JVC TH-A5 User manual

SERVICE MANUAL
No.21062
Jan. 2002
COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.
Safety precautions
Important for laser products
Preventing static electricity
Disassembly method
1-2
1-3
1-4
1-5
Wiring connection
Adjustment method
Description of major ICs
1-12
1-13
1-15~33
Contents
DVD DIGITAL CINEMA SYSTEM
TH-A5
TH-A5
Area suffix
A ------------------ Australia
US -------------- Singapore
UB ------------- Hong Kong
UW -- Brazil,Mexico,Peru
UY --------------- Argentina
UJ ------------- U.S.Military
UG ------------------ Turkey,
South Africa,Egypt
SP-XCA5 SP-XSA5 2
XV-THA5 SP-WA5
DIGITAL
SURROUND
DIGITAL
COMPACT
DIGITAL VIDEO
STANDBY
AUDIO/FM MODE
DSP VOLUME SOURCE
DVD DIGITAL CINEMA SYSTEM TH-A5
STANDBY/ON
DISPLAY TV/VIDEO
TOP MENU
AUDIO
ON
TUNER PRESET
ENTER
VCR CHANNEL
TUNING
DVD FM/A M AUX MU TING
STANDBY/ON
VCR
VCR
CONTROL
MENU
TV
AUDIO/
FM MODE SUBTITLE
RETURN STEP
OFF
TV VOLUME
TV CHANNEL
VOLUME
B.SEARCH F.SEARCH
DOWN UP
REW FF
RM-STHA5U
DVDCINEMA SYSTEM
SP-XSA5 2

TH-A5
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer`s warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc.Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground.Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and meausre the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement.Voltage measured any must not exceed 0.75 V
AC (r.m.s.).This corresponds to 0.5 mA AC (r.m.s.).
1.This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
(This regulation does not correspond to J and C version.)

TH-A5
1-3
Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The compact disc player uses invisible
laserradiation and is equipped with safety switches
whichprevent emission of radiation when the drawer is
open and the safety interlocks have failed or are de
feated. It is dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
CLASS 1
LASER PRODUCT

TH-A5
1-4
Preventing static electricity
1.Grounding to prevent damage by static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged,
can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
2.About the earth processing for the destruction prevention by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.
2-1 Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over
it before placing the traverse unit (optical pickup) on it.
2-2 Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
3. Handling the optical pickup
1. In order to maintain quality during transport and before installation, both sides of the laser diode on the
replacement optical pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
2. Do not use a tester to check the condition of the laser diode in the optical pickup.The tester's internal power
source can easily destroy the laser diode.
4.Handling the traverse unit (optical pickup)
1. Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
2. Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup.For specific
details, refer to the replacement procedure in the text.Remove the anti-static pin when replacing the traverse
unit. Be careful not to take too long a time when attaching it to the connector.
3. Handle the flexible cable carefully as it may break when subjected to strong force.
4. It is not possible to adjust the semi-fixed resistor that adjusts the laser power.Do not turn it.
Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for pick-up and how to detach the substrate.
(caption)
Anti-static wrist strap
Conductive material
(conductive sheet) or iron plate
Solder is put up before the card
wire is removed from connector
on the pick up board as shown in
Figure.
(When the wire is removed
without putting up solder, the CD
pick-up assembly might destroy.)
Please remove solder after
connecting the card wire with
when you install picking up
in the substrate.
1.
2.
DVD loading
mechanism
DVD loader board
Pick up board
Card wire
Short land
Connector
DVD mechanism assembly (bottom side)
(These two points are
soldered respectively,
and are made to
short-circuit)

TH-A5
1-5
Remove the four screws Aattaching the top cover
on the both sides of the body.
Remove the two screws Bon the back of the body.
Remove the top cover from behind in the direction of
the arrow while pulling both sides outward.
1.
2.
3.
Disassembly method
Removing the top cover (See Fig.1)
Prior to performing the following procedure, remove
the top cover.
Remove the one screw aand remove the earth wier.
Remove the three screws Cattaching the front panel
assembly on the bottom of the body.
Remove the two screws Dattaching the front panel
assembly on the both sides of the body.
Remove the claw1, claw2 and claw3, and detach the
front panel assembly toward the front.
Disconnect the card wire from the connector DW20
on the DSP board.
1.
2.
3.
4.
5.
Removing the front panel assembly
(See Fig.2A, 2B and 3)
Prior to performing the following procedure, remove
the top cover.
Disconnect the power cord from the connector CW1
on the main board and pull up the cord stopper
upward.
Notes : The power cord is exchangeable.
1.
Removing the power cord (See Fig.4) D
(both side)
Claw2 (both side)
Fig.1
Fig.2A
Fig.2B
Fig.3
Fig.4
A 2
B
Top cover
CC
Claw1
Power cord
stopper
Power cord
Tie band
Front panel assembly
(bottom side)
Front panel
assembly
Front panel assembly
(Inner side)
Rear panel
Claw3
DSP board
Display board
a
(fixing the earth wire)
DW20
CW1

TH-A5
1-6
Prior to performing the following procedure, remove
the top cover and power cord.
Disconnect the harness from the connector NW11 on
the DSP board.
Remove the two screws F, four screws G, five
screws Iattaching the each boards to the rear panel.
Remove the three screws Jattaching the rear panel
on the back of the body.
1.
2.
3.
Removing the rear panel (See Fig.7 and 8)
Removing the tuner pack (See Fig.7 and 8)
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from the connector CON01
on the tuner pack.
Remove the two screws Fattaching the tuner pack
to the rear panel.
1.
2.
Removing the fan motor (See Fig.7 and 8)
Prior to performing the following procedures, remove
the top cover .
Disconnect the harness from the connector NW11 on
the DSP board .
Removing the two screws Hattaching the fan motor
on the rear panel.
1.
2.
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from the connector VW2 on
the jack board.
Remove the four screws Gattaching the jack board
to the rear panel.
Disconnect the connector VW1 on the jack board
and pull up the jack board.
1.
2.
3.
Removing the jack board (See Fig.7 and 8)
Removing the DVD mechanism assembly
(See Fig.5 and 6)
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from the connector J14 and
J21 on the DVD MPEG board.
Remove the two screws Eattaching the DVD
mechanism assembly and pull up with drawing out.
Disconnect the harness from the connector J2 on the
DVD loader board.
1.
2.
3.
F
JJJ
G
H
I
J2
Fig.5
Fig.6
Fig.8
Fig.7
DVD mechanism
assembly
Tuner pack
Jack board
DSP board
Fan motor
NW11
(on the
DSP board)
VW2
VW1
CON01
Rear panel
E
Rear panel
Rear panel
DVD mechanism assembly
J14
J21
DVD
MPEG
board
DVD loader board

TH-A5
1-7
Prior to performing the following procedure, remove
the top cover, front panel assembly, DVD
mechanism assembly, jack board and DSP board.
Disconnect the card wire from the connector CW4
and CW8 on the main board.
Disconnect the harness from the connector CW3 on
the main board.
Remove the five screws Iattaching the speaker
terminals and jack to the rear panel (see fig.7).
Remove the six screws K1 (short) and one screw K2
(long) attaching the main board.
When the rear panel is not removed, pull up the
main board from front side.
1.
2.
3.
4.
5.
Prior to performing the following procedure, remove
the top cover, front panel assembly, DVD
mechanism assembly, jack board, DSP board and
main board.
After removing the solder part soldered to the main
board, remove each screw and remove the heat sink
from Power transistor.
After removing the solder part soldered to the main
board, remove each screw and remove the heat sink
from Power IC.
1.
2.
Removing the main board (See Fig.10)
Prior to performing the following procedure, remove
the top cover, the front panel assembly and jack
board.
Untied the harness band and disconnect the harness
from the connector CW2 on the main board.
Disconnect the harness from the connector NW11 on
the DSP board.
Disconnect the card wire from the connector VW12
on the DSP board.
Pull up the DSP board from the front side upwards
disconnecting the connector DW10, DW13, DW14
and DW15.
1.
2.
3.
4.
Removing the DSP board (See Fig.9)
Removing the power transistor & power IC
(See Fig.10 and 11)
Fig.11
K2
K1
K1
Solder part
Solder part
(Power IC is fixed)
Solder part Solder part
Heat sink
(to which power IC is attached)
Main board
(Reverse side )
(Each power transistor is fixed)
Fig.9
Fig.10
Harness band
CW2
NW11
DW10DW13
CW3 Power ICs
Heat sink
(to which
power
transistor
is attached)
CW4
CW8
DW14DW15
VW12
DSP board Main board
(Rear panel side)
(Front panel side)
Main board

TH-A5
1-8
1.
2.
3.
Prior to performing the following procedure, remove
the top cover, front panel assembly and DSP board.
Disconnect the harness and card wire from the
connector PW1, PW2 and PW5 on the DVD power
board.
Remove the one screw L1 (short) and two screws L2
(long) attaching the DVD power board.
1.
2.
Removing the DVD power board
(See Fig.12)
Removing the power transformer
(See Fig.12)
Prior to performing the following procedure, remove
the top cover.
Cut off the tie band fixing the harness, if needed.
Disconnect the harness from the connector CW2 on
the main board (see fig.9) and PW1, PW2 on the
DVD power board.
Remove the four screws Mattaching the power
transformer.
Prior to performing the following procedure, remove
the top cover and the front panel assembly.
Disconnect the card wire from the connector FW1 on
the display board.
Remove the five screws Aattaching the display
board on the inner of the front panel assembly.
Remove the four screws Battaching the switch
board on the inner of the front panel assembly.
Disconnect the harness from connector FW2 on the
display board, if needed.
1.
2.
3.
4.
Removing the display board & switch
board (See Fig.1 and 2)
<Front panel assembly section>
Prior to performing the following procedure, remove
the top cover, front panel assembly, display board
and switch board.
Remove the switch buttons, if needed.
Remove the three screws Cattaching the front
window on the front panel.
Remove the eight claws fixing the front window on
the front panel.
1.
2.
3.
Removing the front window
(See Fig.2 and 3)
Fig.12
L1
L2 M
Tie band
PW1
PW5
PW2
DVD
power
board Power
transformer
Fig.1
Fig.2
Fig.3
Front panel assembly
(inner side)
Display board
Claw
Switch board
Switch button
B
CCC
FW2
FW1
A
Front panel assembly (front side)
Front window

TH-A5
1-9
Removing the DVD loader board
(See Fig.1 to 3)
Prior to performing the following procedure, remove
the top cover, DVD mechanism assembly and DVD
loader board.
Remove the two screws B and remove the bracket.
Remove the one screw Cfixing the DVD loading
mechanism.
Move the lever in the direction of the arrow X.
Remove the DVD loading mechanism from the DVD
mechanism assembly by moving it in the direction of
the arrow Y.
1.
2.
3.
4.
Removing the DVD loading mechanism
(See Fig.4)
Prior to performing the following procedure, remove
the top cover and DVD mechanism assembly.
Disconnect the card wire from the connector J6 on
the DVD MPEG board.
Disconnect the harness from the connector on the
motor board.
Disconnect the harness from the connector J5 on the
DVD loader board.
Remove the four screws Aattaching the DVD loader
board to DVD mechanism assembly.
Disconnect the card wire from the connector U9 on
the DVD loader board.
CAUTION!! (see fig.3)
Before removing the card wire which
connects the pickup board and DVD loader
board, solder the two soldering parts and
make it short-circuit.
Moreover, while having removed the card
wire, don't remove these solder.
ONE POINT
How to eject the DVD tray manually
(see fig.2)
The white lever of the mark is moved in
the direction of the arrow. Then, the tray will
be opened.
Moreover, the tray is separable from a DVD
mechanism assembly by removing two
screws of the mark (see fig.1) and drawing
out the tray.
1.
2.
3.
4.
5.
<DVD mechanism assembly section>
Fig.1
Fig.2
Fig.3
Fig.4
DVD MPEG board
Connector
Soldering parts
Pick up
board
DVD loading
mechanism
Motor board
Motor board
DVD mechanism assembly
(top side)
DVD mechanism assembly
(bottom side)
DVD mechanism assembly
(bottom side)
DVD loading
mechanism
DVD loader board
J6
J5
U9
A
C
B
X
Y
Bracket
Lever

TH-A5
1-10
Prior to performing the following procedure, remove
the top cover, DVD mechanism assembly, DVD
loader board and DVD loading mechanism.
Remove the four screws Dattaching the DVD
traverse mechanism to DVD loading mechanism.
1.
Removing the DVD traverse mechanism
(See Fig.5)
Removing the holder & DVD MPEG board
(See Fig.6 and 7)
Prior to performing the following procedure, remove
the top cover, DVD mechanism assembly and DVD
loader board.
Remove the two claws1, and remove the holder from
the DVD mechanism assembly as it is pushed down.
Note: When removing only the DVD MPEG board, it is not
necessary to remove this holder.
Remove the four claws2 and remove the DVD
MPEG board from the holder.
1.
2.
ONE POINT
Insert in after uniting with a lower claws,
when inserting DVD MPEG board in holder.
When inserting DVD MPEG board in
holder. (see fig.8)
Fig.5
Fig.6
Fig.7
Fig.8
DD
DVD loading mechanis
m
(top side
)
DVD traverse
mechanism
Claw1
Claw2
DVD MPEG board
DVD mechanism assembly
(bottom side)
DVD MPEG board
Holder
Holder
Holder

TH-A5
1-11
Remove the six bosses and remove the front panel.
Notes: It will be good to use the tool with a flat tip, since it
is hard to remove. Please take care not to damage the
cabinet at this time.
The packing separates. It removes if needed.
1.
2.
Removing the front panel
(See Fig.1 and 2)
Removing the speaker unit
(See Fig.3 to 5)
<Speaker section>
[SP-WA5 /Woofer]
[SP-XSA5 / Satellite speaker]
[SP-XCA5 / Center speaker]
It is exchange in a unit.
It is exchange in a unit.
Remove the four bosses and remove the net
assembly.
Notes: It will be good to use the tool with a flat tip, since it
is hard to remove. Please take care not to damage the
cabinet at this time.
Remove the eight screws Aattaching the speaker
unit to cabinet.
Disconnect the code from the two terminals of the
speaker unit.
1.
2.
3.
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Front panel
Boss
Boss
Packing
Front panel
(inner side)
Net assembly
Speaker unit
Terminals
black
Speaker unit (reverse side)
The tool with
a flat tip
AA
Code
red
Cabinet

TH-A5
1-12
J2
J5
J3
J21
J6
J14
J4
FW3
PW3
PW4
PW2
PW5
PW1
VW1
VW2
3809-001274
3809-001224
3809-001283
3809-001295
3809-001296
AH39-00368A
AH39-00176A
AH39-50001K
AH39-00104A
AH39-00291A
3809-001294
3809-001273
CON01
TUNER PACK JACK BOARD (V-OUT)
MAIN BOARD
SWITCH BOARD
DISPLAY BOARD
DVD MPEG
BOARD
DVD LOADER BOARD
DSP1 BOARD
DSP2 BOARD
DVD POWER BOARD
POWERTRANCE
VW11
DW20
DW15
DW14
DW13
DW23
DW10
DW11 DW31
FU1
FU2
PT1
CW1
CW5
CW6
CW7
CW4 CW3
3
CW2
CW8
CFU3
FU4
RE3 RE4
DW32
NW11
DW12
FW2
FW1
U9
4
4
5
3
45
0
0
0
0
0
0
0
0
0
0
0
6
6
6
6
1
1
1
1
1
2
2
2
2
02
0
2
2
2
9
9
9
9
9
0
0
0
9
9
9
9
9
8
3
Wiring connection
Color codes are shown below.
1 Brown
2 Red
3 Orange
4 Yellow
5 Green
6 Blue
7 Violet
8Gray
9 White
0 Black
43
0
2
98

TH-A5
1-13
Adjustment method
1. Tuner
: 522~1629KHz (9k step)
: 531~1602KHz (9k step)
530~1600KHz (10k step)
*Adjustment Location of Tuner PCB
AM(MW) OSC Adjustment
Output 1~7.0V
Received FREQ.
Adjustment
point
MO
AM(MW) RF
Adjustment
ITEM
603 KHz
MA
Maximum
Output(Fig1-1)
TESTER
MAIN
PCB VT GND
Fig 1-1 OSC Voltage
A
US/UB/
UW/UJ

TH-A5
1-14
Output 28 dB(
FM THD Adjustment
Output
dB)
98 MHz
Figure1-3 FM Auto Search Level Adjustment
Figure1-2 IF CENTER and THD Adjustment
FM S.S.G GND
28 dB
FM S.S.G
Output
GND
Speaker
Terminal
FM
Antenna
Terminal
Distortion Meter
Input
SET
Input
output
Oscilloscope
FM IN
FM Antenna
SET
20 k
GND
Output
GND
Te
Te SET
Input
output
SSG FREQ.
GND
Output
GND
T
TSET
Input
output
60 dB
Minimum Distortion (0.4% below)
(Figure 1-2)
Adjustment
point
(FD) FM DETECTOR COIL
FM Search Level Adjustment
Adjust SVR1 so that “TUNED” of FL T
is lighted (Figure 1-3)
*Adjust FM S.S.G level to 28dB
SSG FREQ.
Adjustment
point
(SVR3)
98 MHz
BEACON
SENSITIVITY
SEMI-VR(20K ) GND
Output
GND SET
Input
output
OUTPUT
AM SSG
450KHZ
INPUT
AM ANT
IN
Speaker Terminal
60cm
AM IF
VTVM Oscilloscope
Maximum output (Figure 1-4)
Figure1-4 AM I.F Adjustment
OUTPUT
AM(MW) I.F Adjustment
SSG FREQ.
Frequency
Adjustment
point
450 kHz
522 kHz
AA
Notes: This set is a non-adjusted set fundamentally. It is adjusted when the tuner pack is exchanged.

TH-A5
1-15
BA5983FM (U6) : 4CH driver
1
2
3
4
5
6
7
8
9
10
11
12
13
14
BLAS IN
OPIN1(+)
OPIN1(-)
OPOUT1
OPIN2(+)
OPIN2(-)
OPOUT2
GND
STBY1
PowVcc1
VO2(-)
VO2(+)
VO1(-)
VO1(+)
Input for Bias-amplifier
Non inverting input for CH1 OP-AMP
Inverting input for CH1 OP-AMP
Output for CH1 OP-AMP
Non inverting input for CH2 OP-AMP
Inverting input for CH2 OP-AMP
Output for CH2 OP-AMP
Substrate ground
Input for CH1/2/3 stand by control
Vcc for CH1/2 power block
Inverted output of CH2
Non inverted output of CH2
Inverted output of CH1
Non inverted output of CH1
I
I
I
O
I
I
O
-
I
-
O
O
O
O
Pin No. Pin No.
Symbol Symbol
I/O I/O
Function Function
15
16
17
18
19
20
21
22
23
24
25
26
27
28
VO4(+)
VO4(-)
VO3(+)
VO3(-)
PowVcc2
STBY2
GND
OPOUT3
OPIN3(-)
OPIN3(+)
OPOUT4
OPIN4(-)
OPIN4(+)
PreVcc
O
O
O
O
-
I
-
O
I
I
O
I
I
-
Non inverted output of CH4
Inverted output of CH4
Non inverted output of CH3
Inverted output of CH3
Vcc for CH3/4 power block
Input for Ch4 stand by control
Substrate ground
Output for CH3 OP-AMP
Inverting input for CH3 OP-AMP
Non inverting input for CH3 OP-AMP
Output for CH4 OP-AMP
Inverting input for CH4 OP-AMP
Non inverting input for CH4 OP-AMP
Vcc for pre block
1.Block diagram
2.Pin function
28 27 26
Vcc
25 24 23 22
10k 20k
21 20 19 18 17 16 15
STAND BY
CH4
Vcc
10k
10k
10k 10k
10k
10k
10k
10k
10k10k 10k
10k
10k
10k
10k
10k
Vcc
Level Shift
Level Shift
Level Shift
Level Shift
STAND BY
CH1/2/3
10k
10k
10k
10k
10k 20k
123456789
10 11 12 13 14
Description of major ICs
3.Truth table2. Pin function1. Pin layout
74VHC574 (DIC16, DIC17) : Flip flop
OE
D0
D1
D2
D3
D4
D5
D6
D7
GND
Vcc
O0
O1
O2
O3
O4
O5
O6
O7
CP
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
Symbol
D0-D7
CP
OE
O0-O7
Function
Data Inputs
Clock Pulse Input
3-STATE Output Enable Input
3-STATE Outputs
Dn
H
L
X
CP
X
OE
L
L
H
On
H
L
Z
H:HIGH Voltage Level
L:LOW Voltage Level
X:Immaterial
Z:High Impedance
:HIGH to LOW transition
Inputs Outputs

TH-A5
1-16
Name
RESET
VCLK
XOUT
XIN/bypass clk_216
1. Pin layout
2. Pin function (1/4)
ZiVA-5 (U8) : DVD controller
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
104
103
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
156 155 154 153 152 151 150 149 148 147 146 145 144 143 142 141 140 139 138 137 136 135 134 133 132 131 130 129 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105
VDD_3.3
VSS
MDATA31
MDATA30
MDATA29
MDATA28
VDD_3.3
MDQM3
VSS
MDATA27
MDATA26
MDATA25
MDATA24
MDATA23
MDATA22
MDATA21
MDATA20
VDD_3.3
MDQM2
VSS
MDATA19
MDATA18
MDATA17
MDATA16
VDDC
VSS
MDATA15
MDATA14
MDATA13
MDATA12
VDD_3.3
MDQM1
VSS
MDATA11
MDATA10
MDATA9
MDATA8
MDATA7
MDATA6
MDATA5
MDATA4
VDD_3.3
MDQM0
VSS
MDATA3
MDATA2
MDATA1
MDATA0
MCLK
VDD_3.3
VSS
MWE
VDD_3.3
HA1
HAD15 HAD14 HAD13 HAD12 HAD11 HAD10
HAD9 HAD8 HAD7
VDD_3.3
VSS
HAD6 HAD5 HAD4 HAD3 HAD2 HAD1
VDD_3.3
VSS
HAD0
HDTACK/WAIT
HIRQ0
UDS/UWE
LDS/LWE
R/W
IRRX1
VSS
VDDC
VSS
VDD_3.3
MADDR9 MADDR8 MADDR7 MADDR6 MADDR5 MADDR4 MADDR3 MADDR2 MADDR1 MADDR0
VSS
VDD_3.3
MADDR10 MADDR11
BA1 BA0
MCS0 MCS1
MRAS MCAS
DAI-DATA
DAI-BCK/SYSCLKBP
DAI-LRCK/IEC958BP
I
2 C_CL
I
2 C_DA
RTS1
RXD1
TXD1
CTS1
VSS
VDD_3.3
SD-DATA7
SD-DATA6
SD-DATA5
SD-DATA4
VSS
VDDC
SD-DATA3
SD-DATA2
SD-DATA1
SD-DATA0
SD-REQ
SD-EN
VSS
VDD_3.3
SD-ERROR
SD-CLK
VSYNC/HIRQ1
RTS2/SPI_CLK
RXD2/SPI_MISO
TXD2/SPI_MOSI
CTS2/SPI_CS
VDD_5
HCS4
HCS3
HCS2
HCS1
HCS0
VSS
VDD_3.3
TRST
TDO
TDI
TMS
TCK
RESET
ALE
VSS
VDDC
HAD3
HAD2
VSS
DA-IEC958 DA-DATA3 DA-DATA2 VSS VDD_3.3 DA-DATA1 DA-DATA0 DA-BCK DA-LRCK DA-XCK VSS VDDC A_VSS1 A_VDD1 A_VDD2 A_VSS2 XVDD XTAL/VCLK216BP XTAL XVSS VSS_RREF VDAC_RREF VDD_RREF VDAC_DVDD VDAC_DVSS VDAC_0 VDAC_VDD0 VDAC_0B VDAC_1 VDAC_VDD1 VDAC_1B VDAC_2 VDAC_VDD2 VDAC_2B VDAC_3 VDAC_VDD3 VDAC_3B VDAC_4 VDAC_VDD4 VDAC_4B HSYNC/IRQ2 VDATA0 VDATA1 VDATA2 VSS VDD_3.3 VDATA3 VDATA4 VDATA5 VDATA6 VDATA7 VCLK
PinNo.
202
105
138
139
Type
I
I/O
O
I
System Services
Description
Active Low Reset. Assert for at least 5-milliseconds in the presence of
clock to reset the entire chip.
Video clock that outputs 27 MHz.
Crystal output. When the internal DCXO is used, a 13.5 MHz crystal
should be con-nected between this pin and the XIN pin.
Crystal input. When the internal DCXO is used, a 13.5 MHz crystal should
be con-nected between this pin and the XOUT pin. When an external
oscillator or VCXO is used, its output should be connected to this pin.
Whenconfigured foranexternal bypassclock,a 216MHzclock shouldbe
connectedtothis pin.Thefrequency ofan externalVCXOcan beeither27
or13.5 MHz.
1. I - input, O - output, OD - open drain, PU - requires external pull-up resistor.
1

TH-A5
1-17
Name
VNW
VDDP
VDD25
XVDD
VDD
VDD_VDAC[4:0]
VDAC_DVDD
A_VDD[2:1]
VDAC_REFVDD
GNDP
GND
GND25
VDAC_DVSS
AVSS[2:1]
VDAC_REFVSS
XVSS
HCS[4:2]/GPIO[41:43]
HCS[1:0]
HA[3:1]
HA[15:0]
HDTACK/WAIT
HIRQ0
HUDS/UWE
HLDS/LWE
HREAD
ALE
MCS[1:0]
MCAS
MRAS
MDQM[3:0]
MA[11:0]
MD[31:0]
MWE
MCLK
BA[1:0]
HSYNC/HIRQ2/
GPIO1[9]
VCLK
VDATA[7:0]/GPIO[1:7]
VSYNC/HIRQ1/
GPIO36
PinNo.
189
12, 20, 111, 152, 167, 181, 196
32, 44, 55, 63, 74, 87, 98, 104
140
30, 80, 145, 173, 205
118, 121, 124, 127, 130
133
142, 143
134
13, 21, 112, 153, 166, 180, 195, 208
29, 79, 146, 172, 204
31, 43, 54, 61, 72, 85, 96, 103
132
141, 144
136
137
190-192
193, 192
206, 207, 2
3-11,14-19,22
23
24
25
26
27
203
50, 49
52
51
97, 86, 73, 62
46, 45, 33-42
102-99, 95-88, 84-81,
78-75, 71-64, 60-57
53
56
47, 48
116
105
106-110, 113-115
184
Type
Power
Power
Power
Power
Power
Power
Power
Ground
Ground
Ground
Ground
Ground
Ground
Ground
O
I
I/O
I/O
I/OD
I/O
I/O
I/O
I/O
I/O
O
O
O
O
O
I/O
O
O
O
I/O
I/O
I/O
I/O
Power and GroundHost Interface
Description
5-V supply voltage for 5V-tolerant I/O signals.
3.3-V supply voltage for I/O signals
3.3-V supply voltage for SDRAM I/O signals
3.3V Crystal interface power
1.8-V supply voltage for core logic
Analog Video DAC Power
3.3V Digital supply for 5 DACs
3.3-V Analog PLL Power
3.3V Analog Video Reference Voltage
Ground for I/O signals
Ground for core logic
Ground for SDRAM I/O signals
Digital VSS for DACs
Analog PLL Ground
Video Analog Ground
Crystal interface ground
Host chip select. Host asserts HCS to select the controller for a read or
write operation. The falling edge of this signal triggers the read or write
operation. General Purpose I/Os 41, 42, and 43, respectively.
Host chip select. Host asserts HCS to select the controller for a read or
write operation. The falling edge of this signal triggers the read or write
operation.
Host (muxed address) address bus. 3-bit address bus selects one of eight
host inter-face registers. These signals are not muxed in ATAPI master
mode.
HA[15:0] is the 16-bit (muxed address and data) bi-directional host data
bus through which the host writes data to the decoder Code FIFO. MSB of
the 32-bitword iswrit-ten first. The host also reads and writes the decoder
internal registers and local SDRAM/ROM via HA[7:0]. These signals are
not muxed for ATAPI master mode.
Host Data Transfer Acknowledge.
Host interrupt. Open drain signal, must be pulled-up via 4.7k to 3.3 volts.
Driven high for 10 ns before tristate.
Host Upper Data Strobe. Host high byte data, HA[15:8], is valid when this
pin is active.
Host Lower Data Strobe. Host low byte data, HA[7:0], is valid when this pin
is active.
Read/write strobe
Address latch enable
Memory chip select.
Active LOW SDRAM Column Address Strobe.
Active LOW SDRAM Row Address Strobe.
These pins are the bytes masks corresponding to MD[7:0], [15:8], [23:16]
and [31:24].They allow for byte reads/writes to SDRAM.
SDRAM Address
SDRAM Data
SDRAM Write Enable. Specifies transaction to SDRAM: read (=1) or
write (=0)
SDRAM Clock
SDRAM bank select
Horizontal sync. The decoder begins outputting pixel data for a new
horizontal line after the falling (active) edge of HSYNC.
Host Interrupt Request 2
General Purpose I/O 9
Video clock. Clocks out data on input. VDATA[7:0].
Clock is typically 27 MHz.
Video data bus. Byte serial CbYCrY data synchronous with VCLK. At
powerup, the decoder does not drive VDATA. During boot-up, the
decoder uses configuration parameters to drive or 3-state VDATA.
General Purpose I/Os [1:7]
Vertical sync. Bi-directional, the decoder outputs the top border of a new
field onthe first HSYNC after the falling edge of VSYNC. VSYNC can
accept vertical synchroni-zation or top/bottom field notification from an
external source. (VSYNC HIGH = bot-tom field. VSYNC LOW = Top field)
Active Low Host Interrupt Pin
General Purpose I/O 36
2. Pin function (2/4)
SDRAM Interface
Digital Video Input/Output
1. I - input, O - output, OD - open drain, PU - requires external pull-up resistor.
1

TH-A5
1-18
Name
SDDATA[7]/VDATA2[7]
/HDMARQ/GPIO24
SDDATA6/VDATA2[6]
/HXCVR_EN/GPIO25
SDDATA5/VDATA2[5]
HDMACK/GPIO26
SDDATA4/VDATA2[4]/
GPIO27
SDDATA3/
VDATA2[3]/GPIO28
SDDATA2/
VDATA2[2]/GPIO29
SDDATA1/
VDATA2[1]/GPIO30
SDDATA0/
VDATA2[0]/GPIO31
SDCLK
SDERROR
SDEN/GPIO33
SDREQ/GPIO32
VDAC_[4B:0B]
VDAC_4
VDAC_3V
DAC_2
VDAC_1
VDAC_0
VDAC_REF
VCLK
ADATA[3:0]/GPIO[4:1]
BCK
LRCK
XCK
IEC958/GPIO14
DAI_DATA/GPIO15
DAI_BCK/
BYPASS_SYSCLK/
GPIO16
DAI_LRCK/
IEC958BP/GPIO17
Pin No.
168
169
170
171
174
175
176
177
183
182
179
178
117, 120, 123, 126, 129
119
122
125
128
131
135
105
155, 154, 151, 150
149
148
147
156
157
158
159
Type
I
I
I
I
O
Analog O
Analog O
Analog O
Analog O
Analog O
Analog O
Analog I
I/O
O
O
O
I/O
O
I
I
I
Description
Compressed data from DVD DSP. Bit 7. In parallel mode, bit 7 is the first
(earliest in time) bit in the bitstream, while bit 0 is the last bit.
Video Data Bus 2, Bit 7
Host DMA Request
General Purpose I/O 24
Compressed data from DVD DSP. Bit 6.
Video Data Bus 2, Bit 6
ATAPI Transceiver Enable
General Purpose I/O 25
Compressed data from DVD DSP. Bit 5.
Video Data Bus 2, Bit 5
Host DMA Acknowledge
General Purpose I/O 26
Compressed data from DVD DSP. Bit 4.
Video Data Bus 2, Bit 4
General Purpose I/O 27
Compressed data from DVD DSP. Bit 3.
Video Data Bus 2, Bit 3
General Purpose I/O 28
Compressed data from DVD DSP. Bit 2.
Video Data Bus 2, Bit 2
General Purpose I/O 29
Compressed data from DVD DSP. Bit 1.
Video Data Bus 2, Bit 1
General Purpose I/O 30
In serial mode, bit 0 should be used as the input, with the unused bits
either used as GPIOs or tied to ground.
Video Data Bus 2, Bit 0
General Purpose I/O 31
Data clock. The maximum frequency is 25 MHz for parallel mode, and
???? MHz for serial mode. The polarity of this signal is programmable.
Error in input data. This signal carries the error bit associated with the
channel data type (if set, the byte is corrupted).
Data enable. Assertion indicates that data on SDDATA[7:0] is valid.
The polarity of this signal is programmable.
General Purpose I/O [33]
Bitstream request. controller asserts SDREQ to indicate that the bitstream
input buffer has available space.
General Purpose I/O 32
Video DAC Bias Bits[4:0]
DAC video output format: R, V, C, or CVBS. Macrovision encoded.
DAC video output format: B, U, C, or CVBS. Macrovision encoded.
DAC video output format: G or Y. Macrovision encoded.
DAC video output format: C. Macrovision encoded.
DAC video output format: CVBS or Y. Macrovision encoded.
Video DACs Reference Resistor. Connecting to pin 136 through
a 1.18K+/- 1% resis-tor is required.
System clock that drives internal PLLs. ZiVA-5 27-MHz TTL oscillator.
(See descrip-tion of VCLK for Digital Video Output.) Also optional video
clock for internal PLLs or external encoder.
PCM Data Out. Eight channels. Serial audio samples relative to BCK
and LRCK. General Purpose I/Os [4:1]
PCM Bit Clock. BCK can be either 48 or 32 times the sampling frequency
PCM Left Clock. Identifies the channel for each sample. The polarity is
programma-ble.
Audio External Frequency clock input or output. BCK and LRCK are
derived from this clock.
PCM data out (IEC-958 format ) or compressed data out
(IEC-1937 format). General Purpose I/O [14]
PCM data input.
General Purpose I/O [15]
PCM input bit clock.
BYPASS_SYSCLK: Alternate function TBS.
General Purpose I/O [16]
PCM left/right clock.
IEC958 input bypass
General Purpose I/O [17]
Parallel DVD/CD or Serial CD Interface
2. Pin function (3/4)
Analog Video OutputAudio InterfaceDigital Mic In
1. I - input, O - output, OD - open drain, PU - requires external pull-up resistor.
1

TH-A5
1-19
Name
IRRX1/GPIO0
IDC_CL/GPIO18
IDC_DA/GPIO19
RTS1/GPIO20
RXD1/GPIO21
TXD1/GPIO22
CTS1/GPIO23
RTS2/SPI_CLK/
GPIO37
RXD2/SPI_MISO/
GPIO38
TXD2/SPI_MOSI/
GPIO39
CTS2/SPI_CS/
GPIO40
TRST
TDO
TDI/GPI0
TMS/GPI1
TCK
Pin No.
28
160
161
162
163
164
165
185
186
187
188
197
198
199
200
201
Type
I
I/O
O
I
O
I
O
I
O
I
I
O
I
I
I
Description
IR Remote Receive. This input connects to an integrated (photo diode,
band pass, demodulator) IR receiver. General Purpose I/O 0
Serial clock signal for IDC data transfer. It should be pulled up to the
positive supply voltage, depending on the device) using an external
pull-up resistor. General Purpose I/O [18]
Serial data signal for IDC data transfer. It should be pulled up to the supply
voltage using an external pull-up resistor. General Purpose I/O [19]
Ready to send, UART1
General Purpose I/O [20]
Receive data, UART1
General Purpose I/O [21]
Transmit data, UART1
General Purpose I/O [22]
Clear to send, UART1
General Purpose I/O [23]
Ready to send, UART2
Serial Peripheral Interface Clock
General Purpose I/O [37]
Receive data, UART2
Serial Peripheral Interface - Master Input/Slave Output
General Purpose I/O [38]
Transmit data, UART2
Serial Peripheral Interface - Master Output/Slave Input
General Purpose I/O [39]
Clear to send, UART2
Serial Peripheral Interface ????
General Purpose I/O [40]
Test reset. BST reset - resets the TAP controller.
This signal must be pulled low.
Test data Out. BST serial data output.
Test data In. BST serial data chain input.
General Purpose Input pin 0.
Test mode select. Controls state of test access port (TAP) controller.
General Purpose Input pin 1.
Test clock. Boundary scan test (BST) serial data clock.
IR
IDC
2. Pin function (4/4)
3. Block diagram
UART1UART2JTAG
1. I - input, O - output, OD - open drain, PU - requires external pull-up resistor.
1
IR GPIO SPI UART1&2ASYNC BUS IDC
SPARC
Microprocessor
Phase
Lock
Loop
ATAPI
SDRAM Controller
System Control Bus
32-128Mbit
SDRAM
Audio
Output
Unit
JTAG Interface
Track Buffer
Processor
Bus Interface Unit
Audio
Input Unit
Decryption
ZiVA
A/V Core
Graphics
Engine
Interlaced/
Progressive
Video
Encoder
Five 10-bit
Video
DACs
CCIR 656
Digital Video
Composite
Y/R
C
Cr/Pr/G
Cb/Pb/B
Downmix
Left/right
Center/subwoofer
Left/ right/surround
IEC 958/1937
Parallel/serial
DVD Interface
I2S Stereo In
Remote Control 13.5 MHz Crystal

TH-A5
1-20
1. Pin layout
2. Block diagram
CS493292 (DIC11) : Audio decoder
A0,SCCLK
DATA7,EMAD7,GPIO7
DATA6,ENAD6,GPIO6
DATA5,EMAD5,GPIO5
DATA4,EMAD4,GPIO4
VD2
DGND2
DATA3,EMAD3,GPIO3
DATA2,EMAD2,GPIO2
DATA1,EMAD1,GPIO1
DATA0,EMAD0,GPIO0
CS
SCDIO,SCDOUT,PSEL,GPIO9
ABOOT,INTERQ
EXTMEM,GPIO8
SDATAN1
VD3
DGND3
SCLKN1,STCCLK2
LRCLKN1
CMPDAT,SDATAN2,RCV958
CMPCLK,SCLKN2
AUDATA2
DC
DD
RESET
AGND
VA
FILT1
FILT2
CLKSEL
CLKIN
CMPREQ,LRCLKN2
A1,SCDIN RD,R/W,EMOE,GPIO11 WR,DS,EMWR,GPIO10 AUDATA3,XMT958 DGND1 VD1 MCLK SCLK LRCLK AUDATA0 AUDATA1
7
8
9
10
11
12
13
14
15
16
17
39
38
37
36
35
34
33
32
31
30
29
1819 20 2122 2324 2526 2728
6543214443424140
RESET
DATA7:0
EMAD7:0
GPIO7:0 CS
RD
R/W
EMOE
GPIO11
SCDIO
SCDOUT
PSEL
GPIO9 A0 SCCLK A1 SCDIN ABOOT INTERQ EXTMEM
GPIO8
DC
DD
MCLK
SCLK
LRCLK
AUDATA[2.0]
XMT958
/AUDATA3
VD[3:1]DGND[3:1]AGNDVAFILT1 FILT2
CMPDAT
SDATAN2
CMPCLK
SCLKN2
CMPREQ
LRCLKN2
SCLKN1
STCCLK2
SDATAN1
LRCLKN1
CLKIN
CLKSEL
WR
DS
EMWR
GPIO10
PLL
Clock Manager
RAM Input
Buffer
Parallel or Serial Host Interface
Framer
Shifter
Input
Buffer
Controller
Digital
Audio
Input
Interface
Compressed
Data Input
Interface 24-Bit
DPS Processing
RAM
Program
Memory
RAM
Data
Memory RAM
Output
Buffer
ROM
Program
Memory
ROM
Data
Memory
STC
Output
Formatter
