clock Hr" (hour), then adjust the hour.
Select "Clock Min" (minute), then adjust the minute.
Select "24H/1 2H," then "24Hours" or "1 2Hours."
Finish the procedure.
Changing the display information and pattern
When the power is turned off: Check the current clock time
\WI
Ex.: When tuner is selected as the source
Source operation display
•Ifa station has been assigned a title, station
title appears after about 5 seconds.
• To assign a title to a station, see page 33.
*
Audio level meter display
(see "Level Meter" on page 27)
INTRODUCTIONS 5 _

Basic operations .
89
34
13 14
OJ • TUNER: Select preset station.
• HD RADIO: Select channel.
• SIRIUSIXM: Select category.
• CD/USB/CD-CH: Select folder.
• USB-iPod: Enterthe main menu [Hold].
• iPod: Enter the main menu/Pause playback/
Confirm selection.
• BT-PHONE/BT-AUDIO: Select a registered
device.
[1] • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
!:II Display window
[I] USB (Universal Serial Bus) input jack
[[] Select the sound mode.
~ Flip down the control panel.
• To eject the disc, flip down the control panel
then press ~ on the unit.
[II AUX (auxiliary) input jack
[[J • TUNERlHD RADIO/SIRIUSIXM: Search for
station/channel.
• CD/USB/CD-CH/USB-iPod/iPod: Select track.
• BT-AUDIO: Reverse skip/forward skip.
[]:I • Volume control [Turn].
_ 6
• Select the source [Press]*I.
TUNER*2 -+ SIRIUS*3IXM*3 -+ CD*3-+
USB*3 (or USB-iPod)*3 -+ CD-CH*3/iPod*3
(or EXT IN) -+ BT-PHONE*3 -+ BT-AUDIO*3
-+ AUX IN -+ (back to the beginning)
[IQ] • Select/adjust the sound mode.
• Enterthe PSM settings [Hoid].
ITIJ • TUNERlSIRIUSIXM: Select preset station/
channel.
• CD/USB/CD-CH: Select folder/track/disc (for CD
changer).
• USB-iPod: Seiect preset top menu items.
• BT-PHONE: Dial preset phone number*4.
[gJ • Enterfunctions mode.
• BT-PHONE: Activate Voice Dialing [Hold].
ITIl Change the display information and pattern.
[j] . TUNER: Select the bands.
· USB-iPod: Start/pause playback.
• BT-AUDIO: Start/pause playback.
*1 Holding SOURCE will enter the Bluetooth menu.
*2 When the HD Radio tuner box is connected, the
built-in tuner of this unit will be disable. To listen
to the HD Radio broadcast, refer to "Listening to the
radio" an page 8. For more features, see page 17.
*3 You connot select these sources if they are not ready
or not connected.
*4 For storing preset phone number, see page 16.

Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Using the remote controller (RM-RK50) _
Installing the lithium coin battery (CR202S)
OPERATIONS
;
--- --- ---- -- -------------C:J---CJi I
,
~((U~i
'mmE5T~~k3:1'
C:L._._..... f. _ ... - ..!
Remote sensor
Warning (to prevent accidents and damage);
• Do not install any battery other than CR2025 or its
equivalent.
• Do not leave the remote controller in a place (such
as dashboards) exposed to direct sunlight for a long
time.
• Store the battery in a place where children cannot
reach.
• Do not recharge, short, disassemble, heat the battery,
or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar
tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
IT] • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
W • Changes the FMfAM bands with ~ U.
• Changes the preset stations with D T.
• Changes the folder ofthe MP3fWMAIWAV.
• While playing an MP3 disc on an
MP3-compatible CD changer:
- Changes the disc if pressed briefly.
- Changes the folder if pressed and held.
• While listening to the satellite (SIRIUS or XM)
radio:
- Changes the categories.
• While listening to an Apple iPod:
Conneded to KS-PD100:
- Pauses or resumes playback with 0 ....
- Enters the main menu with ~ U.
(Now ~ UfD Tf .... RfF ~ work as the menu
selecting buttons.)*
* ~ U: Returns to the previous menu.
D ... : Confirms the selection.
Conneded to the USB input jack:
- Enter the main menu if pressed and held.
- Select the desired menu if pressed briefly.
- Fast skip in every layer of the main menu if
pressed and held.
Continued on the next page
7 _

IlJ Adjusts the volume level.
[II Selects the sound mode (iEQ: intelligent equalizer).
[K] Selects the source.
[]] For Bluetooth cellular phone:
- Answers calls if pressed briefly.
- Rejects calls if pressed and held.
[l] • Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the tracks if pressed briefly.
• While listening to the satellite (SIRIUS or XMj
radio:
- Changes the channels if pressed briefly.
Listening to the radio
- Changes the channels rapidly if pressed and
held.
• While listening to an iPod (in menu selecting
mode):
Connected to KS-PD100:
- Selects an item if pressed briefly. (Then, press
D ... to confirm the selection.)
- Skips 10 items at a time if pressed and held.
Connected to the USB input jack:
- Start play back the selected folder directly if
pressed and held.
• Reverse skip/forward skip for Bluetooth audio.
~ ... ) Select the bands. [ FM1- FM2 - FM3 - AM J
SOURCE
o
Select'1UNER."
Search for a station to listen-Auto Search.
Manual Search: Hold either one of the buttons until "M" lights up on the display, then
press it repeatedly.
• When receiving an FM stereo broadcast with sufficient signal strength, lights up
on the display.
3 Exit from the setting.
IIOOE

FM station automatic presetting
-SSM (Strong-station Sequential
Memory)
You can preset up to six stations for each band.
1 While listening to a station ...
MODE
m
2_
'0
I ... }
Using the Preset Station list
• When lli'mi9 is shown on the display. you can
move back to the previous screen by pressing number
button 3.
1 Follow steps 1 and 2 of "Using the number
buttons" on the left column.
• By holding ... / .... the Preset Station list will
also appear (go to step 4).
2 MODE
o
7
Ill!ill'l~
FMl P4
• 92. 5MHz
"00i','\
B
'2
(e )
5 Store the station .
rllilil
• You can move to the lists of the other FM bands
by pressing number button 5 ([I!!!I) or
6(il!!!ll) repeatedly.
4 Select the preset number you want to store
into.
C£7
3 Display the Preset Station List.
... ·m'l .. 'K.IfIII"
FMl P4
•92. 5MHz
I or \'
"'lli"I~
FMl
•92. 5MHz
1 00:.';
~
FMl
-SSM-
I 00 '\'
to
Local FM stations with the strongest signals are
searched and stored automatically in the selected
FM band .
•
If an HD Radio tuner box is connected, you
can also search and store the AM station
automatically.
I ... } [Hold]
'0
I ... }
3
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset number
40fthe FMl band.
Using the number buttons
1 ~"'9 rOO-FM2-FM3- AM]
2~
3
Preset number flashes for a while.
OPERATIONS
Continued on the next page
9 _

Pressing (or holding) the following buttons allows you
to ...
Listening to the preset station on
the Preset Station List
1 Display the Preset Station List, then select
the preset station you want to listen to.
2 Change to the selected station.
II1II
C£7*1
[Press] Select track
[Hold] Reverse/fast-forward
track
MP3/WMA: Select folder
7,
>2
CZJ .... €E7
(Number buttons)*2
locate particular folder*3
(for MP3/WMA disc) or track
directly
After pressing M MODE, press the following buttons to ...
~ Skip 10 tracks
~ MP3/WMA: Within the same folder
*1 By holding either one of the buttons, you can display
the Folder List (see page 71).
*2 Press to select number 7 to 6; hold to select number
7t072.
*3 It is required that folders be assigned with 2-digit
numbers at the beginning of their folder names-O 7,
02, 03, and so on.
Repeat Track:
Repeat current track
Repeat Folder:
MP3/WMA: Repeat current folder
8
(2 J
Disc operations
All tracks will be played repeatedly until you change the
source or eject the disc.
Caution:
Make sure to detach the USB device before opening
the control panel, as it might block the opening
mechanism.
• To detach the USB device, see page 12.
To stop play and eject the disc
• Press SOURCE to listen to another playback source.
8
Random Folder:
MP3/WMA: Randomly play all tracks
of current folder, then tracks of next
folders
Random Disc:
Randomly play all tracks
Prohibiting disc ejection
SOURCE
~ + <!ll I IATT
Vf:f;jjf!) [Hold] L - ,J
To cancel the prohibition, repeat the same
procedure.
• You can also cancel the playback mode by selecting
"Off' or press number button 4 (I11III).
• Selecting a folder/track on the list
(only for MP3IWMA file)
• When!IBR is shown on the display, you can
move back to the previous screen by pressing number
button 3.
10

• You can move to the other lists by pressing
number button 5 (!W!!I) or 6( .
repeatedly.
5 Change to the selected item.
® IfFile List is selected
... The list disappears and playback
7 starts.
C,j
MODE
List
[j Folder tl
r~;\, I"
12
a;J
3 Select the list type.
1 MOOE
m
2 Select "LIST."
SOURCE
~
~[TUrnl
Folder - File
4 Select an item.
QV
...
7
® If Folder List is selected
...
7
• If the current folder is selected, File List
appears, then repeat steps 4 and S® to
start playback.
• If another folder is selected, playback starts
from the 1 st file of the selected folder.
Ex.: When "File" is selected in step 3
Listening to the USB device
You can connect a USB mass storage class device such as a USB memory, Digital Audio Player*, portable HOD, etc. to
the unit.
• You can also connect an Apple iPod to the USB input jack. For details of the operations, see pages 22 and 23.
This unit can play MP3/WMAlWMA-DRM10*/WAVtracks stored in a USB device.
* You can connect both MTP (Media Transfer Protocol) devices and USB mass storage doss devices. See also page 36.
USB memory
All tracks will be played repeatedly until you change the source or detach the USB device.
USB input jack
OPERATIONS
Continued on the next page
11 _

Ifa USB device has been attached ...
SOU ACE Playback starts from where it has
a
:) b'ffi ".pp'd '"'00'''
. . • If a different USB device is
currently attached, playback starts
from the beginning.
To stop play and detach the USB device
Straightly pull it out from the unit.
o Press SOURCE to listen to another playback source.
You can operate the USB device in the same way you
operate the files on a disc. (See pages 10 and 11.)
• You can listen to WAY files by following the MP31
WMA files operations listed on pages 10 and 11.
Cautions:
• Avoid using the USB device if it might hinder your
safety driving.
• Do not pull out and attach the USB device repeatedly
while "Reading" is shown on the display.
o Do not start the car engine ifa USB device is
connected.
o This unit may not be able to play the files depending
on the type of USB device.
o Operation and power supply may not work as
intended for some USB devices.
o You cannot connect a computer to the USB input
terminal of the unit.
o Make sure all important data has been backed up to
avoid losing the data.
• Do not leave a USB device in the car, expose to direct
sunlight, or high temperature to avoid deformation
or cause damages to the device.
o Some USB devices may not work immediately after
you turn on the power.
o For more details about USB operations, see pages 3S
and 36.
Using the Bluetooth@ devices
For Bluetooth operations, it is required to connect the
Bluetooth Adapter (KS-BTA200) to the CD changer
jack on the rear of this unit.
o Refer also to the instructions supplied with the
Bluetooth adapter and the Bluetooth device.
• Refer to the list (included in the box) to check
the countries where you may use the Bluetooth@
function.
To use a Bluetooth device through the unit
("BT -PHONE" and "BT-AUDIO") for the first time,
you need to establish Bluetooth wireless connection
between the unit and the device.
o Once the connection is established, it is registered in
the unit even if you reset your unit. Up to five devices
can be registered in total.
o Only one device can be connected at a time for each
source ("BT-PHONE" and "BT -AUDIO").
Registering a Bluetooth device
Registration (Pairing) methods
Use either of the following items in the Bluetooth menu
to register and establish the connection with a device.
o Select "BT -PHONE" or "BT -AUDIO" as the source to
operate the Bluetooth menu.
Open Make the unit ready to establish a new
Bluetooth connection.
Connection is established by operating the
Bluetooth device.
Search Make the unit ready to establish a new
Bluetooth connection.
Connection is established by operating
the unit.
o When _ is shown on the display, you can
move back to the previous screen by pressing number
bunon 3.
_12
OPERATIONS & EXTERNAL DEVICES

Registering using "Open"
Preparation: Operate the device to turn on its
Bluetooth function.
1 Select "BY-PHONE" or "BY-AUDIO."
SOURCE
2 Select "New."
3 Enter setting menu.
[I] Repeat steps OJ and rn until you finish
entering a PIN code.
m Confirm the entry.
_ "Open .. ." flashes on the display.
7
6 Use the Bluetooth device to search and
connect.
On the device to be connected, enter the same
PIN code you have just entered for this unit.
"Connected (and device name)" ap~ears on the
display.
Now connection is established and you can use the
device through the unit.
MODE
-
4 Select "Open."
The device remains registered even after you
disconnect the device. Use "Connect" (or activate
"Auto Connect") to connect the same device from
next time on. (See the following and page 32.)
7
...
Connecting a device
Perform steps 1- 3 on the left column, then ...
1 · Select "Search" to search for available
devices.
The unit searches and displays the list of the
available devices.
If no available device is detected, "Device Not
Found" appears.
• Select "Special" to connect a special device.
The unit displays the list of the preset devices.
7
5 Enter a PIN (Personal Identification Number)
code to the unit.
• You can enter any number you like (l-digit to
16-digit number). [Initial: 0000]
• To enter a PIN code less than 4-digit, firstly
delete the initial PIN code (0000) by pressing
number button 5 (_).
* Some devices have their own PIN code. Enter the
specified PIN code to the unit.
OJ Move to the next (or previous) number
position.
rn Select a number or blank space.
SOURCE -
2 Select a device you want to connect.
tIllY
7
[Turn]
EXTERNAL DEVICES
Continued on the next page
13 _

...
7
...
Press number bunon 3 to select
"No" or return to the previous
screen.
"~"~'ll"~"~'"~
7
""","'--".e
..
-
IJ!t/fII}
..
..
• Select "Delete," then confirm the selection.
4· Select "Connect" or "Disconnect" to
connect/disconnect the selected device.
SOURCE
2 Select a registered device you want to
connect/disconnect/delete.
Connecting/disconnecting/deleting a
registered device
1 Select "BT-PHONE" or "BT-AUDIO."
3· For available devices ...
OJ Enter the specific PI N code of the device to
the unit.
Refer to the instructions supplied with the
device to check the PIN code.
m Use the Bluetooth device to connect.
Now connection is established and you can
use the device through the unit.
• For special device ...
Use "Open" or "Search" to connect.
You can set the unit to connect the Bluetooth device
automatically when the unit is turned on. (See
"Auto Connect" on page 32.)
3 Enter setting menu.
MOOE
-
Using the Bluetooth cellular phone _
Select "BY-PHONE."
Enter Bluetooth menu.
Establish the connection with a device, then make a call (or settings
using the Bluetooth menu).
_14

When a call comes in ....
The source is automatically changed to "BT-PHONE."
When "Auto Answer" is activated ....
The unit answers the incoming calls automatically, see
page 32.
• When" Auto Answer" is deactivated, press any
button (except <!>/I/ATT/control dial) to answer the
incoming call.
To end the call
Hold any button (except <!>/I/ATT/control dial).
• You can adjust the microphone volume level (see
page 32).
When atext message comes in ....
If the cellular phone is compatible with Text Message
and "Message Info" is sello "Auto" (see page 32), the
unit rings and "Received Message" appears on the
display to inform you of the message arrival.
Making a call
You can make a call using one of the Dial Menu items.
• When (IIli9 is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1 Select "BT-PHONE:'
SOURCE
4 Select the method to make a call.
SOURCE
7
• Redial*: Shows the list of the phone numbers
you have dialed. Go to the following step.
• Received*: Shows the list of the received calls.
Go to the following step.
• Phonebook*: Shows the phone book of the
connected cellular phone. Go to the following
step.
• Missed*: Shows the list of the missed calls. Go
to the following step.
• Number: Shows the phone number entry
screen. See "How to enter phone number" on
page 16.
• Voice Dial (Only accessible when the connected
cellular phone has the voice recognition system):
Speak the name (registered words) you want to
call.
* Displayed only when your cellular phone is
equipped with these functions.
- If not displayed, try to transfer the phone book
memory of the cellular phone to this unit.
(Refer to the instruction manual supplied with
your cellular phone.)
- With some cellular phones, the phone book
memory is transferred automatically.
5 Select the name/phone number you want to
call.
2 Enter setting menu.
MODE
3 Select "Dial Menu:'
7
«1' J
EXTERNAL DEVICES
7
Continued on the next poge
15 _

SOURCE
2 Select a phone number .
•
You can also enter a new phone
number (see also "How to enter
phone number" on the left column)
to store.
.. Presetting the phone number
You can preset up to six phone numbers.
• When'" is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1 Display the phone number you want to
preset by using one of the "Dial Menu" items.
Confirm the entry.
Move the entry position.
[Turn] Select a number.
7
..
..
How to enter phone number
4J
J
ii' A!!t'tl' lA"I~M;i' '~.IiXffi"
[Hold]
3 Select a preset number to store.
Using voice command
1MODE "Say ... " appears on the display.
, ••
7B9
'0
"'2
To call a preset number
While in Bluetooth phone ....
2 Speak the name (registered words) you want
to call.
• You can also use voice command from the Dial
Menu. Select "Voice Dial" from the Dial Menu.
• If your cellular phone does not support the voice
recognition system, "Error" appears on the
display.
7B9
'0
"'2
Using the Bluetooth audio player _
• Operations and display indications differ depending on their availability on the connected audio player.
SOURCE
Select IIBT -AUDIO."
If playback does not start automatically, operate the Bluetooth audio player to start playback .
MODE
Reverse skip/forward skip
Start/pause playback
Enter setting menu (Device list)
• Refer also to page 14 for connecting/disconnecting/
deleting a registered device.
Bluetooth Information:
If you wish to receive more information about
Bluetooth, visit the following JVC web site: <http://
www.jvc-victor.co.jp/english/car />.
_16

Listening to the HD Radio ™ Broadcast
1 MODE
-
2
.. Changing HD Radio ~eception
mode
While receiving an HD Radio broadcast, the unit tunes
to digital or analog audio automatically due to the
receiving condition.
1 While listening to an HD Radio station ...
MODE
III Searching for HD Radio stations
only
What is HD Radio Technology?
HD Radio Technology can deliver high-quality digital
sound-AM digital will have FM-like quality (in stereo)
and FM digital will have CD-like quality-with static-
free and clear reception. Furthermore, stations can offer
text and data, such as artist names and song titles.
• When the HD Radio tuner box is connected, it can also
receive conventional analog broadcasts.
• Many HD Radio stations also offer more than one
channel of programming. This service is called
multicasting.
• To find HD Radio stations in your area, visit
www.hdradio.com <http://www.hdradio.com/> .
Before operating, connect HD Radio tuner box,
KT -HD300 (s~parately purchased) to the CD changer
jack on the rear of the unit.
Refer also to pages 8 -10 for basic radio operations.
II When receiving an HD Radio
station ...
Station Call Sign appears.
~.:...-
FMl I., WXYZ-HDl
'.I!. 92. 5MHz
1 :OOMViGmEUI ~
-
28
[Lights up) When holding the digital reception
[Flashes] When holding the analog reception
.. When receiving HD Radio multicast
channels ...
First four letters of Call Sign Channel number
Auto: [Initial] Switch between digital and
analog audio automatically
Digital: Tuning to digital audio only
Analog: Tuning to analog audio only
Select your desired channel.
rHD1-HD2----~HD8J
•If no sound can be heard from the selected setting,
change the setting to "Analog" or "Digital."
• The setting automatically changes to "Auto" if you
tuned in to or change to another station, or if you
turned off the power.
• This setting cannot take effect for the conventional
FM/ AM stations.
•If the radio station forces the reception mode to
digital or analog, the DIGI or ANA indicator lights up.
EXTERNAL DEVICES
17 _

Listening to the CD changer
It is recommended to use a JVC MP3-compatible CD changer with your unit. You can connect a CD changer to the
CD changer jack on the rear of the unit.
• You can only play conventional CDs (including CD Text) and MP3 discs.
Preparation: Make sure "Changer' is selected for the external input setting, see page 29.
Select "CD-CH."
Select a disc to start playing.
[Press] For selecting disc number 1- 6.
[Hold] For selecting disc number 7- 12.
After pressing M MODE, press the following buttons to ...
W Skip 10 tracks
MP3: Within the same folder
Random Folder:
MP3: Randomly play all tracks of
the current folder, then tracks of the
next folder
Random Disc:
Randomly play all tracks of current
disc
Random All:
Randomly play all tracks of the discs
in the magazine
Repeat Track:
Repeat current track
Repeat Folder:
MP3: Repeat all tracks of current
folder
Repeat Disc:
Repeat all tracks of the current disc
B
9
..
MP3: Select folders
[Press] Select track
[Hold] Reverse/fast-forward track
To select a disc/folder/track on the list
See "Selecting a folder/track on the list (only for MP31
WMA file)" on page 11.
Select "Disc" in step 3 to display the Disc list of the CD
changer.
* By holding either one of the buttons, you can display
the Disc List (see page 11).
• You can also cancel the playback mode by selecting
"Off" or press number button 4 (i_).
_18

Listening to the satellite radio
Before operating, connect either one of the following (separately purchased) to the CD changer jack on the rear of
this unit.
· JVC SIRIUS Satellite radio interface, KS-SRA 100, for listening to the SIRIUS Satellite radio.
· JVC Smart Digital Adapter, XMDJVC100, for listening to the XM Satellite radio.
Gel (Global eontrollnformationl update
• If channels are updated after subscription, updating starts automatically.
The following appears and no sound can be heard:
- For SIRIUS Satellite radio: "Updating XX%* Completed"
- For XM Satellite radio: "UPDATING"
• Update takes a few minutes to complete.
• During update, you cannot operate your satellite radio.
* Changes every 20% of update is completion (ex. 20%, 40%, 60%)
EXTERNAL DEVICES
Activate your SIRIUS subscription after
connection
OJ « .. ... )C!>/I/ATT
SIRIUS Satellite radio starts updating all the SIRIUS
channels.
Once completed, SIRIUS Satellite radio tunes in to
the preset channel, CH184.
[II Check your Sirius ID, see page 29.
rn Contact SIRIUS on the internet at
<http://activate.siriusradio.com/> to
activate your subscription, or you can call
SIRIUS toll-free at 1-888-S39-SIRIUS (7474).
"Sub Updated Press Any Key" scrolls on the display
once subscription has been completed.
Activate your XM subscription after
connection
• Only Channel 0, 1, and 247 are available before
activation.
ITJ ..) <!>/I/ATT
I1J SOUACE
XMDirect'· Universal Tuner Box starts updating
all the XM channels. "Channell" is tuned in
automatically.
[II Check your XM Satellite radio ID labelled on
the casing ofthe XMDirect no Universal Tuner
Box, or tune in to "Channel 0" (see page 20).
rn Contact XM Satellite radio on the internet
at <http://xmradio.com/activation/> to
activate your subscription, or you can call
1-800-XM-RADI0 (1-800-967-2346).
Once completed, the unit tunes in to one of the
available channels (Channel 4 or higher).
Continued on the next page
19 _

SOURCE Select "SIRIUS" or "XM."
a
Select the bands.
SIRIUS: [SR1 SR2 SR3 J
XM: [XM1 XM2 XM3 l
Select a category.
SIRIUS: If you select "ALL," you can tune in to all the channels of all categories.
Select a channel to listen .
• Holding the button changes the channels rapidly .
•
While searching, invalid and unsubscribed channels are skipped.
XM: If you do not select a channel within 1S seconds, category selected in step 3
is canceled. You can select all channels of all categories now (including non-
categorised channels).
Checking the XM Satellite radio ID
While selecting "XM1:' "XM2," or ''XM3,'' select
"Channel 0:'
The display alternately shows "RADIO 10" and the
8-digit (alphanumeric) 10 number.
To cancel the ID number display, select any channel
other than "Channel 0."
To change the display information while
listening to a channel
\-/i
Category name - Channel name - Artist!
composer* name - Song/program name -
Audio level meter - (back to the beginning)
* Only for SIRIUS Sotellite rodio.
_20
Storing channels in memory
You can preset six stations for each band .
•
When IBI is shown on the display, you can
move back to the previous screen by pressing number
button 3.
•
When 1!!:!!I/lI!!!!S is shown on the display,
you can move to the other lists by pressing number
button 5 or 6 repeatedly.
Ex.: Storing a SIRIUS channel into preset number 4 of
the SR1 band.
1 Tune in to a channel you want to listen to.
• By holding BAND button, the Preset Channel List
will appear (go to step S).
2 MODE
o
3 Select "LIST:'
..
12
