JVC ProVerite PS-420W User manual

Digital Signage LCD Display
MODELS:
PS-420W
PS-470W
OWNER’S MANUAL
Signage LCD
S
Signage LCD
S
Signage LCD
S
Signage LCD
S
D
S

1
Important Precautions
Electrical Power Related Precautions
Warning
nUse only the power cord supplied with the unit or another manufacturer’s authorized cord.
- Failure to do so may result in re or electrical shock or damage to the display.
nUse only a properly grounded plug and receptacle.
- If you do not, you may be electrocuted or injured. Or the display might be damaged.
nDo not use a damaged or loose plug.
- This may cause electrical shock or re.
nOperate the display only from a power source (i.e. voltage) indicated in the product
specication.
- Otherwise, the display can be damaged, re can occur or you may be electrocuted. If you are not
sure what type of power supply you have, consult a certied electrician.
nIn the presence of thunder and lightning, never touch the power cord and signal cable because
it can be very dangerous.
- It can cause electric shock.
nDo not connect several extension cords, electrical appliances or electrical heaters to a single
outlet. Use a power bar with a grounding terminal designed for exclusive use with the display.
- A re can break out due to overheating.
nDo not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered with
dust, dry the power plug completely or wipe dust off before plugging in the cord.
- You may be electrocuted due to excess moisture.
nIf you do not intend to use the display for a long time, unplug the power cord from the display.
- Covering dust can cause a re, or insulation deterioration can cause electric leakage, electric shock
or re.
nInsert the power plug rmly so it cannot come loose.
- A loose connection can cause re. Hold the plug when pulling out the power cord.
nDo not pull the plug out by the wire. Do not bend the power cord with excessive force or put
heavy objects on the power cord.
- The power line can be damaged, which may cause electric shock or re.
nDo not insert metal or other conductive materials into the display openings. Additionally, do
not touch the power cord right after plugging the cable into the wall input terminal.
- You may be electrocuted.
nThe power supply cord is used as the main disconnection device. The socket-outlet shall be
installed near the equipment and shall be easily accessible.
nDo not unplug the power cord while the display is in use.
- Electrical shock can damage the product.
nAs long as this unit is connected to the AC wall outlet, it is not disconnected from the AC
power source even if the unit is turned off.
Please read these safety precautions carefully before using the display.
Warning Failure to follow those warnings may result in death, serious injury
or damage to the display or other property.

2
Important Precautions
Important Precautions
Precautions in Installing the Display
Warning
nKeep away from heat sources like heaters or open ames.
- Electrical shock, re, malfunction or deformation may occur.
nKeep the packing anti-moisture material or vinyl packing out of the reach of children.
- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and
visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of
children.
nDo not put heavy objects on the display or sit upon it.
- If the display collapses or is dropped, you may be injured. Children must pay particular attention.
nDo not leave the power or signal cable where someone can trip over it.
- The passerby can falter, which can cause electrical shock, re, display breakdown, or injury.
nInstall the display in a neat and dry place. Do not use near water.
- Dust or moisture can cause electrical shock, re, or display damage.
nDo not add accessories that have not been designed for this display.
nIf you smell smoke or other odors or hear a strange sound from the display, unplug the power
cord and contact Customer Service (Please refer to the label on the rear cover).
- If you continue to use without taking proper measures, electrical shock or re can occur.
nIf you dropped the display or the case is broken, turn off the display and unplug the power
cord.
- If you continue to use without taking proper measures, electrical shock or re can occur. Contact
Customer Service (Please refer to the label on the rear cover).
nDo not drop an object on or apply impact to the display. Do not throw any toys or objects at the
display.
- It can cause injury to humans, problems to the display, and damage the display.
nKeep out of reach of children and do not place toys near the display.
nMake sure the display ventilation hole is not blocked. Install the display more than 10cm away
from the wall.
- If you install the display too close to the wall, it may be deformed or re can break out due to internal
heat build-up.
nDo not cover the display with cloth or other material (eg. plastic) while plugged in.
- The display can be deformed or re can break out due to internal overheating.
nPlace the display on a at and stable surface that is large enough to support the display.
- If the display is dropped, you may be injured or the display may be broken.
nInstall the display where no Electromagnetic Interference occurs.
nKeep the display away from direct sunlight.
- The display can be damaged.
nDo not place the display on the oor.
- Small children and others may trip over it.

3
Important Precautions
Precautions in Moving the Display
Warning
nMake sure to turn off the display.
- You may be electrocuted or the display can be damaged.
nMake sure to remove all cables before moving the display.
- You may be electrocuted or the display can be damaged.
nDo not shock the display when moving it.
- You may be electrocuted or the display can be damaged.
nMake sure the display faces forward and hold it with both hands to move.
- If you drop the display, the damaged display can cause electric shock or re.
nDo not place the display face down.
- This may damage the display.
Precautions in Using/Cleaning the Display
Warning
nDo not attempt to disassemble, repair, or modify the display yourself.
- Fire or electric shock can occur.
- Contact Customer Service (Please refer to the label on the rear cover) for repair.
nWhen cleaning the display, unplug the power cord and scrub gently with a soft cloth to prevent
scratching. Do not clean with a wet cloth or spray water or other liquids directly onto the
display. An electric shock may occur. (Do not use chemicals such as benzene, paint thinners,
or alcohol)
nKeep the display away from water.
- Fire or electric shock accident can occur.
nAvoid high temperatures and humidity.
nDo not put or store ammable substances near the display.
- There is a danger of explosion or re.
nKeep the display clean at all times.
nDo not press on the display with a hand or sharp object such as nail, pencil or pen, or make a
scratch on it.
nKeep proper distance from the display and rest from time-to-time.
- Your vision may be impaired if you look at the display too closely or for too long.
nKeep small accessories out of the reach of children.
nLeaving a xed image on the display for a long time may cause damage to the display and
cause image retention. Make sure to use a screen saver on the display. Burn-in and related
problems are not covered by the warranty on this display.
nSpray water onto a soft cloth 2 to 4 times, and use it to clean the front frame; wipe in one
direction only. Too much moisture may cause staining.

4
Important Precautions
On Disposal (Only, Hg lamp used Display)
nThe uorescent lamp used in this display contains a small amount of mercury.
nDo not dispose of this display with general household waste.
nDisposal of this display must be carried out in accordance to the regulations of your local
authority.
Precautions for Image Sticking
To optimize display lifetime and function, pay attention on the following operation
usages:
nNormal operating condition
- Operating Temperature: 0°C to 40°C
- Operating Ambient Humidity: 10% to 90%
- Display Pattern: dynamic pattern (real display)
Note:
Long-term static display can cause image sticking.
nOperating usages under abnormal condition
a. Ambient condition
- Well-ventilated place is recommended to set up the system.
b. Power and screen saver
- Periodical power-off or screen saver is needed after long-term display.
nOperating usages to protect against image sticking due to long-term static display
a. Suitable operating time
- Under 18 hours a day.
b. Static information display recommended to use with moving image
- Cycling display between 5 minutes information (static) display and 10 seconds moving image.
c. Background and character (image) color change
- Use different colors for background and character, respectively.
- Change colors themselves periodically.
d. Avoid combination of background and character with large different luminance
Note:
1) Abnormal condition just means conditions except normal condition.
2) Black image or moving image is strongly recommended as a screen saver.

5
Accessories
Included Accessories
Thank you for your purchase. Ensure that the following accessories are included
with your display. If an accessory is missing, please contact the dealer where you
purchased the display.
v The accessories included may differ from the images shown below.
Remote Control &
Batteries (AAA × 2)
HDMI Cable Power Cord
*Power Cord for EU
(Optional)
Vesa Mount Screws
(4 pcs)(Size : M6 × L20)
CD-ROM (User’s Manual) Quick Start Guide
DMP Mount Screws
(4 pcs)(Size : M3 × L12)
INPUTPOWER
OK
BACKLIGHT
MENU

6
Portrait Mode
To change the display orientation to Portrait mode, rotate the display counter-
clockwise as shown below.

7
Using the Remote Control
Name of the Remote Control Buttons
Power
Turn the display on/off.
Left
Decrease the• values.
Control the tuning bar.•
Change the • options.
Right
Increase t• he values.
Enter the submenu.•
Change th• e options.
Control the tuning bar.•
Up
M• ove upward on the
selection.
Ch• ange selected item.
Down
Move d• ownward on the
selection.
Change• selected item.
Menu
Display OSD (• on-screen
display) menu.
Return to the previous •
menu.
Exit O• SD menu.
Input
Switch the input source.
Backlight
Adjust brightness level.
Installing Batteries into the Remote Control
1. Open the battery cover.
2. Install the batteries matching the
correct polarity.
Install two 1.5V AAA batteries. •
3. Close the battery cover.
Dispose the • used batteries
in the recycle bin to prevent
environmental pollution.
INPUTPOWER
OK
BACKLIGHT MENU
OK
Enter th• e submenu.
Activate the tuning bar.•
Conrm the selection.•
Display information •
banner (current input
source and resolution).

8
Front View
Name and Function of the Parts
* The image shown in the user’s guide could be different from the actual image.
No. Item Description
1Light sensor/
IR Receiver
Used to detect the current level of visible light in the
surrounding environment.
Receive incoming remote control commands.
2Power indicator Indicate power on or sleep mode status.
- Power on: Green LED lights up.
- Sleep mode: Amber LED lights up.
- Power off: LED off.
1
Name and Function of the Parts
2

9
Name and Function of the Parts
Rear View
No. Item Description
1AC Switch Switch the power supply on/off.
2AC Power Input
Connector
Connect the power cord.
3AC Power Output
Connector
Connect the AC power output.
4HDMI Port Connect an HDMI equipment or an HDMI-DVI adapter
cable to devices such as a DVD player or set-top box.
v HDMI Supports High Denition input and HDCP
(High-bandwidth Digital Content Protection). Some
devices require HDCP in order to display HD signals.
5DVI Port Connect an DVI cable to devices such as a DVD player
or set-top box.
6RGB Port Connect to a PC VGA port.
7Audio system Connect External Audio System or headphones.
8RS-232C Serial
Ports
Connect several displays with serial port.
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
SWITCH IN OUT
5.7-2.2A
AC100-240~, 50-60Hz
3.0-1.2A
POWERVIDEO
HDMIIN DVIIN RGBIN
RS232C
ExternalControl
IN OUT
AUDIO
LINEOUT
SWITCH IN OUT
5.7-2.2A
AC 100-240~, 50/60Hz
3.0-1.2A
POWER VIDEO
HDMI IN DVI IN RGB IN
RS232C
External Control
IN OUT
AUDIO
LINE OUT
1 2 3 4 5 6 7 8
Name and Function of the Parts

10
Connecting to External Devices
PC Connection
Check that the computer, display, and the peripherals are turned off. Then, connect
the signal input cable.
A. Connecting with an HDMI Signal Input Cable
HDMI Connection (480p/576p/720p/1080i/1080p)
HDMI supports high denition input and HDCP (High-bandwidth Digital Content
Protection). Some devices require HDCP in order to display HD signals.
DVI IN RGB IN LINE OUTHDMI IN
AUDIO
IN
DVI IN RGB IN LINE OUTHDMI IN
HDMI to DVI signal cable
RCA-PC Audio cable
Display Display
HDMI signal cable
VCR/DVD/Set-top Box
Note: Dolby Digital is not supported.
VCR/DVD/Set-top Box
Recommended Connection, Resolution & Picture Mode
HDMI Connection, 1080p or 1920x1080@60Hz, dynamic
HDMI IN
Rear side of the display

11
Connecting to External Devices
RGB IN
Rear side of the display PC
MAC
Macintosh Adapter
Use only the standard Macintosh adapter.
Do not use other adapter type that is compatible with different
signaling system.
DVI IN
B. Connecting with a DVI Signal Input Cable
C. Connecting with a D-sub(VGA) Signal Input Cable
Rear side of the display
Audio Out Connection
LINE OUT
Rear side of the display
Audio cable
Connecting to External Devices
Power Connection
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
INSWITCH
Rear side of the display
Power cord

12
Connecting to External Devices
VESA FDMI Wall Mounting
This display supports a VESA FDMI compliant mounting interface. These mounts
are purchased separately. Refer to the instructions included with the wall mount for
more info.
v The handles are designed for carrying.
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
HandleHandle
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
SWITCH IN OUT
5.7-2.2A
AC100-240~, 50/60Hz
3.0-1.2A
POWERVIDEO
HDMIIN DVIIN RGBIN
RS232C
ExternalControl
IN OUT
AUDIO
LINEOUT
PS-420W (42”)
PS-470W (47”)
HandleHandle
Model Name VESA-compatible wall bracket (WxH) Mount holes number
PS-420W 200 x 200 mm 4
PS-470W 400 x 200 mm 4

13
Connecting to External Devices
Screen Adjustment Options (using the Control Panel)
OSD Menus
No. Item Description
1Power switch Turn the display on/off.
2Input Switch the input source.
3Menu Display/hide the OSD (on-screen display) menu or
return to the previous menu.
4Down/Up Select menu item (move up/down).
5Right/Left Adjust the settings (increase/decrease the value),
change the option, control the tuning bar, or enter the
submenu.
6Auto/OK Synchronize the display automatically.
(v only for RGB PC connection)
Enter the submenu, activate the tuning bar, or conrm
selection/setting.
7Power Turn the display on from standby or off to standby.
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
SWITCH IN OUT
5.7-2.2A
AC 100-240~, 50/60Hz
3.0-1.2A
POWERVIDEO
HDMI IN DVI IN RGB IN
RS232C
External Control
IN OUT
AUDIO
LINE OUT
SWITCH
INPUT MENU DOWN UP RIGHT LEFT AUTO/OK POWER
2 3 4 5 6 71

14
OSD Menus
Menu Options
Icon Menu Description
Adjust and rene the picture displayed on your
display based on ambient room light and personal
preferences.
SOUND Adjust the audio settings.
SETUP Adjust the general settings such as OSD language,
OSD rotation, and etc.
INFORMATION Display the system information of the display.
Note OSD (On Screen Display)
The OSD function enables you to adjust the screen status conveniently
since it provides graphical presentation.
PICTURE MODE
BRIGHTNESS
CONTRAST
SHARPNESS
BACKLIGHT
COLOR TEMPERATURE
50
51
1
55
USER

15
OSD Menus
OSD Indicator for Control Panel
OSD Menus
Icon Item Description
Power Turn on/off the display set.
AUTO Perform AUTO function (Only VGA source).
OK
Enter next form.•
Exit from tuning bar.•
Activate the tuning bar.•
Left
Decrease the values.•
Activate the tuning bar.•
Change the options.•
Right
Increase the values.•
Enter next form.•
Change the options.•
Activate the tuning bar.•
Up Move the focus vertically.•
Change the selected item.•
Down Move the focus vertically.•
Change the selected item.•
Menu
Display user menu.•
Return to last form. •
Exit user menu.•
Input Switch input sources.
OK
For HDMI/DVI Source:
AUTO
For VGA Source:
Note If icons are colored in gray, the system is in a state such that those keys
are not active.

16
OSD Menus
Adjusting On-Screen Display (OSD) Settings
OK
OK OK
OK
MENU
OK
MENU
OK
1Press the MENU button to display the OSD menu.
2Use the p/q button to select the main menu.
3Press the OK or u button to enter the selected menu screen.
4Use the p/q button to select the menu item.
5Press the OK or u button to enter the submenu.
6Use the t/u button to adjust the setting/select the option.
7Use the OK button to conrm the setting.
8Press the MENU button to return to the previous menu/exit the OSD menu.
Adjusting the Screen Automatically
(*operation using the remote control)
When the display is connected to the computer using the VGA cable, press the
Auto/OK button on the control panel to synchronize the display automatically. The
optimal screen setting will be selected to suit the current mode. If the adjustment is
not satisfactory, you can adjust the screen manually.
Display
OSD
menu
Select
a main
menu
Enter the
selected
menu
Select
a menu
item
Enter the
submenu
Adjust the
setting
Conrm
the
setting
Return
to
previous
menu

17
OSD Menus
Adjusting Screen Color
OSD Menus
MODE
Select a preset view option optimized for different viewing conditions.
DYNAMIC• : This mode is normally used in department store,
Backlight and Sharpness is set to its maximum value. Saturation
of Color becomes high. You can see very bright, clear, and sharp
image.
NORMAL• : This mode shows normal and natural image.
MILD• : This mode is normally used in movie. Soft image can be seen
in this mode. The picture is somewhat darker than other mode.
USER• : User can use the user-dened settings as they wish.
BRIGHTNESS: Adjust the brightness setting.
CONTRAST: Adjust the difference between the light and dark levels in
the picture.
SHARPNESS: Adjust the sharpness of the edges of elements in the
picture.
BACKLIGHT: Adjust the backlight that affects the overall brilliance of
the picture.
Note If the ‘PICTURE MODE’ setting in the PICTURE menu is set to
DYNAMIC, NORMAL, or MILD, the subsequent menus (BRIGHTNESS,
CONTRAST, SHARPNESS, and BACKLIGHT) will be automatically set.
PICTURE MODE
BRIGHTNESS
CONTRAST
SHARPNESS
BACKLIGHT
COLOR TEMPERATURE
50
50
1
55
MILD
PICTURE MODE
BRIGHTNESS
CONTRAST
SHARPNESS
BACKLIGHT
COLOR TEMPERATURE
50
51
1
55
USER

18
OSD Menus
Adjusting Screen Color
COLOR
TEMPERATURE
Adjust color settings.
COOL• : Select this option to adjust color setting to slightly
purplish white.
MEDIUM• : Select this option to adjust color setting to slightly
bluish white.
WARM• : Select this option to adjust color setting to slightly
reddish white.
USER• : Select this option to use the user-dened settings.
RED/GREEN/BLUE: Set your own color levels.
COLOR TEMPERATURE
COLORTEMP. MODE
RED
GREEN
BLUE
128
122
115
MEDIUM
COLOR TEMPERATURE
COLORTEMP. MODE
RED
GREEN
BLUE
128
122
115
USER

19
OSD Menus OSD Menus
Adjusting Screen Color
DCR Adjust the brightness of the display to maximize the picture quality.
BLACK
LEVEL
Adjust the contrast and the brightness of the display according to the
black level of the screen.
(v only for HDMI connection)
VGA
ADJUST
Adjust the PC display.
(v only for RGB PC connection)
AUTO ADJUST• : Synchronize the display automatically.
H POSITION• : Move the screen position horizontally.
V POSITION• : Move the screen position vertically.
CLOCK• : Minimize any vertical bars or stripes visible on the screen
background. The horizontal screen size will also change.
PHASE• : Adjust the focus of the display. This item allows you to
remove any horizontal noise and clear or sharpen the image of
characters.
RESET
Reset all PICTURE settings to the factory default settings.
DCR
BLACK LEVEL
VGA ADJUST
PICTURE RESET
OFF
OFF
AUTO ADJUST
H POSITION
V POSITION
CLOCK
PHASE
50
50
50
50
