E-2 Thank you for purchasing this product. (These instrustions are for SA-DV6000U) Before beginning to operate this unit, please read the instruction manual carefully in order to make sure that the best possible performance is obtained.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. AVERTISSEMENT: POUR EVITER LES RISQUES D’INCENDIE OU D’ELECTRO-CUTION, NE PAS EXPOSER L’APPAREIL A L’HUMIDITE OU A LA PLUIE.
Due to design modifications, data given in this instruction book are subject to possible change without prior notice.
Safety Precautions
POWER SYSTEM Connection of POWER supply The power for the network pack is supplied through the VCR that is connected to the network pack.
This equipment is in conformity with the provisions and protection requirements of the correspond- ing European Directives. This equipment is designed for professional video appliances and can be used in the following environments: •residential area (in houses) or rural area • commercial and light industry; e.g. offices or theatres •urban outdoors In order to keep the best performance and furthermore for electromagnetic compatibility. Use the PC Card which acquired a CE mark.
Caution
Where there are strong electromagnetic waves or magnetism, for example near a radio or TV transmitter, transformer, motor, etc., the picture may be disturbed. In such case, please keep the apparatus away from the sources of the disturbance.
E-3
English
Network Pack
SA-DV6000
Board for encoding/decoding video/audio data by connecting to BR-DV6000.
Setting of the SA-DV6000 is performed on the menu screen of the BR-DV6000 VCR. For details on the setting methods, please see the Network Pack User’s Guide (pdf) included on the provided CD-ROM. SA-DV6000 Users Guide (pdf) When the Streamproducer program included on the provided CD-ROM is installed, the Net- work Pack User’s Guide (pdf) is automatically installed on the PC and added to the Start
menu.
[Start/Programs/JVC/SA-DV6000U/User’s Guide] The Adobe Acrobat Reader is required to view PDF files.
Network Pack Startup Guide
(This document)
This document describes the basic matters for use of the Network Pack.
The following software and these Instructions are included on the provided CD-ROM. • PC Application Software
Application software to enable this product to be used more conveniently.
• Network Pack User’s Guide (pdf)
Reference guide for the Network Pack.
• PC Application Software User's Guide
User's guide for the provided PC application software.
CD-ROM
Product Components

E-4
Contents
Features ................................................................................................................................................. 4 Precautions ............................................................................................................................................ 4 What the SA-DV6000 can be used for ................................................................................................... 6 Names and Functions of Parts ............................................................................................................... 8 Installation Method ................................................................................................................................. 9 Check if Correctly Installed .................................................................................................................. 10 Specifications ....................................................................................................................................... 11
Features
●By installing this product to the BR-DV6000, it is possible to encode the image/sound from VCR
input or tape playback in real-time, as well as to decode streaming data that has been stored on CompactFlash memory card. Video data is converted to MPEG-4 and audio data is converted to G726 or µlaw.
●Connecting a network cable to the LAN connector or installing a LAN-card etc. in the PC card slot
enables real-time streaming.
●The real-time streaming data can be viewed by using Windows Media Player or Quick Time. ●Installing a Compact Flash card in the PC card slot enables real-time capturing. ●Network distribution of the video/audio file created by the SA-DV6000 is possible when the
“Streamproducer” program included on the provided CD-ROM is installed on the PC.
Precautions
●Be sure to turn the VCR’s power supply OFF before the SA-DV6000 is attached to the VCR. ●Be sure to turn the VCR’s power supply OFF before inserting or removing CF (Compact Flash)
cards, etc., into and from the VCR. Inserting or removing cards while the VCR’s power supply is turned ON can result in corruption of the recorded sections of the card or damage to the card itself.
●The SA-DV6000 accepts the following cards for which operation has been confirmed: (As of June
2003) Operating voltage 3.3 V/5 V Current consumption 250 mA •Wired LAN-card
US: EA2900-117 (Revision C) (Name of manufacturer: Socket Communications, Inc)*1
Europe: EA2903-162 (Revision C) (Name of manufacturer: Socket Communications, Inc)*1 Asia: EA2906-194 (Revision C) (Name of manufacturer: Socket Communications, Inc)*1 (The Revision designation is indicated in the upper right of the serial number label affixed to the package.)
•Wireless LAN-card
TEW-201PC,TEW-202CF (Name of manufacturer: TRENDware) WCF11 (Name of manufacturer: LINKSYS)*2
•CF (Compact Flash) card
SDCFB-16 ~ SDCFB-256 (Name of manufacturer: SanDisk)*1
*1: Use PCMCIA card TYPE 1or TYPE 2adapter *2: Use PCMCIA card TYPE 2adapter
Do not use other cards that those for which operation has been confirmed. Improper installation may cause damage to the SA-DV6000. For the latest operational check card, visit the website below or contact your JVC dealer. http://www.jvc-victor.co.jp/english/pro/prodv/
*The names of actual companies and products mentioned in this document may be the trademarks or
