JVC LET0079-001A User manual

XL-MV338BK
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
whicharelocatedeitherontherear,bottomor
side of the cabinet. Retain this information for
the future reference.
Model No.
Serial No.
LET0079-001A
[UF]
GRAPHICS
'
PlayBack
Control
VIDEO CD PLAYER
1234
5678
9 10 +10
RM-SXMV5U REMOTE CONTROL
DISC 1 DISC 2 DISC 3 POWER
PROGRAM CANCEL
RANDOM
HIGHLIGHT ON SCREEN MPX
REPEAT
VIDEO
INTRO
KEY CONTROL
'
COMPACT
DIGITAL VIDEO
STILL
NEXTPREV
VIDEO CD VERSION 2.0VIDEO CD VERSION 2.0 DESIGNED BY JVCDESIGNED BY JVC JAPAN
POWER
KEY CONTROL
STANDBY
NORMAL
MIN MAX
DIGITAL ECHO
PHONES KEY CONTROL
PBC OFFKARAOKE
XL-MV338 VIDEO CD PLAYER
ON/STANDBY
MIN MAX
MIC 1
MIN MAX
MIC 2
MIN MAX
MIC 3
PlayBack Control
BOOKMARK
SURROUND
REPLACE
VOCAL
VIDEO
INTRO
RETURN
NTSC/PAL COMPATIBILITY
DISC
3
TRIPLE TRAY
VIDEO CD
12345
678910
11 12 13 14 15
16 17 18 19 20
+20
PROGRAM
DOWN NORMAL UP
SELECT
XL-MV338BK/Cover 97.8.4, 9:051

Warnings
IMPORTANT for the U.K.
DO NOT cut off the plug for this equipment. If the plug fitted is
not suitable for the power points in your home or the cable is too
short to reach a power point, then obtain an appropriate safety-
approved extension lead or consult your dealer.
BE SURE to replace the fuse only with an identical approved
type, as originally fitted.
If nontheless the plug is cut off, remove the fuse and dispose of
the plug immediately, to avoid a possible shock hazard by
inadvertent connection to the power supply.
If this product is not supplied fitted with a plug then follow the
instructions given below:
IMPORTANT.
DO NOT make any connection to the terminal which is marked
with the letter E or by a safety ground symbol or coloured green
or green/yellow.
The wires in the lead on this product are coloured in accordance
with the following codes:
Blue : Neutral
Brown : Live
As these colours may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
Caution –– POWER switch!
Disconnect the plug to shut the power off completely. The POWER
switch in any position does not disconnect the unit from the power
source. The power can be remote controlled.
CAUTION
To reduce the risk of electrical shock, fire, etc.:
1. Do not remove screws, covers or any parts.
2. Do not expose this appliance to rain or moisture.
G-1
XL-MV338BK/Safety 97.8.4, 9:122

1. CLASS 1 LASER PRODUCT
2. DANGER:Invisiblelaserradiationwhenopenandinterlockfailedor
defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user service-
able parts inside the Unit; leave all servicing to qualified service
personnel.
LABELS
IMPORTANT FOR LASER PRODUCTS
2 WARNING LABEL PLACED INSIDE THE UNIT
1CLASSIFICATION LABEL PLACED ON REAR ENCLOSURE
CLASS 1
LASER PRODUCT
G-2
DANGER: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgå udsæt-
telse for stråling (d)
VARNING: Osynlig laser-
strålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)
XL-MV338BK/Safety 97.8.4, 9:123

Page 1
English
How to handle CDs
When handling a compact disc, do not touch the surface of the disc
(reflective silver side –– the side without the label).
Since compact discs are made of plastic, they are easily damaged. If
a disc gets dirty, dusty, scratched or warped, the sound will not be
picked up correctly and, in addition, such a disc may cause the CD
player to malfunction.
Which compact discs can be used?
Many types of compact discs are sold for a variety of uses. The Video
CD Player can play the following compact discs:
• Video CD
foraudioand video (moving picture) reproduction,
including multiplex sound.
• Video CD with Playback Control function
featuring menu-type operation and super-fine still
pictures for audio and video (moving picture) re-
production, including multiplex sound.
• CD Graphics (CD-G)
for audio and video (still picture) reproduction,
including multiplex sound.
• Digital Audio CD, including single discs
for audio reproduction.
CDs you can't play back
DonotplaybackCD-ROMs,DVDs,orCD-isonthisequipment. Doing
so may generate a noise which can damage your speakers.
Using the remote control
The remote control is ready to use when its batteries are installed
properly.
To use it, point its infrared light-emitting window toward the display
window of the player and press a button. The operating range of the
remote control is up to about seven meters in front of the player and
within about 30 degrees to each side –– with nothing between the
remote control and the player interrupting the beam path.
If pressing a button on the remote control does not produce any
response, check to make sure it is pointed correctly and try again. If it
still does not function, check the batteries.
Care and handling of
compact discs
GENERAL INFORMATION
Even on label side
Do not damage the label side, stick paper to or use any adhesive on
its surface.
Storage
Make sure that discs are kept in their cases. If discs are piled one on
topofanotherwithouttheirprotectivecases,theycanbedamaged. Do
notputdiscsinalocationwheretheymaybeexposedtodirectsunlight,
or in a place where the humidity or temperature is high. Avoid leaving
discs in your car!
Maintenance of discs
Iftherearefingerprintsorotherdirtadheringtoadisc,wipeitwithasoft
dry cloth, moving from the center outwards.
If a disc is difficult to clean, wipe with a cloth moistened with water.
Never use record cleaners, petrol, alcohol or any anti-static agents.
CAUTION
Sometimes during play noise or images may be garbled. This is
sometimesdueto thedisc.(Itmaynotbeuptoindustrystandards.)
These symptom are caused by the discs, not by the malfunction of
the Player.
GRAPHICS
'
'
PlayBack
Control
COMPACT
DIGITAL VIDEO
XL-MV338BK 97.8.1, 4:57 PM1

Page 2
The Video CD Player must be connected directly to a television set or
anamplifier that is connected to atelevision or monitor. The television
set or the amplifier must have audio input jacks for right and left
channels and a video input jack.
Select a level, dry location free of dust and vibration, and having a
temperature maintained between 5 and 35°C (41 and 95°F).
Connecting player to a TV or amplifier
using the Audio Video cord
Firstconnectthe AudioVideocord—beforeconnectingtheACpower
cord.
Firmly insert the yellow pin plug of the Audio Video cord in the yellow
VIDEOOUTjackontherearpanel of the player; theredpinpluginthe
red AUDIO OUT (RIGHT) jack; and the white pin plug in the white
AUDIO OUT (LEFT) jack. (The RIGHT and LEFT output jacks are for
the right and left audio channels.)
Then make sure that the television, amplifier or receiver is turned off,
disconnect the AC power cord and firmly insert the pin plugs at the
other end of the Audio Video cord into the matching video and audio
INPUT jacks.
BEFORE USING FOR THE FIRST TIME
Basic Connections
Notes
• WhenyouplayaNTSCdiscinPALAUTOmodeonaPALexclusive
TV, the image may get distorted.
(If the signal doesn’t synchronize.)
In this case, reselect the mode to “PAL”.
• Select the mode before you play the disc. If you change the mode
during play, images may get distorted. In this situation stop the
player and reset the mode.
• Whenyou play a NTSC discin PAL AUTO mode ona Multi system
TV,theimagemayblinkfor a moment. This symptomiscausedby
the Player detecting the format of the disc and not caused by a
malfunction of the Player.
Connecting the power cord
IMPORTANT
CheckthesettingoftheLINEVOLTSswitchontherearpanelofthe
player.Changethesettingiftheswitchisnotsetforthemainvoltage
supplied to your home.
With the LINE VOLTAGE switch correctly set and the audio-video
connectors connected, insert the smaller plug of the power cord
firmly into the AC POWER CORD socket on the rear panel of the
player.
Whenthepowercordisconnected, the STANDBY indicator on the
left-handsideoftheplayer’sfrontpanelcomeson.[See“Overview
of controls” for a description of the controls on the player.]
VIDEO
OUT
AUDIO OUT VIDEO OUT SELECT
RIGHT LEFT
PAL
NTSC PAL AUTO
(Yellow)(Red) (White) To input audio jack of
the television/amplifier/
receiver
Audio Video cord
To input video jack of
the television/amplifier/
receiver
Video out select
Set the VIDEO OUT SELECT switch on the rear panel to NTSC, PAL,
or PAL AUTO mode according to your television system.
NTSC .................... for NTSC exclusive TV
PAL ....................... for PAL exclusive TV
PAL AUTO ............ for Multisystem TV
PALAUTOisthemodetodetecttheformatofthe
disc (NTSC/PAL) automatically and play the im-
age on screen the right way.
LINE VOLTS
220V-240V
115V-127V
AC POWER CORD
Wall outlet
AC power cord
Line voltage alteration
What is your power main voltage? Is it between 115 and 127V, or 220
and240V? If the LINEVOLTS switch on therear panel of theplayer is
not set to your power main voltage, disconnect the power cord, if it is
already connected, and change the switch setting accordingly.
XL-MV338BK 97.8.1, 4:57 PM2

Page 3
English
BEFORE USING FOR THE FIRST TIME
Putting batteries in the remote control
Thebattery compartment is located on the backof the remote control.
1. Press down on the triangular mark of the compartment cover,
and slide the cover off to open the compartment.
Installing batteries
Precautions for the safe use of batteries
Observe the following precautions for the safe use of batteries. Their
life will be shortened, they may burst or their contents may leak if they
are used improperly:
• Removebatteriesfromtheremotecontrolifitisnotgoingtobeused
for a long period of time.
• Remove dead batteries and dispose of them properly.
• Neverleavedeadbatterieslyingaround,takethemapart,mixthem
with other refuse, or throw them into an incinerator.
• Never touch liquid that has leaked out of a battery.
• Do not mix new and old batteries, or batteries of different types,
when replacing them.
2. Place the two accessory R03 (UM-4)/AAA (24F) batteries in
theremotecontrolaccordingtothepolaritymarkings(“+”and
“–”) inside the compartment and on the batteries.
3. Placethecoveroverthecompartment,pressdownlightly,and
push it upward until it snaps on.
The batteries last about one year with normal use. If function of the
remotecontrolbecomeerratic,replacethebatteries.See“Precautions
for the safe use of batteries” below for more information.
XL-MV338BK 97.8.1, 4:57 PM3

Page 4
OVERVIEW OF CONTROLS
Herethebasicfunctionofcontrols onthefrontpanelofthePlayerandthe
remote control are explained. The function of some controls may be
restrictedinactualusedependingontheon-goingoperations.Theremote
control has nine (9) unique function buttons in addition to those on the
player. ThecontrolswithidenticalnamesonthePlayerasontheremote
control have the same function and are used in the same manner.
SELEC
T
PREV
DOWN
POWER
KEY CONTROL
STANDBY
NORMAL
MIN MAX
DIGITAL ECHO
PHONES KEY CONTROL
PBC OFFKARAOKE
NORMAL UP
XL-MV338 VIDEO CD PLAYER
ON/STANDBY
MIN MAX
MIC 1
MIN MAX
MIC 2
MIN MAX
MIC 3
PlayBack Control
BOOKMARK
SURROUND
REPLACE
VOCAL
VIDEO
INTRO
RETURN
NTSC/PAL COMPATIBILITY
DISC
3
TRIPLE TRAY
VIDEO CD
2
3
4
5
78
9
11
12
13
14
15
16
17
20
22
21
1
6
10
Left front panel of the Player
(controls marked (R) have equivalents on the remote control)
1
POWER button (R)
turns the power on and off.
2STANDBY indicator (Red)
lights when the power cord is connected and the power is turned
off.TheSTANDBY indicator is not lit when the playeristurned on.
3
KEY CONTROL button (R)
Transposes the music key.
DOWN button : used to flatten by a half tone.
NORMAL button: returns to original key tone.
UP # button : used to sharpen by a half tone.
4
MODE switch
Switches the KARAOKE/NORMAL/PBC OFF mode.
KARAOKE mode : one track playing mode.
NORMAL mode : continuous plural tracks playing mode. Re-
quired also for the Playback Control (PBC)
function.
PBC OFF mode : inhibits the Playback Control (PBC) function
of the video CD.
5
DIGITAL ECHO knob
adjuststhedegreeoftheechoeffectforthemicrophone(1through
3) and the wireless microphone voice.
6
MIC1 to MIC3 knobs
adjustsvolumeof the microphone corresponding to MIC number.
7
PHONE jack
used for connecting stereo headphones. The volume is set to a
predetermined level and is not adjustable.
8
KEY CONTROL jack
used for connecting a microphone with key control function.
9
MIC jacks (1 through 3)
used for connecting microphones (1 through 3). The jacks corre-
spond to MIC 1 to 3 volume knobs located above.
Center front panel of the Player
10
DISC1 to DISC3 trays
used to load discs. To insert/remove one or up to three (3) discs,
press the 0OPEN/CLOSE button located at the right of the tray
corresponding to disc number.
11
BOOKMARK button
Place a "bookmark" at a video segment you want to find later for
almost instant play. (See page 12.)
12
SURROUND button
Changes the surround mode. (See page 12.)
13
VOCAL REPLACE button
activates the vocal replace function, which inserts your voice in
place of the vocals on the disc.
14
Display window
shows information about the status of operation.
15
VIDEO INTRO button (R)
applies to video CDs only. The introductory five (5) seconds of
tracksonavideoCDaredisplayedonthetelevisionscreeninorder
to present the contents of the video CD. (See page 11.)
16
RETURN button (R)
Utilized for operation with the PBC function. This button is used to
return to a menu screen during play. (See page 14.)
Right front panel of the Player
17
0(OPEN/CLOSE) buttons (Disc number 1 to 3)
Used to open and close disc trays 1 to 3 respectively. When, after
opening the DISC1 tray, another 0(OPEN/CLOSE) button is
pressed, the DISC1 tray is first closed, then the other DISC tray
selected is opened.
18
DISC1 through DISC3 buttons with indicators (Green) (R)
plays the disc of the number indicated on the button. As soon as
the disc begins playing, the indicator blinks.
XL-MV338BK 97.8.1, 4:57 PM4

Page 5
English
OVERVIEW OF CONTROLS
27
CANCEL button
cancels the latest track you have programmed. The latest pro-
grammed track is canceled whenever you press this button. Also
used to cancel a bookmark.
28
REPEAT button
repeats a track or inserted discs from 1 to 3.
29
RANDOM button
changesthedisctrackprogram toarandomsequencefromDISC
1 through 3 respectively.
30
HIGHLIGHT button
appliestoa video CD to see highlightsofa track. Displays the first
(5) seconds of each of nine (9) equal-time segments of the track.
31
MPX button
activates the multiplex function, which switches to NORMAL
(stereo), L-ch monoral and R-ch monoral.
32
ON SCREEN button
controlswhetheror not control and operation status are displayed
on the television screen or monitor.
33
1/ ¡MANUAL SEARCH button
shifts the playing location backward and forward quickly. Holding
down the button causes it to go much faster.
34
4/ ¢AUTO SEARCH button
skips forward or backward from a current track. Holding down the
button causes it to skip tracks much faster.
27
28
29
30
31
32
33
34
26
1234
5678
9 10 +10
RM-SXMV5U REMOTE CONTROL
DISC 1 DISC 2 DISC 3 POWER
PROGRAM CANCEL
RANDOM
HIGHLIGHT ON SCREEN MPX
REPEAT
VIDEO
INTRO
KEY CONTROL
STILL
NEXT
SELECT
PREV
VIDEO CD VERSION 2.0 DESIGNED BY JVC JAPAN
VIDEO
INTRO
RETURN
DISC
3
TRIPLE TRAY
12345
678910
11 12 13 14 15
16 17 18 19 20
+20
PROGRAM
15
16
17 18
19
20
22 23
21
24 25
19
Number keys (1 to 20) (R:1 to 10)
used to specify a track number for playing, changing, or program-
ming.Tooperatenumbersabovetwenty(20),pressthe+20button
once. The number keys (1 to 20) are then assigned 21 to 40
numbersinsteadof1to20.Themaximumkeynumberassignment
is 99.InPBCfunctionoperation, the numberkeysareadditionally
utilized for the selection of menu items. See page 14 “ Operation
of Playback Control function”.
20
3SELECT (PLAY) button (R)
Starts to play the disc with/without the Playback Control function.
21
4/ ¢PREV / NEXT buttons
During operation with the Playback Control function
invokes previous or next screen.
During operation without the Playback Control function
skipsforwardorbackwardquicklyfromcurrenttrackbeingplayed.
When pressed and held down, play fast backward/forward. See
page 8.
22
7(STOP) button (R)
Stops play.
23
8STILL (PAUSE) button (R)
temporarily suspends playing. Video motion freezes and audio
reproduction stops. Pressing the button repeatedly advances the
picture frame-by-frame. (Video CD only)
24
PROGRAM button (R)
Any desired sequence of tracks can be programmed with the
numberkeysandthe+20button.(ontheremotecontrolpleaseuse
+10) The program button is not available while the Playback
Control function is activated.
25
+20 button
used to shift the numbers assigned to the number keys to 21 or
higher (maximum 99).
On the remote control unit
26
+10 button
used to shift the numbers assigned to the number keys to 11 or
higher (maximum 99).
XL-MV338BK 97.8.1, 4:58 PM5

Page 6
BASIC OPERATIONS
Now you can play a
variety of video CDs!!
Overview of the three modes
This Player has three (3) modes called KARAOKE, NORMAL, and
PBC OFF mode. These are selected by the MODE switch. This
enables various ways of playing a video CD.
Description of the display window
The display window indicates many aspects of control and operation
status.
4
1 52 3
1
Shows the disc number being played.
2
Shows mainly the total number of tracks and the track number
being played.
3
Showsthesurroundmodestatusandthecumulativetime(minutes
and seconds) of the track and afterward, total time of the disc is
displayed.
4
Thecombinationof VCD,PBC, and CD-G indicators lit shows the
type of disc being played.
5
Each indicator in this area lights when the corresponding function
is activated.
KARAOKE mode:One track playing mode. Whenever one track has
completed play, the Player stops.
NORMAL mode: Continuouspluraltracksplayingmode.ThePlayer
plays tracks continuously in the order they appear
on the disc.
PBC OFF mode: This mode is identical to the NORMAL mode,
except that the PBC function is inhibited.
To set the mode, switch the MODE switch on the left side of the front
panel.
Triple disc tray usage
Uptothree (3)discscanbe loadedinthePlayer. Youmayinserta disc
into any of the disc trays 1 through 3 whichever you prefer.
If you want to play only a specified disc, press the corresponding disc
1, 2 or, 3 button located to the right of the 0(OPEN/CLOSE) button.
Whenthreediscsare ininserted,basicorderof playingisasfollowing.
• Pressing DISC 1: DISC 1 =DISC 2 =DISC 3 =STOP
• Pressing DISC 2: DISC 2 =DISC 3 =DISC 1 =STOP
• Pressing DISC 3: DISC 3 =DISC 1 =DISC 2 =STOP
NORMAL PBC OFFKARAOKE
DISC
3
TRIPLE TRAY
XL-MV338BK 97.8.1, 4:58 PM6

Page 7
English
BASIC OPERATIONS
Preparation for playing
Turnonthetelevisionset,amplifierorreceivertowhichthePlayer
is connected, and then select the proper channel and mode to
operate the Player, and set the sound volume to a reasonable
level.
Press the POWER button on the front panel or remote control.
The STANDBY indicator
goes out.
The display window shows the initial information as shown below.
ON/STANDBY
POWER
STANDBY
Easy start up
Withoutpressingthe POWERbuttonyoucan startupthePlayer by
pressing 3SELECT button or disc buttons.
Inserting/removing the disc(s)
Press the 00
00
0(OPEN/CLOSE) button (1 through 3) to open the disc
tray. Then place the disc in the round recess of the tray with label
side up. To close the tray, press the 00
00
0(OPEN/CLOSE) button
again.
If you press the 0(OPEN/CLOSE) button of the playing disc, the
Player stops and then opens the tray.
If you press the 0(OPEN/CLOSE) button of a disc that is not being
played, you can change discs without stopping play.
Notes
• When loading a disc in the disc tray, be sure to position the disc
inside the recess. Otherwise, the disc will be damaged when the
disc tray is closed, and the disc cannot be removed from the unit.
CORRECT
CD
Tray
INCORRECT
Starting to play disc(s)
Pressthe33
33
3SELECT(PLAY)button. ThePlayerstartstoplayfrom
the disc indicated in the Display window.
PressoneoftheDISC1through3buttonsandthePlayerplaysthe
disc you pressed, from the 1st track. For individual track selec-
tion, use the number keys or the 44
44
4/ ¢¢
¢¢
¢PREV/NEXT buttons.
or
SELECT
When you start play, the Display window shows disc number and the
track number being played.
During play, the indicator on the DISC button blinks.
If the PBC function is activated, the display window shows “Pb” until
youplayatrack,andthetelevisionscreenshowstheinitialmenu,DISC
number, and “PBC”. See page 18, “Operation of Playback Control
function”.
When you press 3SELECT button during play, the disc will restart
from the beginning of the track except when the PBC function is
activated.
Using number keys
Press the number keys to select numbers.
On the Player.................... 1 to 20 and +20 key
Example: For number 5, press 5. For number 15, press 15. For
number32,press+20button,then12. Fornumber42,press+20twice,
then 2.
On the remote control ..... 1 to 10 and +10 key
Example: For number 5, press 5. For number 15, press +10, then 5.
For number 20, press +10, then 10. For number 32, press +10 three
times, then 2.
12345
678910
11 12 13 14 15
16 17 18 19 20
+20
1234
5678
9 10 +10
Note
Whenyou press number keys,track will start playingwithout pressing
3SELECT button.
XL-MV338BK 97.8.1, 4:58 PM7
