TH-L1
Multi-Media Sound System

5.1ch Surround Media System for Multi Sources with 5 Cubic
Front/Center/Surround Speakers and 6-5/16” Subwoofer -- featuring
HDMI Input (1080p Pass-rough)/Output, Connection for iPod,
and USB Host
• Dolby Digital/DTS/Dolby Pro Logic II Decoders
• 360W Total Power
• Plays MP3/WMA/WAV/JPEG (USB), and MPEG-4 ASF/-2/-1
(USB)
• Progressive Scan Output
• HDMI Input (x2: 1080p Pass-rough) and Output
• USB Host
• iPod Terminal (Supports Audio and Video)
• Component Video Input (x2) and Output
• Digital Audio Input (Optical: x2 / Coaxial: x1)
• 5.1ch Surround Media System with 360W High Power
• Variety of Terminals for Multi-Channel/Stereo Sources
• 1080p Pass-rough (HDMI) for HD Source
• Connection for iPod (Cable and Stand included)
• USB Host (2.0 Full-Speed)
• Digital Direct Progressive Scan Output
• Digital Surround Mode for 2ch Sound: Dolby Pro Logic II (Movie/
Music)/All Channel Stereo/Stadium/Game
• 5 Cubic Wall-Mountable Satellite Speakers
(Front/Center/Surround)
• 6-5/16” (16cm) Passive Subwoofer
• Multi-Brand Remote Control (TV/DVD)
Center Unit:
• Playable Formats: MP3 (USB), WMA (USB - No DRM), WAV
(USB - L.PCM), JPEG Digital Still (USB), and MPEG-4 ASF/-2/-
1/DivX • Horizontal Lines of Resolution (500) • Playable System:
NTSC • Digital Direct Progressive Scan Output • Multi-Brand
Remote Control (TV/DVD)
Circuitry:
• Video D/A Converter (12-bit/108MHz) • Audio D/A Converter
(192kHz/24-bit) • Dolby Digital Decoder • DTS Decoder • Dolby
Pro Logic II Decoder • All Channel Stereo Mode • Stadium Mode
• Front Surround Mode • Game Mode
USB Host:
• VFP (Video Fine Processor)
Connection for iPod:
• Play, Pause, Skip, Search • Power Supply
Terminals:
• Analog (RCA) Audio In (Front x 1, Rear, x 2) • Digital (Optical)
Audio In (Front x 1, Rear, x 1) • Digital (Coaxial) In (Rear x 1)
• Composite Video In/Out (Front x 1, Rear, x 2) • S-Video In/Out
(Front x 1, Rear, x 2) • Component Video In/Out (Rear, x 2)
• HDMI Digital Out - 2 (1080p Pass-rough) • USB Host (2.0
Full Speed) • Connection for iPod (Audio/Video, Cable and Stand
Included) • Headphone Out (Front)
On-Screen Language:
• English/French/Spanish
Subwoofer:
• 100 watts min. RMS, driven into 4 ohms at 100Hz, with no more
than 10% total harmonic distortion • Bass Reflex (6 5/16” (16cm)
Cone)
Front Speakers (Magnetically Shielded):
• 40 watts per channel, min. RMS, driven into 3 ohms at 1kHz, with
no more than 10% total harmonic distortion • 1 Way, Bass Reflex
(2 9/16” (6.5cm) Cone x 2, Full Range • Frequency Range
(90Hz - 20kHz) • Wall Mountable
Center Speaker (Magnetically Shielded):
• 100 watts, min. RMS, driven into 4 ohms at 1kHz, with no more
than 10% total harmonic distortion • 1 Way, Bass Reflex (2 9/16”
(8cm) Cone x 1, Full Range, • Frequency Range (90Hz - 20kHz)
• Wall Mountable
Surround Speakers (Magnetically Shielded):
• 40 watts per channel, min. RMS, driven into 3 ohms at 1kHz, with
no more than 10% total harmonic distortion • 1 Way,
Bass Reflex (2 9/16” (6.5cm) Cone x 2, Full Range • Frequency Range
(90Hz - 20kHz) • Wall Mountable
Center Unit:
Dimensions (WxHxD) inches: 4 11/16 x 10 15/16 x 9 11/16
Approximate Weight (lbs./kg): 6.4/2.9
Front Speakers:
Dimensions (WxHxD) inches: 3 15/16 x 4 1/8 x 4 3/16
Approximate Weight (lbs./kg): 0.93/0.42
Center Speaker:
Dimensions (WxHxD) inches: 3 15/16 x 4 1/8 x 4 3/16
Approximate Weight (lbs./kg): 0.93/0.42
Surround Speakers:
Dimensions (WxHxD) inches: 3 15/16 x 4 1/8 x 4 3/16
Approximate Weight (lbs./kg): 1.2/0.5
Subwoofer:
Dimensions (WxHxD) inches: 10 1/2 x 10 11/16 x 6 3/16
Approximate Weight (lbs./kg): 6.4/2.9
Product Description
Product Highlights
DISTRIBUTED BY JVC COMPANY OF AMERICA
A Division of JVC Americas Corp.
1700 Valley Road, Wayne, NJ 07470
www.jvc.com
“JVC” is the trademark of Victor Company of Japan, Limited
General Specifications
Details, Weights & Measurements
Basic Features
