JVC NX-DD30 User manual

COMPACT COMPONENT MD SYSTEM
MD 微型组合系统
STANDBY
DISC IN MD IN
DISC LOADING MECHANISM
0 0REC
SURROUND
MODE
OUTPUT
MODE
PHONES/
LINE OUT
VOLUME
for Digital AudioPlayer
DVD/CD LINE FM/AM MD
LINE
DVD/CD MD
FM/AM
--- +
NX-DD30
Consists of CA-NXDD30 and SP-NXDD30
由CA-NXDD30 及SP-NXDD30 组成
INSTRUCTIONS
使用说明书
LVT1430-002A
[UB]
English
中
文
NX-DD30[UB]-01.fm Page 1 Thursday, November 24, 2005 1:47 PM

G-1
IMPORTANT FOR LASER PRODUCTS / 镭射产品的重要说明
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
注意
为了减少触电、火灾等危险：
1. 请勿擅自卸下螺丝钉、盖子或机壳。
2. 请勿让本机受雨淋或置于潮湿环境中。
CAUTION — Fbutton!
Disconnect the mains plug to shut the power off
completely.
The F button in any position does not disconnect the
mains line.
• When the system is on standby, the STANDBY lamp
lights red.
• When the system is turned on, the STANDBY lamp
lights goes off.
The power can be remote controlled.
注意－ F 开关！
想要完全关闭电源，须将电源插头从插座上拔下。
无论 F 键处于何种位置，主电路仍旧没有关闭。
•当系统处于待机状态时， STANDBY 灯发红光。
•当系统处于开启状态时， STANDBY 灯熄灭。
电源开关可用遥控器进行控制。
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to
get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems
must be considered and local rules or laws governing
the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping
or splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
注意
•切勿堵塞通风口或通风孔。
（如果通风口或通风孔被报纸或布等物堵塞，热量将无
法散出。）
•切勿在本系统上放置明火，如点燃的蜡烛。
•想要丢弃电池时，务必考虑环保问题以及严格遵守当地
关于处理废旧电池相关的法律规定和条例。
•切勿让本机受雨淋、受潮湿、落上或溅上水滴，亦勿在
本机上面放置盛满液体的容器，如花瓶。
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no
user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when
open and interlock failed or defeated. Avoid direct
exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED INSIDE THE UNIT.
1. 一级镭射产品。
2. 注意：请勿打开顶盖板，本机内部没有用户可自行维修
的部件；所有维修工作应由有资格的人员完成。
3. 注意：当内部锁定装置失效或者损坏后，打开盖板可能
会产生可见或不可见的镭射辐射。 应避免受到镭射光
束的直接照射。
4. 标签的复制标示： 注意标签位于机内。
Introd uction
Warnings, Cautions and Others / 警告，注意及其他须知事项
NX-DD30[UB]-02.fm Page 1 Monday, October 24, 2005 8:27 PM

G-2
CAUTION — Proper Ventilation
To avoid risk of electric shock and fire and to protect from
damage, locate the apparatus as follows:
Top/Front/Back/Sides: No obstructions should be placed in
the areas shown by the dimensions
below.
Bottom: Place on the level surface. Maintain
adequate air path for ventilation by
placing on a stand with a height of
10 cm or more.
In addition, maintain the best possible air circulation.
注意 —正确的通风方法
为了防止触电，火灾及避免损坏，
按如下要求放置机器：
上面 / 前面 / 后面 / 侧面： 在图中所示范围中，不应放置任何障
碍物。
底部： 放置在水平面上。 放置在一个高 10 cm
或更高的台上以保留足够的通风道。
此外，如图所示，尽可能保持最佳的空气循环。
15cm
15cm
10cm
15cm
1cm 1cm
10cm
STANDBY
DISC IN MDIN
DISC LOADING MECHANISM
REC
SURROUND
MODE
OUTPUT
MODE
PHONES/
LINEOUT
VOLUME
forDigital Audio Player
LINE
DVD/CD MD
FM/AM
0
0
--- +
Wall or
obstructions
墙壁或障碍物 Front
前面
Main unit
本机
Main unit
本机
Front view
前视图
Side view
侧视图
NX-DD30[UB]-02.fm Page 2 Monday, October 24, 2005 7:58 PM

1
Introduction
Table of Contents
marks refer to operation used frequently. You can quickly learn the general usage of this
product by reading those parts only.
Notes on Operation ............................. 3
Suitable Locations for the Main Unit ................. 3
Condensation.................................................... 3
Cleaning the Main Unit ..................................... 3
Listener's Etiquette ........................................... 3
Playable Disc Types ......................................... 4
Disc Structure ................................................... 6
About the Color System.................................... 6
Special Cautions.................................. 7
Notes on Handling ............................................ 7
Supplied Accessories ....................................... 8
Setting Up the Unit .............................. 9
Part Description ...................................10
Remote Control ...................................11
Inserting Batteries into the Remote Control...... 11
Operating the TV Using the Remote Control.... 12
Connections.........................................13
Connecting the Antennas ................................. 13
Connecting the Speakers ................................. 14
Connecting Other Equipment ........................... 15
Connecting with a TV........................................ 16
When a Clearer Picture Is Desired ................... 16
Connecting the Sub-woofer Equipment ............ 17
Connecting the Power Cord.............................. 17
Basic Operations .................................18
Setting the Clock............................................... 18
Turning On/Off the Main Unit...... 19
Adjusting the Volume.................. 19
Temporarily Turning Off the Sound
(FADE MUTING).......................................... 19
Emphasizing Heavy Bass Sound (AHB PRO).. 19
Using Clear Voice Function .............................. 19
Adjusting Bass/Treble Sound ........................... 19
Changing the Brightness of the Display Window
(DIMMER) .................................................... 19
Listening to Radio Broadcasts
.............................................. 20
Setting the AM Tuner Spacing.......................... 20
Selecting a Radio Station ................................. 20
Storing Radio Stations (Preset) ........................ 21
Tuning in to a Preset Radio Station.................. 21
Changing the Display in the Display Window ... 21
Basic Operations of the DVD Player ...22
Playback ..................................... 22
Changing the Display in the Display Window ... 24
Playing Back from a Position 10 Seconds
Before (One Touch Replay)......................... 24
Stopping Playback...................... 25
Resuming Playback (RESUME) ....................... 25
Pausing Playback ............................................. 25
Advancing Picture Frame by Frame ................. 25
Fast Reverse/Fast Forward
Search ................................... 25
Slow Motion Playback ...................................... 26
Skipping to the Beginning of
a Track................................... 26
Skipping to the Beginning of a Track with
the Number Buttons..................................... 26
Selecting a Track from the Menu Screen ......... 26
Skipping at about 5 minute intervals................. 27
Convenient Functions of the DVD
Player ................................................28
Selecting the Audio Language.... 28
Selecting the Subtitle Language....................... 28
Selecting a View Angle..................................... 29
Magnifying the Picture (ZOOM)........................ 29
Adjusting the Picture Quality (VFP) .................. 29
Enjoying Better Pictures (SCAN MODE).......... 30
Playing Back the Bonus Group......................... 30
Browsable Still Pictures (B.S.P.) ...................... 31
Playing Back the Disc in the Desired Order
(Program Playback) ..................................... 31
Random Playback ............................................ 33
Repeat Playback .............................................. 33
Status Bar and Menu Bar ....................34
Using the Status Bar and Menu Bar ................. 34
Playing Back the Designated Part Repeatedly
(A-B Repeat Playback) ................................ 35
Designate the Time (Time Search)................... 35
Playing Back MP3/WMA/JPEG/ASF
and DivX Discs ..................................36
Playback ........................................................... 36
Setting and Adjusting Surround Mode ..38
Selecting the Surround Mode........................... 38
Adjust the Volume for Each Speaker................ 39
Other Settings................................................... 39
Introduction
Preparation
Basic Operations
Listening to Radio Broadcasts
Listening to Discs
NX-DD30[UB]TOC.fm Page 1 Monday, December 19, 2005 3:27 PM

2
Introduction English
PHONES Function...............................40
Using the Surround Headphones Function....... 40
Changing the PHONES/LINE OUT Terminal
Output .......................................................... 40
Preferences .........................................41
Basic Operations .............................................. 41
LANGUAGE...................................................... 41
PICTURE .......................................................... 41
AUDIO .............................................................. 42
OTHERS........................................................... 42
Language Codes .................................43
Country/Area Codes ............................44
Listening to MDs..................................45
Listening to MDs ......................... 45
Changing the Display in the Display
Window .................................. 46
Fast Reverse/Fast Forward
Search.................................... 46
Skipping to the Beginning of
a Track ................................... 46
Specifying the Track (Direct Track Selection)... 46
Group Playback of an MD................................. 47
Program Playback of an MD............................. 47
Random Playback of an MD............................. 48
Repeat Playback of an MD............................... 48
Searching Titles of an MD ................................ 48
Listening to Other Equipment ..............50
Changing the Display in the Display Window ... 50
Recording Sound to
MDs ..................................... 51
Things You Should Know about
MD Recording .............................................. 51
Recording All Tracks from a Disc to an MD...... 52
Quitting Recording............................................ 52
Recording Only One Track from a Disc ............ 53
Recording the Second or Subsequent Track
to the Last Track from a Disc ....................... 53
Program Recording from a Disc ....................... 53
Changing the Display in the Display Window
during Recording.......................................... 53
Recording Sound from Radio or
Other Equipment.......................................... 53
Quitting Recording............................................ 54
Giving (Editing) Titles ..........................55
Things You Should Know about Editing ........... 55
Giving (Editing) Titles ....................................... 55
Entering Titles................................................... 56
Available Characters ........................................ 56
Editing Tracks......................................57
Dividing a Track into Two Tracks (DIVIDE) ...... 57
Joining Tracks (JOIN)....................................... 58
Moving a Track (MOVE) ................................... 58
Erasing a Track (ERASE)........... 59
Erasing All Tracks
(ALL ERASE)......................... 59
Editing Tracks by Group......................60
Forming a Group (FORM GROUP) .................. 60
Adding a Track to a Group (ENTRY GROUP).. 61
Dividing a Group into Two Groups
(DIVIDE GR.) ............................................... 61
Joining Groups (JOIN GROUP)........................ 62
Moving a Group (MOVE GROUP).................... 62
Canceling a Group
(UNGROUP/UNGROUP ALL) ..................... 63
Erasing a Group (ERASE GROUP).................. 64
Using the Timers .................................65
Sleep Timer ...................................................... 65
To Go to Bed Using Sleep Timer and
to Wake Up Using DAILY Timer .................. 65
Recording Timer ............................................... 66
DAILY Timer (Alarm Timer) .............................. 67
Auto Standby.......................................69
Disc/MD Ejection Lock ........................69
Using AV COMPU LINK ......................70
Connection and Setting .................................... 70
Operations ........................................................ 70
Restrictions on MDs ............................71
Serial Copy Management System (SCMS) ...... 71
Handling Discs/MDs ............................72
MD/Disc Messages .............................73
Troubleshooting...................................74
FAQ .....................................................75
Glossary ..............................................76
Specifications ......................................77
Listening to MDs
Listening to Other Equipment
Recording Sound
Editing MDs
Convenient Functions
Reference
NX-DD30[UB].book Page 2 Friday, November 25, 2005 10:26 AM

Introduction
3
7
Notes on Operation
To minimize the need for servicing and maintain
the high quality of this product, do not place the
main unit in the following locations:
• In a position subject to high humidity or consid-
erable dust
• On an uneven or unstable surface
• Near a heat source
• Near a computer, fluorescent light or other elec-
tric appliance
• In a small room with insufficient ventilation
• In a position exposed to direct sunlight
• In a position exposed to excessive cold
• In a position exposed to strong vibration
• Near a TV, other amplifier, or tuner
• Near a magnetic source
CAUTION
• The operating temperature of this product is 5°C to
35°C. Use in temperatures outside this range may
cause a malfunction or damage the product.
Under the following conditions, you may not be
able to operate this product properly due to con-
densation formed on the lens of the main unit:
• When you have just started an air conditioner to
warm your room
• When you have placed the main unit at an area
with high humidity
• When you have moved the main unit from a cold
place to a warm place
When condensation forms, leave the main unit
turned on, wait for approximately 1 or 2 hours, and
then operate the main unit.
When the operation panel becomes dirty, dust it
with a soft dry cloth. When the operation panel is
very dirty, wipe it with a cloth dampened with a
small amount of a neutral detergent, and then wipe
it with a soft dry cloth.
CAUTION
• Do not wipe the operation panel with thinners, ben-
zenes or other chemical agents. Do not spray
insecticides onto the operation panel. These may
cause discoloration and damage to the surface.
When using headphones, keep the volume at a
moderate level so as not to over-stimulate your
ears.
■When enjoying sound from the speakers,
adjust the volume to a suitable level to
avoid disturbing your neighbors.
Even low-volume sound carries a long way,
especially at night. Show consideration to
your neighbors by closing windows or using
headphones.
Suitable Locations for the
Main Unit
Condensation
• Manufactured under license from Dolby Laboratories. "Dolby", "MLP Lossless", and the double-D symbol are trade-
marks of Dolby Laboratories.
• "DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems, Inc.
• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
• DVD Logo is a registered trademark of DVD Format/Logo Licensing Corporation.
• "Official DivX CertifiedTM product", "Plays DivX®5, DivX®4, DivX®3, and DivX®VOD video content (in compliance
with DivX CertifiedTM technical requirements)", "DivX, DivX Certified", and associated logos are trademarks of DivX-
Networks, Inc. and are used under license.
Cleaning the Main Unit
Listener's Etiquette
NX-DD30[UB].book Page 3 Monday, October 24, 2005 7:16 PM

4
Introduction English
• Discs should be finalized before being played back.
1 Among MP3/WMA/JPEG discs, only discs formatted
with ISO 9660 (known as UDF Bridge) are playable.
2 Only when a DVD-RW is compatible with CPRM
(Content Protection for Recordable Media), DVD VR
format can be used.
3 A DivX formatted DVD-ROM is also playable.
It is possible to play back finalized +R/+RW (DVD Video
Format only) discs. "DVD" lights on the front display
panel when a +R/+RW disc is loaded.
Some discs may not be played back because of their disc
characteristics, recording conditions, or damage or stains
on them.
Only sounds can be played back from the following discs:
MIX-MODE CD CD-G
CD-EXTRA CD TEXT
Region code of DVD VIDEO
DVD players and DVD VIDEOs have their own
region code numbers. This product can only play
back a DVD VIDEO recorded with the region code
number "3" (or any region code number that
includes "3") or "ALL".
If a DVD VIDEO with an improper region code
number is loaded, "REGION CODE ERROR!"
appears on the TV screen and playback cannot
start.
• On some DVD VIDEOs, DVD AUDIOs, VCDs,
SVCDs or DivX discs, their actual operation
may be different from what is explained in
this manual. This is due to the disc program-
ming and disc structure, not a malfunction of
this product.
Discs you can play back:
• Playback is impossible in some cases
due to the disc characteristics, recording
condition, scratches or dirt on the disc, or
dirt or condensation on the lens.
• Before using a disc, carefully read the
cautions regarding the disc.
• This product does not support playback
or CD text display of sound files such as
MP3s.
• To play back a CD-RW or DVD-RW on
this product, erase all tracks if the CD-
RW or DVD-RW was recorded in a format
other than the format described on the
left. Using the CD-RW or DVD-RW with-
out erasing all tracks may result in dam-
age to the speakers or other parts caused
by sudden loud volume.
Discs that cannot be played back
• The following discs cannot be played back:
DVD-ROM (except for MP3/WMA/JPEG/ASF/
DivX format), DVD-RAM, CD-ROM, CD-I (CD-I
Ready), Photo CD, SACD, etc.
Playing back these discs will generate noise and
damage the speakers.
• Damaged discs and discs in an extraordinary
shape (other than a disc of 12 cm or 8 cm in
diameter) cannot be played back.
• JVC do not guarantee the operation and sound
quality of discs not authorized by CD-DA, which
is a CD specification.
Before playback, confirm that the disc complies
with this CD specification by checking the marks
and reading notes printed on the package.
Playable Disc Types
CD-R/
CD-RW DVD-R DVD-RW
Audio CD format Playable ——
VCD/SVCD
format Playable ——
MP3/WMA/JPEG
format Playable Playable
1
Playable
1
DVD Video format —Playable Playable
DVD VR format —Playable
2
Playable
2
DivX format Playable Playable
3
Playable
ASF (Advanced
Systems
Format)
Playable Playable Playable
Examples:
Disc Type Mark (Logo)
DVD VIDEO
DVD AUDIO
VCD
SVCD
CD
CD-R
CD-RW
DivX
About CD-Rs/CD-RWs and DVD-Rs/DVD-RWs
NX-DD30[UB].book Page 4 Friday, November 25, 2005 10:26 AM

Introduction
5
(Continued)
Notes on Operation
Caution for DualDisc playback:
The Non-DVD side of a "DualDisc" does not com-
ply with the "Compact Disc Digital Audio" standard.
Therefore, the use of Non-DVD side of a DualDisc
on this product may not be recommended.
About MP3/WMA/JPEG/ASF/DivX discs
Playable MP3/WMA/JPEG/ASF/DivX discs and
files
• CDs recorded in the ISO 9660 format are play-
able (except CDs recorded in the "packet write"
format (UDF format)).
• CDs recorded in the multi-session format are
also playable.
• Files with an extension of ".mp3", ".wma", ".jpg",
".jpeg", ".asf", ".divx", ".div" or ".avi" (extensions
with uppercase and lowercase letters mixed are
also acceptable) are playable.
• This product cannot play back DVDs recorded in
multi-session or multi-border format.
Notes on MP3/WMA/JPEG/ASF discs and files
• A disc may not be played back, or reading it may
take a long time depending on its recording con-
ditions or properties.
• The time needed for reading varies with the num-
ber of groups or tracks (files) recorded on the disc.
• If a character other than single byte English
characters is used in the file name of an MP3/
WMA/JPEG/ASF file, the track/file name will not
be displayed correctly.
• The order of tracks/groups displayed on the
MP3/WMA Control screen, and the order of files/
groups displayed on the JPEG Control screen
may be different from that of files/folders dis-
played on PC's monitor screen.
• In the case of MP3/WMA discs, since groups/
tracks are played back in alphabetical order, a
commercially available MP3/WMA disc may be
played back in an order different from that indi-
cated on the label attached to the disc.
• Playing back an MP3/WMA file including a still
image may take a long time. The elapsed time is
not displayed until playing back starts. If playing
back starts, the elapsed time may not be dis-
played correctly.
• For an MP3/WMA file, a disc with a sampling fre-
quency of 44.1 kHz and transmission rate of 128
kbps is recommended.
• This product is not compatible with MP3i or
MP3PRO.
• This product can play back a baseline JPEG file,
excluding monochromatic JPEG files.
• This product can play back JPEG data taken with a
digital camera conforming to the DCF (Design
Rule for Camera File System) standard (when a
function is applied such as the automatic rotation
function of a digital camera, data goes beyond the
DCF standard, so the image may not be dis-
played).
• If data has been processed, edited and restored
with PC image editing software, the data may
not be displayed.
• This product cannot play back animations such
as MOTION JPEG, or still pictures (TIFF etc.)
other than JPEG, and image data with sound.
• The resolution of 640 x 480 pixels is recom-
mended for JPEG files. If a file has been
recorded at a resolution of more than 640 x 480
pixels, display may take a long time. An image
with a resolution of more than 8192 x 7680 pix-
els cannot be displayed.
• The system supports ASF files recorded with the
maximum bit rate of 384 kbps and an audio
coder decoder of G.726.
Notes on DivX discs and files
• The system supports DivX 5.x, 4.x and 3.11.
• The system supports DivX files with a resolution
of 720 x 480 pixels or less (30 fps) and 720 x
576 pixels or less (25 fps).
• Audio stream should conform to MPEG1 Audio
Layer-2 or MPEG Audio Layer-3 (MP3).
• The system does not support GMC (Global
Motion Compression).
• Files encoded in the interlaced scanning mode
may not be played back correctly.
• Playing back a DivX disc may take a long time.
The elapsed time is not displayed until playback
starts. The elapsed time may also not be dis-
played correctly.
NX-DD30[UB].book Page 5 Thursday, November 24, 2005 1:56 PM

6
Introduction English
DVD VIDEO
A DVD VIDEO consists of "titles" and each title
may be divided into "chapters".
DVD AUDIO
A DVD AUDIO consists of "groups" and each
group may be divided into "tracks".
Some discs include a "bonus group" that requires
a password for playing ( page 31).
VCD/SVCD/CD
VCD, SVCD and CD consist of "tracks".
In general, each track has its own track number.
(On some discs, each track may also be further
divided by indexes.)
MP3/WMA/JPEG/ASF/DivX discs
On an MP3/WMA/JPEG/ASF/DivX disc, each still
picture (material) is recorded as a track [file].
Tracks [Files] are usually grouped into a folder.
Folders can also include other folders, creating
hierarchical folder layers.
This unit simplifies the hierarchical construction of
a disc and manages folders by "groups".
This product can recognize up to 4000 tracks [files]
in a disc. Also, the product can recognize up to
150 tracks [files] per group and up to 99 groups in
a disc. Since the unit ignores the tracks [files]
whose numbers are exceeding 150 and the groups
whose numbers are exceeding 99, they cannot be
played back.
• If there is any type of files other than MP3/WMA/
JPEG/ASF/DivX files in a disc, those tracks
[files] are also counted in the total file number.
Regarding TV mode
This product is suitable for NTSC. The discs using
TV mode other than NTSC (such as PAL) is
converted into NTSC mode before playback.
NOTE
• Some discs may not be played properly, for exam-
ple, the picture movement may not be smooth, or
the aspect ratio (ratio of length and width) may be
changed.
Disc Structure
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
Group 1 Group 2
Track1Track2Track3Track1Track2
Track1Track2Track3Track4Track5
Up to 99 groups
Up to 150 files
Group 1 Group 2
Track 1
[File 1]
Track 2
[File 2] Group 3 Group 4 Group 5
About the Color System
NX-DD30[UB].book Page 6 Friday, November 25, 2005 10:26 AM

Introduction
7
Special Cautions
■Important cautions
Installation of the system
• Select a place which is level, dry and neither too
hot nor too cold; between 5°C and 35°C.
• Leave sufficient distance between the system
and the TV.
• Do not use the system in a place subject to
vibration.
Power cord
• Do not handle the power cord with wet hands!
• A small amount of power is always consumed
while the power cord is connected to the wall
outlet.
• When unplugging the power cord from the wall
outlet, always pull on the plug, not the power
cord.
To prevent malfunctions of the system
• There are no user-serviceable parts inside. If
anything goes wrong, unplug the power cord and
consult your dealer.
• Do not insert any metallic object into the system.
• Do not use any non-standard shape disc (like a
heart, flower or credit card, etc.) available on the
market, because it may damage the system.
• Do not use a disc with tape, stickers, or paste on
it, because it may damage the system.
Note about copyright laws
Check the copyright laws in your country before
recording from CDs. Recording of copyrighted
material may infringe copyright laws.
■Safety precautions
Avoid moisture, water and dust
Do not place the system in moist or dusty places.
Avoid high temperatures
Do not expose the system to direct sunlight and do
not place it near a heating equipment.
When you are away
When away on travel or for other reasons for an
extended period of time, disconnect the power
cord plug from the wall outlet.
Do not block the vents
Blocking the vents may damage the system.
Care of the cabinet
When cleaning the system, use a soft cloth and fol-
low the relevant instructions on the use of chemi-
cally-coated cloths. Do not use benzene, thinner or
other organic solvents including disinfectants.
These may cause deformation or discoloring.
If water gets inside the system
Turn the system off and disconnect the power cord
plug from the wall outlet, then call the store where
you made your purchase. Using the system in this
condition may cause fire or electrical shock.
■When condensation or water drops adhere
to the lens
In any of the following cases, condensation or
water drops may adhere to the lens to prevent the
system from working properly:
• Immediately after roomheating starts
• When the system is installed in a steamy or
damp space
• When the system is suddenly moved from a cold
place to a warm space
In any of these cases, leave the system turned on
for 1 or 2 hours before use.
Notes on Handling
Label sticker
Sticker
Paste
• This product incorporates copyright protection technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
NX-DD30[UB].book Page 7 Monday, October 24, 2005 7:16 PM

8
Introduction English
Check to be sure you have all of the supplied
accessories.
The number in parentheses is the quantity of the
pieces supplied. If anything is missing, contact
your dealer immediately.
Remote control (1)
Batteries (2)
FM antenna (1)
AM loop antenna (1)
Video cord (1)
Power cord (1)
Speaker cord (2 bundles with plugs, 3 meters
each)
Supplied Accessories
NX-DD30[UB].book Page 8 Friday, November 25, 2005 10:26 AM

Introduction
9
Setting Up the Unit
This products allows you to enjoy virtual surround
sound using only the four speakers in the front, as
it is equipped with the 4-speaker front surround
function.
STANDBY
MD IN
DISC LOADING MECHANISM
LINE
SURROUND
OUTPUT
MODE
PHONES/
LINEOUT
VOLUME
--- +
forDigital Audio Player
REC
MODE
DVD/CD MD
FM/AM
Left speaker
(SP-NXDD30F)
Right speaker
(SP-NXDD30F)
Center
surround
speaker
(SP-NX
DD30S)
TV stand
(not supplied)
Center unit
(CA-NXDD30)
Listening Point
• Multi-channel center audio is separated and out-
put through the center surround speaker.
About Front Surround Function
Instead of the traditional 5.1 channel playback system,
we have introduced a virtual surround system that uti-
lizes four speakers situated in the front.
The mechanism is based on an original JVC technique
in which two center speakers, separated by the aver-
age distance between two human ears, deal with the
center signals and the surround signals, while the LFE
(low frequency sound effect) is added to steady the L
channel signal and the R channel signal that are trans-
mitted to the main speakers on the left and right sides.
A high quality digital amplifier drives the speakers at
30W x 4ch.
Characteristics of 4-Speaker Front Surround
• Our original speaker layout and signal processing
does not only save space, but it also ensures a
more realistic sound field.
• Since high quality sound is produced using basic 2
channel stereo, it is ideal for playing music.
• The center surround speaker allows listeners to
enjoy realistic speech localization.
• It provides realistic surround effects, with wider lis-
tening points for both front and back areas.
Information on Speaker Display in
the display window
Sub-Woofer
When the sub-woofer is set to "OFF"
( page 39), or when headphones are
being used, the light is off.
The light is on when the left front speaker
signal is being input.
The light is on when the center speaker signal
is being input.
The light is on when the right front speaker
signal is being input.
The light is on when LFE signal is being input.
The light is on when the left surround speaker
signal is being input.
The light is on when the monophonic signal is
being input.
The light is on when the right surround speaker
signal is being input.
When the line under L, C, R, LS, or LR is on, the
sound is being played from that speaker.
Speaker Display shows input signals and the speaker
in use.
How to remove the speaker cover
When performing maintenance or other procedures,
you can remove the cover of the front speakers by
pulling the cover towards you.
• You cannot remove the cover of the center surround
speaker.
NX-DD30[UB].book Page 9 Monday, October 24, 2005 7:16 PM

10
Introduction/Preparation English
Introduction /Preparation
Part Description
* This terminal is for connecting a pair of headphones equipped with a stereo mini plug (not supplied) or for
connecting a line out cord (not supplied). While the headphones are connected, the speakers do not pro-
duce any sound.
The numbers refer to the pages in which the parts are explained.
STANDBY
DISC IN MD IN
DISC LOADING MECHANISM
LINE
SURROUND
OUTPUT
MODE
PHONES/
LINE OUT
VOLUME
--- +
for Digital Audio Player
STANDBY
REC MODE
OUTPUT
MODE
PHONES/
LINE OUT
for Digital Audio Player
LINE
DVD/CD MD
FM/AM
69 65-68
52
22
2030, 313022, 45, 48
52-54
9, 38
38
36
24, 25, 45, 69
38, 40
22
19, 50, 54
17
19, 20
19, 22, 69
19, 20
40*
45
4045
19, 45
51-54
19, 45-47, 54
Remote control sensor
19
19, 22, 25, 32, 33, 37, 52
20, 25, 46, 53, 58, 59, 66
20, 25, 46, 53, 58, 59, 66
19
31-33
NX-DD30[UB].book Page 10 Friday, November 25, 2005 10:26 AM

Introduction
11
Preparation
Remote Control
CAUTION
• Do not use a used battery and a new battery
together.
• Do not use different types of batteries at the
same time.
• Take out the batteries if the remote control is not
to be used for a long time. Otherwise it may
cause a leakage.
• When operating the remote control, point it at
the front panel of the main unit.
• The effective distance between the remote con-
trol and the remote control sensor on the main
unit is approximately 5 m maximum.
• When the effective distance decreases, replace
the batteries.
• Do not drop the remote control or subject it to
excessive shock.
The numbers refer to the pages in which the parts are explained.
Opening the cover
24
19
19
19 19, 20, 54
19, 45-48,
54
25, 26, 46
19
12, 18
19
29
24, 26
29
29, 30
19
39
19, 39
19
34, 35
39
12, 18, 21,
26, 32, 34,
35, 46, 47,
56, 66, 67
52
52
69
65
52
51
52-54
18, 66-68
48
18, 21, 48, 54,
55, 57-68
18, 32, 47,
56, 66, 68
18, 21, 24, 46,
50, 53, 54, 56
55, 56,
60-64 55-59
33, 48
20, 31-33,
47, 48
31
41
28
28
24
12, 23, 28-31,
34, 35, 37, 41,
49, 55, 57-64
24, 26
26, 30, 37, 46, 47,
53, 55, 61-64
24, 25, 35, 45,
52, 54
12
12
38, 40
12
19, 50, 54
25
19, 22, 25, 32,
33, 37, 52
Inserting Batteries into the
Remote Control
R6P (SUM-3) /AA (15F)
type dry-cell batteries (2)
Remote control operation
18, 23, 28-31,
34-36, 39, 41,
56
18, 20, 25, 46, 49,
53, 55, 57, 58, 60,
61, 66-68
NX-DD30[UB].book Page 11 Monday, October 24, 2005 7:16 PM

12
Preparation English
1Slide the remote control mode
selector to the TV side.
2Hold down .
NOTE
• Hold down until step 4 is completed.
3Press and release.
4Press number buttons (1-9, 0).
Examples:
For a Hitachi TV: Press 1, then 0.
For a Toshiba TV: Press 0, then 8.
If there are two or more manufacturer's codes, try
them in turn and select the one that causes the
product to work properly.
5Release .
NOTE
• The manufacturer's codes may be changed without
notice. You may not be able to operate a TV
produced by the manufacturer shown above.
Operate the remote control by pointing it towards
the TV.
*1 Make sure to slide the remote control mode selector
to the TV side in advance.
NOTE
• When the batteries are replaced, perform the man-
ufacturer's code setting again.
This page is for when operating your TV using
the remote control of this product.
Operating the TV Using the
Remote Control
Setting the manufacturer's code
Manufacturer Code Manufacturer Code
JVC 01 Samsung 12
Hitachi 10 Sanyo 13
Magnavox 02 Sharp 06
Mitsubishi 03 Sony 07
Panasonic 04, 11 Toshiba 08
Philips 14 Zenith 09
RCA 05
Turn on/off the power.
Change channels.
Adjust volume.
- / Select channels.
Change between the previously
selected channel and the cur-
rent channel.
Change between TV and video
input.
For TV operation
*1
NX-DD30[UB].book Page 12 Friday, November 25, 2005 10:26 AM

Introduction
13
Connections
1Set up the AM antenna (supplied).
2Connect the antenna cord.
3Turn the AM loop antenna to find
the best position for radio
reception.
Place the AM loop antenna as far
from the main unit as possible.
• Do not place the AM loop antenna on a
metallic table or close to a TV, computer, or
other electric appliances. Doing so may
affect radio reception.
■When radio reception with the supplied AM
loop antenna is poor
Stretch out the FM antenna to the best position for
radio reception, and then fix it with adhesive tape.
■When radio reception with the supplied FM
antenna is poor, or when using a communal
antenna
When using an antenna other than those
supplied with this product, refer to the operation
manuals for the antenna for details of
connection.
Connect all necessary parts before connecting the power plug.
Connecting the Antennas
Connecting the AM antenna
Insert the tab into
the slot.
Main unit (rear view)
When insulation covers the tips
of the antenna cord, twist and
pull off the insulation.
Black White
Vinyl-covered wire: 3 - 5 m
(not supplied)
Twist together vinyl-
covered wire and the AM
loop antenna cord.
Stretch out the vinyl-
covered wire
horizontally, preferably
in a high place such
as above a window or
outdoors.
Connect the AM loop
antenna cord to the
main unit together with
the vinyl-covered wire.
Main unit (rear view)
When positioning the antennas, find the best position for reception while listening to an actual radio program
(refer to "Listening to Radio Broadcasts" ( page 20)).
Connecting the FM antenna
Main unit (rear view)
FM antenna
(supplied)
STANDBY
MD IN
DISC LOADING MECHANISM
LINE
SURROUND
OUTPUT
MODE
PHONES/
LINEOUT
VOLUME
--- +
forDigital Audio Player
REC MODE
DVD/CD MD
FM/AM
Main unit
(rear view)
Antenna cord
(not supplied)
Communal
antenna terminal
or
Outdoor FM antenna
(not supplied)
Coaxial cable
(not supplied)
NX-DD30[UB].book Page 13 Monday, October 24, 2005 7:16 PM

14
Preparation English
CAUTION
• Do not short-circuit the and speaker termi-
nals. Doing so may damage the speakers.
• The front speaker cord with a black line is to be
connected to the negative terminal. Properly con-
nect the cords to the and speaker terminals.
• Fully insert the speaker cord plugs into the
speaker terminals on the rear of the main unit.
• The speakers of this product are magnetically
shielded, but color irregularities may occur on the
TV depending on how the speakers are installed.
Keep in mind the following.
1. Turn off the main power of your TV before
installing the speakers. Wait for about 30 min-
utes before turning on the TV again.
2. If color irregularity occurs in pictures, keep a
distance of more than 10 cm between the TV
and the speakers.
NOTE
• Improper speaker cord connection spoils the stereo
effect and sound quality.
• The impedance of speakers connected to this
product must be within the range of 4 Ωto 16 Ω.
• Cooling fan is built into the main unit for emitting
generated heat. The internal cooling fan auto-
matically rotates and stops. To ensure sufficient
cooling, leave a space of more than 1 cm
between the main unit and the speakers or other
objects.
Connecting the Speakers
After connecting the speakers, gently pull on the
speaker cords to make sure that they are firmly
connected.
Main unit (rear view)
Connect the speaker plug to the speaker terminal of the same color.
The cord with a black line is connected
to the negative terminal.
NX-DD30[UB]-03.fm Page 14 Thursday, December 8, 2005 11:00 AM

Introduction
15
(Continued)
Connections
CAUTION
• Before connecting other equipment, turn off both
the main unit and the equipment.
CAUTION
• For details of signals to be output, refer to page 42.
Connect all necessary parts before connecting the power plug.
Connecting Other Equipment
Read this section when connecting other audio
equipment to this product.
LINE IN
Other audio
equipment
Audio cord
(not supplied)
Main unit (rear view)
Connecting with digital equipment
AV amplifier with a built-in
decoder (not supplied)
To an optical digital input
terminal
Optical digital cable
(not supplied)
Optical digital cable
(not supplied)
MD player or CS tuner
(not supplied)
To an optical digital
output terminal
Main unit (rear view)
NX-DD30[UB].book Page 15 Monday, October 24, 2005 7:16 PM

16
Preparation English
CAUTION
• Connect the main unit directly with a TV (or a
monitor) without routing through a VCR. Otherwise
it may cause picture distortion while playing back.
(Such picture distortion is caused by a copy
protection system, and thus it is not a malfunction.)
Also, if the main unit is connected to a TV with a
built-in VCR, there may be picture distortion during
playback.
NOTE
• You need to set "MONITOR TYPE" in the
"PICTURE" menu correctly according to the aspect
ratio of your TV. ( page 41)
You can enjoy pictures of better quality using the
following cord instead of the supplied video cord.
You can enjoy better quality pictures than when
using the S-video cord.
CAUTION
• Use one of either the S-video cord or the compo-
nent video cord. If both cords are used, pictures
may not be played back properly.
NOTE
• In order to enjoy pictures with the progressive
mode ( page 30), the TV is required to have
progressive video input.
• If the component video input jacks of your TV are
BNC type, use a plug adapter (not supplied) to
convert the plugs.
Connecting with a TV
When a Clearer Picture Is
Desired
TV
Supplied video cord
Main unit
(rear view)
VIDEO IN
STANDBY
MD IN
DISC LOADING MECHANISM
LINE
SURROUND
OUTPUT
MODE
PHONES/
LINEOUT
VOLUME
--- +
forDigital AudioPlayer
REC MODE
DVD/CD MD
FM/AM
M
a
i
n un
it
Connecting directly
TV
(or monitor)
VCR
Connecting by using the S-video cord
TV
M
a
i
n un
it
(rear view
)
S-video cord
(not supplied)
Connect the ends of S-video cord making
sure that each end matches its compatible
terminal.
Connecting by using the component
video cord
TV
Main unit (rear view)
Component video cord
(not supplied)
NX-DD30[UB].book Page 16 Friday, November 25, 2005 10:26 AM

Introduction
17
(Continued)
Connections
NOTE
• When you connect a sub-woofer to the system, set
"SUB WFR" to "ON" in "Other Settings" (
page
39).
• After making all other necessary connections,
connect in the power plug.
• When you insert the power cord to a plug socket,
STANDBY lamp on the main unit is turned on.
NOTE
• The preset setting such as preset channels and
sound adjustment may be erased in a few days in
the following cases:
- When you disconnect the power plug.
- When a power failure occurs.
Connect all necessary parts before connecting the power plug.
Connecting the Sub-woofer
Equipment
LINE IN
Amplifier-built-in
sub-woofer
To an audio input
terminal
Main unit (rear view)
Audio cord (not supplied)
(If an audio cord comes with the amplifier-
built-in sub-woofer, you can use the cord.)
Connecting the Power Cord
Power cord
Main unit (rear view)
NX-DD30[UB].book Page 17 Monday, October 24, 2005 7:16 PM
